Nitto Kohki SH-100A User manual

PNEUMATIC RECIPROCATING FILE
Please read this manual carefully before you attempt to use
your tool so that you may use it properly and safely.
SUPER HAND Model SH-100A
PROFESSIONAL TOOL
Due to continuous product development/improvement the specifications and configurations in this
document are subject to change without prior notice.
Manufactured by :
NITTO KOHKI Co., Ltd.
2-9-4, Nakaikegami, Ohta-ku,
Tokyo, 146-8555, Japan
TEL : [phone]
FAX : [phone]
E-mail : [email protected]
URL : www.nitto-kohki.co.jp
Keep the manual handy – so you can use it whenever necessary.
Specifications
Model SH-100A
Maximum Operating Pressure 0.6 MPa
Air Consumption (No Load) 0.24 m3/min
Stroke Speed (No Load) 3,700 min-1
Stroke Length 9 mm
Shank Dia. 6 mm
Mass (Weight) 1.1 kg
Sound Pressure Level 76 dB (A)
Sound Power Level 87 dB (A)
Vibration Level [Uncertainty K] 6.8 m/s2[2.5 m/s2]
Thread Size of Inlet Rc1/4
Original Instructions
TQ12692-1

1
The following Safety notations are used throughout the manual to highlight safety precautions for the user and for
the tool.
Warning: Indicates a potentially hazardous situation which, if not avoided by following the
instructions given, could result in death or serious injury.
Caution: Indicates a potentially hazardous situation which, if not avoided by following the
instructions given, could result in injury or material damage.
Please note, however, that failure to observe safety precautions under the “ Caution” category could result in a
serious occurrence depending on the situation: please observe all safety precautions in the manual.
Caution: Important precautions for tool setup, operation and maintenance.
Thank you very much for your purchase of this
Nitto Kohki products.
Before using your tool, please read this manual
carefully so that you may use it properly to get
the most out of it.
Please keep the manual handy - so you can
use it whenever necessary.
・English : Please ask your dealer or
distributor for instruction manual
in local language(s).
・German : Bitte fragen Sie lhren Händler
nach eine Betriebsanleitung in
Landessprache.
・French : S'il vousplait, veuillez demandez
á votre foumisseur de manuel
instruction en langue locale.
・Spanish : Por favor, cantacte con su
distribuidor para el manual de
instrucciones en español.
・Portuguese : Por favor pessa ao seo agente
ou distribuidor o manual de
instrucces ih linguagen local.
・Italian : Per Manuale Istruzioni in lingua
locale Vi preghiamo di rivolgervi
al rivenditore o distributore.
・Dutch : Vraag uw handelaar
om een nederladstalige
gebruiksaanwijzing.
・Swedish : Be er lokala Åtreförsäljare eller
distributör om manualer pá
svenska.
・Danish : Venligst henvend Dem til den
danske distributør for instructions
manualer.
・Polish : Prosze pytac swojego dealera
lub dystrybutora o instrukcje
obslugi w jezyku localnym.
・中文 :請向當地供應商或経銷商詢問中
文使用説明書
CONTENTS page
IMPORTANT SAFETY INSTRUCTIONS …………………… 2
GENERAL: TOOLS ……………………………………………2
GENERAL: PNEUMATIC TOOLS …………………………3
INSTRUCTIONS FOR THIS TOOL …………………………4
1. USAGE ………………………………………………………4
2. CHECK THE CONTENTS OF THE PACKAGE ………… 4
3. AIR SUPPLY ………………………………………………5
4. MOUNTING FILES …………………………………………5
5. HOW TO OPERATE THE TOOL …………………………5
6. STORAGE …………………………………………………5
7. THREAD SIZE OF HOSE FITTING ………………………6
8. OPTIONAL PARTS ………………………………………… 6
9. ORDERING SERVICE PARTS ……………………………6
PICTOGRAPH
Warning: It might be dangerous to operate the tool if
the instructions supplied are not followed.
Using this tool improperly could result in serious injury.
Read the instruction manual before using.
Always wear suitable eye protection.
Always wear suitable hearing protection.
Always wear respiratory protective equipment (PPE).

