User’s Guide for Nokia 6101

Copyright © 2005 Nokia. All rights reserved. i
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-76
is in conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright ©2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered
trademarks of Nokia Corporation. Other product and company names mentioned herein
may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright ©
1997-2005. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA
Security.
Java is a trademark of Sun Microsystems, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without
prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law,
no warranties of any kind, either express or implied, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document. Nokia reserves the
right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia
dealer nearest to you.
Export Controls
This device may contain commodities, technology or software subject to export laws
and regulations from the US and other countries. Diversion contrary to law is
prohibited.
Issue 2
ii Copyright © 2005 Nokia. All rights reserved.

Contents
For your safety............................ vii
General information ..................... x
Overview of functions ....................... x
Access codes ........................................ x
Security code............................................. x
PIN codes.................................................... x
PUK codes ................................................. xi
Barring password .................................... xi
Configuration settings service....... xi
Download content and
applications......................................... xi
Nokia support on the Web............. xii
1. Get started .............................. 1
Open the fold....................................... 1
Install the SIM card and the
battery ................................................... 1
Charge the battery ............................. 2
Switch the phone on and off .......... 2
Plug and play service .............................. 3
Normal operating position............... 3
Wrist strap............................................ 3
2. Your phone.............................. 4
Keys and parts ..................................... 4
Standby mode...................................... 5
Mini display............................................... 5
Main display.............................................. 5
Personal shortcut list.............................. 5
Shortcuts in the standby mode............ 6
Power saving............................................. 6
Indicators ................................................... 6
Keypad lock (keyguard)..................... 7
3. Call functions .......................... 8
Make a call........................................... 8
Speed dialing............................................. 8
Answer or reject a call...................... 8
Call waiting ............................................... 9
Options during a call......................... 9
4. Write text .............................. 10
Settings ............................................... 10
Predictive text input........................ 10
Write compound words....................... 11
Traditional text input ...................... 11
5. Navigate the menus.............. 12
6. Messages................................ 13
Text messages (SMS)....................... 13
Write and send a SMS message ....... 14
Read and reply to a SMS message... 14
Templates ................................................ 15
Multimedia messages (MMS) ....... 15
Write and send a multimedia
message ................................................... 15
Read and reply to a multimedia
message ................................................... 16
Memory full........................................ 17
Folders ................................................. 18
Flash messages.................................. 18
Write a flash message ......................... 18
Receive a flash message ..................... 18
Nokia Xpress audio messaging ..... 19
Create and send an audio message . 19
Receive an audio message.................. 19
Copyright © 2005 Nokia. All rights reserved. iii

Instant messaging (IM) .................. 19
Access the instant messaging
menu......................................................... 20
Connect to the instant messaging
service ...................................................... 20
Start an instant messaging session. 20
Accept or reject an invitation ........... 21
Read a received instant message..... 21
Participate in a conversation ............ 22
Edit your availability status ............... 22
Contacts for instant messaging........ 22
Block and unblock messages............. 23
Groups...................................................... 23
E-mail application........................... 23
Write and send an e-mail................... 24
Download e-mail .................................. 24
Read and reply to e-mail.................... 24
Inbox and other folders....................... 25
Delete e-mail messages ...................... 25
Voice messages................................. 25
Info messages ................................... 25
Service commands........................... 26
Delete messages............................... 26
Message settings ............................. 26
Text and SMS e-mail ........................... 26
Multimedia ............................................. 26
E-mail....................................................... 27
Other settings ........................................ 28
Message counter.............................. 28
7. Contacts ................................ 29
Search for a contact ....................... 29
Save names and phone
numbers.............................................. 29
Save numbers, items, or an
image................................................... 29
Copy contacts ................................... 30
Edit contact details......................... 30
Delete contacts or contact
details .................................................. 30
Business cards ................................... 31
My presence....................................... 31
Subscribed names............................. 32
Add contacts to the subscribed
names....................................................... 32
View the subscribed names................ 32
Unsubscribe a contact......................... 33
Settings ............................................... 33
Groups ................................................. 33
Voice dialing ...................................... 33
Add and manage voice tags............... 33
Make a call with a voice tag ............. 34
Speed dials ......................................... 34
Info, service, and my numbers...... 34
8. Call register ........................... 36
Recent calls lists............................... 36
Counters and timers ........................ 36
9. Settings ................................. 37
Profiles................................................. 37
Themes................................................. 37
Tones.................................................... 37
My shortcuts...................................... 38
Main display....................................... 38
Mini display........................................ 39
Time and date.................................... 39
Call........................................................ 39
Phone................................................... 40
Connectivity....................................... 41
Infrared .................................................... 41
Packet data (EGPRS) ............................ 42
Enhancements................................... 42
Configuration .................................... 43
Security ............................................... 44
Restore factory settings ................. 45
iv Copyright © 2005 Nokia. All rights reserved.

