No Butts Bin SR7903-F User manual

Assembly Instructions
Product Code: SR7903-F
Doc. No.: SR7903F-01-01112021-USA
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]

1210
9
9
13
14
2
2
13
8
4
5
7
5
4
8
1
1
15
6
6
3
4
5
16
Exploded view
2

Parts List
3
ITEM
NO.
PART
NO.
DESCRIPTION
Size (inch) IMAGE
QTY.
1
S1C
S1 - Full Frame - SRC
78.74 x 40.74
11
2
DR
Rafter Bracket
4.3 x 1.6 x 2
20
3
FT3
FT3 Bracket
1.57 x 3.15 x 4.17
10
4
CB1
Corner Bracket - CB1
4.3 x 4.3 x 1.57
8
5
JF1
Joint Flat - JF1
4.33 x 1.57
16
6
FT1
FT1 BRACKET
1.57 x 1.57 x 3.94
3
7
ST3
Roof Tie - ST3
81.1 1
8
DR2R
DR2R Rafter
92.32 6
9
DR2I
DR2 infill panel
85 x 15.75
2
10
DR2PO
DR2 Roof Panel
Outer
92.32 x 41.54
2
11
DR2PI
DR2 Roof Panel Inner
40.75 x 92.30
3
12
DR2T
DR2 Roof Trim
92.32 x 3.15
6
13
DRATO
DR Ally-Angle Trim
Outer
2 x 2 x 41.5
4
14
DRATI
DR Ally-Angle Trim
Inner
2 x 2 x 40.75
6
15
P1
Post Frame - P1
78.74 x 40.74
1
16
EC40
40x40 PLASTIC END
CAP
1.57 x 1.57
3

Tools required:
Drill/Screwdriver
Mallet
Tools included:
WRENCH
Torx bit
4
*
NOTE: THE 1 1/2 inch TECH SCREWS ARE FOR FIXING ROOF COMPONENTS ONLY
Fittings and tools
Type Bolt set M10 T25
T38
*
BTANCM12100
M10 x 60 Nut Washer
Black
Caps
1" Tech
screw
1 1/2"
Tech
screw
M10/12 x 100 mm
Concrete Bolt
Pack A
30 30 60 60 72 30 8

IMPORTANT:
Make sure side frames are aligned as detailed below.
CB1
JF1
83
205.3
S1C
JF1
Step 1
Assemble back and side frames S1C as shown below. Using JF1 brackets for the
straight joints and CB1 brackets for the corners.
5
Check the dimension
of the shelter to
ensure correct alignment

JF1
CB1
CB1
P1
ST3
JF1
Step 2
Attach the ST3 tie bar ans P1 post using CB1 and JF1 brackets.
6

DR
DR1R RafterDR1R RafterDR1R Rafter
DRDR
DR1I
DR1I
DR1R RafterDR1R RafterDR1R Rafter
DR1I
DR1I
40.75 40.75 40.75 40.75 40.75
Front View
Step 3
Secure the DR1R roof rafters into place using the DR Brackets. The DR1I infill panels
are screwed into place using 1" tech screws but must be placed into position at
the same time as the end rafter.
7

DR2PO
DR2PO
DRATO
DRATO
DRATI
DRATI
DR2PI
DR2PI
DR2PI
DRATO
DRATO
DRATI
DRATI
DRATIDRATI
DRATO
DRATIDRATI
DRATO
DRATI
DR2PO
DR2PO
DR2PI
DR2PI
DR2PI
Step 4
8
Line up the roof sheets DR2PO/DR2PI as shown below. Install the DRATI and
DRATO Angle trims to the bottom of the roof panels and using the 1.5" Tech
screws, this will secure the roof sheets.

DR2T
FT3
FT1
Step 5
9
Seal the central gaps and edges with the DR1T strips. Once the shelter is in its
final position and squared up, attch the FT1 and FT3 foot brackets and use
anchor bolts to attach to the ground.
Finally fit the black plastic caps on exposed nuts and bolts.

85.91
205.61
40.75 41.12
40.75 39.17
41.12 40.75 40.75 40.75 40.75
Plan View
Suggested size for concrete base: 8 inch oversized on all 4 sides.
10

11
CONTACT DETAILS:
No Butts Bin Company, Inc.
16 Birch Lane, Madison, CT 06443
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Use metal paint to touch up any exposed metal •
should it get scratched
All Parts and Fixings checked by:
Print Name: Signature:
