Nokia 1661 User manual

Nokia 1661/1662 User Guide

Contents
Safety 4
Get started 6
Insert the SIM card and
battery 6
Remove the SIM card 7
Charge the battery 7
Switch on and off 8
Your phone 9
Keys and parts 9
Main features 10
Make and answer a
call 11
Write text 12
Message 14
Contacts 15
Multi-phonebook 15
Radio 16
Turn the flashlight on or
off 18
General
information 19
Accessories 20
Battery 21
Battery and charger
information 21
Nokia battery
authentication
guidelines 23
Taking care of your
device 24
Recycle 25
Additional safety
information 25
Small children 25
Operating
environment 25
Medical devices 26
Vehicles 27
Potentially explosive
environments 27
2Contents
© 2009 Nokia. All rights reserved.2

Emergency calls 28
Certification information
(SAR) 28
MANUFACTURER’S
LIMITED WARRANTY 29
Contents 3
© 2009 Nokia. All rights reserved. 3

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
4Safety
© 2009 Nokia. All rights reserved.4

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Safety 5
© 2009 Nokia. All rights reserved. 5

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-4C battery.
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
1 Slide the back cover downwards (1), and remove it.
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure that the gold-coloured
contact area is facing down and the bevelled corner of
the SIM card is slided in next.
4 Replace the battery and back cover (4, 5).
6Getstarted
© 2009 Nokia. All rights reserved.6

Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
Tip: To save energy, unplug the charger when the battery
is fully charged.
Get started 7
© 2009 Nokia. All rights reserved. 7

You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
Switch on and off
Press and hold the end key.
Use the phone only in its normal operating position.
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
8Getstarted
© 2009 Nokia. All rights reserved.8

Your phone
Keys and parts
1Flashlight
2Wrist strap eyelet
3Earpiece
4Display
5Selection keys
6Navi™ key;
hereafter referred
to as scroll key
7Call key
8End/Power key
9Keypad
10 Charger connector
11 Headset connector
12 Microphone
Your phone 9
© 2009 Nokia. All rights reserved. 9

Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.
Main features
Select Menu and from the following:
Messages — to create, send, open, and manage messages
Contacts — to save names and phone numbers in the SIM
card and phone memory
Call register — to access phone numbers of missed,
received, and dialled calls
Settings — to set up various features of your phone
Clock — to set the time for the alarm
Radio — to manage radio features
Reminders — to manage reminders
Games — to set up game effects or play the games
installed in your phone
10 Your phone
© 2009 Nokia. All rights reserved.10

Extras — to access various applications, such as the
calculator or flashlight
SIM services — to use additional services, if supported by
your SIM card
Make and answer a call
Make a call
Enter the phone number, including the country code and
area code, if necessary, and press the call key.
Answer a call
Press the call key.
End or reject a call
Press the end key.
Use the loudspeaker or earpiece
During a call, select Loudsp. or Hands..
Adjust the volume
During a call, scroll left or right to adjust the volume of the
earpiece or headset.
Your phone 11
© 2009 Nokia. All rights reserved. 11

Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Write text
Use traditional text input
Press a key repeatedly until the desired letter is displayed.
Activate predictive text input
Select Options > Dictionary and the desired language.
Deactivate predictive text input
Select Options > Dictionary > Dictionary off.
When using predictive text input, press each key once for
a single letter. If the desired word is displayed, press 0, and
start writing the next word. If ? is displayed after the word,
the word is not in the dictionary.
12 Your phone
© 2009 Nokia. All rights reserved.12

Change a word
Press *repeatedly until the desired word is displayed.
Add a word
Select Spell, enter the word using traditional text input,
and select OK.
Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the top of
the display.
Add a number
Press and hold the desired number key.
Add a special character
Press *when using traditional text input; press and hold
*when using predictive text input.
Undo clearing of a message
Select Options > Undo clear.
Your phone 13
© 2009 Nokia. All rights reserved. 13

Message
The message services can only be used if they are
supported by your service provider.
Your device supports text messages beyond the limit for a
single message. Longer messages are sent as two or more
messages. Your service provider may charge accordingly.
Characters with accents, other marks, or some language
options take more space, and limit the number of
characters that can be sent in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length indicator
shows how many characters you can enter in the
message.
3 Select Options > Send, enter the recipient's phone
number or select it from the contacts list, and select
OK.
Delete messages
Select Menu > Messages > Delete messages > All
read or the desired folder.
14 Your phone
© 2009 Nokia. All rights reserved.14