10. Operator menu .................... 46
11. Gallery.................................. 47
12. Media ................................... 48
Camera................................................ 48
Take a photo........................................... 48
Record a video clip ............................... 48
Radio ................................................... 48
Save radio channels ............................. 49
Listen to the radio ................................ 49
Recorder ............................................. 50
Record sound ......................................... 50
List of recordings .................................. 50
13. Organiser ............................. 51
Alarm clock........................................ 51
Stop the alarm....................................... 51
Calendar ............................................. 51
Make a calendar note.......................... 52
A note alarm........................................... 52
To-do list............................................ 52
Notes................................................... 52
Synchronization ............................... 53
Synchronize from your phone........... 53
Synchronization settings .................... 54
Synchronize from a compatible PC.. 54
Calculator........................................... 54
Stopwatch.......................................... 55
Countdown timer............................. 56
14. Applications......................... 57
Games ................................................. 57
Launch a game ...................................... 57
Game downloads................................... 57
Game settings........................................ 57
Collection........................................... 57
Launch an application......................... 57
Other application options................... 57
Download an application.................... 58
15. Push to talk.......................... 59
Push to talk menu ............................ 59
Connect to and disconnect PTT.... 60
Make and receive a PTT call .......... 60
Make a dial out PTT call...................... 60
Make a group call ................................. 61
Make a one-to-one call ...................... 61
Receive a PTT call.................................. 61
Callback requests.............................. 62
Send a callback request ...................... 62
Respond to a callback request .......... 62
Save the callback request sender..... 63
Add a one-to-one contact............. 63
Create and set up groups............... 63
PTT settings ........................................ 65
16. Web....................................... 66
Set up browsing................................ 66
Connect to a service........................ 66
Browse pages..................................... 67
Browse with phone keys ..................... 67
Options while browsing ...................... 67
Direct calling.......................................... 68
Appearance settings ........................ 68
Cookies ................................................ 68
Scripts over secure connection .... 69
Bookmarks.......................................... 69
Receive a bookmark ............................. 69
Download files................................... 69
Service inbox ..................................... 70
Service inbox settings.......................... 70
Cache memory................................... 70
Positioning information.................. 71
Browser security ............................... 71
Security module .................................... 71
Certificates.............................................. 72
Digital signature.................................... 73
Copyright © 2005 Nokia. All rights reserved. v

17. SIM services......................... 74
18. PC connectivity ................... 75
PC Suite .............................................. 75
Packet data, HSCSD, and CSD...... 75
Data communication
applications....................................... 75
19. Battery information ............ 76
Charging and discharging ............. 76
Nokia battery authentication
guidelines........................................... 77
20. Genuine Enhancements ...... 79
Power .................................................. 79
Compact Charger AC-3....................... 79
Audio................................................... 80
Nokia Stereo Headset HS-23............. 80
Nokia Display Headset HS-6.............. 80
21. Care and Maintenance........ 81
22. Additional safety
information ................................ 82
Index ........................................... 86
vi Copyright © 2005 Nokia. All rights reserved.

For your safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the phone on
when wireless phone use is
prohibited or when it may
cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless phones may get
interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions.
Switch the phone off near
medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions.
Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN
REFUELLING
Don't use the phone at a
refuelling point. Don't use
near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Don't
use the phone where blasting
is in progress.
USE SENSIBLY
Use only in the normal
position as explained in the
product documentation.
Don't touch the antenna
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
ENHANCEMENTS AND
BATTERIES
Use only approved
enhancements and batteries.
Do not connect incompatible
products.
WATER-RESISTANCE
Your phone is not
water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up
copies or keep a written
record of all important
information stored in your
phone.
CONNECTING TO OTHER
DEVICES
When connecting to any
other device, read its user
guide for detailed safety
instructions. Do not connect
incompatible products.
Copyright © 2005 Nokia. All rights reserved. vii

