Nidek Medical RT-5100 User manual

REFRACTOR
REFRACTOR
RT-5100
RT-5100
OPERATOR’S MANUAL
OPERATOR’S MANUAL
RT-5100
REFRACTOR
161221687130 承認済
Uncontrolled copy when printed.

NIDEK CO., LTD. : 34-14, Maehama, Hiroishi Gamagori, Aichi 443-0038, JAPAN
(Manufacturer) Telephone: [phone]
Facsimile: [phone]
NIDEK CO., LTD. : 3F Sumitomo Fudosan Hongo Bldg., 3-22-5 Hongo,
(Tokyo Office) Bunkyo-Ku, Tokyo 113-0033, JAPAN
Telephone: [phone]
Facsimile: [phone]
NIDEK INC. : 47651 Westinghouse Drive, Fremont, CA 94539, U.S.A.
(United States Agent) Telephone: [phone]
Facsimile: [phone]
NIDEK S.A. : Europarc, 13 rue Auguste Perret, 94042 Créteil, FRANCE
(EU Authorized Representative) Telephone: [phone]
Facsimile: [phone]
2016-12
34085-P902-P2
Printed in Japan
Original instructions
2005 NIDEK CO., LTD.
C
161221687130 承認済
Uncontrolled copy when printed.

Before using this product, be sure to read “SOFTWARE LICENSE AGREEMENT” at the
end of this manual.
The “SOFTWARE LICENSE AGREEMENT” contains the terms for use of the software and
related materials included for this product.
I
Use this device properly and safely.
BEFORE USE, READ THIS MANUAL.
This operator’s manual includes operating procedures, safety precautions, and
specifications for the NIDEK REFRACTOR RT-5100 when it is used in combination with
any of the NIDEK chart presenting devices. The dioptric powers are indicated with a
reference wavelength of 546.07 nm.
Cautions for safety and operating procedures must be thoroughly understood before
using this device.
Keep this manual handy for verification.
If you encounter any problems or have questions about the device, please contact NIDEK
or your authorized distributor.
*To use the functions described in this manual “only for Plus Package,” the optional 21
Point Exams Plus Package must be installed on the RT-5100.
*For simplicity, examples of chart type used in this manual are from CP-770M only. Any
other type may be used unless specified otherwise.
*This manual indicates the visual acuity by fractions (feet). Refer to “8.3 VA Conversion
Table” (Page 267) for visual acuity represented by decimals (meters).
CAUTION! The United States Federal Law restricts this device to sale by or on the order
of a licensed eye care practitioner.
34085-P902-P2
161221687130 承認済
Uncontrolled copy when printed.

II
Safety precautions
In this manual, signal words are used to designate the degree or level of safety alerting. The defini-
tions are as follows:
WARNING •Indicates a potentially hazardous situation which, if not avoided, may result in
death or serious injury.
CAUTION •Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury or property damage accident.
Even situations indicated by CAUTION might result in serious injury under certain conditions.
Safety precautions must be strictly followed at all times.
161221687130 承認済
Uncontrolled copy when printed.

III
Usage precautions
Before Use
WARNING •Be sure to secure the refractor head to the refractor arm.
If the refractor head is dropped or falls, injury or device failure may result.
•Connect the power plug to a grounded outlet.
Electric shock or fire may result in the event of malfunction or power leakage.
CAUTION •The safety precautions and operating procedures must be thoroughly
understood before using the device.
Improper use may cause unexpected malfunction or unintended results.
•Do not store the device in an area that is exposed to rain or water, or
contains poisonous gas or liquid.
•Do not store the device in dusty, hot, humid places or in direct sunlight.
•When connection between units is removed to move the device, and
reconnection is necessary, contact NIDEK or your authorized distributor.
•Install the device on a stable and level surface.
If the device falls, injury or device failure may result.
•Never install the device in a place exposed to water.
•Install the device in an environment that meets the following conditions.
The following conditions must be maintained during use.
Conditions for use Temperature: 10 to 35°C (50 to 95°F)
Humidity: 30 to 85% (No condensation)
Pressure: 800 to 1060 hPa
Installation place: Interior
No hazardous dust or smoke
A dust-free place
A place with little external light
A place free from vibration and shock
•Be sure to level the refractor head before use.
Failure to do so could affect the data accuracy. Level the refractor head by turning the
leveling adjustment knob until the bubble is centered in the level.
•Be sure to use a wall outlet that meets the power specification
requirements.
If the line voltage is too high or too low, the device may not operate properly. Malfunc-
tion or fire may result.
•Do not overload the electrical outlet.
Fire may result.
•Fully insert the power plug into the outlet.
Incomplete connection may cause fire.
161221687130 承認済
Uncontrolled copy when printed.

