Nilox DOC ECO 3 User manual

1
DOC ECO 3
EN

2
USER MANUAL
Thank you for purchasing a NILOX DOC ECO 3 electric scooter.
Please read this manual carefully before using the product and store it in a safe place for
future reference.

3
1. Introduction
This product is a foldable assisted electric scooter. It can accelerate by being pushed and
decelerate using the foot brake or the brake on the handlebars.
2. Introduction to product parts
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Morsetto serraggio
Bell
Handlebars
e-Brake
Handle grip clip
Quick release clamp
Front light
Steering column
Battery level indicator
Foot brake
Back light
Reflector
Motor
Kick stand
Mudguard
Suspension
Anti-skid pedal
Foldable Buckle

4
3. Warnings
- Only use the battery supplied.
- This is not a toy. This product should be used by adults or minors with AM licences.
- Check the current traffic regulations relating to scooters where the Doc Eco 3 is used.
- Ensure that all parts of the Doc Eco 3 are secured (for example that the screws on the
handlebars are tight)
- Always wear comfortable clothing that does not restrict movement and use personal
protection equipment: on hands/wrists, knees, head and elbows.
- Do not transport objects when riding the scooter
- When riding the scooter pay attention to other people and objects around you and keep a
safe distance
- Ensure that both feet are positioned correctly on the deck.
- We recommend not to accelerate or stop suddenly to avoid losing control of the scooter
- Do not do any stunts.
- Do not get on and off the scooter while it is moving.
- Respect the maximum rider weight requirement
- It is forbidden using the product in adverse weather conditions (for example rain, hail or
snow) to avoid damage to the electrical circuits or motor. In addition avoid using Doc Eco 3

5
on slippery surfaces or on gravel or sand. Do not get on and of the Doc Eco 3 on steep
paths or when going up or down hill.
- Do not use the Doc Eco 3 in temperatures below -5°.
- Do not use the Doc Eco 3 with the kick bar lowered.
- The foot brake may overheat in the event of prolonged use therefore do not touch it until it
has cooled down, likewise do not touch the motor after use.
- The Doc Eco 3 is intended to be used by only one person at a time.
- Using the Doc Eco 3 is not recommended for people with limited motor skills, those with
impaired psychological status or pregnant women.
- When using the Doc Eco 3 for the first time first try it in an open area away from dangers to
practice safely.
- Do not use in flammable environments.
- The manufacturer, importer and distributor are not liable for any damage caused to
persons or things in the event of improper use of the Doc Eco 3.
- Do not attempt to repair the product by yourself, in the event of malfunction contact your
dealer.
- Disconnect from the power supply before cleaning.
- To clean it wipe with a damp cloth or use a solution suitable for cleaning similar devices.
Do not immerse in water or try to clean it with jets of water.

6
- To preserve the battery, it must be charged every 30 days even if the Doc Eco 3 is not
used, otherwise the battery loses efficiency at the expense of autonomy.
- The maximum travel distance when charged can vary according to various factors such as
the rider’s weight, the gradient of the journey, surface characteristics and correct battery
maintenance.
3. Assembling the scooter
3.1 Loosen the
handle with your
hand and press
the release lever.
3.2 Open the
steering column,
press the foot plate
with your left foot to
stabilise it and lift
the steering
column.
3.3 Lock the clamp
to set the
handlebars.
3.4 Remove the handle
grips from the clips and
insert them into the fixed
part of the handlebars.
3.5 Adjust the height with
one hand, hold the T
column with the other
hand and clamp it into the
right position.
3.6 Close the clamp.

7
4. Folding the scooter
T The scooter must be assembled
according to the steps indicated
in the above diagrams.
Please ensure safety during
assembly.
4.1 Loosen the quick
release clamp
4.2 Push the button and
lower the steering
column as much as
possible
4.3 Remove the handle
grips from the
handlebars and attach
them to the clips.

8
5. Introduction on how to use it
Battery indicator
Battery capacity
"4 Bars"
Battery charged
"3 Bars”
Around 75%
"2 Bars”
Around 50%
“1 Bar”
Below 25% recharge the scooter.
With low battery level the scooter will emit a sound indicating that DOC Eco 3 must be
recharged.
Hold the handlebars with both hands and place one foot on the plate, push the other foot off
the ground to accelerate. Repeat again to accelerate further. To slow-down push the foot
brake at the back, take your foot off the brake when you reach the required speed, at this
time the scooter will return to the previous speed. To deactivate the motor use the e-brake.
4.4 Loosen the handle
4.5 Gently push the
steering coloumn
backwards until you hear
a click to fold.
4.6 Folded view of the
scooter.