EMERGENCY CALLS
Ensure the phone is switched
on and in service. Press the
end key as many times as
needed to clear the display
and return to the start screen.
Enter the emergency number,
then press the call key. Give
your location. Do not end the
call until given permission to
do so.
■About your device
The wireless device described in this
guide is approved for use on the EGSM
900 and GSM 1800 and 1900 networks.
Contact your service provider for more
information about networks.
When using the features in this device,
obey all laws and respect the privacy and
legitimate rights of others.
Warning: To use any features in
this device, other than the
alarm clock, the device must be
switched on. Do not switch the
device on when wireless device
use may cause interference or
danger.
■Network services
To use the phone you must have service
from a wireless service provider. Many of
the features in this device depend on
features in the wireless network to
function. These network services may not
be available on all networks or you may
have to make specific arrangements with
your service provider before you can
utilize network services. Your service
provider may need to give you additional
instructions for their use and explain
what charges will apply. Some networks
may have limitations that affect how you
can use network services. For instance,
some networks may not support all
language-dependent characters and
services.
Your service provider may have requested
that certain features be disabled or not
activated in your device. If so, they will
not appear on your device menu. Your
device may also have been specially
configured for your network provider.
This configuration may include changes
in menu names, menu order and icons.
Contact your service provider for more
information.
This device supports WAP 2.0 protocols
(HTTP and SSL) that run on TCP/IP
protocols. Some features of this device,
such as text messages, multimedia
messages, audio messages, instant
messaging service, e-mail, presence
enhanced contacts, mobile Internet
services, content and application
download, and synchronization with a
remote Internet server, require network
support for these technologies.
viii Copyright © 2005 Nokia. All rights reserved.

■Shared memory
The phone has two memories. The
following features may share the first
memory: contacts, text messages,
multimedia messages (but no
attachments), instant messaging, groups,
voice commands, calendar, and to-do
notes. The second shared memory is used
by files stored in Gallery, attachments of
multimedia messages, e-mail, and JavaTM
applications. Use of one or more of these
features may reduce the memory
available for the remaining features
sharing memory. For example, saving
many Java applications may use all of the
available memory. Your device may
display a message that the memory is full
when you try to use a shared memory
feature. In this case, delete some of the
information or entries stored in the
shared memory features before
continuing. Some of the features, such as
text messages, may have a certain
amount of memory specially allotted to
them in addition to the memory shared
with other features.
■Enhancements
A few practical rules about accessories
and enhancements are as follows:
• Keep all accessories and
enhancements out of the reach of
small children.
• When you disconnect the power cord
of any accessory or enhancement,
grasp and pull the plug, not the cord.
• Check regularly that enhancements
installed in a vehicle are mounted
and are operating properly.
• Installation of any complex car
enhancements must be made by
qualified personnel only.
Copyright © 2005 Nokia. All rights reserved. ix

General information
■Overview of functions
Your phone provides many functions
that are practical for daily use, such
as a calendar, a clock, an alarm
clock, a radio, and a built-in camera.
Your phone also supports the
following functions:
• Enhanced data rates for GSM
evolution (EDGE), see "Packet
data (EGPRS)" on page 42.
• Extensible hypertext markup
language (XHTML), see "Web" on
page 66.
• Audio messaging, see "Nokia
Xpress audio messaging" on page
19.
• Instant messaging, see "Instant
messaging (IM)" on page 19.
• e-mail application, see "E-mail
application" on page 23.
• Push to talk, see "Push to talk" on
page 59.
• Presence-enhanced contacts, see
"My presence" on page 31.
• Java 2 Platform, Micro Edition
(J2METM), see "Applications" on
page 57.
■Access codes
Security code
The security code (5 to 10 digits)
helps to protect your phone against
unauthorized use. The preset code is
12345. To change the code, and to
set the phone to request the code,
see "Security" on page 44.
PIN codes
The personal identification number
(PIN) code and the universal
personal identification number
(UPIN) code (4 to 8 digits) help to
protect your SIM card against
unauthorized use. See "Security" on
page 44.
The PIN2 code (4 to 8 digits) may be
supplied with the SIM card and is
required for some functions.
The module PIN is required to access
the information in the security
module. See "Security module" on
page 71.
The signing PIN is required for the
digital signature. See "Digital
signature" on page 73.
xCopyright © 2005 Nokia. All rights reserved.

