Next MAISIE 863077 User manual

Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: [phone]
• Wall fixings are not included.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
• Please do not apply Adhesive substrates for example, sticky tape to the product.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
• We recommend the use of the wall attachment bracket/strap provided for safety reasons.
PRODUCT INFORMATION
• Made from MDF & partical board with a wood effect finish.
• Made in China.
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
863077 MAISIE DRESSING SET
Page 1 of 6

1. Insert 16 x cambolts (F) into panels 1, 2, & 3 and
tighten with a screwdriver.
STEP ONE
FITTINGS
PARTS
Page 2 of 6

1. Glue and insert 8 x wooden dowels (B) into panels 4 &
5, and attach panels 2 & 3 to panels 4 & 5.
2. Insert 6 x camlocks (E) into panels 4 & 5 and tighten
with a screwdriver.
Ensuring the arrow indicator is pointing towards the
panel edge before tightening with a screwdriver.
1. Glue and insert 8 x wooden dowels (B) into panel 1
and attach assembly unit to panel 1.
2. Insert 10 x camlocks (E) into panels 2, 3, 4 & 5 and
tighten with a screwdriver.
Ensuring the arrow indicator is pointing towards the
panel edge before tightening with a screwdriver.
1. Attach 2 x hinges (G) to panels 7 & 8 with 12 x screws
(H) using a screwdriver clockwise until tight.
2. Attach 2 x hinges (G) to panels 8 & 9 with 12 x screws
(H) using a screwdriver clockwise until tight.
STEP TWO
STEP THREE
STEP FOUR
Page 3 of 6

1. Insert 2 x nuts (R) into panel 8.
2. Attach panel 6 to panel 8 with 2 x bolts (I) and tighten
by an Allen key (J).
1. Glue and insert 2 x wooden dowels (A) into panel 1.
2. Attach panel 6 to panel 1 with 6 x screws (Q), and
tighten with a screwdriver.
1. Insert 6 x cambolts (F) into panel 10 and tighten with a
screwdriver.
2. Insert 4 x bolts (L) into panels 11 (x2) and tighten by
hand.
STEP SIX
STEP SEVEN
STEP FIVE
Page 4 of 6

1. Glue and insert 8 x wooden dowels (C) into panels 12
(x2) and attach panels 11 (x2) to panels 12 (x2).
2. Cover 4 x metal half moon pieces (M) onto 4 x bolts
(L) and thread 4 x spring washers (N) onto bolts (L) then
screw 4 x metal nuts (K) with spanner (O) to tighten.
1. Glue and insert 8 x wooden dowels (B) into panel 10
and attach assembly unit to panel 10.
2. Insert 6 x camlocks (E) into panels 11 (x2) & 12 (x2)
and tighten with a screwdriver.
Ensuring the arrow indicator is pointing towards the
panel edge before tightening with a screwdriver.
1. Use 2 x screws and 2 x washer to secure 2 x nylon
strap (P) to the back of the top panel.
2. Secure the other ends of the straps to the wall using
appropriate screws,washers (not provided) and wall
plugs for your wall type.
WARNING: Always ensure the area to be drilled is free
from hidden electrical wires,water and gas pipes.
NB:Wall fixings are not included-Please source suitable
fixing for your wall type. If in doubt please consult a
qualified trades person.
STEP EIGHT
STEP NINE
STEP TEN
Page 5 of 6
