AF-S VR ZOOM NIKKOR ED
70-300 / f4.5-5.6G
JAA79551(MADE IN THAILAND)
REPAIR MANUAL

INC
JAA79551-R.3690.A
- Ｍ  ･ AF-S VR 70-300/4.5-5.6G -
Specications
Type of lens: G-type AF-S Zoom-Nikkor lens with built-in CPU and Nikon bayonet mount
Focal length: 70mm–300mm
Maximum aperture: f/4.5–5.6
Lens construction: 17 elements in 12 groups (2 ED lens elements)
Picture angle: 34°20’-8°10’ [22°50’-5°20’ with Nikon digital cameras
(Nikon DX format); 27°40’-6°40’ with IX240 system cameras]
Focal length scale: 70, 100, 135, 200, 300mm
Distance information: Output to camera body
Zoom control: Manually via separate zoom ring
Focusing: Nikon Internal Focusing (IF) system (utilizing an internal Silent Wave Motor);
manually via separate focus ring
Vibration reduction: Lens-shift method using voice coil motors (VCMs)
Shooting distance scale: Graduated in meters and feet from 1.5m (5 ft.) to innity (∞)
Closest focus distance: 1.5m (4.9 ft.) at all zoom settings
No. of diaphragm blades: 9 pcs. (rounded)
Diaphragm: Fully automatic
Aperture range: f/4.5 to f/32 (at 70mm), f/5.6 to f/40 (at 300mm)
Exposure measurement: Via full-aperture method
Attachment size: 67mm (P = 0.75mm)
Dimensions: Approx. 80mm dia. x 143.5mm extension from the camera’s lens mount ange
Weight: Approx. 745g (26.3 oz)
Specications and designs are subject to change without any notice or obligation on the part of the manufacturer.

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
※Before Disassembly / Reassembly / Adjustment
Caution:
①In desassembly/(re)assembly, be sure to use conductive mat (J5033) and wrist strap (J5033-5), in order
to protect electric parts from static electricity.
②When disassembling, make sure to memorize the processing state of wires, screws to be xed and their
types, etc.
③Because prototypes are used for "Disassembly/(Re)assembly/Adjustment", they may differ from the
actual products in forms, etc.
④Because pictures are processed by a special method, they may differ from the actual ones in texture.
・Lead-free solder is used for this product.
・For soldering work, the special solder and soldering iron are required.
・Do NOT mix up lead-free solder with traditional solder.
・Use the special soldering iron respectively for lead-free solder and lead solder.
They cannot be used in common.
Points to notice for Lead-free solder products
Whenever the 2nd lens-group unit of this lens is removed, replace it with the new
2nd lens-G holding tube of RP. After reassembly, the optical lens-alignment work
becomes necessary.
At service facilities where such work cannot be carried out, do NOT remove the
2nd lens-group unit.
On this lens, the VR (vibration-reduction) unit (inside the 3rd lens-group unit) is mounted to correct the
picture blur.
In order to maintain the functional accuracy of the picture blur correction, if detaching the VR (vibration-
reduction) unit (inside the 3rd lens-group unit) and gyro-FPC or if removing the main base plate unit, be sure
to adjust the VR by using the VR lens adjustment equipment (J15380).
However, if disassembling the parts except the above, the VR adjustment is NOT necessary.
At service agencies where the "VR lens adjustment equipment" is not prepared, do NEITHER disassemble
NOR repair the products of the above case.

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
#92×3
1. Disassembly
Rear cover ring
Rear cover ring
G1 unit #82
G1 unit

INC
JAA79551-R.3690.A
- Ｄ 3・AF-S VR 70-300/4.5-5.6G -
② Set the focus ring to "∞", and the zoom ring to TELE "300", then insert the two innity pins ( ★J11339) to
the two holes.
G2-G3 unit, 2nd lens-group unit
①Remove the hole cover sheet.
Zoom rubber
Zoom rubber
Hole cover sheet
★: New tool
Innity pin（★ J11339)×2
Caution:
When the hole cover sheet is removed,
be careful NOT to damage the lens.

INC
JAA79551-R.3690.A
- Ｄ 4・AF-S VR 70-300/4.5-5.6G -
③Insert the two pin-parts of G2-G3 unit assembling tool ( ★J11337) into the two holes of G2-G3 unit. Then
rotate and remove G2-G3 unit.
④Remove the tool pins that were set in ②.
⑤Remove the washer (#62 : selected from A ～H).
⑥Peel off the sheet (#133) from the 2nd lens group.
⑦Take out three screws (#110), and remove the 2nd lens group.
#110×3
#133
#62:A ～H
Caution 1:
Whenever the 2nd lens group is removed, optical
alignment work becomes necessary after reassembling.
Therefore, at service facilities where this work cannot
be performed, do NOT remove the 2nd lens group.
Caution 2:
Whenever the 2nd lens group is removed, replace it
with the new 2nd lens-G holding tube (refer to page
D20) which is prepared as RP.
G2-G3 unit assembling tool
（★ J11337）
★：New tool
G2-G3 unit
Pin ×2
2nd lens-G unit

INC
JAA79551-R.3690.A
- Ｄ 5・AF-S VR 70-300/4.5-5.6G -
#125×2
#65
#125×2
#65
#126 #126
Zoom coupling lever
①Peel off the two cover sheets (#126).
② Take out four screws (#125), and remove the two zoom coupling levers (#65).
Zoom cover ring

INC
JAA79551-R.3690.A
- Ｄ 6・AF-S VR 70-300/4.5-5.6G -
Zoom ring, Zoom cover ring
Lens body
Zoom ring
③ Remove the zoom ring from the zoom
cover ring.
② Peel off the three pieces of the xing
tape (#111).
Zoom ring
① Rotate the zoom ring until its "300"-mark is positioned approx. 1-cm away from the zoom index. Then
remove the zoom ring from the lens body.
# × 3
Zoom cover ring

INC
JAA79551-R.3690.A
- Ｄ 7・AF-S VR 70-300/4.5-5.6G -
#103
#90
#90
Contacts unit
・Take out two screws (#90), and remove the contact unit.
Contacts unit
Slack of Change-SW unit
・Take out the screw (#103) of the change-SW unit, and leave the unit slightly slackened.
Change-SW unit

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
#92×3
#93
#97×2
#84
#83:A ～I#96
#23 #94
#95
#28
#30
#25
①Take out the three screws (#93) and one screw (#93), and remove the bayonet mount.
②Remove the washer (#83 : selected from A -I).
Bayonet mount
Bayonet mount

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
Mount xed-tube
① Pass the change-SW unit through the hole of the mount xed-tube, and remove it from the lens body.
Caution: Do not lift up the mount xed-tube strongly. Otherwise, change-SW FPC will be cut off.
Hole of mount xed-tube
② Remove the name plate and focusing-index window from the mount xed-tube.
Caution: This removal is NOT necessary except replacing any of the below two parts.
Focusing-index window
Name plate
Mount xed-tube
Change-SW unit
Lens body

INC
JAA79551-R.3690.A
- Ｄ 0・AF-S VR 70-300/4.5-5.6G -
#138
#139
Distance-FPC
Main base plate unit
①Remove each FPC from each connector of the main base plate unit.
Zoom FPC
VCM relay-FPC
GMR FPC
SWM FPC
Gyro-FPC
PSD relay-FPC
Contacts unit
Remove SWM-FPC from the rear
xed-tube.
Caution:
Removing the contacts unit is NOT
necessary except replacing it.
②Remove the spring washer (#138) and the screw (#139). Then remove the main PCB
from the rear xed-tube.
Main base plate unit
Rear xed-tube

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
#106×2
#116
・Disconnect the FPC of the change-SW unit from the connector of the main base plate unit.
Change-SW unit
Change-SW unit
Main base plate unit
Rear xed-tube
・Take out two screws (#106) and the screw (#116). Then remove the rear xed-tube from the front xed-tube.
Rear xed-tube
Front xed-tube

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
Gyro-FPC
Rear xed-tube
Gyro-FPC
・Remove the gyro-FPC from the rear xed-tube.
VCM relay-FPC, PSD relay-FPC
①Remove the FPCs from each connector.
VCM relay-FPC
PSD relay-FPC

INC
JAA79551-R.3690.A
- Ｄ 3・AF-S VR 70-300/4.5-5.6G -
#136×2
#136×2
② Take out four screws (#136). Then remove each FPC from the front xed-tube.
VCM relay-FPC Front xed-tube
PSD relay-FPC
Front xed-tube
③Hold the VCM relay-FPC and PSD relay-FPC with tweezers. Then slide and remove them from
the FPC-xing plate.
VCM relay-FPC
PSD relay-FPC
FPC-xing plate FPC-xing plate

INC
JAA79551-R.3690.A
- Ｄ 4・AF-S VR 70-300/4.5-5.6G -
#121×3
Focus ring unit
Lens body
①Rotate the focus ring unit and align
"∞" with the index.
②Remove the focus ring unit from the
lens body.
Focus ring unit
①Take out three screws (#121), and remove the SWM unit from the front xed tube.
Be careful NOT to touch the metal area directly by hand.
SWM unit
Front xed-tube
SWM unit
Metal area
Index

INC
JAA79551-R.3690.A
- Ｄ 5・AF-S VR 70-300/4.5-5.6G -
③ Take out four screws (#140), and remove the zoom ring unit from the SWM.
② Remove the two pieces of the protection tape (TA-0012× 2), and peel off the focus index sticker from the
SWM unit.
#140×4
SWM unit
Focus index sticker
TA-0012
TA-0012
Be careful NOT to touch the MR head, when the zoom ring unit is removed.
SWM
Zoom ring unit
Metal area
MR head
Be careful NOT to touch the metal area of the SWM.

INC
JAA79551-R.3690.A
- Ｄ 6・AF-S VR 70-300/4.5-5.6G -
⑥ Take out two screws (#541), and remove the GMR unit and [#534].
#534
#541×2
⑤ Take out the screw (#543), and remove the MR retaining springs (#533 and #536).
#501
④ Remove the FPC of GMR unit from #501.
#533
#536
#543
GMR unit
GMR unit

INC
JAA79551-R.3690.A
- Ｄ 7・AF-S VR 70-300/4.5-5.6G -
#73×3
⑦ Take out three screws (#544), and remove [#537] from the SWM.
⑧ Remove the MR ring unit from the SWM.
#544×3
#537
MR ring unit
Be careful NOT to touch the MR tape directly by hand.
MR tape
SWM
①Take out three screws (#73) from the 1st lens-G tube.
1st lens-group tube
1st lens-group tube

INC
JAA79551-R.3690.A
- Ｄ ・AF-S VR 70-300/4.5-5.6G -
#121×3
#74×3
#76::A ～D×3
#75::A ～D×3
②Take out three screws (#121), and remove the 1st lens-G tube.
1st lens-group tube
・Remove the three nuts (#74), three rollers (#76 : selected from A to D), and three rollers
(#75 : selected from A to D) from the cam groove of the front xed tube.to D) from the cam groove of the front xed tube.D) from the cam groove of the front xed tube.
Front xed tube
#145:A×2:A×2A×2
Caution:
The two washers (#145A) are
attached at the positions of
the picture.
