Nokia 6510 User manual

User’s Guide for Nokia 6510

List of menu functions
1. Messages
1. Write message
2. Inbox
3. Outbox
4. Archive
5. Templates
6. My folders
7. Erase messages
8. Voice messages
9. Info messages
10.Service command editor
11.Message settings
2. Call register
1. Missed calls
2. Received calls
3. Dialled numbers
4. Erase Recent Call Lists
5. Call duration
6. Call costs
7. GPRS data counter
8. GPRS connection timer
3. Profiles
1. General
2. Silent
3. Meeting
4. Outdoor
5. Pager
4. Settings
1. Alarm clock
2. Time settings
3. Call settings
4. Phone settings
5. Tone settings
6. Accessory settings1
7. GPRS modem settings
8. Security settings
9. Restore factory settings
5. Games
6. Calculator
7. To-do list
8. Calendar
9. Infrared
10. Radio
11. Extras
1. Voice Recorder
2. Wallet
3. Voice commands
4. Countdown timer
5. Stopwatch
12. Services
1. Home
2. Bookmarks
3. Service inbox
4. Settings
5. Go to address
6. Clear the cache
13. SIM services2
1. Shown only if accessory is connected.
2. The availability, name and contents depend on the SIM card used.
iv Copyright © 2004 Nokia. All rights reserved.

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the product
NPM-9 is in conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © Nokia Corporation 2001. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of Nokia Corporation.
Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia tune is a trademark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2001. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without
prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law,
no warranties of any kind, either express or implied, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document. Nokia reserves the
right to revise this document or withdraw it at any time without prior notice
The availability of particular products may vary by market. Please check with the Nokia
dealer nearest to you.
Issue 1
Copyright © 2004 Nokia. All rights reserved. v

Contents
FOR YOUR SAFETY....................... ix
General information .................... xi
Stickers in the sales package ......... xi
Access codes ....................................... xi
Overview of the functions of the
phone.......................................... xii
GPRS (General Packet Radio
Service) ................................................ xii
HSCSD (High Speed Circuit
Switched Data).................................. xii
WAP (Wireless Application
Protocol)............................................ xiii
Radio .................................................. xiii
Voice features.................................. xiii
1. Your phone .............................. 1
Keys and connectors.......................... 1
Standby mode...................................... 2
2. Getting started ........................ 4
Installing the SIM card and the
battery ................................................... 4
Charging the battery ......................... 5
Switching the phone on and off .... 5
Keypad lock (Keyguard)..................... 6
Changing the covers .......................... 7
3.Call functions............................ 8
Making a call ....................................... 8
Last number redialling............................ 8
Calling your voice mailbox.................... 8
Speed dialling a phone number........... 8
Making a conference call ...................... 9
Answering or rejecting an
incoming call ....................................... 9
Call waiting ............................................... 9
Options during a call ...................... 10
4. Writing text............................ 11
Using traditional text input........... 11
Using predictive text input............ 12
Setting predictive text input on
or off......................................................... 12
Writing words with predictive
text input ................................................ 12
5. Phone book (Names).............. 14
Selecting the phone book
settings................................................ 14
Saving names and phone
numbers (Add name) ....................... 14
Saving multiple numbers and
text items per name............................. 15
Searching for a name in the
phone book......................................... 16
Editing a name, number or
a text item.......................................... 16
Erasing names and numbers ......... 16
Copying phone books ...................... 16
Sending and receiving a
business card ..................................... 17
Speed dialling.................................... 17
Voice dialling..................................... 18
Adding a voice tag................................ 18
Making a call by using a
voice tag.................................................. 19
Replaying, changing or erasing
a voice tag .............................................. 19
Service numbers................................ 19
Caller groups...................................... 19
6. Using the menu...................... 21
Accessing a menu function ........... 21
vi Copyright © 2004 Nokia. All rights reserved.

