Nokia 2690 User manual

Nokia 2690 User Guide
Issue 2.0

Contents
Safety 5
Get started 7
Insert SIM card and
battery 7
Remove the SIM card 8
Insert a microSD card 8
Remove the microSD
card 9
Charge the battery 10
Antenna 11
Headset 12
Magnets and magnetic
fields 12
Keys and parts 13
Switch on and off 14
Standby mode 14
Keypad lock 16
Functions without a SIM
card 17
Applications running in
background 17
General
information 18
About your device 18
Network services 19
Shared memory 20
Access codes 20
Nokia support 21
Calls 23
Make and answer a
call 23
Loudspeaker 23
Dialling shortcuts 24
Write text 25
Text modes 25
Traditional text input 25
Predictive text input 26
Navigate the
menus 28
2Contents
© 2009 Nokia. All rights reserved.

Messaging 29
Text and multimedia
messages 29
Flash messages 32
Nokia Xpress audio
messages 32
E-mail 32
Instant messaging 33
Voice messages 34
Message settings 34
Contacts 36
Call log 38
Settings 39
Profiles 39
Tones 39
Display 40
Date and time 40
Shortcuts 40
Synchronisation and
backup 41
Connectivity 42
Calls and phone 44
Voice commands and
voice dialling 45
Enhancements 47
Configuration 47
Restore factory
settings 48
Operator menu 49
Gallery 50
Media 52
Camera and video 52
FM radio 53
Voice recorder 55
Music player 55
Applications 58
Organiser 60
Alarm clock 60
Calendar and to-do
list 60
Contents 3
© 2009 Nokia. All rights reserved.

Web or Internet 62
Connect to a web
service 63
SIM services 64
Nokia original
accessories 65
Practical rules about
accessories 66
Battery 66
Green tips 68
Save energy 68
Recycle 69
Learn more 69
Product and safety
information 69
Index 88
4Contents
© 2009 Nokia. All rights reserved.

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
Safety 5
© 2009 Nokia. All rights reserved.

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6Safety
© 2009 Nokia. All rights reserved.

Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect
the charger before removing the battery.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Press and slide the back cover towards the bottom of
the phone, and remove it (1).
2 Remove the battery (2).
3 Insert the SIM card into the holder with the contact
surface facing down (3).
Get started 7
© 2009 Nokia. All rights reserved.

4 Insert the battery (4), and replace the back cover (5).
Remove the SIM card
Insert a microSD card
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored
on the card.
Your phone supports microSD cards with a capacity of up
to 8 GB.
A compatible memory card may be supplied with the
device, and may already be inserted in the device. If not,
do the following:
8Getstarted
© 2009 Nokia. All rights reserved.

1 Open the cover of the memory card slot.
2 Insert the card into the memory card slot with the
contact surface facing up, and press until it locks into
place.
3 Close the cover of the memory card slot.
Remove the microSD card
Important: Do not remove the memory card during an
operation when the card is being accessed. Doing so may
Get started 9
© 2009 Nokia. All rights reserved.

damage the memory card and the device, and corrupt data
stored on the card.
You can remove or replace the memory card during phone
operation without switching the device off, but you need
to ensure that no application is currently accessing the
memory card.
Charge the battery
Your battery has been partially charged at the factory. If
the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2Connect the charger to the device.
10 Get started
© 2009 Nokia. All rights reserved.

3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging. If
the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
Antenna
Your device may have internal and external antennas.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
The figure shows the antenna area marked in grey.
Get started 11
© 2009 Nokia. All rights reserved.

Headset
Warning:
Continuous exposure to high volume may damage your
hearing. Listen to music at a moderate level, and do not
hold the device near your ear when the loudspeaker is in
use.
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it
can endanger your safety.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to
the Nokia AV Connector, pay special attention to volume
levels.
Do not connect products that create an output signal as
this may cause damage to the device. Do not connect any
voltage source to the Nokia AV Connector.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
12 Get started
© 2009 Nokia. All rights reserved.

Keys and parts
1Earpiece
2Display
3Selection keys
4Navi™ key; hereafter
referred to as scroll key
5Call key
6Keypad
7End/Power key
Get started 13
© 2009 Nokia. All rights reserved.

8Charger connector
9Headset connector (3.5
mm)
10 Camera lens
11 Microphone
12 Loudspeaker
13 Memory card slot
14 Wrist strap eyelet
15 Micro USB connector
Switch on and off
Press and hold the power key.
Standby mode
When the phone is ready for use, and you have not entered
any characters, the phone is in the standby mode.
14 Get started
© 2009 Nokia. All rights reserved.

1Network signal strength
2Battery charge level
3Network name or operator logo
4Functions of selection keys
The left selection key, Go to, allows you to access the
functions in your personal shortcut list. When viewing the
list, select Options > Select options to view the available
functions, or select Options > Organise to arrange the
functions in your shortcut list.
Get started 15
© 2009 Nokia. All rights reserved.

Keypad lock
To prevent accidental keypresses, select Menu, and press
*within 3.5 seconds to lock the keypad.
To unlock the keypad, select Unlock, and press *within 1.5
seconds. If the security keyguard is on, enter the security
code when requested.
To set the keypad to lock automatically after a preset time
when the phone is in the standby mode, select Menu >
Settings > Phone > Automatic keyguard > On.
To answer a call when the keypad is locked, press the call
key. When you end or reject the call, the keypad locks
automatically.
16 Get started
© 2009 Nokia. All rights reserved.

When the device or keypad is locked, calls may be possible
to the official emergency number programmed into your
device.
Functions without a SIM card
Some functions of your phone may be used without
inserting a SIM card, such as Organiser functions and
games. Some functions appear dimmed in the menus and
cannot be used.
Applications running in background
Leaving applications running in the background increases
the demand on battery power and reduces the battery life.
Get started 17
© 2009 Nokia. All rights reserved.

General information
About your device
The wireless device described in this guide is approved for
use on the (E)GSM 850, 900, 1800, and 1900 MHz
networks. Contact your service provider for more
information about networks.
Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access
third-party sites. These are not affiliated with Nokia, and
Nokia does not endorse or assume liability for them. If you
access such sites, take precautions for security or content.
Warning:
To use any features in this device, other than the alarm
clock, the device must be switched on. Do not switch the
device on when wireless device use may cause interference
or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some
images, music, and other content from being copied,
modified, or transferred.
18 General information
© 2009 Nokia. All rights reserved.

Make back-up copies or keep a written record of all
important information stored in your device.
When connecting to any other device, read its user guide
for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Refer to the user guide for other important information
about your device.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make
specific arrangements with your service provider to use
them. Network services involve transmission of data. Check
with your service provider for details about fees in your
home network and when roaming on other networks. Your
service provider can explain what charges will apply. Some
networks may have limitations that affect how you can use
some features of this device requiring network support
such as support for specific technologies like WAP 2.0
General information 19
© 2009 Nokia. All rights reserved.

protocols (HTTP and SSL) that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu
names, menu order, and icons.
Shared memory
The following features in this device may share memory:
multimedia messaging (MMS), e-mail application, instant
messaging. Use of one or more of these features may
reduce the memory available for the remaining features.
If your device displays a message that the memory is full,
delete some of the information stored in the shared
memory.
Access codes
The security code helps to protect your device against
unauthorised use. The preset code is 12345. You can create
and change the code, and set the device to request the
code. Keep the code secret and in a safe place separate
from your device. If you forget the code and your device is
locked, your device will require service. Additional charges
20 General information
© 2009 Nokia. All rights reserved.