IV
•Never use a power strip or extension cable to supply power to the device.
The electrical safety may be lowered.
•Do not use a power cord other than the one supplied. Do not use the
equipped power cord for any other purpose.
Malfunction or fire may result.
•Install the device in area where the outlet that the power plug is inserted
into is easily accessible during use. In addition, ensure that the power cord
can be disconnected without the use of a tool.
Otherwise, it may interfere with disconnecting of the power from the input power
source in case of abnormality.
•Do not place heavy objects on the power cord.
A damaged power cord may cause fire or electric shock.
161221687130 承認済
Uncontrolled copy when printed.

V
During Use
WARNING •When moving the refractor head, make sure that there are no obstacles in
its path.
If the arm is swung carelessly, it may bump against someone or something and injury
or malfunction may occur. In addition, the near point rod may topple over and injury
may occur.
CAUTION •Unplug the power cord and contact NIDEK or your authorized distributor if
the internal wires are exposed, the table turns on or off when the power
cord is moved, or the cord and/or plug are not to the touch.
This may result in electric shock or fire.
•Do not look directly into the illumination for the near vision test or VD
check.
The retina of the operator or patient may be damaged.
•Keep the measuring windows free of fingerprints and smudges.
Failure to do so could affect the data accuracy.
•In the event of smoke or strange odors, immediately turn off the device and
disconnect the power plug from the outlet. Once it is determined that the
smoke has stopped, contact NIDEK or your authorized distributor.
Continued use of the device under such abnormal conditions may cause fire or elec-
tric shock.
•When the device is not in use, turn it off and cover it with its dust cover.
If the device is not covered for an extended period, the accumulation of dust may
affect the data accuracy.
•Do not touch the touch-screen panel with anything other than the tip of a
touch-screen pen.
Contact with a hard or sharp object such as a ball point pen may scratch the panel.
In addition, although the tip of a touch-screen pen is covered with resin which is
unlikely to scratch the panel, the panel may be scratched by strongly pressing the pen
against the panel.
Do not touch the panel with fingers. Doing so could decrease the panel sensitivity or
make the panel dirty. It may affect the test accuracy.
•Perform the visual and operation checks before using the device. If any
abnormality is found, do not use the device.
Continued use of the device under such abnormal conditions may affect the data
accuracy. Unexpected malfunction or faulty diagnosis may induce unexpected health
hazards.
•Before each patient, always clean the patient’s contact area (forehead rest
and face shields) using disinfectant alcohol.
161221687130 承認済
Uncontrolled copy when printed.

VI
•If the device fails, disconnect the power cord from the power outlet, then
contact NIDEK or your authorized distributor without touching the interior
of the device.
•Take care not to catch hands or fingers in moving parts.
•Do not modify the device or touch the interior of the device.
This may result in electric shock or malfunction.
•When connecting interface devices to the device, confirm the terminal
markings, then connect them securely without applying unnecessary great
force.
Terminals or cables may become damaged.
•Be sure to use only the printer paper (80620-00001) specified by NIDEK.
Other printer paper may cause improper printing and make the data unreadable.
•Do not apply adhesive tape to the printed paper.
Printed characters may fade.
•If the device is connected to a computer that does not comply with IEC
60601-1 (except those that use an AC adapter that meets the Class II
requirements of IEC 60950-1), supply power to the device and PC through
isolation transformers.
Electric shock may result. Contact NIDEK or your authorized distributor for installing
isolation transformers.
161221687130 承認済
Uncontrolled copy when printed.

