Nilfisk-Advance GM 80P User manual

GM 80P - GM 80P LC
Instructions for use
107418517 A (06. 2017)

3
Power cord
Diffuser
Plastic hose and plastic tube Suction power regulation
Rubber or plastic hose with
curved steel tube
Filter cleaning
12 3
12 3
45
12
Hose connection

4
HEPA
ULPA
12 3
Suction with dust bag
Exhaust filter Blowing attachment Sound suppressor Motor protection filter

*) Optional accessories / Option depending on model
Original instruction
5
1 IMPORTANT SAFETY INSTRUCTIONS
1.1 Symbols used to mark instructions
DANGER
Danger that leads directly to serious or irreversible injuries, or
even death.
WARNING
Danger that can lead to serious injuries or even death.
CAUTION
Danger that can lead to minor injuries and damage.
Before starting up your machine for the first time, this instruction manual must be read through
carefully. Save the instructions for later use.
1.2 Instructions for use
Besides the operating instructions and the binding accident prevention regulations valid in the country
of use, observe recognised regulations for safety and proper use.
1.3 Purpose and intended use
This machine is for industrial use, such as e.g. plants, construction sites and workshops. This machine
is also intended for commercial use, for example in hotels, schools, hospitals, factories, shops, offices
and rental businesses. Accidents due to misuse can only be prevented by those using the machine.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
This machine is suitable for picking up dry, non-flammable dust.
Any other use is considered as improper use. The manufacturer accepts no liability for any damage
resulting from such use. The risk for such use is borne solely by the user. Proper use also includes
proper operation, servicing and repairs as specified by the manufacturer.
For Dust Class L machines (with type designation LC) following applies:
The appliance is suitable for picking up dry, non-flammable dust, hazardous dusts with OEL1) value
> 1mg/m3. Dust Class L (IEC 60335-2-69). The dusts which belong to this class have OEL1) values
> 1mg/m3. For machines intended for the Dust Class L, the filter material is tested. The maximum
degree of permeability is 1% and there is no special requirement for disposal. Observe national regu-
lations before use.
1.4 Important warnings
WARNING
• This machine is for dry use only.
• Do not use to pick up flammable or combustible liquids such as
gasoline, or use in areas where they may be
pre sent.
• To reduce the risk of fire, electric shock, or injury, please read and
follow all safety instructions and caution markings before use. This

6*) Optional accessories / Option depending on model
Original instruction
vacuum cleaner is designed to be safe when used for cleaning
functions as specified. Should damage occur to electrical or me-
chanical parts, the cleaner and / or accessory should be repaired
by a competent service station or the manufacturer before use in
order to avoid further damage to the machine or physical injury to
the user.
• To reduce the risk of electric shock – Do not use outdoor or on wet
surfaces.
• This machine is for indoor use only.
• This machine shall only be stored indoors.
• Do not leave the machine when it is plugged in. Unplug from the
socket when not in use and before maintenance.
• Do not use with damaged cord or plug. To unplug grasp the plug,
not the cord. Do not handle plug or cleaner with wet hands. Turn off
all controls before unplugging.
• Do not pull or carry by cord, use cord as a handle, close a door on
cord, or pull cord around sharp edges or cor ners. Do not run clean-
er over cord. Keep cord away from heated surfaces.
• Keep hair, loose clothing, fingers and all parts of the body away
from ope nings and moving parts. Do not put any objects into open-
ings or use with opening blocked. Keep openings free of dust, lint,
hair, and anything else that could re du ce the flow of air.
• For standard machines (without type designation LC) following ap-
plies: This machine is not suitable for picking up hazardous dust.
• Do not pick up anything that is burning or smoking, such as ciga-
rettes, mat ches or hot ashes.
• This appliance is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge.
• Children shall be supervised to make sure that they do not play
with the appliance.
• Cleaning and user maintenance shall not be made by children with-
out supervision.
• Use extra care when cleaning on stairs.
• Do not use unless filters are fitted.
• If the cleaner is not working properly or has been dropped, da m-
a ged, left out doors, or dropped into water, re turn it to a service
center or dealer.
• Operators shall be adequately instructed on the use of these ma-
chines.