7. Menu functions ..................... 22
Messages (Menu 1) ......................... 22
Writing and sending messages ......... 22
Options for sending a message......... 22
Text and picture templates ................ 23
Reading and replying to a
message................................................... 24
Inbox and outbox folders ................... 25
Erasing the messages........................... 25
Archive folder and My folders........... 25
Voice messages...................................... 25
Info messages ........................................ 26
Service command editor..................... 26
Message settings .................................. 26
Call register (Menu 2)..................... 26
Missed calls and received calls......... 27
Dialled numbers ................................... 27
Erase recent call lists........................... 27
Call counters and call timers............. 27
Profiles (Menu 3) ............................. 28
Settings (Menu 4)............................ 29
Alarm clock............................................. 29
Time settings.......................................... 29
Call settings............................................ 30
Phone settings ....................................... 31
Tone settings.......................................... 33
Accessory settings ................................ 33
GPRS modem settings ......................... 34
Security settings ................................... 34
Restore factory settings...................... 35
Games (Menu 5)............................... 35
Starting a game..................................... 35
Game settings........................................ 36
Calculator (Menu 6)........................ 36
Making a currency conversion.......... 37
To-do list (Menu 7) ......................... 37
Calendar (Menu 8)........................... 38
Making a calendar note...................... 39
When the phone alarms for
a note ....................................................... 39
Infrared (Menu 9)............................. 40
Radio (Menu 10)............................... 40
Tuning a radio channel........................ 41
Using the radio ...................................... 41
Extras (Menu 11).............................. 42
Voice Recorder....................................... 42
Wallet....................................................... 43
Voice commands ................................... 45
Countdown timer.................................. 45
Stopwatch............................................... 46
Mobile Internet services,
WAP (Menu 12)................................. 47
Basic steps for accessing and
using WAP services............................... 47
Setting up the phone for a WAP
service ...................................................... 47
Making a connection to a WAP
service ...................................................... 50
Browsing the pages of a WAP
service ...................................................... 51
Ending a WAP connection.................. 52
Appearance settings of the WAP
browser .................................................... 52
Download settings................................ 53
Bookmarks............................................... 53
Service inbox.......................................... 54
The cache memory................................ 54
Security indicator.................................. 55
Security module .................................... 55
SIM services (Menu 13).................. 57
8. Data and fax
communication........................... 58
Communication applications and
modem drivers................................... 58
PC Suite ................................................... 58
Modem setup ......................................... 58
Using data communication
applications ............................................ 59
Copyright © 2004 Nokia. All rights reserved. vii

9. Battery statements................ 60
Charging and Discharging............. 60
10. Genuine Accessories............ 61
Battery ................................................ 61
Indoor.................................................. 62
ACP-8 Fast & Light Charger .............. 62
Indoor & Vehicle .............................. 62
HDD-1 Dual Purpose Headset ........... 62
HDC-5 Personal Headset Kit.............. 62
Vehicle ................................................ 63
MBD-10 Phone Holder ........................ 63
LCH-9 Mobile Charger......................... 63
PPH-1 Plug and Play Handsfree ....... 63
11. Care And Maintenance ....... 64
12. mportant Safety
Information ................................ 65
Index ........................................... 70
viii Copyright © 2004 Nokia. All rights reserved.

FOR YOUR SAFETY
Read these simple guidelines. Breaking
the rules may be dangerous or illegal.
Further detailed information is given in
this manual.
Do not switch the phone on
when wireless phone use is
prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Don't use a hand-held phone
while driving.
INTERFERENCE
All wireless phones may get
interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any regulations or rules.
Switch the phone off near
medical equipment.
SWITCH OFF IN AIRCRAFT
Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELLING
Don't use the phone at a
refuelling point. Don't use near
fuel or chemicals.
SWITCH OFF NEAR BLASTING
Don't use the phone where
blasting is in progress. Observe
restrictions, and follow any
regulations or rules.
USE SENSIBLY
Use only in the normal position.
Don't touch the antenna
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may
install or repair phone
equipment.
ACCESSORIES AND BATTERIES
Use only approved accessories
and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your phone is not water-
resistant. Keep it dry.
BACKUP COPIES
Remember to make backup
copies of all important data.
CONNECTING TO OTHER DEVICES
When connecting to any other
device, read its user's guide for
detailed safety instructions. Do
not connect incompatible
products.
CALLING
Ensure the phone is switched on
and in service. Enter the phone
number, including the area code,
then press . To end a call,
press . To answer a call,
press .
EMERGENCY CALLS
Ensure the phone is switched on
and in service. Press as
many times as needed (e.g. to
exit a call, to exit a menu, etc.)
to clear the display. Enter the
emergency number, then press
. Give your location. Do
not end the call until told to do
so.
Copyright © 2004 Nokia. All rights reserved. ix

Network Services
The wireless phone described in this guide is approved for use on the EGSM 900 and
GSM 1800 network.
Dualband is a network dependent feature. Check with your local service provider if you
can subscribe to and use this feature.
A number of features included in this guide are called Network Services. These are
special services that you arrange through your wireless service provider. Before you can
take advantage of any of these Network Services, you must subscribe to them through
your service provider and obtain instructions for their use from your service provider.
Note: Some networks may not support all language-dependent characters
and/or services.
Check the model number of any charger before use with this device. This
device is intended for use when supplied with power from ACP-7, ACP-8 and
LCH-9.
Warning: Use only batteries, chargers and accessories approved by the phone
manufacturer for use with this particular phone model. The use of any other
types may invalidate any approval or warranty applying to the phone, and
may be dangerous.
For availability of approved accessories, please check with your dealer.
When you disconnect the power cord of any accessory, grasp and pull the
plug, not the cord.
x Copyright © 2004 Nokia. All rights reserved.

General information
■Stickers in the sales
package
The stickers contain important
information for service and
customer support purposes.
■Access codes
•Security code (5-10 digits): The
security code protects your
phone against unauthorised use,
and is supplied with the phone.
The preset code is 12345. Change
the code in the Settings menu,
see ”Security settings” on page
34. Keep the new code secret and
in a safe place separate from your
phone.
Set the phone to request the
code, see ”Security settings” on
page 34.
•PIN code (4 to 8 digits): The PIN
(Personal Identification Number)
code protects your SIM card
against unauthorised use. The
PIN code is usually supplied with
the SIM card.
Set the phone to request the PIN
code each time the phone is
switched on, see ”Security
settings” on page 34.
•PIN2 code (4 to 8 digits): The
PIN2 code may be supplied with
the SIM card and is required to
access some functions, such as
charging unit counters.
•PUK and PUK2 codes (8 digits):
The PUK (Personal Unblocking
Key) code is required to change a
blocked PIN code. The PUK2 code
is required to change a blocked
PIN2 code.
If the codes are not supplied with
the SIM card, contact your local
service provider for the codes.
•Barring password: The barring
password is needed when using
the Call barring service, see
”Security settings” on page 34.
The password is obtained from
your service provider.
•Wallet code (4-10 digits): The
wallet code is needed to access
the wallet services. For further
information, see ”Wallet” on
page 43.
•Signing PIN: The Signing PIN is
needed for the digital signature.
The signing PIN is supplied with
the SIM card if the SIM card has a
security module in it.
Copyright © 2004 Nokia. All rights reserved. xi

Overview of the functions of the phone
The Nokia 6510 phone provides
many functions which are very
practical for daily use, such as Clock,
Alarm clock, Countdown timer,
Games, Calculator, Calendar, Wallet
and many more.
■GPRS (General Packet
Radio Service)
GPRS is a technology that allows
mobile phones to be used for
sending and receiving data over the
mobile network. GPRS as such is a
data bearer that enables wireless
access to data networks such as the
Internet. The applications that use
GPRS are WAP, SMS messaging and
the GPRS dial-up (for example,
Internet and e-mail).
Before you can use GPRS
technology
• You need to subscribe to the
GPRS service.
For availability and subscription
to the GPRS service, contact your
network operator or service
provider.
• You need to save the GPRS
settings for the applications used
over GPRS.
See ”Setting up the phone for a
WAP service” on page 47.
See ”Message settings” on page
26.
See ”GPRS modem settings” on
page 34 and ”Data and fax
communication” on page 58.
Pricing for GPRS and applications
Both the active GPRS connection
and the applications used over GPRS,
for example using WAP services,
sending and receiving data and SMS
messages, are priced. For more
detailed information on pricing,
contact your network operator or
service provider.
■HSCSD (High Speed
Circuit Switched Data)
The phone enables you to use GSM
high-speed data services. You can
use high-speed functionality when
your phone is connected to a
computer via an IR connection and
when the modem drivers supporting
high-speed data software are
installed on your computer and
selected as an active modem.
xii Copyright © 2004 Nokia. All rights reserved.

For availability and subscription to
high-speed data services, please
contact your network operator or
service provider.
See also ”Data and fax
communication” on page 58.
■WAP (Wireless
Application Protocol)
You can access various WAP services
such as banking, news, weather
reports and flight times. These
services are specially designed for
mobile phones and they are
maintained by WAP service
providers.
Check the availability of WAP
services, pricing and tariffs with your
network operator and/or the service
provider whose service you wish to
use. Service providers will also give
you instructions on how to use their
services.
See ”Mobile Internet services, WAP
(Menu 12)” on page 47.
■Radio
Your phone has an integrated FM
radio. You can listen to the radio by
using a headset. See ”Radio (Menu
10)” on page 40.
■Voice features
Your phone offers you the following
voice features:
• Voice dialling - to make a call by
using a voice tag, see ”Voice
dialling” on page 18.
• Voice commands - to activate
certain functions in your phone
that are listed in the Voice
comms. menu, see ”Voice
commands” on page 45.
• Recorder - to make voice
recordings, see ”Voice Recorder”
on page 42.
Copyright © 2004 Nokia. All rights reserved. xiii

xiv Copyright © 2004 Nokia. All rights reserved.