Contacts
You can save names and phone numbers in the phone and
SIM card memory. The contacts list can contain up to 500
contacts, stored in the phone memory.
Search for a contact
Scroll down in the standby mode, enter the first characters
or letters of the name, and scroll to the desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add contact.
Copy contacts between the phone and SIM card
memory
Select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate phonebooks for
multiple users. When the multi-phonebook is activated,
only the contacts in the active phonebook are visible.
A contact can belong to one or several phonebooks. The
contacts in Shared contacts are accessible from all
phonebooks.
Your phone 15
© 2009 Nokia. All rights reserved. 15

Select Menu > Contacts > Settings > Multi-
Phonebook and the appropriate options.
Activate the multi-phonebook
Select Phonebook style > Multi-Phonebook.
Activate a phonebook
Select Current phonebook and the desired phonebook or
Shared contacts.
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired phonebook.
Radio
The FM radio depends on an antenna other than the
wireless device antenna. A compatible headset or
accessory needs to be attached to the device for the FM
radio to function properly.
To open the radio, select Menu > Radio, or press and hold
*.
16 Your phone
© 2009 Nokia. All rights reserved.16

Select from the following:
Switch off — Close the radio.
Save channel — Save an active channel.
Auto-tuning — Tune radio channels automatically. To
start automatic tuning, scroll up or down.
Manual tuning — Tune radio channels manually. To
change the frequency, scroll up or down.
Set frequency — Enter a desired frequency.
Delete channel — Delete a saved channel.
Rename — Rename a saved channel.
Clock radio — Manage clock radio features.
Loudspeaker or Headset — Listen to the radio using the
loudspeaker or a headset.
To adjust the volume of the radio, scroll left or right.
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Your phone 17
© 2009 Nokia. All rights reserved. 17

Turn the flashlight on or off
Select Menu > Extras > Flashlight.
18 Your phone
© 2009 Nokia. All rights reserved.18

General information
About your device
The wireless device described in this
guide is approved for use on the EGSM
900 and 1800 MHz networks. Contact
your service provider for more
information about networks.
Your device may have preinstalled
bookmarks and links for third-party
internet sites and may allow you to
access third-party sites. These are not
affiliated with Nokia, and Nokia does
not endorse or assume liability for them.
If you access such sites, take precautions
for security or content.
Warning:
To use any features in this device, other
than the alarm clock, the device must be
switched on. Do not switch the device on
when wireless device use may cause
interference or danger.
When using this device, obey all laws
and respect local customs, privacy and
legitimate rights of others, including
copyrights. Copyright protection may
prevent some images, music, and other
content from being copied, modified, or
transferred.
Make back-up copies or keep a written
record of all important information
stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect
incompatible products.
The images in this guide may differ from
your device display.
Refer to the user guide for other
important information about your
device.
Network services
To use the device you must have service
from a wireless service provider. Some
features are not available on all
networks; other features may require
that you make specific arrangements
with your service provider to use them.
Network services involve transmission
of data. Check with your service provider
for details about fees in your home
network and when roaming on other
General information 19
© 2009 Nokia. All rights reserved. 19

networks. Your service provider can
explain what charges will apply.
Your service provider may have
requested that certain features be
disabled or not activated in your device.
If so, these features will not appear on
your device menu. Your device may also
have customized items such as menu
names, menu order, and icons.
Support
When you want to learn more about
how to use your product or you are
unsure how your device should
function, see the user guide or see the
support pages at www.nokia.com/
support or your local Nokia website, or
with a mobile device, www.nokia.mobi/
support.
If this does not resolve your issue, do the
following:
•Restart the device: switch off the
device, and remove the battery.
After about a minute, replace the
battery, and switch on the device.
•Restore the original factory
settings as explained in the user
guide.
If the issue remains unsolved, contact
Nokia for repair options. See
www.nokia-asia.com/repair. Before
sending your device for repair, always
back up the data in your device.
Accessories
Nokia original accessories
Warning:
Use only batteries, chargers, and
accessories approved by Nokia for use
with this particular model. The use of
any other types may invalidate any
approval or warranty, and may be
dangerous. In particular, use of
unapproved chargers or batteries may
present a risk of fire, explosion, leakage,
or other hazard.
For availability of approved accessories,
check with your dealer.
20 Accessories
© 2009 Nokia. All rights reserved.20
