Next SPARKLE 766733 User manual

H80 x L30 X D23.3cm
Actual product size
IMPORTANT - RETAIN FOR FUTURE REFERENCE
SPARKLE CORNER CABINET
766733
Assembly instructions
Produced in China for Next Retail Ltd
766733 - 2014 - V1
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999

BEFORE YOU START
Produced in China for Next Retail Ltd 1
Keep fittings out of children’s reach and keep children
well away from construction area.
Please periodically check all fittings and re-tighten as
necessary.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause cracking of the wood and
deterioration of the colour.
Warnings
Important: Retain these instructions for future reference.
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to prevent it from
damage.
Do’s
We suggest you spend a short time reading through this
leaflet before you start.
When you are ready to start, make sure that you have the
right tools, plenty of space and a clean, dry area for assembly.
During assembly children should be kept away from the
product due to possible risk of injury.
Tools not included.
Ensure that this product is fully assembled as illustrated
before use and all fixings are fully tightened before use .
Check all screws or bolts are tightened and inspect regularly.
Don’ts
Do not use power tools to construct this product.
Do not tighten screws until fully assembled.
Do not overtighten screws or bolts.
Do not sit or stand on the product.
Do not use this product if parts are missing, damaged or worn.
Do not drag or pull your furniture.
Never use scourers, abrasives or chemical cleaners.
Number of people required to assemble
Two people are required to assemble this product.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
you your product please If have a fault with contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range please visit www.next.co.uk
1 hour
not supplied not supplied not supplied
PH2 7mm
Unwrap all packaging materials and place the components
on a clean surface to protect it from damage.
We recommend that the packaging is used to protect the
surface during assembly.
To clean your item, wipe with soft cloth slightly dampened
with water. Then buff with a dry clean cloth.
Do not use silicone based furniture polish. Silicone in
furniture polishes can break down the lacquer finish.
Carefully check that you have all the parts before beginning
assembly.
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1

GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd 2
3
1
2
6
7
4
5
X2
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1

Components supplied-Use this guide if you require a replacement part.
Ref Dimensions Visual Qty
1
2
3
4
30 x 21.3cm 1
75 x 22.5cm
30 x 21.3cm
27 x 20.5cm
1
1
2
Produced in China for Next Retail Ltd 3
Fixtures and fittings
supplied (actual size)
6 x 30mm 8
A
E
Ref QtyDimensions
3 x 12mm 10
C
8 x 15mm 8
3 x 10mm 6
D
Ref Dimensions Visual Qty
5
6
80 x 30cm 1
76.5 x 14cm 1
775 x 22.5cm 1
4 x 30mm 8
B
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1
1 20 30 40
10
mm 20 30 40 50 60 70 80 90 100 110 120 130

1
Produced in China for Next Retail Ltd 4
2
6 x 30mm
A x 8
4 x 30mm
B x 4
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1

3
Produced in China for Next Retail Ltd 5
4
3 x 12mm
C x 10
4 x 30mm
B x 4
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1

5
Produced in China for Next Retail Ltd 6
6
3 x 10mm
D x 6
8 x 15mm
E x 8
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1

7
7
8
SPARKLE CORNER CABINET
766733
Assembly instructions
Produced in China for Next Retail Ltd
766733 - 2014 - V1

9
Produced in China for Next Retail Ltd 8
SPARKLE CORNER CABINET
766733
Assembly instructions
766733 - 2014 - V1
Wall fixings are not included please source suitable fixings for your wall type. If in doubt,
please consult a qualified trades person. WARNING: Always ensure the wall to be drilled
is free from hidden electrical wires, water and gas pipes.

Produced in China for Next Retail Ltd 9
Actual product size
H80 x L30 X D23.3cm
SPARKLE CORNER CABINET
766733
766733 - 2014 - V1
755 mm
275 mm
210 mm
