Nokia 1280 User manual

Nokia 1280 User Guide
Issue 1.0

Contents
Safety 3
Get started 5
Insert the SIM card and
battery 5
Remove the SIM card 6
Charge the battery 6
Switch on and off 7
Your phone 9
Keys and parts 9
Main features 10
Calls 11
Write text 12
Message 13
Contacts 14
Multi-phonebook 15
FM Radio 16
Flashlight shortcuts in
standby mode 17
Product and safety
information 17
2Contents
© 2009 Nokia. All rights reserved.

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
Safety 3
© 2009 Nokia. All rights reserved.

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
4Safety
© 2009 Nokia. All rights reserved.

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-5CB battery.
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
1 Place your finger in the recess at the bottom of the
device, and carefully lift and open the back cover (1).
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure the contact surface area
is facing down and the bevelled corner of the SIM card
is facing the bottom of the device.
4 Replace the battery (4) and back cover (5, 6, 7).
Get started 5
© 2009 Nokia. All rights reserved.

Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
6Getstarted
© 2009 Nokia. All rights reserved.

Tip: To save energy, unplug the charger when the battery
is fully charged.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
Switch on and off
Press and hold the end key.
Use the phone only in its normal operating position.
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
Get started 7
© 2009 Nokia. All rights reserved.

cause a higher power level during operation and may
reduce the battery life.
8Getstarted
© 2009 Nokia. All rights reserved.

Your phone
Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key (scroll key)
5Call key
6End/Power key
7Keypad
8Headset connector
(3.5mm)
9Flashlight
10 Microphone
11 Wrist strap eyelet
12 Charger connector
Your phone 9
© 2009 Nokia. All rights reserved.

13 Loudspeaker
Main features
Select Menu and from the following:
Messages Create, send, and manage messages.
Contacts Save names and phone numbers.
Call register Access missed, received, and dialled calls.
Settings Set up various features of your device.
Clock Set the time for the alarm.
10 Your phone
© 2009 Nokia. All rights reserved.

Radio Manage radio features.
Reminders Manage reminders.
Games Play or set up the games in your device.
Extras Access various applications.
SIM services Use supported SIM card services.
Calls
To make a call, enter the phone number, including the
country code and area code, if necessary, and press the call
key. To answer a call, press the call key. To end or reject a
call, press the end key.
To use a loudspeaker or earpiece during a call, select
Loudsp. or Hands.. To adjust the volume during a call,
scroll left or right.
When the volume is high, do not hold the device near your
ear.
Your phone 11
© 2009 Nokia. All rights reserved.

Write text
To enter text, you can use traditional or predictive text
input. Not all languages are supported by predictive text
input.
Use traditional text input
Press a key repeatedly until the desired letter is displayed.
Activate predictive text input
Select Options > Dictionary and the desired language.
Deactivate predictive text input
Select Options > Dictionary > Dictionary off.
When using predictive text input, press each key once for
a single letter. If the desired word is displayed, press 0, and
start writing the next word. If ? is displayed after the word,
the word is not in the dictionary.
Change a word
Press *repeatedly until the desired word is displayed.
12 Your phone
© 2009 Nokia. All rights reserved.

Add a word
Select Spell, enter the word using traditional text input,
and select OK.
Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the top of
the display.
Add a number
Press and hold the desired number key.
Add a special character
Press *when using traditional text input; press and hold
*when using predictive text input.
Undo clearing of a message
Select Options > Undo clear.
Message
The message services can only be used if they are
supported by your service provider.
Your phone 13
© 2009 Nokia. All rights reserved.

Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
options take more space, and limit the number of
characters that can be sent in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length indicator
shows how many characters you can enter in the
message.
3 Select Options > Send, enter the recipient's phone
number or select it from the contacts list, and select
OK.
Delete messages
Select Menu > Messages > Delete messages > All
read or the desired folder.
Contacts
You can save names and phone numbers in the phone and
SIM card memory. The contacts list can contain up to 500
contacts, stored in the phone memory.
14 Your phone
© 2009 Nokia. All rights reserved.

Search for a contact
Scroll down in the standby mode, enter the first characters
or letters of the name, and scroll to the desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add contact.
Copy contacts between the phone and SIM card
memory
Select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate phonebooks for
multiple users. When the multi-phonebook is activated,
only the contacts in the active phonebook are visible.
A contact can belong to one or several phonebooks. The
contacts in Shared cont. are accessible from all
phonebooks.
Select Menu > Contacts > Settings > Multi-
Phonebook and the appropriate options.
Your phone 15
© 2009 Nokia. All rights reserved.

Activate the multi-phonebook
Select Phonebook style > Multi-Phonebk..
Activate a phonebook
Select Current phonebook and the desired phonebook or
Shared cont..
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired phonebook.
FM Radio
The FM radio depends on an antenna other than the
wireless device antenna. A compatible headset needs to be
attached to the device for the FM radio to function properly.
You may need to purchase a compatible headset
separately.
To open the radio, select Menu > Radio. To adjust the
volume of the radio, scroll left or right.
You need at least one saved channel for the clock radio to
function properly.
16 Your phone
© 2009 Nokia. All rights reserved.

Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Flashlight shortcuts in standby mode
To switch on, scroll up twice. To switch off, scroll up once.
Do not shine the flashlight in anyone's eyes.
Product and safety information
General information
About your device
The wireless device described in this guide is approved for use on the EGSM 900 and
1800 MHz networks. Contact your service provider for more information about
networks.
Warning:
To use any features in this device, other than the alarm clock, the device must be
switched on. Do not switch the device on when wireless device use may cause
interference or danger.
Product and safety information 17
© 2009 Nokia. All rights reserved.

When using this device, obey all laws and respect local customs, privacy and
legitimate rights of others, including copyrights. Copyright protection may prevent
some images, music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored in
your device.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Network services
To use the device you must have service from a wireless service provider. Some
features are not available on all networks; other features may require that you make
specific arrangements with your service provider to use them. Network services
involve transmission of data. Check with your service provider for details about fees
in your home network and when roaming on other networks. Your service provider
can explain what charges will apply.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu.
Your device may also have customized items such as menu names, menu order, and
icons.
Support
When you want to learn more about how to use your product or you are unsure how
your device should function, see the user guide or see the support pages at
www.nokia.com/support or your local Nokia website, or with a mobile device,
www.nokia.mobi/support.
If this does not resolve your issue, do the following:
18 Product and safety information
© 2009 Nokia. All rights reserved.

•Restart the device: switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.
•Restore the original factory settings as explained in the user guide.
If the issue remains unsolved, contact Nokia for repair options. See www.nokia-
asia.com/repair. Before sending your device for repair, always back up the data in
your device.
Accessories
Nokia original accessories
Warning:
Use only batteries, chargers, and accessories approved by Nokia for use with this
particular model. The use of any other types may invalidate any approval or warranty,
and may be dangerous. In particular, use of unapproved chargers or batteries may
present a risk of fire, explosion, leakage, or other hazard.
For availability of approved accessories, check with your dealer.
An extensive range of accessories is available for your device. For more details, see
www.nokia-asia.com/accessories.
Product and safety information 19
© 2009 Nokia. All rights reserved.

Practical rules about accessories
•Keep all accessories out of the reach of small children.
•When you disconnect the power cord of any accessory, grasp and pull the plug,
not the cord.
•Check regularly that accessories installed in a vehicle are mounted and are
operating properly.
•Installation of any complex car accessories must be made by qualified personnel
only.
Battery
Type Talk time Standby
BL-5CB Up to 12.78 hours Up to 720 hours
Important: Battery talk and stand-by times are estimates and only possible under
optimal network conditions. Actual battery talk and standby times depend on SIM
cards, features used, battery age and condition, temperatures to which battery is
exposed, network conditions, and many other factors, and may be significantly
shorter than those specified above. Ringing tones, hands free call handling, use in
digital mode, and other features will also consume the battery, and the amount of
time a device is used for calls will affect its stand-by time. Likewise, the amount of
time that the device is turned on and in the standby mode will affect its talk time.
Battery
Battery and charger information
Your device is powered by a rechargeable battery. The battery intended for use with
this device is BL-5CB. Nokia may make additional battery models available for this
device. This device is intended for use when supplied with power from the following
chargers: AC-3. The exact charger model number may vary depending on the type of
20 Product and safety information
© 2009 Nokia. All rights reserved.
