Nokia C2-03 User manual

Nokia C2-03/C2-06 User Guide
Issue 1.3

Contents
Safety 4
Get started 5
Your dual SIM phone 5
Keys and parts 5
Insert a SIM card and battery 6
Insert a second SIM card 7
Insert a memory card 8
Charge the battery 9
Attach a strap 10
Switch the phone on or off 10
GSM antenna 11
Basic use 11
Access codes 11
Set which SIM card to use 12
Lock or unlock the keys and screen 13
Touch screen actions 13
Swipe to open an application or
activate a feature 14
Indicators 14
Copy contacts or messages from your
old phone 15
Change the volume of a call, song, or
video 16
Calls 16
Make a call 16
Call the last dialled number 16
View your missed calls 17
Contacts 17
Save a name and phone number 17
Use speed dial 17
Write text 18
Switch between text input modes 18
Write using traditional text input 18
Use predictive text input 19
Messaging 19
Send a message 19
Retrieve a multimedia message 20
Listen to voice messages 21
Send an audio message 21
Personalise your phone 21
About the home screen 21
Personalise the home screen 22
Personalise your phone tones 22
Time management 23
Change the time and date 23
Set an alarm 24
Add an appointment 24
Connectivity 24
Bluetooth 24
USB data cable 25
Music and audio 26
FM radio 26
Media player 27
Pictures and videos 28
Take a picture 28
Record a video 28
Send a picture or video 28
Web 29
About the web browser 29
Browse the web 29
Fit a web page to your phone display 30
Add a bookmark 30
Clear your browsing history 31
Keep in touch with your online
friends 31
About Communities 31
Mail and chat 31
About Mail 31
2Contents

Send a mail 32
Read and reply to mail 32
About Chat 32
Chat with your friends 32
Maps 33
About Maps 33
View your current location on the
map 34
Find a place 34
Share your location or a place 34
Create a walking route 35
Nokia's Ovi services 35
Availability and costs of Nokia's Ovi
services 35
Access Nokia's Ovi services 35
Find help 35
Support 35
Keep your phone up to date 36
Nokia original accessories 38
Practical rules about accessories 38
Battery 39
Product and safety information 39
Index 46
Contents 3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
4Safety

Get started
Your dual SIM phone
You can insert two SIM cards.
Some benefits of a dual SIM phone
•You can make savings when you use services from different service providers.
•Use one phone number for personal calls and another for work, but carry only
one phone.
•Avoid network coverage variation between service providers.
Both SIM cards are available at the same time when the device is not being used, but
while one SIM card is active, for example, making a call, the other is unavailable.
If you only have one SIM card, insert the card into the SIM1 card holder. Some features
and services may only be available when using the SIM card in the SIM1 card holder.
If there is a SIM card only in the SIM2 card holder, you can only make emergency calls.
A GPRS connection cannot be open in the background. If an application is using a GPRS
connection, and you return to the home screen or switch to another application,
menu, or other view, the connection is automatically closed.
Keys and parts
1Display
Get started 5

2Call key
3Keypad
4Earpiece
5Wrist strap hole
6Volume up/Zoom in key
7Volume down/Zoom out key
8Key lock switch
9End/Power key
10 Microphone
11 Nokia AV Connector (3.5 mm)
12 Micro-USB connector
13 Charger connector
14 Camera lens. Before using the camera, remove the protective tape from the lens.
15 Loudspeaker
16 SIM card slot (SIM 2)
To switch between SIM cards, on the home screen, press and hold *.
Insert a SIM card and battery
Note: Switch the device off and disconnect the charger and any other device
before removing any covers. Avoid touching electronic components while changing
any covers. Always store and use the device with any covers attached.
Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card. Please consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.
Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.
This phone is intended for use with a BL-5C battery. Always use original Nokia
batteries.
If you only have one SIM card, insert the card into the internal SIM card holder.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Place your finger in the recess at the top of the phone, and carefully lift and
remove the back cover (1). If the battery is inserted, lift it out (2).
6 Get started

2 Open the SIM card holder (3), and insert or remove the SIM card (4 or 5). Make
sure the contact area of the card is facing down.
3 Line up the contacts of the battery and the battery compartment, and insert the
battery (6). To replace the back cover, direct the bottom locking catches toward
their slots (7), and press down until the cover locks into place (8).
Insert a second SIM card
Have a second SIM card, but want to keep using your main SIM card? You can insert
or remove a second SIM card without switching the phone off.
Get started 7

1 Open the cover of the external SIM card slot, marked with .
2 Make sure the contact area of the card is facing up, and insert the SIM card. Push
the card in, until it locks into place. Close the cover.
Remove the second SIM card
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
Your phone supports memory cards with a capacity of up to 32 GB.
8 Get started

1 Switch the phone off, and remove the back cover and battery.
2 To release the memory card holder, slide the holder in the direction indicated by
the arrow on the holder. Lift the memory card holder (1).
3 Insert a compatible memory card. Make sure the contact area of the card is facing
down (2).
4 Lower the memory card holder (3).
5 To lock the memory card holder, slide the holder to its original position (4).
Remove the memory card
1 Switch the phone off.
2 Remove the back cover and battery.
3 To release the memory card holder, slide the holder in the direction indicated by
the arrow on the holder. Lift the memory card holder, and remove the memory
card.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time. If the phone indicates a low
charge, do the following:
Get started 9

1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Attach a strap
Straps may be available separately.
Switch the phone on or off
Press and hold the power key .
10 Get started