Your phone
Copyright © 2004 Nokia. All rights reserved. 1
1. Your phone
■Keys and connectors
1. Power key,
Switches the phone on and off.
While in the phone book or in
menu functions, or when the
keypad is locked, pressing the
power key briefly turns the
phone’s display lights on for
approximately 15 seconds.
2. Volume keys
The upper key increases and the
lower key decreases the earpiece
(and headset) volume.
3. Selection keys, and
The function of the keys depends
on the guiding text shown on the
display above the keys, for
example Menu and Names in
standby mode.
4. Scroll keys, and
Enables scrolling through names,
phone numbers, menus or
settings.
5. dials a phone number, and
answers a call. In standby mode it
shows the most recently called
number.
6. ends an active call. Exits
from any function.
7. - enter numbers and
characters. Pressing and holding
calls your voice mailbox.
and are used for
various purposes in different
functions.

Your phone
2 Copyright © 2004 Nokia. All rights reserved.
1 - Charger connector
2 - Headset connector
3 - Infrared (IR) port
■Standby mode
When the phone
is ready for use,
and no
characters have
been entered by
the user, the
phone is in standby mode.
Selection keys in standby mode are
Menu and Names.
xxxx Indicates the cellular
network in which the phone
is currently being used.
Shows the signal strength of
the cellular network at your
current location. The higher
the bar, the stronger the
signal.
The signal strength indicator
is replaced with the
indicator when a GPRS
connection is set to Always
online. See ”Setting up the
phone for a WAP service” on
page 47.
Shows the battery charge
level. The higher the bar, the
more power in the battery.
Other essential indicators in
standby mode:
You have received one or
several text or picture
messages. See ”Reading and
replying to a message” on
page 24.
You have received one or
several voice messages. See
”Voice messages” on page
25.
The phone’s keypad is
locked. See ”Keypad lock
(Keyguard)” on page 6and
”Keyguard settings” on page
32.
The phone does not ring at
an incoming call or a text
message when Incoming
call alert is set to Off and
Message alert tone is set to
Off. See ”Tone settings” on
page 33.

Your phone
Copyright © 2004 Nokia. All rights reserved. 3
The alarm clock is set to On.
See ”Alarm clock” on page
29.
The countdown timer is
running. See ”Countdown
timer” on page 45.
GPRS modem connection is
established, refer to ”GPRS
modem settings” on page
34.
The is replaced with the
indicator if there is an
incoming or outgoing call
during a GPRS modem
connection. The GPRS
connection is suspended.
All your calls are diverted to
another number, Divert all
voice calls. If you have two
phone lines, the divert
indicator for the first line is
and for the second line
. See ”Call divert” on
page 30.
Calls are limited to a closed
user group (network
service). See ”Security
settings” on page 34.

Getting started
4 Copyright © 2004 Nokia. All rights reserved.
2. Getting started
■Installing the SIM card
and the battery
• Keep all miniature SIM cards out
of the reach of small children.
• The SIM card and its contacts can
easily be damaged by scratches
or bending, so be careful when
handling, inserting or removing
the card.
• Before installing the SIM card,
always make sure that the phone
is switched off and then remove
the battery.
1. With the back of the phone
facing you, press the back cover
release button (1) and slide the
back cover off the phone (2).
Remove the battery by lifting it
from the finger grip (3).
2. To release the SIM card holder,
slightly lift the front edge of the
cover on the card holder (4) and
slide it backwards (5). Open the
cover (6).
3. Insert the SIM card into the SIM
card holder (7). Make sure that
the SIM card is inserted properly
and that the golden contact area
on the card is facing downwards.
Close the cover of the SIM card
holder (8).

Getting started
Copyright © 2004 Nokia. All rights reserved. 5
4. Replace the battery (9).
5. Direct the back cover towards the
locking catches on the front
cover (10) and slide the back
cover until it locks into its place
(11).
■Charging the battery
1. Connect the lead of the charger
to the socket on the bottom of
your phone.
2. Connect the charger to an AC
wall socket.
The text Charging is displayed
briefly if the phone is switched
on. If the battery is completely
flat, it may take a few minutes
before the charging indicator
appears on the display or any
calls can be made.
You can use the phone while the
charger is connected.
The charging time depends on the
charger and the battery used. For
example, charging a BLB-2 battery
with the ACP-8 charger takes about
1 hour and 40 minutes.
■Switching the phone on
and off
Press and hold the
power key, .
Note that if the
phone displays
Insert SIM card even
though the SIM card
is properly inserted,
contact your
network operator or service provider.
Your phone does not support 5 Volt
SIM cards and the card may need to
be changed.

Getting started
6 Copyright © 2004 Nokia. All rights reserved.
• If the phone asks for a PIN code,
key in the PIN code (displayed
as ****), and press OK.
See also PIN code request in
”Security settings” on page 34
and ”Access codes” on page xi.
• If the phone asks for a security
code, key in the security code
(displayed as *****), and press OK.
See also ”Access codes” on
page xi.
Warning: Do not switch the
phone on when wireless
phone use is prohibited or
when it may cause
interference or danger.
TIPS ON EFFICIENT
OPERATION: Your
phone has a built-
in antenna. As
with any other
radio transmitting
device, do not
touch the antenna
unnecessarily
when the phone is
switched on.
Contact with the
antenna affects
call quality and
may cause the
phone to operate at a higher power
level than otherwise needed. Not
touching the antenna area during a
phone call optimises the antenna
performance and the talktime of
your phone.
■Keypad lock (Keyguard)
You can lock the keypad to prevent
the keys being accidentally pressed.
•Locking the keypad
In standby mode, press Menu
and then within 1.5
seconds to lock the keypad.
When the keypad is locked,
appears at the top of the display.
•Unlocking the keypad
Press Unlock and then
within 1.5 seconds to unlock the
keypad.
•When the keyguard is on
To answer a call, press .
During a call, the phone can be
operated normally. When you end
or reject the call, the keypad will
automatically be locked. See also
”Keyguard settings” on page 32.

Getting started
Copyright © 2004 Nokia. All rights reserved. 7
Note: When Keyguard is on,
calls may be possible to the
emergency number
programmed into your
phone (e.g. 112 or other
official emergency number).
Key in the emergency
number and press .
The number is displayed
only after you have keyed in
its last digit.
■Changing the covers
Before changing the cover, always
switch off the power and disconnect
the phone from the charger or any
other device. Always store and use
the phone with the covers attached.
1. Remove the back cover of the
phone. With the back of the
phone facing you, press the back
cover release button and slide the
cover off the phone. See
”Installing the SIM card and the
battery” on page 4.
2. Gently pull the phone off the
front cover starting from the
bottom of the phone (1).
3. Replace the key mat on the new
front cover (2).
4. To replace the front cover, align
the top of the phone with the top
of the front cover (3) and gently
push the phone towards the
cover (4). Ensure that the front
cover is closed into place.
5. Replace the back cover of the
phone. Direct the back cover
towards the locking catches on
the front cover and slide the back
cover until it locks into place. See
”Installing the SIM card and the
battery” on page 4.

Call functions
8 Copyright © 2004 Nokia. All rights reserved.
3. Call functions
■Making a call
1. Key in the phone number,
including the area code. To edit
the number on the display, press
or to move the
cursor and Clear to delete the
character to the left of the cursor.
For international calls, press
twice for the international
prefix (the + character replaces
the international access code)
and then key in the country code,
area code and the phone number.
2. Press to call the number.
3. Press or End call to end
the call (or to cancel the call
attempt).
When you are using the phone with
the Handsfree Car Kit, PPH-1 or
CARK 132, you can switch from
handsfree mode to privacy mode by
disconnecting the PPH-1 or CARK
132 from the phone. To switch back
to handsfree, plug the PPH-1 or
CARK 132 into the phone.
Making a call using the phone book
1. See ”Searching for a name in the
phone book” on page 16
2. Press to call the number
on the display.
Last number redialling
In standby mode, press once
to access the list of the twenty
numbers you last called or
attempted to call. Scroll to the
number or name you want, and press
to call the number.
Calling your voice mailbox
In standby mode, press and hold
, or press and .
If the phone asks for the voice
mailbox number, key it in and press
OK. See also ”Voice messages” on
page 25.
Speed dialling a phone
number
Assign a phone number to one of the
speed dialling keys, from ( to
), and you can call that number
in either of the following ways:
• Press the speed dialling key you
want and then press .
•IfSpeed dialling is set to on,
press and hold a speed dialling
key until the call is started. See
”Speed dialling” on page 31.
See also ”Speed dialling” on page
17.
