Nilfisk-Advance BRV 900 User manual

A-English
B-Türkçe
Instructions for Use
Original Instructions
Kullanim Talimatlari
11/09 revised 8/11
FORM NO. 56041806
Models: 56602002
BRV900
INSTRUCTIONS FOR USE

A-2 / ENGLISH
A-2 - FORM NO. 56041806 - BRV900
TABLE OF CONTENTS
Page
Introduction...........................................................................................A-2
Cautions and Warnings........................................................................A-3
Know Your Machine.....................................................................A-4 –A-5
Control Panel........................................................................................A-6
Prepare the Machine for Use
Install the Batteries...............................................................................A-7
Install the Brushes................................................................................A-8
Install the Filter Bag..............................................................................A-9
Operating the Machine
Vacuuming..........................................................................................A-10
Using the Wand..................................................................................A-10
After Use.............................................................................................A-12
Maintenance Schedule.......................................................................A-12
Lubricating the Machine.....................................................................A-12
HEPAFilter Maintenance....................................................................A-12
Charging the Batteries (Wet)..............................................................A-13
Check the Battery Water Level...........................................................A-13
Charging the Batteries (Gel)...............................................................A-13
Side Broom Maintenance...................................................................A-14
Troubleshooting..................................................................................A-15
Technical Specifications.....................................................................A-15
INTRODUCTION
This manual will help you get the most from your Nilfisk BRV 900 (rider vacuum). Read it thoroughly before operating the machine.
Note: Bold numbers in parentheses indicate an item illustrated on pagesA-4 – A-6.
This product is intended for commercial use only.
PARTSAND SERVICE
Repairs, when required, should be performed by yourAuthorized Nilfisk Service Center, who employs factory trained service personnel, and maintains an
inventory of Nilfisk original replacement parts and accessories.
Call the NILFISK DEALER named below for repair parts or service. Please specify the Model and Serial Number when discussing your machine.
(Dealer, affix service sticker here.)
NAME PLATE
The Model Number and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering repair parts for
the machine. Use the space below to note the Model Number and Serial Number of your machine for future reference.
MODELNUMBER ______________________________________________________
SERIALNUMBER ______________________________________________________
UNCRATE THE MACHINE
When the machine is delivered, carefully inspect the shipping packaging and the machine for damage. If damage is evident, save the shipping carton (if
applicable) so that it can be inspected. Contact the Nilfisk Customer Service Department immediately to file a freight damage claim. Refer to the unpacking
instruction sheet included with the machine to remove the machine from the pallet.

ENGLISH /A-3
FORM NO. 56041806 - BRV900 - A-3
CAUTIONSAND WARNINGS
SYMBOLS
Nilfisk uses the symbols below to signal potentially dangerous conditions. Always read this information carefully and take the
necessary steps to protect personnel and property.
DANGER!
Is used to warn of immediate hazards that will cause severe personal injury or death.
WARNING!
Is used to call attention to a situation that could cause severe personal injury.
CAUTION!
Is used to call attention to a situation that could cause minor personal injury or damage to the machine or other property.
Read all instructions before using.
GENERAL SAFETY INSTRUCTIONS
Specific Cautions and Warnings are included to warn you of potential danger of machine damage or bodily harm.
WARNING!
•This machine shall be used only by properly trained and authorized persons.
•While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only
while ascending (driving up) the ramp.
•Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
•Charging the batteries produces highly explosive hydrogen gas. Charge batteries only in well-ventilated areas, away from open
flame. Do not smoke while charging the batteries.
•Remove all jewelry when working near electrical components.
•Turn the key switch off (O) and disconnect the batteries before servicing electrical components.
•Never work under a machine without safety blocks or stands to support the machine.
•Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where flammable
liquids exist.
•Do not clean this machine with a pressure washer.
•Only use the brushes provided with the appliance or those specified in the instruction manual. The use of other brushes may
impair safety.
CAUTION!
•This machine is not approved for use on public paths or roads.
•This machine is not suitable for picking up hazardous dust.
•When operating this machine, ensure that third parties, particularly children, are not endangered.
•Before performing any service function, carefully read all instructions pertaining to that function.
•Do not leave the machine unattended without first turning the key switch off (O) and removing the key.
•Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
•Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
•The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be
safely done in accordance with your local environmental regulations.
•Do not use on surfaces having a gradient exceeding that marked on the machine.
•All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
•This machine is for indoor use only.
•This machine shall be stored indoors only.
SAVE THESE INSTRUCTIONS

