No Butts Bin SR8296 User manual

Assembly Instructions
Shelter Type: SR8296
SR8296-01-27102021-USA

1
9
11
11
2
17
1817
18
10
12
12
13
12
14
15
14
16
16
16
16
10
6
7
2
4
3
8
4
5
5
3
4
2
EXPLODED VIEW

3
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION
Size (inch) IMAGE
QTY.
1
S1
Frame
78.74 x 40.74
3
2
S3
Frame
78.74 x 20.3
2
3
CB1
Corner Bracket
4.3 x 4.3 x 1.6
8
4
JF1
Straight Bracket
8.7 x 1.6
5
5
ST15
ST15 ROOF TIE BAR
20.15 x 1.57 x
1.57 2
6
ST5
ST5 Roof Tie Bar
60.75 2
7
P5
P5 POST
77.15 x 1.57 x
1.57 1
8
JFT
Bracket
8.66 x 5.9
1
9
DR
Rafter Bracket
4.3 x 1.6 x 2
12
10
DR1R
Rafter
45 4
11
DR1I
Infill Panel
44.6 x 7.9
2
12
DRATO
DR Ally-Angle Trim Outer
2 x 2 x 41.5
4
13
DRATI
DR Ally-Angle Trim Inner
2 x 2 x 40.75
2
14
DR1PO
Roof Panel Outer
47.7 x 41.5
2
15
DR1PI
DR1 Roof Panel Inner
47.6 x 40.75
1
16
DR1T
Roof Trim
47.7 x 3.1
4
17
FT1
Foot Bracket
4.3 x 3.9 x 1.6
3
18
FT3
FT3 Bracket
1.57 x 3.15 x
4.17 4
19
EC40
Plastic end cap
1.6 x 1.6
6

4
FIXINGS
Tools required:
Drill/Screwdriver
Mallet
17mm Wrench
T25 Torx bit
Fittings Bolt set M10 T25 T38 BTANCM12100
M10 x 60mm Nut Washer
1" Tech
screw
1.5"
Tech
screw
Black
Caps
M10/12 x 100 mm
Concrete Bolt
Pack A+B
33 33 66 136 40 66 11

21.93
123.82
20.35
42.28
MEASURE THE WIDTH AND DEPTH
OF THE SHELTER TO CHECK
CORRECT ALIGNMENT.
Please note 1.5" Tec Screws
are for roof panels only
CB1CB1CB1
CB1
CB1
JF1JF1JF1JF1JF1
CB1
CB1
CB1
P5 POST
ST5
ST5
ST15
ST15
S3
S1
ENSURE CORRECT
ALIGNMENT ON
CORNERS
CB1
CB1
JF1 JF1
JF1
JFT
DETAIL A
SCALE 1 : 10
DETAIL B
SCALE 1 : 10
DETAIL C
SCALE 1 : 10
DETAIL D
SCALE 1 : 10
Step 1
Assemble S1 and S3 frames to make up the main structure using CB1
brackets for the corners and JF1 brackets for the straight joints.
Attach ST15 tie bars, the ST3 Tie bars and the P5 post using CB, JF1 and JFT
Brackets as shown below.
5

DR1R
DR1R
DR1R
DR1R
DR BRACKET
DR1I
DR1I
40.75 40.75 40.75
6
Step 2
Attach DR1R rafters using DR brackets. Secure the END PANELS (DR1I) to frames
using 1" tech screws. The end rafters need to be placed in position at the
same time as the DR1I

DR1PO
DR1PO
DR1PI
DRATO
DRATO
DRATO
DRATO
DR1T
DR1T
DR1T
DR1T
DRATI
DRATI
7
Step 3
Attach the DR1PO and DR1PI to the top of the rafters with the DR1PO on either
end and the DR1PI in the middle. Seal the gap between the panels using the
DR1T strips. Then attach the DRATO and DRATI parts to the lower part of the
rafters as shown below.

FT1 FT3
8
Step 4
Move the shelter into its desired position and attach the foot brackets
FT1/FT3 before fixng in place.

79.92 42.70
42.78
122.62
20.61
PLAN VIEW
OVERALL DIMENSIONS AND GROUND FIXING POSITIONS
Suggested size for concrete base: 8" oversized on all 4 sides.
9

10
MAINTENANCE:
To ensure your products give you many years of use we recommend that you:
THANK YOU
FOR PURCHASING THIS PRODUCT
Clean panels regularly with soapy water •
Ensure all fittings are tight (for example after a big storm) •
Touch up any exposed metal should it get scratched •
CONTACT DETAILS:
Email : [email protected]
Web : www.nobutts.com
Tel : [phone]
No Butts Bin Company, Inc. 16 Birch Lane, Madison, CT 06443
All Parts and Fixings checked by:
Print Name: Signature:
