Nokia C2-05.1 User manual

Nokia C2–05.1 User Guide
5555555
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Contents
Safety 5
Get started 7
Keys and parts 7
Insert a SIM card and
battery 9
Insert a memory card 11
Charge the battery 13
Switch the device on or
off 14
GSM antenna 16
Attach a strap 17
Basic use 17
Access codes 17
Lock the keys 18
Indicators 19
Copy contacts or
pictures from your old
device 20
Change the volume of a
call, song, or video 21
Use your device offline 22
Calls 22
Make a call 22
Call the last dialled
number 23
View your missed calls 23
Contacts 24
Save a name and phone
number 24
Use speed dial 24
Write text 25
Switch between text
input modes 25
Write using traditional
text input 26
Use predictive text
input 27
Messaging 28
Send a message 28
Listen to voice
messages 30
Send an audio message 30
Personalise your
device 31
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

About the home screen 31
Personalise the home
screen 32
Personalise your device
tones 33
Connectivity 33
Bluetooth 33
USB data cable 35
Music and audio 36
Media player 36
FM radio 40
Mail and Chat 42
About Mail 42
Send a mail 43
Read and reply to mail 43
About Chat 43
Chat with your friends 44
Web 44
About the web browser 44
Browse the web 45
Clear browsing history 45
Nokia's Ovi services 46
Ovi by Nokia 46
Availability and costs of
Nokia's Ovi services 47
Access Nokia's Ovi
services 47
Camera and video 47
Take a picture 47
Record a video 48
Send a picture or video 49
Find help 50
Support 50
Subscribe to the Tips
and Offers service 51
Keep your device up to
date 51
Protect the
environment 55
Save energy 55
Recycle 56
Product and safety
information 56
www.nokia.com/support 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Index 69
4 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is
not allowed or when it may cause interference
or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair
this product.
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do
not hold the device near your ear when the
loudspeaker is in use.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Get started
Keys and parts
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1Earpiece
2Display
3Selection keys
4Call key
5Keypad
6Navi™ key (scroll key)
7End/Power key
8Wrist strap hole
9Loudspeaker
10 Camera lens
8
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

11 Microphone
12 Charger connector
13 Micro-USB connector
14 Nokia AV connector (3.5 mm)
Insert a SIM card and battery
Note: Switch the device off and disconnect the charger
and any other device before removing any covers. Avoid
touching electronic components while changing any
covers. Always store and use the device with any covers
attached.
Important: To prevent damage to the SIM card, always
remove the battery before you insert or remove the card.
This device is intended for use with a BL-4C battery. Always
use original Nokia batteries.
The SIM card and its contacts can be easily damaged by
scratches or bending, so be careful when handling,
inserting, or removing the card.
1 Place your finger in the recess at the top of the device,
and carefully lift and remove the back cover (1).
2 If the battery is inserted, lift the battery out (2).
9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

3 Insert or remove the SIM card (3 or 4). Make sure the
contact area of the card is facing down.
10
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

4 Line up the contacts of the battery and the battery
compartment, and insert the battery (5). To replace the
back cover, direct the bottom locking catches toward
their slots (6), and press down until the cover locks into
place (7).
Insert a memory card
Use only compatible memory cards approved by Nokia for
use with this device. Incompatible cards may damage the
card and the device and corrupt data stored on the card.
Your device supports memory cards with a capacity of up
to 32 GB.
11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1 Remove the back cover.
2 Insert the memory card. Make sure the contact area of
the card is facing down. Push the card in, until it locks
into place.
3 Replace the back cover.
Remove the memory card
Important: Do not remove the memory card when an
application is using it. Doing so may damage the memory
card and the device, and corrupt data stored on the card.
You can remove or replace the memory card without
switching the device off.
12
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1 Remove the back cover.
2 Push the card in, until it is released, and pull the card
out.
3 Replace the back cover.
Charge the battery
Your battery has been partially charged at the factory, but
you may need to recharge it before you can switch on your
device for the first time.
If the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

You do not need to charge the battery for a specific length
of time, and you can use the device while it is charging.
During charging, the device may feel warm.
If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the
display or before any calls can be made.
If the battery has not been used for a long time, to begin
charging, you may need to connect the charger, then
disconnect and reconnect it.
Charging the device while listening to the radio may affect
the quality of reception.
Switch the device on or off
Press and hold the power key .
14
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

You may be prompted to get the configuration settings
from your service provider (network service). For more
information, contact your service provider.
15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

GSM antenna
The figure shows the GSM antenna area marked in grey.
Avoid touching the antenna area unnecessarily while the
antenna is transmitting or receiving. Contact with
antennas affects the communication quality and may
cause a higher power level during operation and may
reduce the battery life.
16
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Attach a strap
Straps may be available separately.
Basic use
Access codes
The security code helps to protect your device against
unauthorised use. You can create and change the code, and
set the device to request the code. Keep the code secret
and in a safe place separate from your device. If you forget
the code and your device is locked, your device will require
service. Additional charges may apply, and all the personal
data in your device may be deleted. For more information,
contact a Nokia Care point or your device dealer.
The PIN code supplied with the SIM card protects the card
against unauthorised use. The PIN2 code supplied with
17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

some SIM cards is required to access certain services. If you
enter the PIN or PIN2 code incorrectly three times in
succession, you are asked for the PUK or PUK2 code. If you
do not have them, contact your service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
To set how your device uses the access codes and security
settings, select Menu > Settings > Security.
The personal unblocking key (PUK) code and the universal
personal unblocking key (UPUK) code (8 digits) are required
to change a blocked PIN code and UPIN code, respectively.
The PUK2 code (8 digits) is required to change a blocked
PIN2 code. These codes are not supplied with the SIM card.
Contact your local service provider for the codes.
Lock the keys
To avoid accidentally making a call when your device is in
your pocket or bag, lock the keys.
Close the slide, and select Lock.
Unlock the keys and screen
Select Unlock, and press *.
18
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Set the keys to lock automatically
1 Select Menu > Settings and Device > Automatic
keyguard > Automatic keyguard on.
2 Define the length of time after which the keys are
locked automatically.
Indicators
You have unread messages.
You have unsent, cancelled, or failed
messages.
The keypad is locked.
The device does not ring for incoming calls or
text messages.
An alarm is set.
or The device is registered to the GPRS or EGPRS
network.
or A GPRS or EGPRS connection is open.
or The GPRS or EGPRS connection is suspended
(on hold).
Bluetooth is activated.
All incoming calls are diverted to another
number.
Calls are limited to a closed user group.
The currently active profile is timed.
A headset is connected to the device.
19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

The device is connected to another device,
using a USB data cable.
Copy contacts or pictures from your old device
Want to copy your content from your previous compatible
Nokia device and start using your new device quickly? You
can copy, for example, contacts, calendar entries, and
pictures to your new device, free of charge.
1 Activate Bluetooth in both devices.
