INSTRUCTION MANUAL
52026469 © 2006 NIBCO Inc. 12/06
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
PC-10M
Battery-powered
Pressing Tool
NIBCO Inc. – World Headquarters
1516 Middlebury Street
Elkhart, IN 46516
USA
Technical Services
Phone: [phone]
Fax: [phone]

NIBCO, Inc. 21516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Warranty ......................................................................... 2
Important Safety Information ......................................3-4
Identication................................................................... 5
Specications................................................................. 5
Operation.....................................................................6-8
Maintenance................................................................... 8
Troubleshooting.............................................................. 9
Description
The PC-10M Battery-powered Pressing Tool is a
hand-held, self-contained tool intended to press 1/2"
through 1" copper NIBCO press ttings and valves onto
type K, L, and M hard-drawn copper tubing.
Safety
Safety is essential in the use and maintenance of NIBCO
tools and equipment. This manual and any markings on
the tool provide information for avoiding hazards and
unsafe practices related to the use of this tool. Observe
all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all users with
the safe operation and maintenance procedures for the
tool:
PC-10M Battery-powered Pressing Tool
with 120-volt Charger and (2) batteries
PC-100M Battery-powered Pressing Tool
with 120-volt Charger, (2) batteries
and 1/2", 3/4" and 1" Pressing Jaws
Keep this manual available to all users.
For additional copies of the manual, visit the NIBCO
website: www.nibco.com
Warranty
For warranty information on the NIBCO pressing tools,
contact NIBCO technical services at 1-888-446-4226,
or visit the NIBCO website: www.nibco.com.
Do not discard this product or throw away!
For recycling information, go to www.nibco.com.
All specications are nominal and may change as design improve-
ments occur. NIBCO, Inc. shall not be liable for damages resulting
from misapplication or misuse of its product.
Tellus is a registered trademark of Shell Oil Company.

NIBCO, Inc. 31516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
IMPORTANT SAFETY INFORMATION
This symbol is used to call your attention to
hazards or unsafe practices which could result in
an injury or property damage. The signal word,
dened below, indicates the severity of the hazard.
The message after the signal word provides infor-
mation for preventing or avoiding the hazard.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Hazards which, if not avoided, COULD result in
severe injury or death.
Immediate hazards which, if not avoided, WILL
result in severe injury or death.
SAFETY
ALERT
SYMBOL
Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Failure to observe this warning
could result in severe injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning could
result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Do not use solvents or ammable
liquids to clean the pressing tool.
Solvents or ammable liquids could
ignite and cause serious injury or
property damage.
Keep hands away from the pressing
tool head when pressing.
Failure to observe this warning could
result in severe injury or death.
Skin injection hazard:
Oil under pressure easily punctures
skin causing serious injury,
gangrene, or death. If you are injured
by escaping oil, seek medical atten-
tion immediately.
• Do not use hands to check for
leaks.
• Depressurize the hydraulic system
before servicing.

NIBCO, Inc. 41516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
IMPORTANT SAFETY INFORMATION
Note: Keep all decals clean and legible, and replace
when necessary.
Inspect tool before use. Replace any worn or
damaged parts. A damaged or improperly assem-
bled tool can break and strike bystanders.
Failure to observe this warning could result in severe
injury or death.
Do not dispose of batteries in a re. They will vent
fumes and may explode.
Failure to observe this warning could result in severe
injury from harmful fumes or burns from ying d ebris.
• Do not operate the tool without a tting in place.
Damage to the pressing head can result.
• This tool is not designed for continuous use.
After 30 to 40 pressing cycles, allow the press-
ing tool to cool for 15 minutes.
• Do not secure this tool in a vise. This tool is
designed for hand-held operation.
• This tool may be used in damp or wet environ-
ments; however, air-drying is recommended
before use if the tool becomes soaked. Damage
may result when the tool is operated prior to
thorough drying when electrical components are
soaked.
• Use this tool for the manufacturer’s intended
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Do not allow anything to contact the battery
terminals.
• Do not immerse the batteries in liquid. Liquid
may create a short circuit and damage the
battery. If batteries are immersed, contact your
service center for proper handling.
• Do not place the battery into a pocket, tool
pouch, or tool box with conductive objects.
Conductive objects may create a short circuit
and damage the battery.
• Do not place a battery on moist ground or
grass. Moisture may create a short circuit and
damage the battery.
Failure to observe these precautions may result in
injury or property damage.
• Do not store the battery at more than 60 °C
(140 °F). Damage to the battery can result.
• Do not use another manufacturer’s charger.
Other manufacturers’ chargers may overcharge
and damage the battery.
• Do not attempt to open the battery. It contains
no user-serviceable parts.
Failure to observe these precautions may result in
injury or property damage.
Do not perform any service or maintenance other
than as described in this manual. Injury or damage
to the tool may result.
Failure to observe this precaution may result in
injury and property damage.
An incomplete press can cause a leak.
• Use proper tting and tubing combinations.
Improper combinations can result in an incom-
plete press.
• The relief valve will sound and the drive rollers
automatically retracts when a complete press
has been achieved. If you do not hear a “pop”
and the drive rollers do not automatically
retract, the press is not complete.
Failure to observe these precautions may result in
injury or property damage.

NIBCO, Inc. 51516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
Identification
Specifications
Pressing Tool
Length (with jaws and battery) ........................................................................18-3/8" (467 mm)
Width................................................................................................................... 2-3/8" (60 mm)
Depth .................................................................................................................. 3-3/4" (95 mm)
Mass/Weight (with battery)..................................................................................... 5.5 lb (2.5 kg)
Sound Level ...............................................................................................70.6 dB (A) at 1 meter
Vibration .......................................................................................................................< 2.5 m/s2
Hydraulic Oil...................................................................................................... Shell Tellus®T 15
Recommended Operating Temperature Range ................... -15 °C (5 °F) through 50 °C (120 °F)
Pressing Capacities
Maximum Pressing Force .......................................................................................44 kN (5 tons)
Average Pressing Time ................................................................................................ 5 seconds
Average Presses per Charge ............................................................................ approximately 65
Battery
Charging Voltage...................................................................................................................9.6 V
Charging Time.................................................................................................................... 45 min
1. Lock Pin
2. Pressing Head
3. Retract Button
4. Battery Lock
5. Battery Cartridge
6. Trigger
1
6
5
3
2
4

NIBCO, Inc. 61516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
Operation
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning could
result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
ying debris or hydraulic oil.
Inspect tool before use. Replace any worn or
damaged parts. A damaged or improperly
assembled tool can break and strike bystanders.
Failure to observe this warning could result in severe
injury or death.
• Do not use this tool for continuous use. After
30 to 40 cycles, allow the tool to cool for 15
minutes.
• Do not secure this tool in a vise. This tool is
designed for hand-held operation.
• This tool may be used in damp or wet environ-
ments; however, air-drying is recommended before
use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough
drying when electrical components are soaked.
• Use this tool for the manufacturer’s intended
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Charging the Battery
Read the instructions supplied with the battery charger.
Important Features of the Unit
• The hydraulic unit incorporates an automatic retraction
which returns the drive rollers into its starting position
when the maximum operating pressure is reached.
• The unit is equipped with a special brake which stops
the forward motion of the drive rollers when the trigger
is released.
• The pressing head can be smoothly turned by 350°
around the longitudinal axis in order to gain better
access to tight corners and other difcult working areas.
An incomplete press can cause leaks.
• Use proper tting and copper tubing combina-
tions. Improper combinations can result in an
incomplete press.
• The relief valve will sound and the drive rollers
automatically retracts when a complete press
has been achieved. If you do not hear a “pop”
and the drive rollers do not automatically retract,
the press is not complete.
Failure to observe these precautions may result in
injury or property damage.
Pinch points:
Keep hands away from the pressing
tool head when pressing.
Failure to observe this warning could
result in severe injury or death.