VII
Patient environment
CAUTION •Use devices that comply with IEC 60601-1 in the patient environment. If any
device that does not comply with IEC 60601-1 is to be used, use an isolating
transformer or common protective grounding
The patient environment is the volume of space in which contact can occur between
the patient and any part of the device (including any connected device) or between
the patient and any other person(s) touching the device.
Radius of 1.5 m
1.5 m 1.5 m
2.5 m
161221687130 承認済
Uncontrolled copy when printed.

VIII
After Use
CAUTION
•After using the device, remove the near point rod from the device and store
it in a secure location.
If the near point rod is not removed, it may topple over and injury may occur.
•If the device will not be used for a long time, disconnect the power cable
from the wall outlet.
Settled dust may collect moisture, and short circuit or fire may result.
•Occasionally clean the prongs of the power plug with a dry cloth.
If dust settles between the prongs, it may collect moisture, and short circuit or fire may
result.
•Do not pull the power cord to disconnect the plug from an outlet.
This can damage the metal core of the cord and may result in electric shock, short cir-
cuit or fire.
•Before moving the device to another location, disconnect all the cords and
cables.
Maintenance
CAUTION
•Only NIDEK service representatives or hospital personnel trained by NIDEK
should attempt to modify or touch the interior of the device and/or upgrade
the software.
NIDEK is not responsible for any accidents resulted from improper servicing.
•When performing maintenance work, secure sufficient maintenance space.
Maintenance work in an insufficient space may result in injury.
•When sending the device back to NIDEK for repair or maintenance, wipe the
surfaces of the device (especially, the areas that come into patient contact)
with a clean cloth dampened with ethyl alcohol for disinfection.
•Never use organic solvents such as a paint thinner to clean the exterior of
the device.
It may ruin the surface of the device.
•When cleaning the measuring window, be sure to remove any dust with a
blower brush and wipe lightly with a soft cloth.
Wiping the window without removing dust may scratch the lens coating and impair
measurement of the power or visual acuity.
•To ensure the continued safe use of the device, it is recommended that the
manager of this device make sure that maintenance and preventive
inspection are performed at least once a year.
For details of maintenance and preventive inspection, ask NIDEK or your authorized
distributor. If the manager of this device cannot perform the maintenance and preven-
tive inspection, contact NIDEK or your authorized distributor.
161221687130 承認済
Uncontrolled copy when printed.

•In rare cases, a pixel may be missing on the screen or a red, blue, or green pixel point may
always be displayed.
This does not represent a failure of the touch-screen panel; this is due to the structure of the liquid
crystal display.
IX
Disposal
CAUTION •Follow local governing ordinances and recycling plans regarding disposal
or recycling of device components. The device contains the circuit board
with a lithium battery mounted. Because the disposal method of lithium
batteries varies according to the local government, follow the local
governing ordinates and recycling plans when disposing of the circuit
board with the lithium battery.
It is recommended to commission the disposal to a designated industrial waste dis-
posal contractor. Inappropriate disposal may contaminate the environment.
•When disposing of packing materials, sort them by material and follow
local ordinances and recycling regulations.
Inappropriate disposal may contaminate the environment.
161221687130 承認済
Uncontrolled copy when printed.

X
161221687130 承認済
Uncontrolled copy when printed.

