Mod l JF143E/JF143-2E
El ctric
Own r’s Manual
BroilV ction™

This page intentionally left blank.

3
TABLE F C NTENTS
A. General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
A.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
A.2 Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
A.3 Service/Technical Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
A.4 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
B. Machine Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.1 Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.2 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.3 eveling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.4 Hood Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.5 Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.6 Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
B.7 Pre-Operation Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
C. perating Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
C.1 Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
C.2 Step-by-Step Operating Procedure . . . . . . . . . . . . . . . . . . . . . . . . . .9
C.3 Shutdown Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
C.4 Control Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
D. Assembly/Disassembly and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
E. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
F. Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
G. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Nieco Corporation - Model JF143E / JF143-2E

4
A. GENERAL INF RMATI N
A.1 Description
The Nieco®Model JF143E automatic broiler features patented BroilVection™
technology, easy cleaning and a simple and intuitive control package to help
eliminate broiling problems and provide the operator with even greater control
over the broiling environment.
This manual provides the safety, installation and operating procedures for the
Nieco Automatic Broiler Model JF143E. We recommend that all information
contained in this manual be read prior to installing and operating the broiler.
A.2 Warranty Information
Please read the full text of the limited Warranty in this manual.
If the unit arrives damaged, contact the carrier immediately and file a damage
claim with them. Save all packing materials when filing a claim. Freight damage
claims are the responsibility of the purchaser and AREN T covered under warranty.
The warranty does not extend to:
• Damages caused in shipment or damage as a result of improper use.
• Installation of electrical service.
• Normal maintenance as outlined in this manual.
• Malfunction resulting from improper maintenance not in accordance with the steps contained in
this manual and any applicable training.
• Damage caused by abuse or careless handling outside of the normal operating procedures
contained in this manual.
• Damage from moisture into electrical components.
• Damage from tampering with or removal of any safety device.
IMP RTANT!
Keep these instructions for future reference. If the unit changes ownership,
be sure this manual accompanies the equipment.
IMP RTANT
The Nieco Corporation reserves the right to change specifications and product design. Such revi-
sions do not entitle the buyer to corresponding changes, improvements, additions or replacements
for previously purchased equipment.
Nieco Corporation - Model JF143E / JF143-2E

5
A.3 Service/Technical Assistance
If you experience any problems with the installation or operation of your broiler, contact your local
Authorized Nieco Distributor.
Fill in the information bellow and have it handy when calling your authorized service agency for assistance.
The serial number is on the broiler rating plate on the side of the unit.
Purchased from:
Date of Purchase:
Model No.:
Serial No.:
For the name of your local Authorized Nieco Distributor, please call [phone].
Use only genuine Nieco replacement parts in your broiler. Use of replacement parts other than those sup-
plied by Authorized Nieco Distributors and Service Agencies will void the warranty and may significantly
alter the performance of your broiler. The use of non-Nieco parts is capable of affecting these criteria, and
may affect broiler performance, parts longevity and food safety. Your local Authorized Nieco Distributor and
Service Agent has been factory trained and has a complete supply of parts for your Nieco Automatic
Broiler.
You may contact the factory direct at [phone] if you have trouble locating your local Nieco
Distributor.
A.4 Important Safety Information
Throughout this manual, you will find the following safety words and symbols that signify important safety
issues with regards to operating or maintaining the equipment:
WARNING
GENERALWARNING. Indicates
information important to the proper
operation of the equipment. Failure
to observe may result in damage to
the equipment and/or severe bodily
injury or death.
WARNING
ELECTRICALWARNING. Indicates
information relating to possible
shock hazard. Failure to observe
may result in damage to the equip-
ment and/or severe bodily injury or
death.
CAUTI N
GENERALCAUTI N. Indicates
information important to the proper
operation of the equipment. Failure
to observe may result in damage to
the equipment.
WARNING
H TSURFACEWARNING. Indicates
information important to the han-
dling of equipment and parts.
Failure to observe caution could
result in personal injury.
Nieco Corporation - Model JF143E / JF143-2E

6
A.4 Important Safety Information (Continued.)
In addition to the warnings and cautions in this manual, use the following guidelines for safe operation of
your Nieco Automatic Broiler:
• Read and follow all instructions before using this equipment.
• Install or locate broiler only for its intended use as described in this manual.
• Do not operate this equipment if it has a damaged cord or plug, if it is not working properly or if it
has been otherwise damaged.
• This equipment should only be serviced by authorized personnel. Contact your local Nieco
Distributor for adjustment or repair.
• Use only genuine Nieco replacement parts for your broiler. Failure to do so will void the warranty
and may significantly alter the performance of your broiler. The use of non-Nieco parts is capable
of affecting these criteria, and may affect broiler performance, parts longevity and food safety.
The following warnings and cautions appear throughout the manual and should be carefully
observed:
• Turn the broiler off, close the main gas valve, and disconnect the plug before
performing any service, maintenance or cleaning on the broiler.
• Always allow the broiler to fully cool before performing any service, maintenance or
cleaning. Failure to wait for the broiler to cool fully may result in personal injury.
• The procedures in this manual may include reference to the use of chemical products. The
Nieco Corporation does not endorse the use of any particular cleaning/degreasing agent.
Use only those chemicals that are approved for use in your restaurant.
• The broiler should be grounded according to local electrical codes to prevent the
possibility of electrical shock. It requires a grounded receptacle with separate electrical
lines, protected by fuses or circuit breakers of the proper rating.
• All electrical connections must be in accordance with local electrical codes and any other
applicable codes.
• The use of adequate ventilation (as rated in this manual) with this broiler is mandatory.
Failure to adequately ventilate this unit and provide safe operating distances (as specified
in this manual) is a fire safety hazard. Follow the instructions for emergency broiler
shutdown in the event of an emergency.
• No attempt should be made to operate this appliance in the event of a power failure.
WARNINGELECTRICALSH CKHAZARD. FAILURE T F LL W THESE INSTRUCTI NS C ULD
RESULT IN SERI US INJURY R DEATH:
_Electrical ground is required on this appliance.
_Check with a qualified electrician if you are in doubt as to whether the appliance is properly
grounded.
_Do not use water on or near the control box for risk of serious injury or death due to
electrical shock.
WARNING, HIGHTEMPERATURES WITH H T SURFACES. FAILURE T F LL W THESE PR CE-
DURES C ULD RESULT IN SERI US INJURY:
_Do not attempt to clean, disassemble or perform maintenance on this broiler until it is fully
cooled as per the instructions contained in this manual.
Nieco Corporation - Model JF143E / JF143-2E

7Nieco Corporation - Model JF143E / JF143-2E
B. INSTALLATI N
B.1 Pre-Installation
Uncrate the broiler and inspect for shipping damage. Remove the tape securing the machine parts, and
install the parts in their proper location. If there are obvious or concealed damages to any part of the
broiler, please contact your freight carrier. The factory warranty does not cover freight damage.
B.2 Mounting
Follow the mounting instructions if this function is not performed by the installer.
B.3 Leveling
The grease drain system is based on a gravity-flow design. Therefore, it is extremely important that the
broiler be placed on a level surface.
B.4 Hood Requirements
This appliance must be installed under a ventilation hood of adequate size. Do not obstruct the flow of
combustion and ventilation air. An adequate air supply must be available for safe and proper operation.
For installations in the Commonwealth of Massachusetts the following shall apply: Venting shall be in
compliance with NFPA Section 10.3.5.2 for the Model JF143E / JF143-2E.
B.5 Clearance
Keep appliance area free from combustibles.
To facilitate disassembly and service of the unit a minimum of 24” (610 mm) should be allowed on the
control panel (feed end) of the broiler.
REQUIRED for
installation near
combustible walls
and construction
REQUIRED for installa-
tion near non-com-
bustible walls and
construction
REC MMENDED by
Nieco for proper disas-
sembly and service
Back of broiler
Sides of broiler
Front of broiler
(Feed end)
REQUIRED AND REC MMENDEDCLEARANCES
12” (305 mm) 0” (0 mm)
0” (0 mm)
24” (610 mm)
0” (0 mm)
0” (0 mm)
0” (0 mm)
12” (305 mm)
12” (305 mm)
B.6 Electrical Connection
Power requirements are stated on the unit nameplate and must be connected accordingly. This appli-
ance, when installed must be electrically grounded in accordance with local codes, or in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA
C22.2, as applicable. Before starting broiler, tighten all electrical connections in control box. An electrical
wiring diagram can be found inside the control box.
Note: Disconnect power before servicing.
B.7 Pre- peration Check
Be sure that all parts are installed in the proper location:
 Ventilation is turned on
 Broiler is plugged in

8Nieco Corporation - Model JF143E / JF143-2E
C. PERATI N
C.1 Controls and Indicators
On the front of the broiler:
1.Belt Speed Control - Used to set the broil time for the
meat belt
2.Main On/Off Switch - Turns the broiler on and off.
3.Power Indicator ight - Glows green when the power to
the broiler is on.
On the side of the broiler:
4. oad Stabilizer Control - Controls the energy input to the
broiler when it is under load.
5. Bun Platen Temperature Control - Used to control the
temperature of the bun platen.
6.Belt Reverse Button - Push and hold to reverse the
direction of the belt to help clear a belt jam.
1.
4.
5.
6.
2.
3.

