Nokia NSB-9 User manual

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
SERVICE
MANUAL
NSB-9
Cellular Phones
NMP Part No: Original 0274280
COMPANY CONFIDENTIAL

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
Amendment Record Sheet
Amendment No Date Inserted By Comments
04/2003 ViK Issue 1

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
Nokia NSB-9 Service Manual Structure
1. Foreword
2. General Information
3. System Module
4. Parts List
5. Service Software Instructions
6. Service Tools
7. Disassembly Instructions
8. Troubleshooting Instructions
9. Schematics

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
IMPORTANT
This document is intended for use by qualified service personnel only.
Company Policy
Our policy is of continuous development; details of all technical modifications will be
included with service bulletins.
While every endeavour has been made to ensure the accuracy of this document, some
errors may exist. If any errors are found by the reader, NOKIA CORPORATION should be
notified in writing.
Please state:
Title of the Document + Issue Number/Date of publication
Latest Amendment Number (if applicable)
Page(s) and/or Figure(s) in error
Please send to:
Nokia Corporation
Nokia Mobile Phones Ltd
CCS Technical Documentation
PO Box 86
FIN-24101 SALO
Finland
Note: This manual is COMPANY CONFIDENTIAL material.

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
Warnings and Cautions
Please refer to the phone's user guide for instructions relating to operation, care and
maintenance including important safety information. Note also the following:
Warnings:
1. CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELEC-
TRONIC ENGINE MANAGEMENT SYSTEMS AND ANTI-SKID BRAKING SYS-
TEMS. UNDER CERTAIN FAULT CONDITIONS, EMITTED RF ENERGY CAN
AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/
MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC
SYSTEMS TO RF ENERGY.
2. THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY
TO CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES EG PETROL STATIONS
(SERVICE STATIONS), BLASTING AREAS ETC.
3. OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLU-
LAR TELEPHONES, MAY INTERFERE WITH THE FUNCTIONALITY OF INADE-
QUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE
MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS.
OTHER ELECTRONIC EQUIPMENT MAY ALSO BE SUBJECT TO INTERFERENCE.
Cautions:
1. Servicing and alignment must be undertaken by qualified personnel only.
2. Ensure all work is carried out at an anti-static workstation and that an anti-
static wrist strap is worn.
3. Ensure solder, wire, or foreign matter does not enter the telephone as dam-
age may result.
4. Use only approved components as specified in the parts list.
5. Ensure all components, modules screws and insulators are correctly re-fit-
ted after servicing and alignment. Ensure all cables and wires are reposi-
tioned correctly.

Customer Care Solutions
Technical Documentation
Issue 1 04/03
Copyright 2003 Nokia Corporation. All Rights Reserved
ESD Protection
Nokia requires that phone repair places have sufficient ESD protection
(against static electricity) when servicing cellular phones.
A cellular phone, which is ready for use, can be handled normally without ESD
protection. The SIM card and battery can be replaced in normal conditions of
use.
To replace the color cover ESD protection must be applied, except for the
phone covers which can be replaced by the customer.
All electronic parts of the phone , including the display, are susceptible to ESD.
Resistors, too, can be damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the phone or handling the phone compo-
nents must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an
EPA.
For more detailed information about ESD protection and EPA, contact your
local Nokia After Market Services representative.

CCS Technical Documentation
NSB-9 Series Transceivers
Issue 1 04/03 Nokia Corporation
General Information

NSB-9
CCS Technical Documentation
Page 2 Nokia Corporation Issue 1 04/03
Table of Contents
Page No
NSB-9 Product Selection ............................................................................................... 3
Accessories List ............................................................................................................. 4
Technical Specifications ................................................................................................ 5
General Specifications of Transceiver NSB-9 .............................................................5
Environmental conditions ......................................................................................... 6
Transceiver Features ....................................................................................................6
Electrical Characteristics .............................................................................................7

CCS Technical Documentation
NSB-9
Issue 1 04/03 Nokia Corporation Page 3
NSB-9 Product Selection
The NSB-9 is a dualband radio transceiver unit designed for the GSM850 and GSM1900
networks. GSM850 power class is 4, GPRS850 power class is 5 and GSM1900 power class
is 1. It is a true DCT-4 based transceiver with new advanced features.
NSB-9 Product and modules
Figure 1: NSB-9 transceiver
Name Module name Module code
Basic transceiver NSB-9 0508623
Radio module RM9 0202046
Flip NHL-6 Flip 0262868
Flip NSB-9 Flip basic LTA 9458924
NSB-9 Flip basic CAN 9459047
Mechanics assembly parts NSB-9 HDB58 0262884
Software module ( basic SW ) SW NSB-9 basic
mech.module
0243727

NSB-9
CCS Technical Documentation
Page 4 Nokia Corporation Issue 1 04/03
Accessories List
Batteries Product code:
Semi-fixed Battery BLC-2 1000mAh 0670403
Chargers Product code:
Travel Charger ACP-12E (EUR) 0675294
Travel Charger ACP- 12X (UK) 0675296
Travel Charger ACP-12U (US) Made in country 0675303
Travel Charger ACP- 12UB (US) (Countries like Brazil/Portugal) 0675293
Travel Charger ACP-12G (US) (Countries like Brazil/Gradient) 0675295
Travel Charger ACP-12K (Korea) 0675301
Travel Charger ACP-12AR (Argentina) 0675298
Travel Charger ACP-12A (Australia) 0675300
Mobile Charger LCH-12 0675328
Note! ACP-7, ACP-8, and LCH-8 chargers are also compatible with NSB-9
Portable and Office Accessories Product code:
Boom Headset HDB-4 0694094
Stereo Headset HDS-3 0694093
Loopset LPS-4 0630443
DCV-14 Connectivity Stand 0273869
DT-1 Music Stand 0694119
Mobile Accessories: Product code:
Mobile Holder MBC-13L 0650048
Swivel Mount HHS-15 0620060
Car Installation Kit 126 CARK126 (Full Car Kit providing charging)
Handsfree Unit HFU-4
HF Microphone HFM-8
External HF Speaker HFS-12
Mounting Plate MKU-1
System Cable SCU-4
Power Cable PCU-4
0085197
0694103
0690016
0692009
0620036
0630471
0630478
Other Accessories: Product code:
Connectivity Cable DKU-5 (FBUS /USB Cable) 0730235
PC Suite
Carrying accessories

CCS Technical Documentation
NSB-9
Issue 1 04/03 Nokia Corporation Page 5
Technical Specifications
General Specifications of Transceiver NSB-9
Variation in operating times may occur depending on SIM card, network and usage set-
tings, usage style and environments.
Unit Dimensions (mm)
(L x W x T)
Weight
(g)
Volume
(cm3)
NSB-9 Transceiver with BLC-2 bat-
tery pack
55 x 117 x 22.5 122 105
Parameter Unit
Cellular System GSM850, GSM1900
RX Frequency Band GSM850: 869.2 - 893.8 MHz
GSM1900: 1930.2 - 1989.8 MHz
TX Frequency Band GSM850: 824.2 - 848.8 MHz
GSM1900: 1850.2 - 1909.8 MHz
Output Power GSM850 : +5 ...+33 dBm / 3.2 mW ... 2 W
GSM1900: +0 ...+30 dBm / 1.0 mW ... 1 W
Number of RF Channels GSM850: 124
GSM1900: 299
Channel Spacing 200 kHz
Number of TX Power Levels GSM850 *: 15
GSM1900: 16
Talk time
Battery : BLC-2 up to 4.5 hours
Talk time variations:
Integrated Handsfree (IHF) talk time up to 4 hours
Standby time
Battery: BLC-2 up to 10 days (240 hours)
Radio + headset up to 30 hours
Radio + IHF up to 16 hours

NSB-9
CCS Technical Documentation
Page 6 Nokia Corporation Issue 1 04/03
Environmental conditions
Transceiver Features
Transceiver main HW parts / features include:
• Dual band GSM 850/1900
• FM Stereo Radio
• Passive matrix colour display 4096 colours (128x128 pixels used in applica-
tions i.e. Series 40, active area 30.8mm x 30.8mm), Display brightness control
• 4-way joystick
• ITU-T keypad and full alphanumeric keyboard
• Side volume keys, also used in integrated handsfree mode to control the
speaker volume
• Internal antenna
• Internal vibra
• Integrated handsfree (IHF)
• Speech Codecs: FR, EFR, AMR
• Real time clock (RTC)
• Pop-Port (TM) connector
Environmental condition Ambient temperature Notes
Normal operation -10 oC ... +55 oCSpecifications fulfilled
Reduced performance +55 oC ... +65 oCOperational only for short periods
Intermittent operation -20 oC ... -10 oC and
+65 oC ... +80 oC
Operation not guaranteed but an attempt to
operate will not damage the phone
No operation -40 oC ... -20 oCOperation not possible but an attempt to
operate will not damage the phone
No operation or storage < -40 oC and > +80 oCNo storage; an operation attempt may cause
permanent damage
Charging allowed -25 oC ... +60 oC
Long term storage conditions 0 oC ... +40 oC

CCS Technical Documentation
NSB-9
Issue 1 04/03 Nokia Corporation Page 7
Electrical Characteristics
Absolute Maximum Ratings
Supply Voltages
Current Consumption
Parameter Min. Typical Max. Unit
Battery Voltage, Idle -0.3 5.0 V
Battery Voltage, Call -0.3 4.8 V
Charger Input Voltage -0.3 16 V
Charging Current 850 mA
Parameter Min. Typical Max. Unit / Notes
Battery Voltage 3.1 3.6 4.2 V / SW cut-off 3.2 V
Condition Min. Typical Max. Unit
Call
GSM 850
GSM 1900
250
280
mA
Idle 2.5-3.5 mA
Power off 150 µA

NSB-9
CCS Technical Documentation
Page 8 Nokia Corporation Issue 1 04/03
[This page left intentionally blank.]

