Next PORTOFINO 678708 User manual

Produced in Romania for Next Retail Ltd.
673886-2014-V1
H107 x W 164 x L 218 cm
IMPORTANT ─ RETAIN FOR FUTURE REFERENCE
With: Assembly instructions
Missing or damaged parts
Actual product size
PORTOFINO DOUBLE BED
678708
Assembly instructions
Need help?
CALL: 0333 777 8999
Page 1

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
Warnings
We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well
away from construction area.
This product should only be used on firm level ground
Please periodically check all fittings and re-tighten as
necessary
Please do not jump or stand on your bed
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause damage to the
materials and deterioration of the colour
Do’s
We suggest you spend a short time reading through this
leaflet before you start
When you are ready to start, make sure that you have the
right tools and plenty of space
Due to the size of the product we recommend that it is
assembled in the room intended for use
Unwrap all packaging materials and place the components
on a clean surface to protect it from damage,
We recommend that the packaging is used to protect the
surfaces during assembly
Carefully check that you have all the parts before beginning
assembly
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use. Check fixings
regularly to ensure they remain tight
When moving your assembled bed. It is best to lift the bed
and never to drag it. Please check that the
centre support rail is securely fixed in place
When adjusting the support legs ensure that the foot is set
5-10mm from the floor surface without the
mattress in place. When in use the legs will create the
required support for the product.
Don’ts
Never allow any kind of liquid to remain on your furniture.
Absorption can cause materials to warp or finishes to de-
laminate.
To clean your item, please use a vacuum or lightly brush
clean.
Periodically check the condition of your bed slats and plastic
locating caps to ensure they are in good
condition and have not become loose.
BEFORE YOU START
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be
sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had
the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and repair
the product where possible.
If you have had the product for more than 28 days we will
send an independant home service technician to review and
repair the product where possible and recommend further
action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
2 hours
supplied supplied
Page 2

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
1
2
3
4
4
5
6
7
8
Components supplied. Please use this guide if you require replacement parts.
Ref. Ref.
1
2
3
4
5
6
7
164 X 92 cm
164 X 45 cm
192 x 17 cm
18 x 7 cm
192 x 10 cm
25 x 5 cm
70 x 1 cm
Dimensions DimensionsVisual Visual
Qty. Qty.Ctn. Ctn.
1
1
2
4
1
2
30
1
1
2
1
2
2
3
Page 3

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
Fixtures and fittings
supplied (actual size)
mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Ref. Dimensions Qty.
A
B
D
E
F
G
C
40 x 40 mm
20 X 8 mm
40 X 6 mm
16 x 16 mm
12 x 12 mm
150 x 33 mm
30 X 8 mm
4
8
12
2
1
4
2
Page 4

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
Fixtures and fittings
supplied (actual size)
mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Ref. Dimensions Qty.
H
I
100 x 50 mm
75 x 30 mm
1
60
Page 5

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
1
2
1
1
2
2
4
4
4
A
1 cm
Ax4
B x 8 E x 8
B
E
G
G
Screws "B" are prefitted.
Unscrew until 1 cm space.
Page 6

3
3
60 X 8 mm
D
Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
4
5
6
D
H
F
Page 7
G
E
B
D x 2 F x 2
H
Screws "D" are prefitted.
Unscrew them before fitting the feet in place.
Repeat this step in every corner of the bed.

5
5
C
G
E
1
C x 4
E x 4
Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Assembly instructions
6 7
I7
I
Press the ansemble
formed by (7) and (I) pieces
until it "clicks" into place
Page 8
I x 60
Screws "C" are prefitted.
Unscrew them before fitting the central bar in place.
Repeat this step for either side of the bed.

Produced in Romania for Next Retail Ltd.
673886-2014-V1
PORTOFINO DOUBLE BED
678708
Actual product size
192 cm
192 cm
107 cm
15 cm
45 cm
92 cm
218 cm
218 cm
164 cm
164 cm
Page 9
164 cm
218 cm
107 cm
H107 x W 164 x L 218 cm