9Nieco Corporation - Model JF143E / JF143-2E
C.2 PERATING PR CEDURES
1. Broiler is
centered under
hood and
plugged in
2. Turn ventilation
system on
WARNING
THE VENTILATI N SYSTEM MUST
BE N AT ALL TIMES DURING
BR ILER PERATI N. PERAT-
ING BR ILER WITH UT PR PER
VENTILATI N IS A SEVERE FIRE
N RMALIGNITI N
PRE- PERATING PREPARATI N
1. Turn the MAINP WER SWITCH on. 1.
2.2. Check the elements to verify they are on and glowing.
1. Allow the broiler
to run free of
any product for
10 minutes.
This will burn
the chain clean.
2. Turn off the
Main Power
Switch.
3. Wait for 30
minutes
for the
broiler to
cool.
C.3 Shutdown Procedures
SHUTD WN
CAUTI N
F R Y UR SAFETY: Do not store
or use gasoline or other flammable
vapors or liquids in the vicinity of
this or any other appliance.
CAUTI N
F R Y UR SAFETY: In the event of
a prolonged power failure, no
attempt should be made to operate
this appliance.

10 Nieco Corporation - Model JF143E
C.4 Control peration
IMP RTANT:THISBR ILERISSHIPPEDWITHFACT RYPRESETSTHATMUSTBE
CHANGED.
Adjust the broil times for safe cook out of your products. If this is the initial start-up of your broiler, follow the procedures for
automatic calibration to properly calibrate the broiler.
C NTR L PERATI N
1. SETTINGBELTSPEEDS
Press up arrow to increase broil time; press the
down arrow to decrease broil time. After you have
set the control the display will be flashing. Press
the center square to save your changes. NOTE:
After making changes to the broil time, if you do
not press the center square button, your changes
will not be saved.
2. L ADSENSINGC NTR L
How it works:
The load sensing control cycles the elements to
help keep the broiler stable during cooking.
3. CALIBRATI N
Perform calibration in the morning when the broil-
er is cool.
a. Turn the broiler on and set the set point (bot-
tom number on the control) to 1000. et the broil-
er warm up for one hour. Do not cook during the
warm up period.
b. After an hour, push the down arrow to lower
the set point to 20º BE OW the actual
temperature.
c. Your broiler is now calibrated.
BUNPLATENTEMPERATUREC NTR L
To change the set point temperature: Press and
hold the center square button for 5 seconds until
the control display changes to the flashing set
point number. Use the up and down buttons to
set the bun platen temperature. After you are
done making your changes, press the center
square button to save your changes.
The control will then display the new set point for
a few seconds, then display the actual tempera-
ture.
Under normal operation, when the platen is
warming up, the control will display ‘ o’, then it
will display ‘Rdy’ when it is ready for use.
Calibration
Raise the set point
temperature to 1000.
Let broiler run for 1
hour.
Lower the set point
temperature to 20ª
BEL W the actual
temperature.
Do not cook during
calibration.
The numbers on your
broiler will be different
than those shown
here.
Use the up and down
arrows to set the time.
Press the center
square button to save
your changes.
a
b

11 Nieco Corporation - Model JF143E / JF143-2E
C.4 Control peration
Use the adjustment levers to adjust the height of
the bun platens. The lever on the right controls
the crown side of the bun belt, while the left side
control the height of the heel side of the bun belt.
Adjust the levers up or down to increase or
decrease the height of the bun platen for proper
bun grilling.
ADJUSTING THE BUN BELT

12 Nieco Corporation - Model JF143E / JF143-2E
D. CLEANING ANDDISASSEMBLY
Turn broiler off. Disconnect the power supply to the broiler before cleaning or servicing. If this broiler is con-
nected using a restraint, and disconnection of the restraint is necessary for cleaning or moving the broiler, the
restraint must be reconnected after the broiler has been returned to its originally installed position. Allow to
cool for 30 minutes prior to cleaning/disassembly. Leave the ventilation system on during cooling. Use only
approved cleaning, degreasing and sanitizing solutions.
ALL PARTS ARE CLEANED N A DAILY BASIS UNLESS THERWISE N TED
Follow the steps for proper disassembly. Reverse the order for reassembly.
CAUTI N
Follow the Disassembly and
Reassembly steps to ensure proper
operation of the broiler. Failure to
do so may result in operational
problems.
WARNING
BR ILER PARTS ARE H T. D
N TATTEMPTT DISASSEMBLE
THEBR ILERUNTILITISFULLY
C L. FAILURE T F LL W THIS
INSTRUCTI N MAY RESULT IN
SEVERE INJURY.
WARNING
LEAVETHEVENTILATI NH D
NDURING C LING. FAILURE
T D S C ULD P SE A FIRE
SAFETY HAZARD.
How to read the cleaning section
The location of the part. When to clean the part.
Picture of the part to
be removed and
How to remove and
clean the parts.
The tools needed
to clean the part
The name of the part to be

13 Nieco Corporation - Model JF143E / JF143-2E
Instructions
1. Allow the broiler to run free of product for 10
minutes before turning it off. This allows
any residue to burn off the
chains.
2. Shut the broiler off and let it cool for 30
minutes before disassembly and
cleaning.
3. Close the main gas valve and unplug the
broiler before cleaning.
4. Always leave the ventilation hood on during
the 30 minute cool down period.
5. Use only approved cleaning solutions.
6. Allow parts to air dry after cleaning.
Cleaning the Broiler
3-Compartment Sink
No-Scratch
Pad Scrub Towel
Heat
Resistan
t Gloves
Degreaser
Soft
Bristle
Shaft Cleaning
Tool
Tools Needed
This “Stop” sign shows a step in the procedure
that must be followed exactly or personal
safety could be affected.
This warning symbol shows a step in the
procedure that must be followed exactly or
broiler performance could be affected.
This “puzzle” symbol shows a step in the
reassembly procedure that must be followed.
Important Symbols
STOP
1. Pull the release pin.
2. ift wire belt feeder bases up and off.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
REASSEMB Y: Place feeder base in place. Push
engagement pin back in; you may need to
manually rotate the wire belt to renegage the push
pin.
Wire Belt Feeder Base (If equipped)
Feed End
Tools
Instructions
3-Compartment Sink
Clean: Every 4 hours
Scrub
Wire Brush

14 Nieco Corporation - Model JF143E / JF143-2E
1. ift and remove.
2. Wash, rinse, and sanitize in the 3-
compartment sink.
REASSEMB Y: Hang feeder housing on brackets.
Feeder Housing
Feed End
Tools
Instructions
3-Compartment Sink
Clean: Daily
Scrub
1. Slide grease pan out.
Make sure grease pan is cool before putting in
water or it may warp the pans.
2. Take to sink area and spray with degreaser.
3. Wash with a scrub pad, rinse, and sanitize in
the 3-compartment sink.
Grease Pan
Feed End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser

15 Nieco Corporation - Model JF143E / JF143-2E
1. Slide the sheet out from under the bun platen.
2. Using a clean, damp cloth, wipe the sheet
clean.
REASSEMB Y: Slide the sheet back under the
bun platen.
Wipe PTFE Sheets
Feed End
Tools
Instructions
3-Compartment Sink
Clean: Daily
Scrub
1. Slide out from under bun belt.
2. Wash, rinse, and sanitize in the 3-
compartment sink.
Crumb Tray
Feed End
Tools
Instructions
3-Compartment Sink
Clean: Daily
Scrub

16 Nieco Corporation - Model JF143E / JF143-2E
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-compartment
sink.
Feed End Heat Shield
Feed End
Tools
Instructions
Clean: As needed
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Discharge Heat Shield
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser

17 Nieco Corporation - Model JF143E / JF143-2E
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Discharge Awning
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser
1. ift sizzle plate up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Sizzle Plate
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser

18 Nieco Corporation - Model JF143E / JF143-2E
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Patty Catch Pan
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser
1. Tilt stripper blade away from chain; lift off
brackets.
Make sure stripper blade is cool before putting in
water or it may warp.
2. Take to sink area and spray with degreaser.
3. Wash with a scrub pad, rinse, and sanitize in
the 3-compartment sink.
REASSEMB Y: Hang stripper blade on brackets.
Stripper Blade
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser

19 Nieco Corporation - Model JF143E / JF143-2E
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Bun Blade
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Heat Resistant
Degreaser
1. ift up and off.
2. Take to sink area and spray with degreaser.
3. Wash, rinse, and sanitize in the 3-
compartment sink.
Grease Chute
Discharge End
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Degreaser

20 Nieco Corporation - Model JF143E / JF143-2E
1. ift grease box off.
2. Take to sink area and spray with degreaser.
3. Wash with a scrub pad, rinse, and sanitize in
the 3-compartment sink.
REASSEMB Y: Put grease box on before the
grease trough.
NOTE: If your broiler is on legs and not a stand
your grease box will be as shown in picture two.
Grease Box
Side
Tools
Instructions
Clean: Daily
3-Compartment Sink
Scrub Pad
Degreaser
EXTREME Y HOT! Be careful not to burn
yourself.
1. Grasp handle and lift Catalyst off to remove
from Shroud.
2. SOAK IN WARM WATER FOR 1 HOUR.
RINSE WITH WATER ON Y. NEVER
USE ANY CHEMICA S ON THE
CATA YST.
3. ay flat to drain water and let air dry overnight.
Incendalyst™
Top
Tools
Instructions
Heat Resistant Gloves
Clean: Daily
CAUTION: Extremely
Hot