Table of Contents
XI
1. BEFORE USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Outline of the Refractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.3 Connectable Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.4 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.4.1 Refractor head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.4.2 Control box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
1.4.3 Relay box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
1.4.4 Connecting each unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
1.4.5 Connecting peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
1.5 Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
1.6 Before First Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
1.7 Getting Started and Exiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1.7.1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1.7.2 Restore from power saving mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
1.7.3 Exiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
2. OPERATING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . 29
2.1 Operation Flow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
2.2 Entering Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2.2.1 From an auto refractometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2.2.2 From a lensmeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
2.2.3 Manual data entry with the dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
2.2.4 From an Eye Care card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
2.2.5 Entering day and night data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
2.2.6 Entering day and night data from ARK-10000 or OPD Scan III . . . . . . . . . . . . . . .36
2.3 Setting Prism Lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2.3.1 Switching between rectangular and polar coordinates . . . . . . . . . . . . . . . . . . . . . .40
2.3.2 Rectangular coordinates (XY). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2.3.3 Polar coordinates (rq) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
2.3.4 Removing rotary prism lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
2.3.5 Prism data clear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
2.3.6 Prism data comparison . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
2.4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
2.5 Standard Program Refraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
2.5.1 Program A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
2.5.2 Program Day/Night . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
2.5.3 Program #7 (only for Plus Package) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
2.6 Chart Presentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
2.6.1 Chart selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
161221687130 承認済
Uncontrolled copy when printed.

:
XII
2.6.2 Visual acuity chart mask functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
2.6.3 Low illumination, glare lamp, and contrast functions (SSC series). . . . . . . . . . . . . 78
2.6.4 Contrast function, Night mode, and Reverse function (SC series) . . . . . . . . . . . . . 81
2.7 Power Adjustment (Final Fit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
2.7.1 Auto adjustment of far powers (with Program A) . . . . . . . . . . . . . . . . . . . . . . . . . . 83
2.7.2 Auto adjustment of far powers (with Program B) . . . . . . . . . . . . . . . . . . . . . . . . . . 84
2.7.3 Power adjustment without standard programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
2.7.4 Fine adjustment after auto adjustment (Semi-auto adjustment). . . . . . . . . . . . . . . 86
2.7.5 Manual power adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
2.8 Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
2.8.1 Printing with QR code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
2.8.2 Printing 21 Point Exams result (only for Plus Package) . . . . . . . . . . . . . . . . . . . . . 92
3. ADVANCED FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . 95
3.1 Presenting Screen to Patient. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
3.2 Data List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
3.3 Displaying Refraction Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
3.4 Presenting Near Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
3.5 Range of Clear Vision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
3.5.1 Changing power while checking the range of clear vision . . . . . . . . . . . . . . . . . . 108
3.6 Displaying Image Information for Explanation . . . . . . . . . . . . . . . . . . . . . . . . . . 110
3.6.1 Image information “About Eye”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
3.6.2 Image information “Vision” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
3.7 Setting Auxiliary Lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
3.8 Fog Function with Both Eyes Open . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
3.9 Specifying Sub Window Display Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
3.10 Changing ID No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
3.11 Age Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
3.12 Calling Up Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
3.12.1 Calling up measurement data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
3.13 Link Off Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
3.14 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
3.14.1 Clearing programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
3.14.2 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
3.14.3 Operating programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
3.14.4 Importing or exporting programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
3.15 Entering Comments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
3.16 Setting Time and Date. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
3.17 Controlling Backlight Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
3.18 Touch-screen Panel Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
161221687130 承認済
Uncontrolled copy when printed.

XIII
:
3.19 Parameter Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
3.19.1 Parameter Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
3.19.2 Writing/Reading parameter setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
3.20 Clearing Stored Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
3.21 Exporting Data to Computer or OPD-Scan III. . . . . . . . . . . . . . . . . . . . . . . . . . . 147
3.22 Exporting Data to Eye Care Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
3.23 Displaying Images (SC series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
4. TEST METHOD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
4.1 Visual Acuity Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
4.1.1 Unaided Visual Acuity Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
4.1.2 Aided Visual Acuity Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
4.1.3 Visual Acuity Test with Addition Powers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
4.1.4 Visual Acuity Test using pin hole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
4.1.5 Input method of the correct character and incorrect character. . . . . . . . . . . . . . . 154
4.1.6 VA measurement of day data in brightness for Night mode . . . . . . . . . . . . . . . . . 155
4.2 Astigmatism test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
4.2.1 Astigmatism test with astigmatism clock dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
4.2.2 Astigmatism test with cross cylinder lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
4.2.3 Astigmatism power test with cross cylinder lens
(hold and remove cross cylinder testing method). . . . . . . . . . . . . . . . . . . . . . . . . 158
4.3 Spherical Refinement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
4.3.1 Red-green test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
4.3.2 Cross grid test for far vision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
4.4 Binocular Visual Function Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
4.4.1 Binocular balance test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
4.4.2 Binocular red-green test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
4.4.3 Phoria test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
4.4.4 Phoria with fixation test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
4.4.5 Mallet test (horizontal phoria) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
4.4.6 Mallet test (vertical phoria) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
4.4.7 Von Graefe test (horizontal phoria) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
4.4.8 Von Graefe test (vertical phoria). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
4.4.9 Maddox test (horizontal phoria) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
4.4.10 Maddox test (vertical phoria) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
4.4.11 Vertical coincidence test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
4.4.12 Horizontal coincidence test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
4.4.13 Schober test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
4.4.14 Stereo test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
4.4.15 Worth test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
4.4.16 Pointer test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
4.4.17 Double pointer test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
4.5 Divergence Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
161221687130 承認済
Uncontrolled copy when printed.

:
XIV
4.6 Convergence Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198
4.7 Supravergence Test for Final Prescription (only for Plus Package) . . . . . . 200
4.8 Infravergence Test for Final Prescription (only for Plus Package) . . . . . . . . 201
4.9 Near Point of Convergence (NPC) Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
4.10 Near Point of Accommodation (NPA) Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
4.11 Negative Relative Accommodation (NRA) Test . . . . . . . . . . . . . . . . . . . . . . . . . 204
4.12 Positive Relative Accommodation (PRA) Test . . . . . . . . . . . . . . . . . . . . . . . . . . 205
4.13 Visual Acuity Test by ETDRS chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 206
5. 21 Point Exams (only for Plus Package) . . . . . . . . . . . 209
5.1 Switching for 21 Point Exams list (only for Plus Package) . . . . . . . . . . . . . . . 209
5.2 21 Point Exams (only for Plus Package) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
5.2.1 #7 Subjective value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
5.2.2 #8 Horizontal phoria (Far), #13B Horizontal phoria (Near). . . . . . . . . . . . . . . . . . 211
5.2.3 Gradient AC/A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
5.2.4 #11 Divergence (Far), #17 Divergence (Near) . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
5.2.5 #9,10 Convergence (Far), #16 Convergence (Near) . . . . . . . . . . . . . . . . . . . . . . 216
5.2.6 #21 Negative relative accommodation (NRA) . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
5.2.7 #20 Positive relative accommodation (PRA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
5.2.8 #14A Cross cylinder (monocular) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
5.2.9 #15A Horizontal phoria (according to #14A). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
5.2.10 #14B Cross cylinder (binocular) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
5.2.11 #15B Horizontal phoria (according to #14B). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
5.2.12 #19 Accommodation with addition of minus lens . . . . . . . . . . . . . . . . . . . . . . . . . 224
5.2.13 #19 Near point of accommodation (NPA). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
5.2.14 Near point of convergence (NPC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
5.2.15 #12A Vertical phoria (Far), #18A Vertical phoria (Near). . . . . . . . . . . . . . . . . . . . 228
5.2.16 #12B Supravergence (Far), #18B Supravergence (Near) . . . . . . . . . . . . . . . . . . 230
5.2.17 #12B Infravergence (Far), #18B Infravergence (Near). . . . . . . . . . . . . . . . . . . . . 232
5.3 21 Point Exams Result (only for Plus Package) . . . . . . . . . . . . . . . . . . . . . . . . 234
5.3.1 21 Point Data List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
5.3.2 Visual function analysis graph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
5.3.3 Comparison display with the Morgan’s criterion . . . . . . . . . . . . . . . . . . . . . . . . . . 242
5.4 Changing 21 Point Exams Setting (only for Plus Package) . . . . . . . . . . . . . . 243
6. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
6.1 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
6.2 Cleaning Forehead Rest. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
6.3 Cleaning Face Shields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
6.4 Replacing Printer Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
161221687130 承認済
Uncontrolled copy when printed.