*) Optional accessories / Option depending on model
Original instruction
7
1.5 Double-insulated appliances*)
CAUTION
• Use only as described in this manual and only with the manufactur-
er’s re com men ded attachments.
• BEFORE YOU PLUG IN YOUR CLEANER, check the rating plate
at the cleaner to see if the rated vol ta ge agrees within 10% of the
voltage available.
• This appliance is provided with double insu la tion. Use only identical
re pla ce ment parts. See instructions for ser vi cing double insulated
appliances.
In a double-insulated appliance, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated appliance, nor should a mean for grounding be
added to the appliance. Servicing a double-insulated appliance requires extreme care and knowl-
edge of the system, and should be done only by qualified service personnel. Replacement parts for a
double-insulated appliance must be identical to the parts they replace. A double insulated appliance
is marked with the words “DOUBLE INSULATION” or “DOUBLE INSULATED.” The symbol (square
within a square) may also be used on the product.
The machine is equipped with a specially designed cord which if damaged, must be replaced by a
cord of the same type. This is available at authorised service centres and dealers and must be in-
stalled by trained personnel.
1.6 Electrical connection
WARNING
• The vacuum cleaner must not be used if the electrical cable or plug
show any sign of damage. Regularly inspect the cable and the plug
for damage. If this becomes damaged, it should be repaired only
by Nilfisk or an authorised Nilfisk Service Dealer, in order to avoid a
hazard.
• Do not handle the electrical cable or plug with wet hands.
• Do not unplug by pulling on cable. To unplug, grasp the plug, not
the cable. The plug must always be removed from the socket outlet
before starting any service or repair work of the machine or the ca-
ble.
1.7 Hazardous materials
WARNING
Hazardous materials.
Vacuuming up hazardous materials can lead to serious or even fatal in-
juries.
The following materials must not be picked up by the machine:
• hot materials (burning cigarettes, hot ash, etc.)
• flammable, explosive, aggressive liquids (e.g. petrol, solvents,

8*) Optional accessories / Option depending on model
Original instruction
acids, alkalis, etc.)
• flammable, explosive dust (e.g. magnesium or aluminium dust,
etc.)
For standard machines (without type designation LC) following further
applies: The following materials must not be picked up by the machine:
• Hazardous dust.
1.8 Maintenance
Always keep the cleaner in a dry place. The cleaner is designed for continuous heavy work. Depend-
ing on the number of running hours – the dust filters should be renewed.
Keep the container clean with a dry cloth, and a small amount of spray polish.
For Dust Class L machines (with type designation LC) following applies:
During maintenance and cleaning, handle the machine in such a manner that there is no danger for
maintenance staff or other persons.
In the maintenance area
• Use filtered compulsory ventilation
• Wear protective clothing
• Clean the maintenance area so that no harmful substances get into the surroundings.
1.9 Regular servicing and inspection
Regular servicing and inspection of your machine must be carried out by suitably qualified personnel
in accordance with relevant legislation and regulations. In particular, electrical tests for earth continui-
ty, insulation resistance, and condition of the flexible cord should be checked frequently.
In the event of any defect, the machine MUST be withdrawn from service, completely checked and
repaired by an authorized service technician.
At least once a year, a Nilfisk technician or an instructed person must perform a technical inspection
including filters, air tightness and control mechanisms.
For Dust Class L machines (with type designation -0L, -2L) following applies:
During maintenance and cleaning, handle the machine in such a manner that there is no danger for
maintenance staff or other persons.
In the maintenance area
• Use filtered compulsory ventilation
• Wear protective clothing
• Clean the maintenance area so that no harmful substances get into the surroundings.
During maintenance and repair work all contaminated parts that could not be cleaned satisfactorily
must be:
• Packed in well sealed bags
• Disposed of in a manner that complies with valid regulations for such waste removal.
For details of after sales service contact your dealer or Nilfisk service representative responsible for
your country. See reverse of this document.
2.0 Warranty
Our general conditions of business are applicable with regard to the guarantee.
Unauthorised modifications to the appliance, the use of incorrect brushes in addition to using the ap-
pliance in a way other than for the intended purpose exempt the manufacturer from any liability for
the resulting damage.
As specified in European Directive 2012/19/EU on old electrical and electronic appliances, used
electrical goods must be collected separately and recycled ecologically. Contact your local au-
thorities or your nearest dealer for further information.