PUK codes
The personal unblocking key (PUK)
code and the universal personal
unblocking key (UPUK) code (8
digits) is required to change a
blocked PIN code and UPIN code,
respectively. The PUK2 code (8
digits) is required to change a
blocked PIN2 code. If the codes are
not supplied with the SIM card,
contact your local service provider
for the codes.
Barring password
The barring password (4 digits) is
required when using the Call barring
service. See "Security" on page 44.
■Configuration settings
service
To use some of the network services,
such as mobile Internet services,
MMS, Nokia Xpress audio
messaging, or remote Internet server
synchronization, your phone needs
the correct configuration settings.
You may be able to receive the
settings directly as a configuration
message. After receiving the settings
you need to save them on your
phone. The service provider may
provide a PIN that is needed to save
the settings. For more information
on availability, contact your network
operator, service provider, nearest
authorized Nokia dealer, or visit the
support area on the Nokia Web site,
<www.nokia-asia.com/support>.
When you have received a
configuration message
Configuration settings received is
displayed.
To save the settings, select Show >
Save. If the phone requests Enter
settings' PIN:, enter the PIN code for
the settings, and select OK. To
receive the PIN code, contact the
service provider that supplies the
settings. If no settings are saved yet,
these settings are saved and set as
default configuration settings.
Otherwise, the phone asks Activate
saved configuration settings?.
To discard the received settings,
select Exit or Show > Discard.
To edit the settings, see
"Configuration" on page 43.
■Download content and
applications
You may be able to download new
content (for example themes) to the
phone (network service). Select the
download function (for example, in
the Gallery menu). To access the
download function, see the
respective menu descriptions. For
the availability of different services,
pricing, and tariffs, contact your
service provider.
Copyright © 2005 Nokia. All rights reserved. xi

Important: Use only
services that you trust and
that offer adequate security
and protection against
harmful software.
■Nokia support on the
Web
Check
<www.nokia-asia.com/support> or
your local Nokia Web site for the
latest version of this guide,
additional information, downloads,
and services related to your Nokia
product.
xii Copyright © 2005 Nokia. All rights reserved.

Get started
Copyright © 2005 Nokia. All rights reserved. 1
1. Get started
■Open the fold
When you open the fold of the
phone, it opens up to approximately
155 degrees. Do not try to force the
fold open more.
■Install the SIM card and
the battery
Always switch the device off and
disconnect the charger before
removing the battery.
Keep all SIM cards out of the reach
of small children. For availability and
information on using SIM card
services, contact your SIM card
vendor. This may be the service
provider, network operator, or other
vendor.
This device is intended for use with
BL-4C battery.
The SIM card and its contacts can
easily be damaged by scratches or
bending, so be careful when
handling, inserting, or removing the
card.
To remove the back cover of the
phone press the release buttons (1),
and slide the back cover to remove it
from the phone (2).
Remove the battery as shown(3).
Release the SIM card holder (4).
Insert the SIM card (5). Make sure
that the SIM card is properly
inserted, and that the golden
contact area on the card is facing
downwards. Close the SIM card
holder (6) and press it until it snaps
into position.

Get started
2Copyright © 2005 Nokia. All rights reserved.
Replace the battery (7). Observe the
battery contacts. Always use original
Nokia batteries. See "Nokia battery
authentication guidelines" on page
77.
Slide the back cover into its place
(8, 9).
■Charge the battery
Warning: Use only
batteries, chargers, and
enhancements approved by
Nokia for use with this
particular model. The use of
any other types may
invalidate any approval or
warranty, and may be
dangerous.
Check the model number of any
charger before use with this device.
This device is intended for use when
supplied with power from an AC-3,
AC-4, and DC-4 charger, and from
AC-1, ACP-7, ACP-12, and LCH-12
charger when used with the charger
adapter CA-44.
For availability of approved
enhancements, please check with
your dealer.
1. Connect the charger to a wall
socket.
2. Connect the lead from the
charger to the socket on the
bottom of your phone.
If the battery is completely
discharged, it may take a few
minutes before the charging
indicator appears on the display or
before any calls can be made.
The charging time depends on the
charger and the battery used. For
example, charging a BL-4C battery
with the AC-3 charger takes
approximately 2 hours and 12
minutes while the phone is in the
standby mode.
■Switch the phone on
and off
Warning: Do not switch the
phone on when wireless
phone use is prohibited or
when it may cause
interference or danger.

Get started
Copyright © 2005 Nokia. All rights reserved. 3
Press and hold the end key.
If the phone asks for a PIN or a UPIN
code, enter the code (displayed as
****), and select OK.
Plug and play service
When you switch on your phone for
the first time, and the phone is in the
standby mode, you are asked to get
the configuration settings from your
service provider (network service).
Confirm or decline the query. See
"Connect to service provider
support", on page 44, and
"Configuration settings service" on
page xi.
■Normal operating
position
Use the phone only in its normal
operating position.
Your device has an external antenna.
Note: As with any other
radio transmitting device,
do not touch the antenna
unnecessarily when the
device is switched on.
Contact with the antenna
affects call quality and may
cause the device to operate
at a higher power level than
otherwise needed. Avoiding
contact with the antenna
area when operating the
device optimizes the
antenna performance and
the battery life.
■Wrist strap
Remove the back cover and the
battery. Insert the strap as shown in
the picture. Replace the battery and
the back cover.

Your phone
4Copyright © 2005 Nokia. All rights reserved.
2. Your phone
■Keys and parts
• Earpiece (1)
• Main display (2)
• Left selection key (3)
Middle selection key (4)
Right selection key (5)
The function of these keys
depends on the guiding text
shown on the display above the
keys.
• Volume key (6)
• 4-way navigation key (7)
Scroll up, down, left, and right.
• Call key (8)
• Push to talk (PTT) key, and camera
release key (9)
• Infrared (IR) port (10)
• End key and power key (11)
• Charger connector (12)
•Pop-Port
TM connector (13)
• Microphone (14)
• Loudspeaker (15)
• Camera lens (16)
• Mini display (17)

Your phone
Copyright © 2005 Nokia. All rights reserved. 5
■Standby mode
When the phone is ready for use, and
you have not entered any characters,
the phone is in the standby mode.
Mini display
When the fold is closed, the mini
display may show the following:
• The signal strength of the cellular
network at your current location
and the battery charge level
• The name of the network, or if
the phone is not in service, it is
indicated by a text note
• The time and date, the active
profile, and the alarm clock or
calendar note alerts
When you have an incoming call, the
caller’s name or number is shown if
it is identified.
Main display
• Name of the network or the
operator logo (1)
• Signal strength of the cellular
network at your current location
(2)
• Battery charge level (3)
• Left selection key is Go to (4).
• Middle selection key is Menu (5)
• Right selection key is Names (6)
or another shortcut to a function
that you selected. See "My
shortcuts" on page 38. Operator
variants may have an
operator-specific name to access
an operator-specific Web site.
Personal shortcut list
The left selection key is Go to.
To view the functions in the personal
shortcut list, select Go to. To
activate a function select it.
To view a list with available
functions, select Go to > Options >
Select options. To add a function to
the shortcut list, select Mark. To
remove a function from the list,
select Unmark.
To rearrange the functions on your
personal shortcut list, select Go to >
Options > Organise. Select the
desired function and Move and the
place where you want to move the
function.

Your phone
6Copyright © 2005 Nokia. All rights reserved.
Shortcuts in the standby
mode
• To access the list of dialed
numbers, press the call key once.
Scroll to the number or name
that you want; and to call the
number, press the call key.
• To open the web browser, press
and hold 0.
• To call your voice mailbox, press
and hold 1.
• Use the navigation key as a
shortcut. See "My shortcuts" on
page 38.
Power saving
A digital clock
view overwrites
the display when
no function of
the phone has
been used for a
certain period of
time. To activate
the power saver, see Power saver in
"Main display" on page 38, and
"Mini display" on page 39. To
deactivate the screen saver, open the
fold, or press any key.
Indicators
You received one or several
text or picture messages.
See "Read and reply to a
SMS message" on page 14.
You received one or several
multimedia messages. See
"Read and reply to a
multimedia message" on
page 16.
The phone registered a
missed call. See "Call
register" on page 36.
The keypad is locked. See
"Keypad lock (keyguard)" on
page 7.
The phone does not ring for
an incoming call or text
message when Incoming call
alert and Message alert tone
are set to Off. See "Tones" on
page 37.
The alarm clock is set to On.
See "Alarm clock" on page
51.
When the packet data
connection mode Always
online is selected and the
packet data service is
available, the indicator is
shown. See "Packet data
(EGPRS)" on page 42.

Your phone
Copyright © 2005 Nokia. All rights reserved. 7
A packet data connection is
established. See "Packet
data (EGPRS)" on page 42
and "Browse pages" on page
67.
The packet data connection
is suspended (on hold), for
example, if there is an
incoming or outgoing call
during a packet data dial-up
connection.
When the infrared
connection is activated, the
indicator is shown
continuously.
■Keypad lock (keyguard)
To prevent the keys from being
accidentally pressed, select Menu,
and press *within 3.5 seconds to
lock the keypad.
To unlock the keypad, select Unlock,
and press *. If the Security keyguard
is set On, enter the security code if
requested.
To answer a call when the keyguard
is on, press the call key. When you
end or reject the call, the keypad
automatically locks.
For Automatic keyguard and
Security keyguard, see "Phone" on
page 40.
When the keyguard is on, calls still
may be possible to the official
emergency number programmed
into your device.