2
IMPORTANT SAFETY
INSTRUCTIONS
When using the tool, please observe the safety
precautions below to prevent possible accident or
injury.
GENERAL: TOOLS
Warning
TO OPERATORS
●Wear proper clothing for the type of work being
done.
Take care so that clothing, ties, hair, etc. will not
become entangled with the moving parts. If items
become entangled it will cause the operator to be
pulled towards the tool and lead to possible cause of
accident or injury.
●Always wear suitable eye protection.
Remember, regular glasses are not safety glasses.
The lenses are only shock resistant, which will not
give you sufficient eye protection you may need in
your working environment.
●Always wear suitable hearing protection.
●Wear respiratory protective equipment (PPE).
Wear respiratory protective equipment (PPE) when
working in an environment where dust particles are
generated in operation.
●Always wear protective gloves for protection of
hands from vibration and shock.
●Avoid working posture that is too stressful.
Always ensure a firm footing and well balanced
posture.
●Do not operate the tool if you are too tired.
●Never touch any moving parts of the tool when
running.
ABOUT WORK AREA
●Keep the work area clean.
Cluttered work areas (e.g. workbench) invite
accidents.
●Carefully select the work area.
Do not expose tool to rain.
Do not use tool in a wet or soaked area.
See that the work area is adequately illuminated.
●Never work near inflammable liquid or in a
potentially explosive atmosphere.
●Keep children away from the work area.
Keep children and unauthorized people away from
the work area to avoid accident or injury.
BEFORE OPERATION
●Inspect tool before use.
Before using, check that screws are securely
tightened, that any protective cover or guard is
securely in place, other parts are free from damage
and that the tool runs as it should.
Check that moving parts are properly adjusted for
positioning and tightened, that parts are free from
damage and properly mounted, and that all other
parts are in good condition for normal operation.
Should you find any damage to the protective
cover or other part, replace it in accordance with
the Operation Manual. If there are no instructions
in the Manual, please contact the sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
Likewise, if a switch failure occurs, contact sales
agent through which you have purchased your tool
or an authorized dealer near you for repair.
Do not use the tool if it does not start or stop with
the start/stop switch.
●Securely mount cutter
An improperly mounted cutter may fly out, causing
possible damage to the tool or injury to the operator.
●Always remove spanner, wrench, etc., once
adjustment has been made with them.
●Use a tool appropriate for the application.
Avoid heavy-duty application that is beyond the
capacity of tool.
●Do not use the tool for purposes other than what
it is designed for.
●Do not abuse tool.
Use tool in accordance with the specifications: you’ll
get the most out of it while ensuring safety.
●Securely fasten workpiece in place.
Use a viceor clamp tosecurely fasten the workpiece
in place. It is much safer this way than holding it in
your hand, allowing you to operate the tool with both
hands.
ABOUT HANDLING
●How to store tool.
When the tool is not used, store it in a dry area and
out of reach of children.
●How to carry tool.
Do not touch the start switch while the tool is being
carried.
●Do not leave the tool unattended while it is
running.
Turn off the start switch and disconnect the tool from

