Ninja 3000 Series User manual

www.Ninjapaintball.com
1
NINJA AIR SYSTEMS
Proudly Made in the USA
Series 3000 PCP FILL STATION
SAFETY FIRST!
FOR 3000 PSI MAXIMUM SERVICE
Date: February 2013
KEEP ALL PETROLEUM LUBRICANTS AWAY FROM PARTS OF THE PCP
FILL ADAPTER. PETROLEUM LUBRICANTS MAY CAUSE FIRE OR
EXPLOSION IF INTRODUCED INTO THE HIGH PRESSURE TUBE OF YOUR
PCP AIRGUN.
PRIOR TO USE READ AND UNDERSTAND ALL FILL STATION
INSTRUCTIONS.

www.Ninjapaintball.com
2
SETTING UP THE NINJA PCP FILL ADAPTER
Your fill adapter is equipped with a standard “UFA” fitting on the input side. This
fitting will connect to any Ninja high pressure regulator.
On the backside of the fill station is a vent port.
▲FOR SAFETY REASONS, THE VENT PORT #7 MUST BE
DIRECTED AWAY FROM THE OPERATOR AND BYSTANDERS.
This port is equipped with 1/8 NPT threads so that if desired, a vent hose or
muffler may be attached.
Do not over tighten the vent knob as this may damage the
seal. Only turn the knob enough to stop the release of gas.
▲ALL HOSE, FITTINGS, AND MUFFLERS MUST HAVE A
MINIMUM WORKING PRESSURE OF 3000 PSI. Do not use a
bronze sintered muffler!!
▲Never operate the PCP Fill Adapter unless a PCP AIR RIFLE is
attached to the fill adapter on the end of the fill hose. Operating
the PCP Fill Adapter without a PCP AIR RIFLE attached will
cause the fill hose to “whip”. Injury may result!!
Date: February 2013
WARNING: Compressed air will rush out of the vent station hole (part #7) when
relieving pressure from the fill hose. Use caution in directing the venting air.
ALWAYS WEAR GLOVES AND SAFETY GLASSES WHEN OPERATING THIS
FILL STATION!!
WARNING: Do NOT disconnect the hose under pressure. Disconnecting the hose
under pressure could cause damage to the hose fitting and personal injury to the
operator.

www.Ninjapaintball.com
3
1.0 OPERATION with a HIGH PRESSURE COMPRESSED AIR BOTTLE
THIS FILL ADAPTER WILL VENT GASES STORED UNDER HIGH
PRESSURE MAKE CERTAIN THE VALVE VENT KNOB (part #5) IS
CLOSED (turned fully clockwise) BEFORE CONNECTING TO A HIGH
PRESSURE COMPRESSED AIR BOTTLE!
1.1 Close the vent station (part #4) by turning the vent knob (part #5) fully in a clockwise direction, do
not over tighten.
1.2 Turn the knob on the UFA (part #2) counter clockwise until it stops. Screw the UFA onto the High
Pressure Air bottle regulator making certain all components are clean and dry. Tighten securely by
hand ONLY. Do NOT use tools to tighten.
1.3 Ensure the air rifle you are filling has a 1/8 male Industrial Interchange quick disconnect, see
figure 1.4a. Pull the sleeve/collar back on the quick disconnect #6 and Connect the fill station
female quick disconnect socket (part #6) to the fill nipple on your PCP air gun. THE SLEEVE
/COLLAR MUST SNAP FORWARD AND BE SECURE! Do not force it on and if it does not fit
properly do not fill. See figure 1.4c.
1.4 MAKE SURE CONNECTION IS SECURE.

www.Ninjapaintball.com
4
1.5 Once attached do not let the fill station, air system or rifle hang by any component. Support the fill
station, rifle and air system.
1.6 Open the valve slowly by turning the UFA knob (part# 2) in a clockwise direction. You should
hear the air gun filling with air. A complete fill should take no more than approximately 10
seconds. Fill the air gun to manufacturer recommendation.
1.7 Check the air gun pressure gauge. The gauge should read a pressure equal to the output pressure of
the bottle regulator pressure you are filling from, typically 3000 psi. Do not over pressurize the
rifle, check the rifle owner’s manual for the correct pressure.
1.8 Upon Completion of filling, turn the UFA knob (part # 2) in a counter-clockwise direction until it
stops.
1.9 Bleed the pressure from the fill hose by turning the vent station knob (part # 5) slowly in a
counter-clockwise direction.
1.10 Disconnect the quick disconnect from the gun, if it does not open easily insure the fill station
is vented and no air is in the fill station.
1.11 Disconnect the UFA from the High Pressure Air bottle regulator.
3.0Maintenance and Care of the Ninja PCP Fill Adapter
Keep the Fill Adapter clean and dry.
Periodically check the fill adapter and fill hose for thread integrity, cracks or other wear
replace any suspect part immediately for assistance call 877-646-5287
www.ninjapaintball.com
Date: February 2013
WARNING: Do NOT disconnect the hose under pressure. Disconnecting the
hose under pressure could cause damage to the hose fitting and personal
injury to the operator.
WARNING: Compressed air will rush out of the vent station hole (part #7)
when relieving pressure from the fill hose. Use caution in directing the venting
air. ALWAYS WEAR GLOVES AND SAFETY GLASSES WHEN
OPERATING THIS FILL STATION!!