A-4 / ENGLISH
A-4 - FORM NO. 56041806 - BRV900
KNOW YOUR MACHINE
As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item shown on these
pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in the text. NOTE: Refer to the
service manual for detailed explanations of each item illustrated on the next 3 pages.
1 Operator’s Seat
2 Drive Pedal, Directional/Speed
3 Drive Wheel
4 Drive Wheel Circuit Breaker (70Amp)
5 Control Circuit Circuit Breaker (10Amp)
6 Emergency Stop
7 Hourmeter (optional)
8 Side Broom Circuit Breaker (5Amp)
9 Vacuum Deck
10 Battery Compartment (under seat)
11 Vacuum Deck Raise/Lower Lever
12 Side Broom HeightAdjustment Knob
13 Rear Wheel
14 SeatAdjustment Knob
15 Front Roller Bumper
16 Right Side BroomAssembly
17 Wand
18 Wand Control Lever
19 Spare Bag Tray (behind seat)
20 Side Broom Release Latch

ENGLISH /A-5
FORM NO. 56041806 - BRV900 - A-5
KNOW YOUR MACHINE
22 Steering Wheel TiltAdjust Knob
23 Control Panel
24 Battery ChargerAccess Door
25 Battery Charger (optional)
26 Machine Battery Connector
27 Seat Prop-Rod
28 HEPAFilter Access Door
29 Vacuum Motor Foam Filter
30 Filter BagAccess Door
31 Filter Bag

A-6 / ENGLISH
A-6 - FORM NO. 56041806 - BRV900
B
E
I
D
F
G
A
C
H
CONTROL PANEL
A Key Switch
B Battery Indicator
C Quiet Mode Button
D Quiet Mode Indicator
E Horn
F Wand Button
G Wand Button Indicator
H Bag Full Indicator
I Fault Indicator

ENGLISH /A-7
FORM NO. 56041806 - BRV900 - A-7
BATTERIES
If your machine shipped with batteries installed do the following:
Check that the batteries are connected to the machine (26).
Turn ON the Key Switch (A) and check the Battery Indicator (B). If the green light is ON, the batteries are ready for use. If the green light is OFF, the
batteries should be charged before use. See the “Charging The Batteries” section.
IMPORTANT!: IF YOUR MACHINE HASAN ONBOARD BATTERYCHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
See TSBUS2008-984 for the latest battery charger algorithms.
If your machine shipped without batteries installed do the following:
Consult yourAuthorized Nilfisk dealer for recommended batteries. Install the batteries by following the instructions below.
DO NOT install two 12 volt batteries in your machine. This affects the stability of the machine.
IMPORTANT!: IF YOUR MACHINE HASAN ONBOARD BATTERYCHARGER REFER TO THE OEM PRODUCT MANUAL FOR INSTRUCTIONS
REGARDING SETTING THE CHARGER FOR BATTERY TYPE.
See TSBUS2008-984 for the latest battery charger algorithms.
INSTALL THE BATTERIES
WARNING !
Use extreme caution when working with batteries. Sulfuric acid in batteries can cause severe injury if allowed to contact the skin or
eyes. Explosive hydrogen gas is vented from inside the batteries through openings in the battery caps. This gas can be ignited by
any electrical arc, spark or flame.
When Servicing Batteries...
• Remove all jewelry.
• Do not smoke.
• Wear safety glasses, a rubber apron and rubber gloves.
• Work in a well-ventilated area.
• Do not allow tools to touch more than one battery terminal at a time.
•ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent sparks.
•ALWAYS connect the negative cable last when installing batteries.
CAUTION !
Electrical components in this machine can be severely damaged
if the batteries are not installed and connected properly. Batteries
should be installed by Nilfisk or by a qualified electrician.
1 Turn the Key Switch (A) off (O) and remove the key. Then swing open the
Battery Compartment Cover (10) and set the Prop-Rod (27).
2 Using (2) people and an appropriate lifting strap, carefully lift the batteries into
the compartment tray exactly as shown. Refer to decal 56601589 battery
cable layout.
3 See Figure 1. Install battery cables as shown and tighten the nuts on the
battery terminals.
4 Install the battery boots and secure tightly to the battery cables with the
supplied tie straps.
5 Connect the battery pack connector to the machine connector (26) and close
the battery compartment cover.
CAUTION !
Before changing batteries consult TSBUS2008-984 or visit http://
www.nilfisk-advance.com
FIGURE 1

