No Butts Bin SR7900F User manual

Assembly Instructions
Shelter type: SR7900F
SR7900F-01-211021-USA

13
1
10
7
3
4
1
2
6
1
8
9
5
11
10
14
12
13
14
2
Exploded View of Shelter
ITEM
NO. PART NAME
DRG NUMBER LENGTH QTY.
1 S1C Frame S1C
Default
6
2 P1 Post P1
Default
1
3 CB1 Bracket CB1
Default
7
4 JF1 Bracket JF1
Default
6
5 40x40 End cap EC40
40 x 40 x
20 3
6 ST1 Roof Tie ST1
Default
1
7 DR Bracket DR
Default
8
8 FT1 Bracket FT1
Default
3
9 FT3 Bracket FT3
Default
5
10 DR2I Infill Panel DR2I
Default
2
11 DR2PO Roof Panel DR2PO
Default
2
12 DR2R DR2R
Default
3
13 DR2T Roof Trim DR2T
Default
3
14 DRAT2 Roof Trim DRAT2
Default
2

3
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION
Size (inch) IMAGE
QTY.
1
S1C
S1 - Full Frame - SRC
78.74 x 40.74
6
2
P1
Post Frame - P1
78.74 x 40.74
1
3
CB1
Corner Bracket -
CB1
4.3 x 4.3 x 1.57
7
4
JF1
Joint Flat - JF1
4.33 x 1.57
6
5
EC40
40x40 PLASTIC END
CAP
1.57 x 1.57
3
6
ST1
Roof Tie - ST1
40.35 1
7
DR
Rafter Bracket
4.3 x 1.6 x 2
8
8
FT1
FT1 BRACKET
1.57 x 1.57 x 3.94
3
9
FT3
FT3 Bracket
1.57 x 3.15 x 4.17
5
10
DR2I
DR2 infill panel
85 x 15.75
2
11
DR2PO
DR2 Roof Panel
Outer
92.32 x 41.54
2
12
DR2R
DR2R Rafter
92.32 3
13
DR2T
DR2 Roof Trim
92.32 x 3.15
3
14
DRAT2
Ally-Angle Trim 2M
2 x 2 x 83
2

4
FIXINGS
Drill/Screwdriver
Mallet
Wrench
Torx bit
TOOLS REQUIRED
Fittings Bolt set M10 T25 T38 BTANCM12100
M10 x 60mm Nut Washer
1" Tech
screw
1.5"
Tech
screw
Black
Caps
M10/12 x 100 mm
Concrete Bolt
Pack A
30 30 60 72 30 60 13
Required 14 14 28 68 64 56 8

83
83
IMPORTANT:
Check overall dimensions
to ensure corrct alignment
S1
ST1
JF1
CF1
P1
NOTE: Insert EC40 into ST1
and P1 before installation.
CB1
JF1 JF1
CB1CB1
CB1CB1
Ensure corners are aligned
correctly
Step 1
Assemble S1 frames to make up the main structure using CB1 brackets
in the corners and JF1 brackets on straight joints. Then attach P1 post using
one JF1 bracket. Then attach ST1 Tie bar using a JF1 bracket and one CB1
bracket.
5

40.75 40.75
FRONT VIEW
DR2R
DR
DR2I
DR2I
Step 2
Attach DR Brackets to the top of the frames, and bolt the DR2R rafters in
place through the brackets. The DR2I infill panels have to be placed in
position at the same time at the end rafters.
6

DR2PO
DRPO
Step 3
Align the DR2PO roof panels with the outer roof rafters but don't screw into
place at this stage.
7

DRAT2
DR2T
DR2T
DRAT2
FT3
FT1
Step 4
Screw down the DR2T directly into the rafters as shown below,
using 2" Tech screws. Then attach the DRAT2 angles on both sides and
secure all the roof components with 2" Tech screws.
Attache the FT1 and FT3 foot brackets and use anchor bolts to sucure the
shelter to the ground. FT1 brackets are used where there is only a single
leg and FT3 for double legs.
8

85.87
40.75 41.12
40.75
39.17
40.75 41.12
85.87
41.12 44.74
Ground anchor positions and overall size
Suggested concrete base size: 8 inch oversized on all four sides
Scale 1:15
9

10
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
No Butts Bin Company, Inc.
16 Birch Lane, Madison, CT 06443
Email: [email protected]
Web: www.nobutts.com
Tel: [phone]
All Parts and Fixings checked by:
Print Name: Signature:
