Nokia RH-92 User manual

nokia
CONNECTING PEOPLE PAGE 1 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
RH-92/93
Transceiver characteristics:
•Band: Dual-band phone
•- RH-93: GSM 900/1800MHz
•- RH-92: GSM 850/1900
•Display: FSTN 96 x 68 pixel monochrome display with
•white backlight
•Connector: Easy Flash connector
Transceiver with BL-5CA Li-Ion battery pack
Environmental characteristics:
•Lead-free soldered
Talk time Standby Note
Up to 5h Up to 10-15days Depends on network
parameters
SERVICE MANUAL
Service Level 1&2
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 2 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
TABLE OF CONTENT
Page
1. INTRODUCTION ...........................................................................................................................................................3
2. GENERAL REPAIR INFORMATION...............................................................................................................................4
3. PATHFINDER FOR WORKSHOP STAFF........................................................................................................................5
4. EXPLODED VIEW AND COMPONENT DISPOSAL.........................................................................................................6
5. COMPONENT OVERVIEW.............................................................................................................................................7
6. SPARE PARTS LIST.......................................................................................................................................................8
7. SERVICE TOOLS ............................................................................................................................................................9
8. SW-UPDATE .............................................................................................................................................................. 11
9. DISASSEMBLY INSTRUCTIONS................................................................................................................................. 12
10. LEGEND FOR QUICK TROUBLE SHOOTER ............................................................................................................ 15
11. QUICK TROUBLE SHOOTER PART 1..................................................................................................................... 16
12. QUICK TROUBLE SHOOTER PART 2..................................................................................................................... 17
13. GONOGO TEST....................................................................................................................................................... 18
14. BATTERY TEST ...................................................................................................................................................... 18
CHANGE HISTORY
Status Version No. Date Comments
Draft 0.1 16.Apr.2006 Initial draft
Approved 1.0 15.Mai.2006 Approval
Approved 2.0 14.Jun.2006 2310 RM-189 removed
Approved 3.0 03.Jul.2006 Battery changed from BL-5C to BL-5CA
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 3 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
1. INTRODUCTION
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to
NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it
is confidential. Please note that NOKIA provides also other guidance documents (e.g. Service Bulletins) for service
suppliers, follow these regularly and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may exist.
If you find any errors or if you have further suggestions, please notify NOKIA using the address below:
mailto:cc-ts-rc.docume[email protected]
Please keep in mind also that this documentation is continuously being updated and modified, so watch always
out for the newest version.
Warnings and Cautions
Please refer to the phone’s user guide for instructions relating to operation, care and maintenance including
important safety information. Note also the following:
Warnings:
1.
2.
3.
CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELECTRONIC ENGINE
MANAGEMENT SYSTEMS AND ANTI–SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT CONDITIONS, EMITTED RF
ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/MANUFACTURER TO
DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN
POTENTIALLY EXPLOSIVE ATMOSPHERES EG PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE
WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE
MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY
ALSO BE SUBJECT TO INTERFERENCE.
Cautions:
1. Servicing and alignment must be undertaken by qualified personnel only.
2. Ensure all work is carried out at an anti–static workstation and that an anti–static wrist strap is worn.
3. Use only approved components as specified in the parts list.
4. Ensure all components, modules screws and insulators are correctly re–fitted after servicing and alignment.
5. Ensure all cables and wires are repositioned correctly.
Electrostatic discharge can easily damage the sensitive components of electronic products.
Therefore every Service Supplier has to take care of all precautions, which are mentioned in
the service level related “Service Partner Requirements”, available on NOKIA Online. Also see
ESD Protection Requirements in this Service Manual.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 4 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
2. GENERAL REPAIR INFORMATION
In this section the technician will get some general hints how to carry out repairs:
oTo familiarize oneself with NOKIA product read the tutorials or user guide on www.nokia.com -->Support-->
Phones, by selecting the Phone Model.
oBefore starting the repair you must take care of ESD precautions like being in your ESD Protected Area and
connecting your wristband.
oUse gloves to avoid corrosion and fingerprints.
oProtect windows and displays with a film to avoid dust and scratches.
oWhen cleaning the LCD Module any lint-free cloth can be used (e.g. Micro-Fibre cloth).
oWhen cleaning the pads you have to use a soft cloth/ESD brush and Isopropanol. It is not allowed to use a
glass fiber pencil because it scratches the surface and will lead later on to corrosion.
oMechanical parts (except shielding lids and bent parts), which didn’t repair the failure, can be reused, if they
are not soldered.
oWhen removing the shielding lids make sure to replace them with new ones, otherwise the high-frequency
leakage can have an influence on the device.
oAlways use original NOKIA spare parts.
oCheck the soldering joints of the parts, which are concerned regarding the indicated error (e.g. soldered
connectors or switches) and resolder them if necessary (Level 2 only).
oRemove redundant soldering flux after repair.
oMeet the torque requirements when assembling the unit (see also the document “torques for transceiver
assembly” on NOKIA Online).
oAlways use your own equipment for testing where you are sure that it works. E.g. if the customer complains
about charger function, please test the phone with your own charger to be sure if phone or charger causes the
malfunction.
oA SIM card is needed for all GoNoGo tests.
oWhen doing the fault log entries, always note the Item code, which caused the malfunction. Also, fill in the
appropriate part code from the assembly, if needed.
oPlease be aware that some malfunctions could be software related and solved by an update.
oThere are several documents available on NOL, which have to be followed:
oFirst, take care for the latest content pages of Service Bulletins, which are always available for each folder on
NOKIA Online. This is also important to recognize, if existing documents have become invalid.
oThe service level indicator at the bottom of each document tells the appropriate destination.
Example:
Downloads > Support Library >
1. Instructions
2. General Service Bulletins
3. Product related documents
4. Spare Part Service Bulletins
5. Service Tools Service Bulletins
6. Common Software Service Bulletins
etc,…
Please also check NOKIA Online (NOL) for latest news and files on a regular basis.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 5 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
3. PATHFINDER FOR WORKSHOP STAFF
In addition to the information in this Service Manual, there are several instructions and information, which have to
be followed. Main documentation database is NOKIA Online with the purpose of serving different multimedia
content, like video clips or interactive tutorials.
It is mandatory to watch for newest technical and organizational information on a daily basis to be updated as
required (see “Latest files in Support Library”). Every new information has to be processed and implemented as
soon as possible.
When logged into NOL you can also find needed information in different folder like:
Support Library
Phones
Service Manuals
Service Bulletins
Software
Repair Information
Level 1&2 e-learning (former NOKIA CarePoint) on NOKIA Online
Former NOKIA CarePoint
content, such as
•Online Troubleshooting
•Product information
•Videos – Disassembly/Assembly
can be found on
NOKIA Online
NOKIA Online
Care Services
Training
Phone Models
Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use
the phone:
Overview & Guides
Basic information about the
phone, features and technologies
Disassembly & Assembly
Instructions how to disassemble
and assemble the phone
Troubleshooting
Step-by-step instructions on how to
locate and repair the most common
problems with the phone
To reduce the server traffic it is recommended to download newest version of huge files like videos, Phoenix
packages or Service Manuals only once and distribute it internally for further use.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 6 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
4. EXPLODED VIEW AND COMPONENT DISPOSAL
Recommendation for the ecologically friendly disposal of components. Colorized components show the different
categories. See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 7 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
5. COMPONENT OVERVIEW
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 8 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
6. SPARE PARTS LIST
Please exchange this page (placeholder) with latest corresponding Service
Bulletins (spare parts, SWAP units and service tools) from NOL!
This will ensure, that you are using up-to-date order codes only.
Therefore Service Bulletins have to be checked from NOL on daily basis.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 9 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
7. SERVICE TOOLS
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package,
developed specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Internal Battery BL-5CA
Inserted under the back cover, this Li-Ion battery provides power
in a lightweight package.
Travel Charger ACP-12
Small and lightweight charger for fast charging of your phone
battery.
Headset HS-7
Comfortable handsfree operation with a remote control button
for answering and ending calls makes this headset convenient
and easy-to-use.
CA-28DS
Service Cable is used to connect FLS-4S to SF-10 .
CA-65DS
Service Cable is used to connect FLS-4S to the phone.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 10 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
SF-10
POS Flash Adapter is used in POS (Point of Sales) environment for
software updating. It provides controlled supply voltage and
necessary connections between the phone and the Flash Device.
It substitutes for the phone’s standard battery during the
software update.