9
6. Battery and charger
6.1. Lithium battery
Fully charge the battery when you first use the Doc Eco 3
6.1.1. When the battery is running low recharge it immediately to avoid damaging it and
limiting autonomy.
6.1.2. If the scooter is not used for a long time, charge it at least once a month.
6.1.3. If the battery capacity is lower than the protection status and the scoter does not
work contact your dealer immediately.
6.2. Recharging
The battery charger supplied has a charging protection function. Power is automatically cut
off when the battery is 100% charged. Damage caused by water, collisions and other factors
are not covered by the warranty.
6.2.1. Open the rubber cover on the charging port on the lower part of the foot plate
of the scooter and insert the power input connector into the charging port.
6.2.2. Insert the charger input plug into the power outlet (AC100V-240V ).
6.2.3. . If the indicator on the charger is red the battery is charging; when it turns
green the battery is fully charged.
6.2.4. When charging the battery always place it in a dry and ventilated place.
7. Care and Maintenance
Lubrification: a small quantity of white grease or lubricant must be applied to the steering
column folding mechanism every three months.
Wheels: this product is fitted with solid wheels. If a wheel needs to be replaced due to
obvious wear or damage, please contact the service centre to replace it with an original one.
Always check the wheels are tightened.
Positioning and daily care:
Do not leave the scooter in the sun or in humid places for long periods; clean it with a dry or
damp cloth.
l
3
4
5

10
8. Doc Eco 3 Parameters
Model
Doc Eco 3
Dimensions
860*320*135 mm when folded
Weight
7.9 K g
Frame material
Aluminium
Wheel dimensions
8”
Colour
Back, Grey, Camo
Engine Power
150 W
Maximum speed*
12 Km/h
Maximum autonomy*
10 km
Maximum gradient
5°
Battery Capacity
21.6 V 2500 m Ah
Recharge parameters
Input 100-240V - 25.2 V 1 A
Recharge time
3-4 hours
Maxim Rider Weight
100 Kg
•Rider weight of 60 kg
9. Warranty (Validity and Limitations)
- The warranty validity period for consumers, i.e. those that purchase items for purposes
unrelated to their professional or business activity. For those that purchase items using a
VAT Code for purposes related to their professional activity, the legal assurances provided 1
year from delivery as the law states.
- The warranty is valid in the event the product has a material or manufacturing defect.
Consumers are not entitled to the warranty in the following cases:
- lack of proof of purchase (invoice or receipt).
- attempts to repair parts and/or changes carried out by unauthorised parties
- using accessories or items that are not supplied with the product;
- normal wear and tear of the product;

11
- accidental damage and falls;
- improper use of the product
10. Package contents
Accessory
Quantity
Doc Eco 3
1
Power supply
1
Manual
1
Front and back
lights
1
Key
1
Note: The performance and parameters of the product supplied are subject to change
without notice. The company reserves the right to the final interpretation of all terms and
conditions in this manual.
ENVIRONMENTAL INFORMATION
This product may contain substances that can be harmful to the environment and
human health if not disposed of properly. We therefore provide you with the following
information to prevent the release of such substances and to optimize the use of natural
resources. The electrical and electronic components should not be disposed of in the
normal household waste but should be properly and correctly collected and treated. The
crossed-out wheelie bin symbol on the product and on this page indicates the need to
properly dispose of the product at the end of its lifespan. In this way you can avoid
non-specific treatment of the substances contained in these products, or improper use of
parts of these which can have harmful consequences for the environment and human
health. Moreover, you can contribute to the recovery, recycling and reuse of many of the
materials in these products. This is why the manufacturers and distributors of Electrical and
Electronic Equipment (EEE) organize proper collection and disposal of the equipment
themselves. At the end of the product’s lifespan, please contact your dealer for instructions

12
regarding disposal. When purchasing this product your distributor will inform you of the
possibility to replace your old device with a new one, on condition that the type of product
and its functions are the same. If the dimensions are not over 25 cm, the EEE (Electrical
and Electronic Equipment) can be returned without any equivalent product purchase
obligation. Disposal of the product in any other way will be liable to the penalties provided
by the laws in force in the country where the product is disposed of. Moreover, we suggest
the following measures to protect the environment: recycling the inner and outer packaging
supplied with the product and disposing of used batteries (if contained in the product)
correctly. With your help, we can reduce the amount of natural resources used in the
manufacture of EEE (Electrical and Electronic Equipment), minimize use of landfills for
product disposal and improve quality of life by preventing the release of potentially
dangerous substances into the environment.
BATTERY INSTALLATION AND REPLACEMENT
The product contains a battery that could be replaced during the lifespan of the
product itself. Dispose of the battery contained in the product correctly at the end of its
lifespan (for instance when it can no longer be charged) by placing it in an appropriate
battery disposal container separate from the generic unsorted waste. Collection and
recycling of batteries helps protect the environment and preserve natural resources,
allowing recovery of valuable materials.

13
Distribuited by Nilox
Produced and imported by
Exhibo S.p.A. via Leonardo da Vinci 6
20854-Vedano al Lambro (MB) ITALIA
Made in China

1
DOC ECO 3
IT

2
MANUALE D’USO
Vi ringraziamo per l’acquisto del monopattino elettrico NILOX DOC ECO 3.
Vi preghiamo di leggere il manuale prima dell’utilizzo del prodotto e di mantenerlo in un
luogo sicuro per future consultazioni.
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.