3
power source. Do not leave the work area until the
tool comes to a complete stop.
MAINTENANCE/SERVICE
●Do not take apart or modify tool.
Disassembly or modification carried out without
the supervision of a qualified or authorized service
engineer could result in an accident or injury.
●Inspect cutting tool and accessories, etc.
Always check to see that cutting tool and
accessories, etc. are in good operating condition
without damage or deterioration before you mount
them on the tool. Should you find any damage to
an accessory or part, please contact sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
●Check parts for damage.
When you have found damage to accessory or other
part, carefully check the damaged part to determine
the extent of influence it has upon the functions
of the tool – that is, determine whether it can still
perform its normal functions.
Check to see that the linkage of the moving parts
is OK, that all parts are OK without damage,
that they are properly mounted, and that the tool
functions normally. Should you find any damage
to an accessory or part that may hamper proper
functioning of the tool, please contact sales agent
through which you have purchased your tool or an
authorized dealer near you for repair.
●Have your tool repaired at an authorized Nitto
Service Center.
For repair or parts replacement, please contact the
sales agent through which you have purchased your
tool or an authorized dealer near you.
●Use only Nitto genuine parts.
Use of improperpartsmay result in seriousaccident.
To obtain a Nitto genuine part, consult this Manual
or contact the sales agent from which you have
purchased your tool directly.
●Do not detach label or nameplate from tool.
When a label/nameplate gets damaged, worn or
becomes missing, contact the sales agent through
which you have purchased your tool or Nitto Kohki
Co. Ltd, directly for a replacement.
DISPOSAL
When a tool is taken permanently out of service, it is
advised that the tool is disassembled, degreased and
parts separated by material and recycled locally in the
appropriate manner.
GENERAL: PNEUMATIC
TOOLS
Warning
●Use appropriate air pressure.
Excessively high air pressure will increase the
number of revolutions or strokes causing not only
potential premature failure/breakage but could also
lead to an unexpected accident or injury.
●Connect tool to air supply line.
There are various types of pipes running in a factory
in addition to the pneumatic line (such as oxygen,
nitrogen, gas and water). For this reason, always
ensure that you are connecting to the pneumatic
line.
●Start tool properly.
Turn the start switch OFF before connecting to the
air supply line.
●Always disconnect the tool from the air supply
line before putting on/taking off any accessory
and prior to carrying out any maintenance work.
●Avoid exposure to exhaust air.
Pneumatic tool exhaust air contains oil and
contaminated moisture. Make sure the exhaust air is
not directed towards your face or anyone else within
the work area.
●Keep tool off electricity.
This pneumatic tool is not electrically insulated. To
avoid a potential electric shock do not use where
there is a possibility of coming into contact with live
electricity.
Caution
●Handle tool carefully.
Abusive use of tool could invite failure or accident.
Do not throw, drop or shock the tool.
●Handle air hose carefully.
Do not carry the tool by the air hose.
Do not pull the air hose to disconnect.

4
INSTRUCTIONS FOR
THIS TOOL
About Your Tool
Warning
●Wear protective glasses and a dustproof mask
Operation generates chips and dust particles, etc.
which may cause eye and/or respiratory injury:
Always use PPE (Personal Protective Equipment) for
eye and respiratory protection.
●Wear vibration reducing and shock absorbing
gloves.
This is a power tool utilizing vibration. Wear vibration
reducing and shock absorbing gloves. When your
hands, fingers, arms, etc. feel discomfort during
operations, immediately stop your work. Long hour
operation should be prohibited, for it may cause
vibration-induced disorder.
Caution
●Insert tip tool shaft of tip tool into the holder as
deep as possible before using the tool.
Imperfect imsertion of the file shaft of tip tool not
only damages the main body but also causes tip tool
to jump out and may cause accidents.
●When you replace or adjust tip tool or any
component, be sure to detach the tool from the
air hose.
●Ne v er touc h tip m obile p o rtion while i n
operation.
1. USAGE
This tool is for filing workpieces using the exclusive
file.
2. CHECK THE CONTENTS OF THE PACKAGE
Check the contents and make sure that the tool does
not have any damage which may have occurred
during transportation. The contents should correspond
to the list as follows. In case of damage/missing
parts, please contact the sales agent from whom you
purchased the tool.
Package Contents Qty Check
SUPER HAND SH-100A 1set
Rat Tail File SF-10 1
Triangular Taper File SF-11 1
Half Round File (Rat Tail/Double Cut)
SF-12 1
Flat Bastard File SF-13 1
Hex. Socket Screw Key 3 1
Bushing R1/4×NPT1/4 1
Instruction Manual 1
Declaration of Conformity 1
Caution for Use 1
Rat tail File SF-10
Triangular Taper File SF-11
Half Round File SF-12