A-8 / ENGLISH
A-8 - FORM NO. 56041806 - BRV900
INSTALL THE BRUSHES
CAUTION !
Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
1 Make sure the Vacuum Deck is in the RAISED position. Make sure the Key Switch (A) is off (O).
2 See Figure 2. Loosen both Thumb Screws (AA) slide the IdlerAssembly (AB) down and off of the vacuum deck and away from the brush.
4 Slide the brush into the housing, lift slightly, push and turn until it seats. Re-install the IdlerAssemblies (AB) and Thumb Screws (AA).
FIGURE 2

ENGLISH /A-9
FORM NO. 56041806 - BRV900 - A-9
INSTALL THE FILTER BAG
1 Turn the knob on the Filter BagAccess Door (30) one half turn counterclockwise and open the access door.
2 See Figure 3. Swing open the filter collar (AC), held closed by Magnet (AD).
Install either a Cloth Filter Bag or a Paper (Disposable) Filter Bag
3 Expand the filter by pulling out the pleats.
4 Hold onto the filter’s cardboard square and slide the filter into the collar.
5 Swing closed the filter collar pushing the filter bag’s rubber seal onto the intake tube. Rest the bag on top of the bag support platform.
6 Close the Filter BagAccess Door. Do not pinch the filter between the door and the housing.
FIGURE 3

A-10 / ENGLISH
A-10 - FORM NO. 56041806 - BRV900
OPERATING THE MACHINE
WARNING!
Be sure you understand the operator controls and their functions.
While on ramps or inclines, avoid sudden stops when loaded. Avoid abrupt sharp turns. Use low speed down hills. Clean only while
ascending (driving up) the ramp.
To Vacuum...
Follow the instructions in “preparing the machine for use” section of this manual.
1 See Figure 4. While seated on the machine, adjust the steering wheel to a comfortable position using the Steering Wheel TiltAdjust Knob (22). The seat can
be adjusted if necessary by tipping up the seat and using the adjustment knob (14).
2 Turn the Master Key Switch (A) ON (I). This will display the control panel indicator lights. Reference the Battery Indicator (M) before proceeding.
3 To transport the machine to the work area, apply even pressure with your foot on the front of the Drive Pedal (2) to go forward or the rear of the pedal for
reverse. Vary the pressure on the foot pedal to obtain the desired speed.
4 Be certain that the carpet to be vacuumed is completely dry.
CAUTION!
Never attempt to pick-up water or vacuum wet carpet. This machine is designed for dry pick-up only.
5 Lower the side broom to the operating position. This is done by pressing down on the Side Broom Release Latch (20) while lifting up on the outer edge of
the side broom assembly (see the decal on top of the side broom) then set the side broom down. Once in the operating position the side broom will move up
and down with the vacuum deck. If it is not desired to use the side broom it can remain up, in the storage position.
6Lower the vacuum deck and side broom using the Vacuum Deck Raise/Lower Lever (11). This will turn on the vacuum motors and activate scrub and side
broom systems. Scrub and side broom systems will start when the Drive Pedal (2) is activated in forward.
7 Begin vacuuming by driving the machine forward in a straight line at a normal walking speed and overlap each path by 2-3 inches (50-75 mm).Adjust the
machine speed when necessary according to the condition of the floor.
8 The machine has two vacuum motors which can both run for maximum pick up ability. Press the Quiet Mode Button (C) to turn off one of the vacuum motors
and reduce the noise level of the machine. This will cause the Indicator (D) to turn ON. Press the button again to turn the second vacuum motor back on.
The machine will default to the last setting (one or two vacuum motors) upon start up.
9 When vacuuming, check behind the machine occasionally to see that all of the debris is being picked up. Occasionally check the level of debris in the filter
bag and empty/replace once it has reached the level indicated on the side of the bag.
10 When the Bag Full Indicator (H) turns ON, the vacuum motor(s) will continue to run, but the machine will not pick up debris if the filter bag is full.
11 When the operator wants to stop vacuuming or the Bag Full Indicator (H) turns ON;
Use the Vacuum Deck Raise/Lower Lever (11) to manually raise the scrub deck and side broom, this will stop the scrub brushes, side broom and the vacuum
motors.
12 Drive the machine to a designated waste “DISPOSALSITE” and remove the filter bag. Dispose of a paper bag filter or empty a cloth filter bag (depending on
type being used). Install a new/empty filter bag and continue vacuuming.
NOTE: Make sure the Filter BagAccess Door (30) and the HEPAFilter Access Door (28) are properly seated or the machine will lose vacuum power and not pick-
up debris correctly.
When the batteries require recharging the Battery Indicator (B) will flash red. Then the brush and vacuum motors will turn OFF automatically and cease to
function, manually raise the vacuum deck. Transport the machine to a service area and recharge the batteries according to the instructions in the Battery section
of this manual.
USING THE WAND
The machine’s built in Wand makes it easy to clean high surfaces or reach into tight corners. The wand can be used with the operator on or off the machine, and
the vacuum deck in the up or down position.
1 Remove the Wand (17) from its holder.
2 Turn the Wand Control Lever (18) (clockwise) to the wand position.
3 Turn the Master Key Switch (A) ON and press the Wand Button (F) to turn on the vacuum motors. The vacuum motors will run continuously until the button
is pressed again to turn them OFF.
4 NOTE: If seated on the machine and the deck is in the down position, the vacuum motors will run continuously, regardless of pressing Wand Button (F).
SERVICE NOTE: Refer to the service manual for detailed functional descriptions of all controls and optional programmability.