CCS Technical Documentation
NSB-9 Series Transceivers
Issue 1 04/03 Nokia Corporation
System Module and User
Interface

NSB-9
System Module and User Interface CCS Technical Documentation
Page 2 Nokia Corporation Issue 1 04/03
Table of Contents
Page No
Glossary of terms ........................................................................................................... 3
Introduction.................................................................................................................... 6
System Module: Baseband............................................................................................. 7
Baseband Module, technical summary ........................................................................7
Baseband Technical Specifications .............................................................................9
Absolute Maximum Ratings...................................................................................... 9
DC Characteristics..................................................................................................... 9
Power Distribution diagram .................................................................................... 11
Baseband External and Internal Signals and Connections ........................................12
Internal Signals and Connections............................................................................ 12
External Signals and Connections........................................................................... 18
Baseband Functional Description ................................................................................ 23
Modes of Operation ...................................................................................................23
No supply ................................................................................................................ 23
Backup..................................................................................................................... 23
Acting Dead............................................................................................................. 23
Active ...................................................................................................................... 23
Sleep mode .............................................................................................................. 24
Charging .................................................................................................................. 24
Power Up and Reset ...................................................................................................24
Power up with PWR key ......................................................................................... 25
Power up when charger is connected ...................................................................... 25
Power up when battery is connected ....................................................................... 26
RTC alarm power up ............................................................................................... 27
A/D Channels .............................................................................................................27
FM Radio ...................................................................................................................28
FM-radio audio connections.................................................................................... 29
Keyboards ..................................................................................................................29
Engine Keyboard..................................................................................................... 29
Flip .......................................................................................................................... 30
Flip keyboard........................................................................................................... 30
Flip position detection............................................................................................. 31
IR Module ..................................................................................................................31
SIM Interface .............................................................................................................31
System Connector ......................................................................................................33
External accessory regulator ......................................................................................33
Battery ........................................................................................................................34
Backup Battery ..........................................................................................................35
LCD & Keypad Illumination .....................................................................................36
LCD ...........................................................................................................................37
ACI ............................................................................................................................38
External Audio ...........................................................................................................38
External Microphone Connection ........................................................................... 38
External Earphone Connections .............................................................................. 40
Internal Audio ............................................................................................................40
Internal Microphone................................................................................................ 40

CCS Technical Documentation System Module and User Interface
NSB-9
Issue 1 04/03 Nokia Corporation Page 3
Internal Speaker....................................................................................................... 41
Integrated Hands Free ............................................................................................. 41
Memory Block ...........................................................................................................42
Security ......................................................................................................................42
Production / After Sales Interface ..............................................................................43

NSB-9
System Module and User Interface CCS Technical Documentation
Page 4 Nokia Corporation Issue 1 04/03
Glossary of terms
ACI Accessory Control Interface
ADC Analog-Digital Converter
AEC Acoustic Echo Canceller
AFC Automatic Frequency Control
AGC Automatic Gain Control
AIF Application Interface
ALWE Background noise suppressor
AMS After Market Service
AMR Adaptive Multi Rate
ARM Processor architecture
ASIC Application Specific Integrated Circuit
BB Baseband
CBus Control Bus
CCS Customer Care Solutions
CMT Cellular Mobile Telephone (MCU and DSP)
CPU Central Processing Unit
CTSI Clocking Timing Sleep Interrupt
COG Chip On Glass
CSP Chip Scale Package
CSTN Color Super Twisted Nematic
DAC Digital-Analog Converter
DAI Digital Audio Interface
DB Dual band

CCS Technical Documentation System Module and User Interface
NSB-9
Issue 1 04/03 Nokia Corporation Page 5
DCN Offset Cancellation control signal
DLL Dynamic Link Library
DRC Dynamic Range Controller
DSP Digital Signal Processor
EFR Enhanced Full Rate
EMC Electromagnetic compatibility
EMI Electromagnetic Interference
ESD Electro Static Discharge
EXT RF External RF
FBUS Asynchronous Full Duplex Serial Bus
GPRS General Packet Radio Service
GSM Global System for Mobile communications
HS Half Rate Speech
HSCSD High Speed Circuit Switched Data
IC Integrated Circuit
IHF Integrated Hands Free
I/O Input/Output
IrDA Infrared Association
LCD Liquid Crystal Display
LDO Low Drop-Out
LNA Low Noise Amplifier
MBUS 1-wire half duplex serial bus
MCU Micro Controller Unit
MDI MCU-DSP Interface

NSB-9
System Module and User Interface CCS Technical Documentation
Page 6 Nokia Corporation Issue 1 04/03
MFI Modulator and Filter Interface
PA Transmit Power Amplifier
PC Personal Computer
PCM Pulse Code Modulation
PCM SIO Synchronous serial bus for PCM audio transferring
PIFA Planar Inverted F-antenna
PWB Printed Wiring Board
RF Radio Frequency
SIM Subscriber Identity Module
UEM Universal Energy Management
UI User Interface
UPP Universal Phone Processor
VCXO Voltage Controlled Crystal Oscillator
VCTCXO Voltage Controlled Temperature Compensated Crystal Oscillator.