1)OEL=Occupational Exposure Limit
Original instruction
9
2.1 Spare parts and accessories
CAUTION
Spare parts and accessories.
The use of non-genuine spare parts, brushes and accesso-
ries can impair the safety and or function of the appliance.
Only use original spare parts and accessories from Nilfisk.
Spare parts that can affect health and safety of the operator and
or function of the appliance, are specified below:
Description Order No.
Filter, polyester 1 pcs. 62348600
Filter, cotton 1 pcs. 61543000
Dust bag, fleece 5 pcs. 107418525
Dust bag, paper 5 pcs. 81620000
Motor protection filter, 1 pcs. 11730410
Exhaust micro-static filter, 2 pcs. 11641000
Specifications
GM 80P
100 V
GM 80P
110-120 V
GM 80P
110-120 V
GM 80P
220-240 V
GM 80P LC
220-240 V
Rated power W
HP 850 1100
1.48 1100 1.48 1200 1200
Protection class
(electrical) I II I ll ll
Max. airflow
l/s
m3/h
CFM
33
120
70
38
137
81
38
137
81
38
137
81
38
137
81
Max. vacuum
kPa
hPa
inH2O
18
180
72
20
209
84
20
209
84
27
270
108
27
270
108
Sound pressure level LPA
(IEC 60335-2-69) dB(A) 66 ± 2 66 ± 2 66 ± 2 66 ± 2 66 ± 2
Vibration ISO 5349 ahm/s2 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5 ≤ 2,5
Sack filter, surface area m/s22100 2100 2100 2100 2100
Dust bag capacity litres L 6,25 6,25 6,25 6,25 6,25
Weight kg
lb 8
21 8 21 8 21 8 21 8 21
Dust Class - - - - L
Specifications and details are subject to change without prior notice.

1)OEL=Occupational Exposure Limit
Original instruction
10
EU Declaration of Conformity
Nilfi sk A/S
Kornmarksvej 1
DK-2605 Broendby
DENMARK
Hereby solely declare, that the:
Products
VAC - Industrial - Dry
Description 220-240V, 50/60Hz, IPX0
Type
GM 80P, GM 80P LC
Are in compliance with the following standards:
EN 60335-1:2012+A11:2014
EN 60335-2-69:2012
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Following the provisions of:
2006/42/EC
2014/30/EU
Hadsund 31-3-2017
Anton Sørensen
Senior Vice President – Global Operations