Test Pins
for Flash Adapter SF-10
RJ-79
Soldering Jig
Lead-free Solder Wire
Mandatory for lead-free products (Level 2 only).
0772040 NMP Standard Toolkit (V2)
For more informations refer to the Service Bulletin (SB-011) on
NOKIA Online.
Supplier or manufacturer contacts for tool re-order can be
found in “Recommended service equipment” document
on NOKIA Online.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 11 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
8. SW-UPDATE
Flash Concept – (Point of Sales)
To use FLS-4S Flash Dongle you have to follow the user guide inside the sales package. Please check always for the
latest version of flash software, which is available on NOKIA Online.
Easy Flash Concept POS Flash Concept
It is very important to follow this insertion and removal procedure, otherwise the contact pins of Flash Adapter
will be damaged (only for POS Flash Concept).
Insert the Flash Adapter SF-10 like a battery, start at the
Battery Connector side.
Now, push down the bottom side of the phone, do not
use too much force.
When removing the phone, always start from the bottom
side of the unit.
Now, take the unit away.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 12 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
9. DISASSEMBLY INSTRUCTIONS
1.) Needed tools for disassembly and assembly.
2.) Protect the window with a film.
3.) Press the Release Button and remove the B-Cover.
4.) Use the SRT-6 to unlock the A-Cover on both sides.
5.) Remove the A-Cover. Always start on the top side
of the device when re-assembling the A-Cover.
6.) Use SRT-6 to remove the Keymat and protect the
inner side of the window with a film.
For Nokia 1112 assembly only!
7.) Fit the Keymat to the A-Cover, paying attention to
its correct position.
8.) Unscrew the six, Torx Plus®size 6 screws in the
shown order. For assembly, use the reverse order and
a Torx Plus®size 6 driver with a torque setting of
24Ncm.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 13 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
9.) Lift the LCD Shielding while pressing on the LCD
Module with a clean cloth carefully.
10.) Remove the LCD Shielding.
11.) Remove the Acoustic Channel. 12.) Protect the LCD Module with a film.
13.) Take care to the surrounding components when
opening the LCD connector.
14.) Use the SRT-6 to open the LCD connector in the
order shown. Take care to the flex foil of the LCD
Module.
15.) Remove the LCD Module.
16.) Remove the Light Guide Assy.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 14 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
17.) Lift the Engine Module a bit with the SRT-6 and
remove it from the D-Cover Assy.
18.) The Antenna IHF Assy drops out when turning
the D-Cover Assy.
19.) Press out the Easy Flash Connector by using the
DC-plug.
20.) Remove the Microphone with the slotted
screwdriver.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 15 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
10.LEGEND FOR QUICK TROUBLE SHOOTER
This legend is valid for all parts of the Quick Trouble Shooter
Follow the steps until the problem is solved. If this doesn’t help, you are not authorized to go forward.
Only marked components ( e.g. I002 ) can be changed.
The start point of repair activities regarding the appeared fault symptoms.
Follow the arrows step by step
Pads or contacts: Check optical and mechanical condition particularly regarding
to corrosion. Clean if necessary.
Measure component for electrical functionality and change, if needed.
(Level 2 only)
Pads or contacts: Check optical and mechanical condition particularly regarding
to corrosion. Clean with ESD brush only, if necessary.
No more actions possible send product to the appropriate service supplier with
higher service level.
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 16 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
11.QUICK TROUBLE SHOOTER PART 1
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 17 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
12.QUICK TROUBLE SHOOTER PART 2
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.

nokia
CONNECTING PEOPLE PAGE 18 (18) Approved 3.0
CMO Operations & Logistics MGR
Training and Vendor Development
Multimedia Creation & Support Confidential 03.Jul.2006
13.GONOGO TEST
After the optical check, a GoNoGo test has to be carried out if the unit has been unscrewed to guarantee the
functionality of the phone.
Please refer to the actual information on NOKIA Online. When using delivered tester support files, take
care of the right setup according to the tester type and product type.
Please refer to “Recommended Service Equipment” on NOKIA Online.
Mobile Phone Tester
14.BATTERY TEST
A battery tester lets you test the capacity of NOKIA batteries.
Please refer to the actual information on NOKIA Online.
http://www.astratec.co.uk/
http://www.cadex.com/
Service Manual 1112 RM-92/93 Level 1&2 Copyright © 2006 NOKIA Corporation. All rights reserved.