3
1.Introduzione
Questo prodotto è un monopattino elettrico pieghevole assistito. Può implementare
l'accelerazione tramite spinta e la decelerazione attraverso il freno a piede o tramite
l’interruttore posto sul manubrio.
2.Introduzione delle parti del prodotto
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Please read this manual carefully before using S11 electric power assisted booster.
Beginners should first practice in the open area to grasp kinetic energy of the
vehicle and riding skills before riding on the road.
Manubrio
Staffa reggi manopola
Campanello
Manubrio
e-Brake
Reggi manopola
Morsetto sgancio rapido
Luce anteriore
Stelo manubrio
Indicatore livello batteria
batteria
Freno
Luce posteriore
Catarifrangente
Motore
Cavalletto
Parafango
Ammortizzatore
Fibbia pieghevole
Pedana antiscivolo

4
3. Avvertenze
- Utilizzare solo l’alimentatore fornito in dotazione.
- Questo prodotto non è un giocattolo.
- Controllare le normative vigenti sulla circolazione dei monopattini del paese in cui si
utilizza Doc Eco 3
- Nelle aree pedonali non è possibile superare i 6 Km/h di velocità.
- Verificare che tutti i componenti del Doc Eco 3 siano fissati (ad esempio viti manubrio
siano ben salde)
- Utilizzare sempre un abbigliamento che non sia di intralcio ai movimenti e utilizzare
attrezzature di protezione personale: per le mani/polsi, per le ginocchia, per la testa e per i
gomiti.
- Non trasportare oggetti durante l’utilizzo del monopattino.
- Durante la guida prestare attenzione alle altre persone e agli oggetti intorno e mantenere
un’adeguata distanza di sicurezza
- Assicurarsi che entrambi i piedi siano posizionati correttamente sulla pedana.
- Si consiglia di non accelerare e di non arrestare il veicolo in maniera improvvisa in modo
da evitare la perdita del controllo del monopattino.
- Non eseguire acrobazie.

5
- Non salire e scendere dal monopattino mentre è in movimento.
- Rispettare il peso massimo previsto per l’utilizzatore.
- Evitare l’utilizzo del prodotto in presenza di condizioni atmosferiche avverse ( ad esempio
pioggia, grandine o neve) per evitare danni ai circuiti elettrici o al motore. Inoltre evitare
l’utilizzo di Doc Eco 3 su superfici con presenza di ghiaia, sabbia o scivolose. Non salire o
scendere da Doc Eco 3 in percorsi scoscesi, in discesa o in salita.
- In caso di scarsa visibilità è necessario accendere le luci anteriori e posteriori ed utilizzare
un abbigliamento retroriflettente ad alta visibilità.
- Non usare Doc Eco 3 con temperature al di sotto dei -5°.
- Non usare Doc Eco 3 con il cavalletto laterale abbassato.
- Il freno a pedale potrebbe surriscaldarsi in caso di uso prolungato per cui non toccarlo con
le mani fino a quando non si sia raffreddato, così come il motore non va toccato appena
dopo il suo l’utilizzo.
- E’ vietato salire su Doc Eco 3 in più persone.
- L’uso di Doc Eco 3 è vietato a persone con abilità motorie limitate, a persone con stato
psicofisico alterato e a donne in gravidanza.
- In caso di primo utilizzo provare Doc Eco 3 in un’area aperta lontano da pericoli per fare
pratica in tutta sicurezza.
- Non usare in ambienti infiammabili.

6
- Il produttore, l’importatore ed il distributore non sono responsabili di danni provocati a
cose o persone in caso di un uso improprio di Doc Eco 3.
- Non provare a riparare il prodotto da soli, ma, in caso di malfunzionamento contattare il
rivenditore.
- Prima della pulizia scollegate l’alimentazione
- Per la pulizia utilizzare un panno appena inumidito con acqua o con una soluzione adatta
alla pulizia di simili dispositivi. Non immergerlo in acqua o cercare di pulirlo con getti di
acqua.
- Per preservare la batteria, questa deve essere caricata ogni 30 giorni anche se Doc Eco 3
non viene utilizzato. In caso contrario la batteria perderà di efficienza a scapito
dell’autonomia.
- La distanza massima percorsa con una carica può variare in base a determinati fattori
quali il peso del conducente, l’inclinazione del percorso, le caratteristiche della superficie e
la corretta manutenzione della batteria
3. Aprire il monopattino
3.1. Allentare con
la mano la
maniglia e
premere la leva di
sblocco.
3.2 Aprire l'asta.
Premere la pedana
con il piede sinistro
per stabilizzarlo e
sollevare lo stelo
con le mani.
3.3.Bloccare la
maniglia per
fissare il manubrio.
