NI RTI-12309 User manual

RTI-12309 Getting Started
Rear Transition Interface for Generic DIO/AO/AI with
8 IX Headers
Contents
Overview..................................................................................................................... 3
Installing the RTI-12309..............................................................................................4
Connecting JR1......................................................................................................5
RTI-12309 Pinout........................................................................................................ 6
RTI-12309 Getting Started

Overview
This document describes the features of the RTI-12309. You can use the RTI-12309 to
connect to any SLSC module supporting fully compatible rear I/O. The eight 10-pin Hirose
ix Industrial (or equivalent) connectors provide access to up to 8 banks of signals for DIO,
AI, or AO.
NOTE
Before you begin, read the RTI-12309 Safety, Environmental, and Regulatory
Information document on ni.com/manuals and complete the soware and
hardware installation procedures in your chassis documentation.
2 ni.com
RTI-12309 Getting Started

Installing the RTI-12309
Figure 1 : Installing the RTI-12309 into the SLSC chassis
CAUTION
Do not touch the contacts or remove the I/O boards or cables while the system is
energized.
Complete the following steps to install the RTI-12309 in the chassis.
1. Power o the main DC power source or disconnect it from the chassis before
installing any RTIs.
2. Ensure that the chassis is powered o.
The POWER LED should be o. If it is not o, do not proceed until it is o.
3. Loosen the screws of the upper rear panel of the chassis.
4. Position the RTI-12309 at the desired slot and insert the securing screws, but do not
fully tighten them.
© National Instruments Corporation 3
RTI-12309 Getting Started

5. Insert an SLSC module into the same slot as its corresponding RTI-12309 while
firmly holding the RTI-12309 in place until the RTI-12309 is firmly connected to the
module.
6. Repeat steps 4 and 5 for all required RTIs.
7. Tighten the screws for all RTIs and the screws of the upper rear panel of the chassis.
This ensures proper alignment for future connections between modules and RTIs.
Connecting JR1
To connect JR1, complete the following steps.
1. Prepare a terminal wire for JR1 by stripping insulation and installing a Molex Ultra-
Fit crimp terminal following the manufacturer's specifications.
2. Insert a prepared terminal into an appropriate terminal socket of Molex Ultra-Fit 8-
position receptacle housing.
3. Repeat steps 1 and 2 for all appropriate terminals.
4. Insert a receptacle housing into JR1 until the plastic retention latch snaps into
place.
JR1 is keyed to prevent reverse installation of the receptacle housing.
4 ni.com
RTI-12309 Getting Started

RTI-12309 Pinout
Figure 2 : RTI-12309 Front and Rear Views
Bank 8
Bank 7
Bank 6
Bank 5
Bank 4
Bank 3
Bank 2
Bank 1
Captive Screws x3
JR2
JR1
XP3
XP2
JR3
JR4
JR5
JR9
JR8
JR7
JR6
Figure 3 : JR1 Pinout
JR1 XP3
A
B
C
D
E
F
G
H
8
4
V1+
V1+
V1-
V1-
5
1
V4+
V4+
V4-
V4-
3V2-
V2-
2V3-
V3-
7 6V2+
V2+
V3+
V3+
Table 1 : JR1 Connector Descriptions
JR1 Signal XP3 Contact JR1 Pin Description
V1+ H 8 Positive voltage for signal 1
© National Instruments Corporation 5
RTI-12309 Getting Started

JR1 Signal XP3 Contact JR1 Pin Description
V1- G 4 Negative voltage/Return for signal 1
V2+ F 7 Positive voltage for signal 2
V2- E 3 Negative voltage/Return for signal 2
V3+ D 6 Positive voltage for signal 3
V3- C 2 Negative voltage/Return for signal 3
V4+ B 5 Positive voltage for signal 4
V4- A 1 Negative voltage/Return for signal 4
Figure 4 : JR2 — JR9 Pinout
IO x.H
IO x.G
AUX/GND (J)
IO x.F
IO x.E
IO x.A
IO x.B
REF/GND (I)
IO x.C
IO x.D
10
9
8
7
6
1
2
3
4
5
Table 2 : JR2 — JR9 Connector Signal Descriptions
Signal Description
IO x.yElement y in Bank x
REF/GND (I) Reference connection, signal ground
AUX/GND (J) Auxiliary connection, shorted to REF/GND
6 ni.com
RTI-12309 Getting Started

Table 3 : Mapping Standard Signals to Generic Element Names
Generic Element
Name (in Bank x)
Generic Single-
Ended (Digital or
Analog)
Generic Dierential
(Digital or Analog) Other Signal Types
IO x.A x.0 x.0+
Contact NI for more information about
standard pinouts.
IO x.B x.1 x.0-
IO x.C x.2 x.1+
IO x.D x.3 x.1-
IO x.E x.4 x.2+
IO x.F x.5 x.2-
IO x.G x.6 x.3+
IO x.H x.7 x.3-
© National Instruments Corporation 7
RTI-12309 Getting Started

Figure 5 : XP2 Connector Organization
XP2
d e fc
b
az
GND A
1
11
15
25
GND A
GND A
GND B
GND B
GND B
Bank 1
Bank 2
Bank 3
Bank 4
IO 7.x
IO 8.x
Bank 5
Bank 6
Bank 7
Bank 8
IO 2.x
IO 3.x
IO 4.x
IO 1.x
IO 6.x
IO 5.x
NOTE
Column z pins are tied to GND A or B on the RTI-12309, and are designed to contact
an optional lower shield on the SLSC module connector, if the shield is present.
Column f pins are all no-connects (NC) on the RTI-12309, and are designed to
contact the same upper shield on the SLSC module connector. The SLSC module
designer configures these pins as GND A or GND B.
NOTE
JR2-5 (Banks 1-4) are referenced/routed to GND A on the XP2 connector, and JR6-9
(Banks 5-8) are referenced/routed to GND B on the XP2 connector.
Table 4 : XP2 Input/Output Pin Assignments
Row z a b c d e f
1 GND A (NC) IO 1.A IO 1.B RSVD0 IO 1.C IO 1.D GND X (NC)
2 GND A (NC) IO 1.E IO 1.F RSVD1 IO 1.G IO 1.H GND X (NC)
3 GND A (NC) GND A GND A GND A GND A GND A GND X (NC)
4 GND A (NC) IO 2.A IO 2.B RSVD2 IO 2.C IO 2.D GND X (NC)
5 GND A (NC) IO 2.E IO 2.F RSVD3 IO 2.G IO 2.H GND X (NC)
8 ni.com
RTI-12309 Getting Started

Row z a b c d e f
6 GND A (NC) GND A GND A GND A GND A GND A GND X (NC)
7 GND A (NC) IO 3.A IO 3.B RSVD4 IO 3.C IO 3.D GND X (NC)
8 GND A (NC) IO 3.E IO 3.F RSVD5 IO 3.G IO 3.H GND X (NC)
9 GND A (NC) GND A GND A GND A GND A GND A GND X (NC)
10 GND A (NC) IO 4.A IO 4.B RSVD6 IO 4.C IO 4.D GND X (NC)
11 GND A (NC) IO 4.E IO 4.F RSVD7 IO 4.G IO 4.H GND X (NC)
15 GND B (NC) IO 5.A IO 5.B RSVD8 IO 5.C IO 5.D GND X (NC)
16 GND B (NC) IO 5.E IO 5.F RSVD9 IO 5.G IO 5.H GND X (NC)
17 GND B (NC) GND B GND B GND B GND B GND B GND X (NC)
18 GND B (NC) IO 6.A IO 6.B RSVD10 IO 6.C IO 6.D GND X (NC)
19 GND B (NC) IO 6.E IO 6.F RSVD11 IO 6.G IO 6.H GND X (NC)
20 GND B (NC) GND B GND B GND B GND B GND B GND X (NC)
21 GND B (NC) IO 7.A IO 7.B RSVD12 IO 7.C IO 7.D GND X (NC)
22 GND B (NC) IO 7.E IO 7.F RSVD13 IO 7.G IO 7.H GND X (NC)
23 GND B (NC) GND B GND B GND B GND B GND B GND X (NC)
24 GND B (NC) IO 8.A IO 8.B RSVD14 IO 8.C IO 8.D GND X (NC)
25 GND B (NC) IO 8.E IO 8.F RSVD15 IO 8.G IO 8.H GND X (NC)