ENGLISH /A-11
FORM NO. 56041806 - BRV900 - A-11
FIGURE 4
B
C
F
G
D
A
H

A-12 / ENGLISH
A-12 - FORM NO. 56041806 - BRV900
AFTER USE
1 When finished vacuuming, manually raise the vacuum deck to turn off all systems. Then drive the machine to a service area for daily maintenance and
review of other needed service up keep.
2 Remove the brushes then rinse them with warm water and remove any built up string, hair or carpet fibers. Hang the brushes up to dry.
3 Check the maintenance schedule below and perform any required maintenance before storage.
MAINTENANCE SCHEDULE
Keep the machine in top condition by following the maintenance schedule closely. Maintenance intervals given are for average operating conditions.
Machines used in severe environments may require service more often.
MAINTENANCE ITEM Daily Weekly Monthly Yearly
Charge Batteries X
Check/Empty/Replace the Filter Bag X
Check/Clean the HEPAFilters X
Check/Clean the Brushes X
Check/Clean the vacuum motor foam filter(s) X
Check Each Battery Cell(s) Water Level X
Lubrication of Machine X
* Check Carbon Brushes X
* Have Nilfisk check the vacuum motor carbon motor brushes once a year or after 300 operating hours. The brush and drive motor carbon brushes check every
500 hours or once a year.
NOTE: Refer to the Service Manual for more detail on maintenance and service repairs.
4 Store the machine indoors in a clean dry place. Keep from freezing.
5 Turn the Master Key Switch (A) OFF (O) and remove the key.
SERVICING THE VACUUM MOTORS
Have your Nilfisk-Advance Dealer check the carbon motors brushes once a year or after 300 operating hours.
IMPORTANT!
Motor damage resulting from failure to service the carbon brushes is not covered under warranty. See the Limited Warranty Statement.
LUBRICATING THE MACHINE
Once a month, pump a small amount of grease into each grease fitting on the machine until grease seeps out around the bearings. Wipe off any excess grease to
avoid staining carpet.
Grease fitting locations (or apply grease to) (AA):
• Vacuum Deck Caster Wheels
Once a month lubricate the pivot points below. For
best results, use a spray silicone lubricant.
• Steering Chain
• General Pivot Points for the Side Broom and
Vacuum Deck Linkage.
• Steering Wheel Shaft Universal joint
• Side Broom Front Roller Bumper
HEPAFILTER MAINTENANCE
The HEPAfilters may be cleaned when they become
dirty. If cleaning is not sufficient to increase airflow then
they will need to be replaced.
1 See Figure 5. Loosen the two Screws (AE) then
remove the Filter Panel (AF) from the back of the
machine.
2 Flip open the Clamps (AG) and pull out the HEPA
Filters (AH).
3 Use compressed air from the back side to blow out
debris. Do not allow these filters to get wet.
FIGURE 5