NIBCO, Inc. 71516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
Operation (cont’d)
For 1/2", 3/4" and 1" copper tubing sizes:
1. Select the proper pressing jaw for the intended
application. Examine the jaw for wear, damage, dirt
and copper buildup. Clean the compression area if
dirty and replace if worn or damaged.
2. Depress lock pin 1 (see views below) and rotate
counterclockwise to disengage the pin on the
pressing tool.
3. Install the jaw into the pressing tool and align
mounting hole in jaw with lock pin. Depress the lock
pin to secure the jaw (see views below).
Before changing the pressing jaws,
remove battery to avoid unintentional
operation.
Failure to observe this warning could
result in severe injury or property
damage.
1
2
1
4. Compress the ends of the jaw together to open the
jaws and locate the jaws around the tting to be
pressed (see view below).

NIBCO, Inc. 81516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
5. Reinstall the battery and depress the tool trigger
to press the tting. Continue to depress the trigger
until the relief valve actuates and the drive rollers
automatically retract.
Notes:
If the drive rollers do not automatically retract, the
press is incomplete.
The pressing cycle can be interrupted at any
moment by releasing the trigger.
6. Release the trigger until the drive rollers retract
completely.
7. Compress the jaw ends together to open the jaws
and remove the jaws from the pressed tting.
Notes:
The pressing jaws must close completely to ensure
a leak-free connection. Always check that jaws
close completely during a pressing cycle and no
foreign objects are between the pressing jaws and
mechanism.
The pressing cycle can be interrupted at any
moment by releasing the trigger.
If it is necessary to remove the jaws before a press
cycle is complete, push the retract button. Pushing
the retract button will cause the drive rollers to
retract completely.
If the pressing cycle must be stopped before the
crimp is complete, and the jaws have to be removed
from the fitting, the fitting should be replaced or
pressed a second time.
This tool is intended to press NIBCO press fittings
onto type K, L, and M hard-drawn copper tubing.
Operation (cont’d) Maintenance
Each Operating Day
Before use:
1. Inspect jaws for wear or damage such as cracks,
gouges, or chips.
2. Inspect the tool for damage or leaks. If damage is
detected, call NIBCO technical services or return
the tool to an authorized NIBCO service center for
inspection.
Do not use solvents or ammable
liquids to clean the pressing tool.
Solvents or ammable liquids could
ignite and cause serious injury or
property damage.
Skin injection hazard:
Do not use hands to check for
oil leaks. High pressure oil easily
punctures skin causing serious
injury, gangrene, or death. If injured,
seek medical help immediately to
remove oil.
After use:
1. Wipe all tool surfaces clean with a damp cloth and
mild detergent.
2. Fully retract the drive rollers. Place the tool in the
carrying case. Store in a cool, dry place.
3. Charge the battery.
Monthly
1. Thoroughly clean all surfaces.
2. Oil the pin joints on the jaws.
Annually or After 10,000 Presses
Call NIBCO technical services for referral to an
authorized NIBCO service center.

NIBCO, Inc. 91516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
Troubleshooting
Before You Begin
1. Make sure that the battery is charged. Recheck
the battery after several minutes to make sure the
battery is holding its charge.
2. Use a nonflammable contact cleaner or pencil
eraser to clean the electrical contacts on the battery
and pressing tool.
3. Reinstall the battery and check the tool again.
Problem Probable Cause Probable Remedy
Tool is inoperative. Dirt, contaminants, etc., in ram area Clean tool.
of tool.
Pressing tool battery contacts damaged. Reform contacts.
Tool components worn or damaged. Call NIBCO technical services for referral
to an authorized NIBCO service center.
Jaws stop during operation. Oil level is low. Call NIBCO technical services for referral
to an authorized NIBCO service center.
Air in hydraulic system. Pull trigger and hold retract button
simultaneously. Hold for approximately
10 seconds.
Tool loses oil. Damaged internal seal. Call NIBCO technical services for referral
to an authorized NIBCO service center.

NIBCO, Inc. 10 1516 Middlebury Street • Elkhart, IN 46516 USA • 888-446-4226
PC-10M Battery-powered Pressing Tool
NIBCO Inc. - World Headquarters
1516 Middlebury Street
Elkhart, IN 46516
USA
Technical Services
Phone: [phone]
Fax: [phone]
