Nokia 101 User manual

Nokia 101 User Guide
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Issue 1.1 EN

Keys and parts
12
3
4
5
6
7
8
Select
Back
1Earpiece
2Screen
3End/Powerkey
4Keypad
5Microphone
6Scrollkey
7Callkey
8 Selection keys
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

9
10
11
12
13
9 Charger connector
10 Flashlight
11 Memory card slot
12 Loudspeaker
13 Headset connector
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert the SIM card and battery
Slide the back cover down.
1
Open the SIM card holder.
2
Insert SIM1.
3
Close the SIM card holder.
4
Slide SIM2 under the metal part.
5
Make sure the plastic tab holds the SIM
card in place.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Line up the contacts.
7
Push the battery in.
8
Slide the back cover up.
9
Insert a memory card
Open the cover of the memory card
slot. See vi) in General information.
1
Make sure the contact area is facing up,
and push the card in.
2
Close the cover.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Charge the battery
Connect the charger to a wall outlet.
1
Connect the charger to the phone.
2
The phone indicates a full charge. You
can use the phone while charging.
3
Switch on
2 seconds
Press and hold the power key .
1
SIM1
SIM2
2
1
OK
Dual SIM
Set which SIM card to use. Press OK.
See v) in General Information.
2
OK Back
:00
09
To set the hour, press up or down. You
can also press the number keys.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

OK Back
15:00
To set the minutes, press right, and
then press up or down. Press OK.
4
Time is set
The time is changed.
5
OK Exit
Date:
.04.201108
To set the date, press up or down.
Press OK.
6
Menu Go to
The phone is ready to use.
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Explore your phone
Menu Go to
To see the available functions, press
Menu.
1
Select Exit
To go to a function, press the scroll key
up, down, left, or right.
2
Select Exit
To select the function, press Select.
3
Select Back
To select an item, press Select.
4
Select Back
To return to the previous view, press
Back.
5
Select Exit
To return to the home screen, press
.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Select a SIM card for calls and messages
SIM1
SIM2
SIM1
SIM2
You can use two SIM cards, and share
your phone with your family.
Menu Go to Select Exit
Press Menu. Select Settings.
1
Tone settings
Select Back
Dual SIM
settings
Display
settings
Select Dual SIM settings. See v) in
General Information.
2
Select Back
Ask every time
Default SIM for
calls
Ask every time
Default SIM for
msgs
Select Default SIM for calls.
3
Select Back
Ask every time
SIM1
SIM2
Select Ask every time.
4
OK
Default SIM for
calls:
Ask every time
Press the call key to
call directly!
Your phone asks which SIM card to use
when you make a call.
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Select Back
Ask every time
Default SIM for
calls
Ask every time
Default SIM for
msgs
Select Default SIM for msgs.
6
Select Back
Ask every time
SIM1
SIM2
Select Ask every time.
7
OK
Default SIM for
msgs.:
Ask every time
Press the call key to
send the message
directly!
Your phone asks which SIM card to use
when you send a message.
8
Tip: To open Dual SIM settings from
the home screen, press and hold *.