ENGLISH /A-13
FORM NO. 56041806 - BRV900 - A-13
CHARGING WET BATTERIES
Charge the batteries each time the machine is used or when the Battery Condition Indicator (B) is flashing RED.
WARNING!
Do not fill the batteries before charging.
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
•Remove all jewelry
•Do not smoke
•Wear safety glasses, rubber gloves and a rubber apron
•Work in a well-ventilated area
•Do not allow tools to touch more than one battery terminal at a time
•ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent sparks.
•ALWAYS connect the negative cable last when installing batteries.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Open the Battery Compartment (10) and the Battery ChargerAccess Door (24) for proper ventilation. Unwind the electrical cord from the side of the
onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Open the Battery Compartment (10) and set the Prop-Rod (27). Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector
(26). Follow the instructions on the battery charger. SERVICE NOTE: Make sure you plug the battery charger into the connector that attaches to the batteries.
CAUTION!
To avoid damage to floor surfaces, wipe water and acid from the top of the batteries after charging.
CHECKING THE BATTERY WATER LEVEL
Check the water level of the batteries at least once a week.
After charging the batteries, remove the vent caps and check the water level in each battery cell. Use distilled or demineralized water in a battery filling dispenser
(available at most auto parts stores) to fill each cell to the level indicator (or to 10 mm over the top of the separators). DO NOT over-fill the batteries!
CAUTION!
Acid can spill onto the floor if the batteries are overfilled.
Tighten the vent caps. Wash the tops of the batteries with a solution of baking soda and water (2 tablespoons of baking soda to 1 liter of water).
CHARGING GEL (VRLA) BATTERIES
Charge the batteries each time the machine is used or when the Battery Condition Indicator (B) is flashing RED.
WARNING!
Charge batteries in a well-ventilated area.
Do not smoke while servicing the batteries.
When Servicing Batteries...
•Remove all jewelry
•Do not smoke
•Wear safety glasses, rubber gloves and a rubber apron
•Work in a well-ventilated area
•Do not allow tools to touch more than one battery terminal at a time
•ALWAYS disconnect the negative (ground) cable first when replacing batteries to prevent sparks.
•ALWAYS connect the negative cable last when installing batteries.
CAUTION!
Your voltage regulated lead acid (VRLA) battery will deliver superior performance and life ONLY IF IT IS RECHARGED PROPERLY!
Under or overcharging will shorten battery life and limit performance. Be sure to FOLLOW PROPER CHARGING INSTRUCTIONS!
DO NOTATTEMPTTO OPEN THIS BATTERY! If a VRLAbattery is opened, it loses its pressure and the plates become oxygen
contaminated. THE WARRANTY WILLBE VOIDED IF THE BATTERYIS OPENED.
If your machine shipped with an onboard battery charger do the following:
Turn the Key Switch (A) OFF. Open the Battery Compartment (10) and the Battery ChargerAccess Door (24) for proper ventilation. Unwind the electrical cord from the side of the
onboard charger and plug it into a properly grounded outlet. Refer to the OEM product manual for more detailed operating instructions.
If your machine shipped without an onboard battery charger do the following:
Open the Battery Compartment (10) and set the Prop-Rod (27). Disconnect the batteries from the machine and push the connector from the charger into the Battery Pack Connector
(26). Follow the instructions on the battery charger. SERVICE NOTE: Make sure you plug the battery charger into the connector that attaches to the batteries.
IMPORTANT: Make sure you have an appropriate charger for use on Gel cell batteries. Use only “voltage-regulated” or “voltage-limited” chargers.
Standard constant current or taper current chargers MUST NOT be used. Atemperature-sensing charger is recommended, as manual adjustments are
never accurate and will damage any VRLAbattery.

A-14 / ENGLISH
A-14 - FORM NO. 56041806 - BRV900
SIDE BROOM MAINTENANCE
The side broom moves dirt and debris away from walls or curbs and into the path of the main brushes. Adjust the side broom so that the bristles are contacting the
floor from the 10 O’clock (AA) to the 3 O’clock (BB) area shown in Figure 6 when the broom is down and running.
To adjust the Side Broom...
1The side broom is adjusted simply by turning the Side Broom HeightAdjustment Knob (12), clockwise to raise and counterclockwise to lower the side broom.
NOTE: The machine should be stored with the Side Broom in the raised position. The Side Broom should be replaced when the bristles are too worn or they
become ineffective.
To replace the Side Broom...
1Raise the Side Broom.
2Remove the three hex Screws (AJ) and Washers (AK) holding the Side Broom (AL) on to the hub and remove the broom.
3Install the new broom by using the same hardware.
FIGURE 6

ENGLISH /A-15
FORM NO. 56041806 - BRV900 - A-15
GENERAL MACHINE TROUBLESHOOTING
Problem Possible Cause Remedy
Poor vacuuming performance Wand Control Lever set to Wand instead
of brushes Rotate the wand control lever to brushes
Brushes are worn or have taken a set Replace brushes
Moving machine too fast Slow down
Side broom does not operate Side broom is in the raised storage
position Lower the side broom into the operating position
Tripped 5Amp circuit breaker Check for and remove the cause of the
side broom motor overload (binding etc.).
Reset the circuit breaker.
Machine does not run Battery connector disconnected Reconnect battery connectors
Operator seat safety switch Check for open circuit and replace
Main system controller Check error fault codes
(see service manual)
Tripped 10Amp circuit breaker Check for electrical short circuit & reset
No FWD/REV wheel drive Drive system speed controller Check error fault codes
(see service manual)
Tripped 70Amp circuit breaker Check for drive motor overload
Emergency stop switch tripped Reset the Emergency Stop Switch
Filter bag full indicator is lit when
filter bag is not full Blocked HEPAfilters Clean filters or replace if necessary
Blocked wand tool or hose Clear the hose
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model BRV 900
Model No. 56602002
Voltage, Batteries V 24V
Battery Capacity Ah 305/415
Protection Grade Do not spray
Sound Pressure level – LpA
(IEC 60335-2-72, ISO 11201) dB(A) 67.0 64.0 (quiet mode)
Sound Pressure level - KpA
(IEC 60335-2-72, ISO 11201) Uncertainty dB(A) 3.0
Gross Weight lbs / kg 1,026/465.4
Maximum Wheel Floor Loading (center front) psi / kg/cm2158 / 11.1
Maximum Wheel Floor Loading (right rear) psi / kg/cm2115 / 8.1
Maximum Wheel Floor Loading (left rear) psi / kg/cm285 / 6.0
Vibrations at the Hand Controls
(ISO 5349-1) m/s2.25
Vibrations at the Hand Controls
(ISO 5349-1) Uncertainty m/s2.05
Vibrations at the Seat (EN 1032/ISO 2631-1) m/s2.01
Vibrations at the Seat (EN 1032/ISO 2631-1)
Uncertainty m/s2.002
Gradeability Transport 16% (9°)
Gradeability Cleaning 9% (5°)

B-2 / TÜRKÇE
B-2 - FORM NO. 56041806 - BRV900
İÇİNDEKİLER
Sayfa
Giriş...................................................................................................... B-2
Önlemler ve Uyarılar............................................................................. B-3
Makinenizi Tanıyın.......................................................................B-4 – B-5
Kontrol Paneli ....................................................................................... B-6
Makinenin Kullanıma Hazırlanması
Bataryaların Takılması.......................................................................... B-7
Fırçaların Takılması.............................................................................. B-8
Filtre Torbasının Takılması.................................................................... B-9
Makinenin Çalıştırılması
Vakum................................................................................................. B-10
Sopanın Kullanılması.......................................................................... B-10
Kullanım Sonrası................................................................................ B-12
Bakım Takvimi .................................................................................... B-12
Makinenin Yağlanması....................................................................... B-12
HEPA Filtresinin Bakımı...................................................................... B-12
Bataryaların (Islak) Şarj Edilmesi ....................................................... B-13
Batarya Su Seviyesinin Kontrol Edilmesi............................................ B-13
Bataryaların(Jel) Şarj Edilmesi ........................................................... B-13
Yan Süpürgenin Bakımı...................................................................... B-14
Sorun giderme.................................................................................... B-15
Teknik Özellikler.................................................................................. B-15
GİRİŞ
Bu kılavuz, Nilfisk BRV 900 (temizlik arabasından) en iyi verimi almanızda yardımcıolacaktır. Makineyi çalıştırmadan önce kılavuzu baştan sona okuyun.
Not: Parantez içinde verilen koyu numaralar, B-4 – B-6 arasısayfalarda gösterilen bir parçayıbelirtmektedir.
Bu ürün sadece ticari amaçlarla kullanıma yöneliktir.
PARÇALAR VE SERVİS
Gerekli onarımlar, fabrikada eğitilmişpersoneli olan ve Nilfisk orijinal yedek parça ve
aksesuarlarınıkullanan bir Nilfisk Yetkili Servis Merkezinde yapılmalıdır.
Yedek parça veya servis için Nilfisk i arayınız. Makinenizle ilgili başvurunuzda Model ve Seri Numarasınıbelirtin.
(Distribütör buraya çıkartmasınıyapıştıracak)
KÜNYE
Makinenizin Model ve Seri Numarasıakü bölmesinde bulunan Künyede yazılıdır. Bu bilgi makine için siparişverirken gereklidir. Aşağıdaki bölüme makinenizin
Model ve Seri Numarasınıileride gerekli olduğunda bakmak için yazın.
Model_______________________________________________
Seri Numarası________________________________________
AMBALAJIN ÇIKARILMASI
Makineyi teslim aldığınızda, nakliye sırasında herhangi bir hasar meydana gelip gelmediğini anlamak için makineyi ve ambalajıkontrol edin. Eğer hasar meydana
geldiği açık bir şekilde belliyse, daha sonra incelenmesi için (mümkünse) ambalajımuhafaza edin. Hasarın tazmin edilmesine ilişkin bir talep formu doldurmak için
hemen Nilfisk Müşteri Hizmetleri Bölümünü arayın. Makineyi paletten indirmek için makineyle birlikte verilen ambalajın çıkarılmasıtalimatlarına bakın.

TÜRKÇE / B-3
FORM NO. 56041806 - BRV900 - B-3
UYARI VE ÖNLEM
SEMBOLLERİ
Nilfisk potansiyel tehlikelerin ikazıolarak aşağıdaki sembolleri kullanır. Bu bilgileri dikkatlice okuyup insanların ve eşyaların koruması
için gerekli önlemleri alın.
TEHLİKE!
Ciddi yaralanma ve ölüm tehlikesini belirtir.
UYARI!
Ciddi yaralanma ve ölüm tehlikesine yol açabilecek durumlarıbelirtir.
DİKKAT!
İnsanların, makine veya diğer eşyaların maruz kalabileceği hafif yaralanma ya da hasar oluşturabilecek durumlarıbelirtir.
Kullanmadan önce bütün talimatlarıdikkatlice okuyunuz.
GENEL GÜVENLİK TALİMATLARI
İnsanlara ve makinelere yönelik potansiyel zararlarla ilgili özel uyarılar ve dikkat edilmesi gereken hususlar aşağıda belirtilmektedir.
UYARI!
Bu makine sadece kalifiye ve yetkili personel tarafından kullanılmalıdır.
Yokuşçıkışveya inişlerde, yüklü iken ani duruşlardan kaçının. Ani keskin dönüşler yapmaktan kaçının. Yokuşaşağıinişleri düşük hızlarda
yapın. Yalnızca yokuşyukarıçıkarken temizlik yapın.
Kıvılcım, çıplak alev ve duman çıkaran maddeleri akülerden uza tutunuz. Normal kullanım esnasında patlayıcıgazlar salınır. Akülerin şarj
edilmesi oldukça patlayıcıolan hidrojen gazıçıkmasına neden olur. Aküleri, yalnızca iyi havalandırılan, çıplak alevden uzak yerlerde şarj edin.
Aküleri şarj ederken sigara içmeyin.
Elektrik aksamına yakın bölgelerde çalışırken tüm mücevher takılarınızıçıkarın.
Elektrikli aksama bakım yaparken anahtarıkapalı(0) konumuna getirin ve akü bağlantılarınısökün.
Makinenin üstünde duracağıpayanda veya takoz olmadan makinenin altında asla çalışmayın.
Yanıcıtemizlik maddeleri kullanmayın, makineyi bu gibi maddelerin yanında veya yanıcısıvıların bulunduğu alanlarda çalıştırmayın.
Bu makineyi basınçlıyıkama cihazlarıile yıkamayın.
Bu makineyi %2 den daha yüksek eğimlerde veya yokuşlarda kullanmayın
Yalnızca donanım ile verilmişolan veya kullanma talimatlarında belirtilen fırçalarıkullanın. Diğer fırçaların kullanılmasıgüvenli olmayabilir.
DİKKAT!
Bu makine trafiğe açık yollarda kullanıma uygun değildir.
Bu makine tehlikeli tozların toplanmasıiçin uygun değildir.
Bu makineyi kullanırken üçüncü şahısların, özellikle çocukların tehlike altında kalmamsına dikkat edin.
Herhangi bir bakım ve tamir işlemi gerçekleştirmeden önce talimatlarıtamamen ve dikkatlice okuyun.
İlk önce kontak anahtarınıkapatmadan (O) ve anahtarıçıkarmadan makinenin yanından ayrılmayın.
Fırçalarıdeğiştirirken ve panelleri açarken önce Kontak Anahtarını(0) konumuna getirip anahtarıçıkartın.
Saçların, mücevherlerin ve bol giysilerin makinenin hareket eden parçalarına takılmamalarınıengellemek için gerekli bütün önlemleri
alın.
Makine çalışmaz hale gelmeden aküler çıkarılmalıdır. Akülerin imhasıyerel yönetmeliklere uygun olarak güvenli bir şekilde yapılmalıdır.
Makineyi belirtilenden daha dik yokuşlarda kullanmayın.
Bu makine kullanılmadan önce tüm kapılar ve kapaklar kullanım talimatlarında belirtildiği konumda olmalıdır.
Bu makine sadece kapalıalanda kullanım içindir.
Bu makine sadece kapalıalanda muhafaza edilmelidir.
BU TALİMATLARI SAKLAYINIZ

B-4 / TÜRKÇE
B-4 - FORM NO. 56041806 - BRV900
MAKİNENİZİTANIYIN
Bu kılavuzu okurken, parantez içinde koyu harfle yazılmışbir numara veya harf göreceksiniz- örnek: (2). Bu numaralar, aksi belirtilmedikçe, bu sayfada gösterilen
bir bileşene atıf yapmaktadır. Metinde bahsedilen bir bileşenin yerini tam olarak belirlemek için gerekli olduğunda bu sayfaya bakınız. NOT: Takip eden 3 sayfada
gösterilen her bir bileşene ait ayrıntılıaçıklamalar için servis el kitabına bakınız.
1 Sürücü Koltuğu
2 Sürme Pedalı, Yön/Hız
3 Tahrik Tekerleği
4 Tahrik Tekerleği Devre Kesicisi (70 Amp)
5 Kontrol Devresi Devre Kesicisi (10 Amp)
6 Acil Durdurma
7 Saat sayacı(opsiyonel)
8 Yan Süpürge Devre Kesicisi (5 Amp)
9 Vakum Güvertesi
10 Batarya Bölmesi (koltuk altında)
11 Vakum Güvertesi Kaldırma/İndirme Kolu
12 Yan Süpürge Yükseklik AyarıDüğmesi
13 Arka Tekerlek
14 Koltuk Ayar Düğmesi
15 Ön MakaralıTampon
16 SağTaraf Süpürge Tertibatı
17 Sopa
18 Sopa Kontrol Kolu
19 Yedek Torba Tablası(koltuğun arkasında)
20 Yan Süpürge Açma Mandalı

TÜRKÇE / B-5
FORM NO. 56041806 - BRV900 - B-5
MAKİNENİZİTANIYIN
22 Direksiyon Eğimi Ayar Düğmesi
23 Kontrol Paneli
24 Batarya Şarj CihazıErişim Kapağı
25 Batarya Şarj Cihazı(isteğe bağlı)
26 Makine Batarya Konektörü
27 Koltuk Destek Çubuğu
28 HEPA Filtresi Erişim Kapağı
29 Vakum Motoru Köpük Filtresi
30 Filtre TorbasıErişim Kapağı
31 Filtre Torbası

B-6 / TÜRKÇE
B-6 - FORM NO. 56041806 - BRV900
B
E
I
D
F
G
A
C
H
KONTROL PANELİ
A Kontak Anahtarı
B Batarya Göstergesi
C Sessiz Modu Düğmesi
D Sessiz Modu Göstergesi
E Korna
F Sopa Düğmesi
G Sopa Düğmesi Göstergesi
H Torba Dolu Göstergesi
I Hata Göstergesi