5
Flat Bastard File SF-13
Fig. 1
3. AIR SUPPLY
3-1.Air Pressure
Adjust air pressure with the air regulator to the level
appropriate for the pneumatic tool used.
Air pressure that is too low will fails the tool to
operate at full capacity.
Air pressure that is too high may cause damage to
the tool.
3-2. Air Line (Fig.2)
Use a 9.5mm (3/8”) I.D. connecting hose between
the compressor and the tool.
Drained water, etc., if flown into the tool, could
cause tool failure. Install an air filter. between the
compressor and the tool.
Air Regulator Oiler
Air Filter
Compressor
Lubrication
Tool 9.5mm (3/8”) I.D.
Hose
Cupla
Fig. 2
3-3. Lubrication
.lootehtdnarosserpmocehtneewtebrelionallatsnI
Use the machine oil ISO VG-10. Failure to lubricate
as required may result in damage to the tool. Use
of oil that is too thick will reduce the performance of
tool.
4. MOUNTING FILES
Warning
Always turn off the air supply and disconnect the air
supply hose.
To mount a file, loosen the Hex. Socket Set Screw,
insert the file shaft, and retighten the screw with the
Hex. Socket Screw Key until the file is securely fixed.
Fig. 3
5. HOW TO OPERATE THE TOOL
To start, push the slide switch forward to the “ON”
position. The tool may not start if the switch is pushed
forward gradually.
To stop, pull up the slide switch to the “OFF” position.
Fig. 4
6. STORAGE
Caution
When tool is not used, store it out of reach of
children.
Avoid storing the tool in a location subject to high
humidity. If the tool is left as it is used, residual
moisture on the inside can cause rusting. Before
storing, and after operation, oil the tool at the air inlet
with machine oil ISO VG-10 and run it for a short time.

6
7. THREAD SIZE OF HOSE FITTING
)cirtem(cRhtiwgnittfilatemahtiwsemoctcudorpehT
thread. Connect the Bushing R thread X NPT thread
included as standard accessories, if you would like to
have American NPT thread instead.
8. OPTIONAL PARTS
In addition to standard accessory parts, the following
parts are available for your applications and needs.
Part No. Description Qty
TA9A222 Rat Tail File SF-10 5pcs
TA9A223 Triangular Taper File SF-11 5pcs
TA9A224 Half Round File (Rat Tail / Double
Cut) SF-12 5pcs
TA9A225 Flat Bastard File SF-13 5pcs
TP00707 Diamond Tip, Round SDF-10 1
TP00708 Diamond Tip, Triangular SDF-11 1
TP00704 Diamond Tip, Flat Bastard SDF-12 1
TP00709 Diamond Tip, Half Round SDF-13 1
TA91752 Round Tip, Rubber Pad Ass’y 1
TA94625 Supporter Ass’y 1set
Fig. 5
9. ORDERING SERVICE PARTS
For further operational and handling information or
for replacement of parts and components, contact the
company from whom you purchased the tool or an
authorized dealer.
In ordering parts and components give each part
number, part name and quantity required.
Use only NITTO genuine parts.

Printed in JAPAN TQ12692-1
Overseas Affiliates / Offices
NITTO KOHKI U.S.A., INC.
46 Chancellor Drive, Roselle, IL 60172 U.S.A.
Tel:[phone] Fax:[phone]
NITTO KOHKI EUROPE CO., LTD.
Unit 21, The Empire Centre Imperial Way,
Watford Herts, WD24 4TS, U.K.
Tel:[phone] Fax:[phone]
NITTO KOHKI DEUTSCHLAND GMBH
Lerchenstr.47 D-71144 Steinenbronn, Germany
Tel:[phone] Fax:[phone]
NITTO KOHKI CO., LTD., SINGAPORE BRANCH
10 UBI CRESCENT #01-62,
UBI TECHPARK LOBBY D, SINGAPORE 408564,
Tel:[phone] Fax:[phone]
NITTO KOHKI CO., LTD.,
BANGKOK REPRESENTATIVE OFFICE
M&A Business Center 38Q. House Convent Bldg.,
7th Floor, Unit 7A, Convent Rd., Silom, Bangrak,
Bangkok 10500 Thailand
Tel:[phone] Fax:[phone]
NITTO KOHKI AUSTRALIA PTY. LTD.
77 Brandl St., Brisbane Technology Park,
Eight Mile Plains QLD 4113 Australia
Tel:[phone] Fax:[phone]
NITTO KOHKI (SHANGHAI) CO., LTD.
Room1506, suite C, Orient International Plaza,
NO85 LouShanGuan Road,Shanghai, 200336, CHINA
Tel: [phone] Fax:[phone]
NITTO KOHKI CO., LTD.,
SHENZHEN REPRESENTATIVE OFFICE
2005C Shenzhen ICC Tower, Fuhuasanlu 168, Futian District,
Shenzhen, Guangdong, 518048 China
Tel: [phone] Fax:[phone]