HEAD QUARTER
DENMARK
Nilfi sk A/S
Kornmarksvej 1
DK-2605 Broendby
Tel.: [phone]
www.nilfi sk.com
SALES COMPANIES
ARGENTINA
Nilfi sk srl.
Edifi cio Central Park
Herrera 1855, 6th fl oor/604
Ciudad de Buenos Aires
Tel.: [phone]
www.nilfi sk.com.ar
AUSTRALIA
Nilfi sk Pty Ltd
Unit 1/13 Bessemer Street
Blacktown NSW 2148
Tel.: [phone]
www.nilfi sk.com.au
AUSTRIA
Nilfi sk GmbH
Metzgerstrasse 68
5101 Bergheim bei Salzburg
Tel.: [phone]
www.nilfi sk.at
BELGIUM
Nilfi sk n.v-s.a.
Riverside Business Park
Boulevard Internationalelaan 55
Bâtiment C3/C4 Gebouw
Bruxelles 1070
Tel.: [phone]
www.nilfi sk.be
BRAZIL
Nilfi sk do Brasil
Av. Eng. Luis Carlos Berrini, 550
40 Andar, Sala 03
SP - 04571-000 Sao Paulo
Tel.: [phone]
www.nilfi sk.com.br
CANADA
Nilfi sk Canada Company
240 Superior Boulevard
Mississauga, Ontario L5T 2L2
Tel.: [phone]
www.nilfi sk.ca
CHILE
Nilfi sk S.A. (Comercial KCS Ltda)
Salar de Llamara 822
8320000 Santiago
Tel.: [phone]
www.nilfi sk.cl
CHINA
Nilfi sk
4189 Yindu Road
Xinzhuang Industrial Park
201108 Shanghai
Tel.: [phone]
www.nilfi sk.cn
CZECH REPUBLIC
Nilfi sk s.r.o.
VGP Park Horní Počernice
Do Čertous 1/2658
193 00 Praha 9
Tel.: [phone]
www.nilfi sk.cz
DENMARK
Nilfi sk Danmark A/S
Industrivej 1
Hadsund, DK-9560
Tel.: [phone]
www.nilfi sk.dk
FINLAND
Nilfi sk Oy Ab
Koskelontie 23 E
02920 Espoo
Tel.: [phone]
www.nilfi sk.fi
FRANCE
Nilfi sk SAS
26 Avenue de la Baltique
Villebon sur Yvette
91978 Courtabouef Cedex
Tel.: [phone]
www.nilfi sk.fr
GERMANY
Nilfi sk GmbH
Guido-Oberdorfer-Straße 2-10
89287 Bellenberg
Tel.: (+49) (0)7306/72-444
www.nilfi sk.de
GREECE
Nilfi sk A.E.
Αναπαύσεως 29
Κορωπί Τ.Κ. 194 00
Tel.: [phone]
www.nilfi sk.gr
HOLLAND
Nilfi sk B.V.
Versterkerstraat 5
1322 AN Almere
Tel.: [phone]
www.nilfi sk.nl
HONG KONG
Nilfi sk Ltd.
2001 HK Worsted Mills
Industrial Building
31-39, Wo Tong Tsui St.
Kwai Chung, N.T.
Tel.: [phone]
www.nilfi sk.com
HUNGARY
Nilfi sk Kft.
II. Rákóczi Ferenc út 10
2310 Szigetszentmiklós-Lakihegy
Tel.: [phone]
www.nilfi sk.hu
INDIA
Nilfi sk India Limited
Pramukh Plaza, ‘B’ Wing, 4th fl oor, Unit
No. 403
Cardinal Gracious Road, Chakala
Andheri (East) Mumbai 400 099
Tel.: [phone]
www.nilfi sk.in
IRELAND
Nilfi sk
1 Stokes Place
St. Stephen’s Green
Dublin 2
Tel.: [phone]
www.nilfi sk.ie
ITALY
Nilfi sk SpA
Strada Comunale della Braglia, 18
26862 Guardamiglio (LO)
Tel.: (+39) (0) 377 414021
www.nilfi sk.it
JAPAN
Nilfi sk Inc.
1-6-6 Kita-shinyokohama, Kouhoku-ku
Yokohama, 223-0059
Tel.: [phone]
www.nilfi sk.com
MALAYSIA
