Nivelco Thermocont tfp series User manual

tfp121en1804h



1 / 2

Thank you for choosing a NIVELCO instrument!

1. APPLICATION

Resistance thermometers are the fundamental elements of the industrial process control. The design of the

TFP−−resistance thermometer-family measures the temperature in industrial applications. Primarily, they

are used as sensors for heated tools and bearings. The sensor tip of the TFP−5 and TFP−6 types is made from

copper, to provide faster response time. The TFP−3 and TFP−4 have process connection with a suitable mounting

bolt. The TFP−1, TFP−2, TFP−5 and TFP−6 have different types of mounting bolts that are ordered separately. The

mounting bolts allow the sensors to be screwed into various threads.

2. TECHNICAL DATA

Type THERMOCONT TFP−−

Process temperature –50…+200 °C (–58…+392 °F)

Sensor Pt100

Accuracy class A or B (MSZ EN 60751), as per order codes

Measuring current max. 5 mA

Time constant (9 / 10) TFP−5, TFP−6: 35 sec.

TFP−1, TFP−2, TFP−3, TFP−4: 45 sec.

Housing material DIN 1.4571 stainless steel

Probe length (L) max. 250 mm (9.8"), as per order codes

Connection Teflon-coated wire, 0.35 mm2(AWG22); dual or 4-wire: 0.14 mm2(AWG26);

Cable protection Tinned copper-braid protective jacket

Cable length 0.6…12 m (2…40 feet), as per order codes

Mechanical protection IP54

Electrical protection Class III.

Weight Max. 0.6 kg (1.3 lb) (Depending on model)

2.1. ACCESSORIES

User’s manual

Warranty Card

EU Declaration of Conformity

2.2. ORDER CODES (NOT ALL COMBINATIONS POSSIBLE!)

THERMOCONT T F P – –

TUBE SIZE CODE SENSOR DESIGN CODE PROBE LENGTH CODE CABLE LENGTH CODE

6 1* Class A single 1 60 mm 1 0.6 m 0

8 2* Class B single 2 100 mm 2 1 m 1

M12x1.5 (8) 3 Class A dual 4** 160 mm 3 2 m 2

M8x1 (6) 4 Class B dual 5** 250 mm 4 3 m 3

6, fast response 5* Class B, single, 4-wire 6 10 mm*** 5 6 m 4

8, fast response 6* Class A, single, 4-wire 7 30 mm*** 6 12 m 5

* Mounting bolts are ordered separately

** Only with TFP-2, TFP-3, TFP-6 types

*** Only with TFP-3, TFP-4 types

Available mounting bolts (Material: DIN 1.4571 stainless steel)

Thread TFP−5−TFP−6−

M10 TFP−511−0M−000−01 –

M12 TFP−511−0M−000−02 TFP−611−0M−000−02

M12x1,5 TFP−511−0M−000−03 TFP−611−0M−000−03

M14x1 TFP−511−0M−000−04 TFP−611−0M−000−04

M20x1,5 TFP−511−0M−000−05 TFP−611−0M−000−05

⅛" TFP−511−0M−000−06 –

¼" TFP−511−0M−000−07 TFP−611−0M−000−07

⅜" TFP−511−0M−000−08 TFP−611−0M−000−08

½" TFP−511−0M−000−09 TFP−611−0M−000−09

2 / 2 tfp121en1804h

2.3. DIMENSIONS

TFP−1-(6)

TFP−2-(8)

TFP−3-(8)

TFP−5-(6)

TFP−6-(8)

TFP−4-(6)

Copper sensor tip

Mounting bolt

X Y ØZ

M10 7 6 –

M12 8 6 8

M12X1,5 8 6 8

M14X1 10 6 8

M20X1,5 13 6 8

⅛" 7 6 –

¼" 8 6 8

⅜" 13 6 8

½" 16 6 8

3. MOUNTING

The temperature sensor can be mounted into a hole, which is suitable both for the probe length, tube size and the threaded connection. The tube length under the shrink

tube is 10 mm (0.4"). The mounting bolt can be pulled with a wrench on the notches (Y), or with a tool, that fits the groove.

When using the mounting bolt – if the mounting bolt was ordered – the plastic shrink tube seal must be removed!

The probe length (L) does not change with the use of a mounting bolt!

4. WIRING

Dual Single 4-wire

Pt 100 Pt 100

-WIRES WITH IDENTICAL COLOR

Pt 100

-WIRES WITH IDENTICAL COLOR

On the 4-wire version, the same sensor wires are marked with the same color.

On the dual sensor version, the wires of one of the sensors are marked with the same color.

5. MAINTENANCE, REPAIR

The device does not require regular maintenance. The warranty card contains the terms and conditions. Before returning the device for repairs, it must be cleaned thoroughly. The parts

in contact with the medium may contain harmful substances; therefore, they must be decontaminated. Our official form (Returned Equipment Handling Form) must be filled and

enclosed in the parcel. Download it from our website www.nivelco.com. The device must be sent back with a declaration of decontamination. A statement must be provided in the