XV
:
6.5 Cleaning the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
6.6 Cleaning Measuring Windows. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
6.7 Cleaning Exterior. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
6.8 Cleaning Eye Care Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
6.9 Retightening Near Point Chart Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
6.10 List of Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
7. SPECIFICATIONS AND ACCESSORIES. . . . . . . . . . . . 257
7.1 Classifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
7.2 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
7.3 Standard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
7.3.1 Standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
7.3.2 Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260
8. APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
8.1 Descriptions of Power Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
8.2 Linkage between Charts and Auxiliary Lenses . . . . . . . . . . . . . . . . . . . . . . . . . 266
8.3 VA Conversion Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
8.4 Preset Addition Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
8.5 Relational Table of Age and Accommodation . . . . . . . . . . . . . . . . . . . . . . . . . . 269
8.6 Estimated Visual Acuity Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
8.7 Fog Amount in Binocular Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271
8.8 Standard Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
8.9 Near Point Chart (Standard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
8.10 Near Point Chart II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
9. EMC (ELECTROMAGNETIC COMPATIBILITY) . . . . . . 281
10.INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 285
161221687130 承認済
Uncontrolled copy when printed.

:
XVI
161221687130 承認済
Uncontrolled copy when printed.

1
1
1. BEFORE USE
1.1 Outline of the Refractor
The NIDEK REFRACTOR Model RT-5100 is a computerized refractor used for subjective refraction in
connection with the NIDEK AUTO REFRACTOMETER (AR), AUTO REF/KERATOMETER (ARK),
AUTO REF/KER/TONOMETER (RKT), or AUTO LENSMETER (LM).
The RT-5100 includes a refractor head, control box, relay box, and printer.
The relay box is used for connecting not only the other three units but also the auto refractometer or
lensmeter. The control box includes the key panel and display. The display is a touch-screen panel.
The control box not only displays data and is used to perform almost all operations. In addition, the
control box not only operates the refractor head but also the connected chart presenting device. It
allows the refractor and charts to be controlled together.
Normally, the relay box and printer are installed on the system table (not included in the RT-5100
package.)
* In this operator’s manual, the keys on the control box are indicated by key representations such as
or . The touch buttons on the touch panel other than chart buttons are indicated by brack-
ets such as [Div.].
The touch panel chart buttons are indicated by button representations such as .
1.2 Intended Use
Instrument providing means of positioning spherical and cylindrical lenses, prisms and other optical
devices in front of a subject’s eyes for purpose of determining refractive error and binocular functions.
1.3 Connectable Devices
Connectable Chart
Presenting device
Space Saving Chart: SSC-330, SSC-350, SSC-370
Chart Projector: CP-690, CP-770
System Chart: SC-1600, SC-1600Pola, SC-1700Pola, SC-2000
Connectable Lensmeter LM-500, LM-600P, LM-970, LM-990, LM-990A, LM-1000, LM-
1000P, LM-1200, LM-1800P, LM-1800PD
Connectable Auto
Refractometer/Ref-
Keratometer
AR-1 series, AR-20, AR-310A, AR-330A, AR-360A, AR-600, AR-
600A, AR-610, AR-630A, AR-660A, HandyRef, ARK-1 series,
ARK-30, ARK-510A, ARK-530A, ARK-560A, ARK-700A, ARK-
710A, ARK-730A, ARK-9000, ARK-10000, HandyRef-K, OPD-
Scan III, RKT-7700, TONOREF II, TONOREF III
161221687130 承認済
Uncontrolled copy when printed.

2
BEFORE USEConfiguration
1.4 Configuration
1.4.1 Refractor head
RT-5100
REFRACTOR
5. Forehead rest knob
4. Forehead rest
3. VD check window
2. Near point lamp
1. Measuring window
8. Near point rod
Operator’s side
6. Level
9. Level adjustment
7. Near point chart
Patient’s side
1. Measuring window
10. Forehead rest
11. Face shield
knob
detection lamp
161221687130 承認済
Uncontrolled copy when printed.