Nilfi sk Sdn Bhd
Sd 33, Jalan KIP 10
Taman Perindustrian KIP
Sri Damansara
52200 Kuala Lumpur
Tel.: [phone]
www.nilfi sk.com
MEXICO
Nilfi sk de Mexico, S. de R.L. de C.V.
Pirineos #515 Int.
60-70 Microparque
Industrial WSantiago
76120 Queretaro
Tel.: (+52) (442) 427 77 00
www.nilfi sk.com
NEW ZEALAND
Nilfi sk Limited
Suite F, Building E
42 Tawa Drive
0632 Albany Auckland
Tel.: [phone]
Website: www.nilfi sk.com
NORWAY
Nilfi sk AS
Bjørnerudveien 24
1266 Oslo
Tel.: [phone]
www.nilfi sk.no
PERU
Nilfi sk S.A.C.
Calle Boulevard 162, Of. 703, Lima 33-
Perú
Lima
Tel.: [phone]
www.nilfi sk.com
POLAND
Nilfi sk Sp. Z.O.O.
Millenium Logistic Park
ul. 3 Maja 8, Bud. B4
05-800 Pruszków
Tel.: [phone]
www.nilfi sk.pl
PORTUGAL
Nilfi sk Lda.
Sintra Business Park
Zona Industrial Da Abrunheira
Edifi cio 1, 1° A
P2710-089 Sintra
Tel.: [phone]
www.nilfi sk.pt
RUSSIA
Nilfi sk LLC
Vyatskaya str. 27, bld. 7/1st
127015 Moscow
Tel.: [phone]
www.nilfi sk.ru
SINGAPORE
Den-Sin
22 Tuas Avenue 2
639453 Singapore
Tel.: [phone]
www.densin.com
SLOVAKIA
Nilfi sk s.r.o.
Bancíkovej 1/A
SK-821 03 Bratislava
Tel.: [phone]
www.nilfi sk.sk
SOUTH AFRICA
Nilfi sk (Pty) Ltd
Kimbult Offi ce Park
9 Zeiss Road
Laser Park
Honeydew
Johannesburg
Tel: [phone]
www.nilfi sk.co.za
SOUTH KOREA
Nilfi sk Korea
3F Duksoo B/D, 317-15
Sungsoo-Dong 2Ga
Sungdong-Gu, Seoul
Tel.: [phone]
www.nilfi sk.co.kr
SPAIN
Nilfi sk S.A.
Torre d’Ara,
Passeig del Rengle, 5 Plta. 10a
08302 Mataró
Tel.: [phone]
www.nilfi sk.es
SWEDEN
Nilfi sk AB
Taljegårdsgatan 4
431 53 Mölndal
Tel.: [phone]
www.nilfi sk.se
SWITZERLAND
Nilfi sk AG
Ringstrasse 19
Kircheberg/Industri Stelz
9500 Wil
Tel.: [phone]
www.nilfi sk.ch
TAIWAN
Nilfi sk Ltd
Taiwan Branch (H.K)
No. 5, Wan Fang Road
Taipei
Tel.: [phone]
www.nilfi sk.tw
THAILAND
Nilfi sk Co. Ltd.
89 Soi Chokechai-Ruammitr
Viphavadee-Rangsit Road
Ladyao, Jatuchak, Bangkok 10900
Tel.: [phone]
www.nilfi sk.co.th
TURKEY
Nilfi sk A.S.
Serifali Mh. Bayraktar Bulv. Sehit Sk. No:7
Ümraniye, 34775 Istanbul
Tel.: [phone]
www.nilfi sk.com.tr
UNITED ARAB EMIRATES
Nilfi sk Middle East Branch
SAIF-Zone
P.O. Box 122298
Sharjah
Tel.: (+971) (0) 655-78813
www.nilfi sk.com
UNITED KINGDOM
Nilfi sk Ltd.
Nilfi sk House, Bowerbank Way
Gilwilly Industrial Estate, Penrith
Cumbria CA11 9BQ
Tel: (+44) (0) 1768 868995
www.nilfi sk.co.uk
UNITED STATES
Nilfi sk, Inc.
9435 Winnetka Ave N,
Brooklyn Park
MN- 55445
www.nilfi sk.com
VIETNAM
Nilfi sk Vietnam
No. 51 Doc Ngu Str.
P. Vinh Phúc, Q.Ba Dinh
Hanoi
Tel.: [phone]
www.nilfi sk.com
