Nokia N900 User manual

Contents
Safety 6
About your device 6
Network services 7
Shared memory 7
Set up your device 8
Insert the SIM card and battery 8
Insert the memory card 9
Charge the battery 10
Keys and parts 11
Keys and parts (front) 11
Keys and parts (back) 12
Keys and parts (top) 12
Keys and parts (sides) 12
First start-up 13
Switch the device on 13
Start-up wizard 13
Kickstand 13
Stylus 14
Use accessories 14
Headset 14
Wrist strap 14
Introduction 15
About Maemo software 15
About the desktop 15
Application menu 16
Status area and status menu 16
Dashboard 18
About the touch screen 18
Basic use 19
About your device 19
Protect your device 21
Text input 21
Use shortcuts 24
Personalise your device 25
Edit and personalise the desktop 25
Profile settings 26
Change the background image 26
Change the device language 26
Change themes 27
Connect your device 27
About connectivity 27
Network settings 27
Use a WLAN connection 28
Use packet data connection 31
Active data connections 32
Disable wireless connections 32
Internet connection settings 33
Bluetooth connectivity 33
2Contents

USB connections 35
Browse the web 35
About browser 35
Open and browse web pages 36
Browser toolbar 37
Organise bookmarks 37
Clear private data 37
Connection security 38
Download files 38
Save web pages 39
View browsing history 39
Install add-ons 39
Modify browser settings 40
Organise your contacts 41
Add and edit contacts 41
Add and edit My information 42
Sort contacts 42
Import and export contacts 42
Send contact cards 43
Add shortcuts to desktop 43
Synchronise your contacts 44
Contacts settings 44
Make calls 44
About calls 44
Proximity sensor 44
Make voice calls 45
Make internet calls 47
Options during a call 48
Call timers 48
Emergency calls 48
Send text and instant messages 49
About Conversations 49
Send text messages 49
Send instant messages 50
Delete messages and conversations 51
Filter conversations 52
Text message and instant message settings 52
Mail 52
About mail 52
Read your work mail using Mail for Exchange 52
Set up your mail 53
Read and send mail 55
Organise your mail 57
Synchronise with Mail for Exchange 58
Modify mail settings 58
Capture images and record video clips 61
Camera 61
Capture images 62
Record video clips 64
Change camera settings 65
View images with Photos 67
Share your images and video clips 69
About sharing content 69
Contents 3

Create a sharing account 70
Share items 70
Tags 70
Share items using Bluetooth connectivity 70
Send items using mail 71
Modify sharing settings 71
View sharing status 71
Edit sharing account 71
Play music and video clips 72
About Media player 72
File formats 72
Add the media widget to desktop 73
Search for media files 73
Play music with Media player 73
Use the FM transmitter 75
Play video clips with Media player 75
Listen to internet radio with Media player 76
Browse media servers 77
Find and view locations 77
Positioning (GPS) 77
Ovi Maps for mobile 79
Synchronise and transfer content from another
device 80
Synchronise content 80
Transfer data 81
Manage transfer details 81
Back up and restore data 82
About backups 82
Create a new backup 82
Restore a backup 82
Update software and install applications 82
About Application manager 82
Install additional applications 83
Add catalogues 84
Check for updates 85
Update software 85
Manage time 86
View time and set alarms 86
View and manage calendar 87
Use utilities and manage data 90
Manage files 90
Memory 90
Restore the original settings 91
Use utilities 92
Play games 94
Blocks 94
Chess 95
Mahjong 95
Marbles 96
Install other games 97
Modify settings 97
Modify personalisation settings 97
4Contents

Modify connectivity settings 99
Modify general settings 102
Third party application settings 102
Open source software notice 103
Standards 103
Accessories 104
Battery 104
Battery and charger information 104
Nokia battery authentication guidelines 105
Taking care of your device 105
Recycle 105
Additional safety information 106
Small children 106
Operating environment 106
Medical devices 106
Vehicles 106
Potentially explosive environments 106
Emergency calls 107
Certification information (SAR) 107
Index 108
Contents 5

Safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for further
information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in
aircraft, near medical equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do
not connect incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
About your device
The wireless device described in this guide is approved for
use on the (E)GSM 850, 900, 1800, 1900, and UMTS 900, 1700,
2100 networks. Contact your service provider for more
information about networks.
Your device may have preinstalled bookmarks and links for
third-party internet sites and may allow you to access third-
party sites. These are not affiliated with Nokia, and Nokia
does not endorse or assume liability for them. If you access
such sites, take precautions for security or content.
6Safety

Warning:
To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on
when wireless device use may cause interference or danger.
When using this device, obey all laws and respect local
customs, privacy and legitimate rights of others, including
copyrights. Copyright protection may prevent some images,
music, and other content from being copied, modified, or
transferred.
Make back-up copies or keep a written record of all important
information stored in your device.
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible
products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about
your device.
Network services
To use the device you must have service from a wireless
service provider. Some features are not available on all
networks; other features may require that you make specific
arrangements with your service provider to use them.
Network services involve transmission of data. Check with
your service provider for details about fees in your home
network and when roaming on other networks. Your service
provider can explain what charges will apply. Some networks
may have limitations that affect how you can use some
features of this device requiring network support such as
support for specific technologies like WAP 2.0 protocols (HTTP
and SSL) that run on TCP/IP protocols and language-
dependent characters.
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
these features will not appear on your device menu. Your
device may also have customized items such as menu names,
menu order, and icons.
Shared memory
The following features in this device may share memory:
bookmarks; image, audio, and video files; notes, sketch, and
other files; contacts; e-mail messages; and applications. Use
of one or more of these features may reduce the memory
available for the remaining features. If your device displays
a message that the memory is full, delete some of the
information stored in the shared memory.
Safety 7

Set up your device
Insert the SIM card and battery
Always switch the device off and disconnect the charger
before removing the battery.
Important: To prevent damage to the SIM card, always
remove the battery before you insert or remove the card.
1 To prevent the battery from coming loose, place the
device so that the back cover is facing up.
2 Place your finger in the grip, and lift the back cover up.
You do not need to press a button to release the back
cover.
3 To release the SIM card holder, slide the holder to the left
(1), and lift the right end of the holder up (2). Make sure
that the bevelled corner on the card is facing up, and that
the contact area on the card is facing the connectors on
the device (3). Close the holder (4), and slide it to the right
to lock it into place (5).
4 Align the contacts of the battery with the corresponding
connectors on the battery compartment, and insert the
battery in the direction of the arrow.
5 To replace the back cover, direct the locking catch toward
its slot, and press down until the cover locks into place.
8 Set up your device

Insert the memory card
Use only compatible MicroSD cards approved by Nokia for use
with this device. Nokia uses approved industry standards for
memory cards, but some brands may not be fully compatible
with this device. Incompatible cards may damage the card
and the device and corrupt data stored on the card.
The memory card can be safely inserted or removed even
when the device is switched on.
A memory card may be already inserted in the device. If not,
do the following:
1 To prevent the battery from coming loose, place the
device so that the back cover is facing up.
2 Place your finger in the grip, and lift the back cover up.
You do not need to press any button to release the back
cover.
3 To release the memory card holder, slide the holder
towards the battery (1), and lift up the end of the holder
(2). Insert a compatible memory card into the holder (3).
Make sure the contact area on the card is facing the
connectors on the device. Close the holder (4), and slide
it back to lock it into place (5).
Set up your device 9

4 Replace the back cover. Keep the device facing down
when replacing the cover. Make sure the cover is properly
closed.
Charge the battery
Your battery has been partially charged at the factory. If the
device indicates a low charge, do the following:
Charge the battery using the charger
1 Connect the charger to a wall outlet.
2 Connect the charger to the micro USB connector of the
device.
3 When the device indicates a full charge, disconnect the
charger from the device, then from the wall outlet.
The indicator light blinks when the device is charging. The
indicator light stays lit when the battery is fully charged.
You do not need to charge the battery for a specific length of
time, and you can use the device while it is charging. If the
battery is completely discharged, it may take several minutes
10 Set up your device

before the indicator light starts blinking or before any calls
can be made.
Charge the battery using the USB cable
You can charge your device using a compatible USB device,
for example a computer, when a wall outlet is not available.
You can also transfer data while charging the device.
1 Connect a compatible USB cable between a compatible
USB device and your device.
Depending on the type of device that is used for charging ,
it may take a while for charging to start.
2 If your device is switched on, USB mode options are
displayed. Select Mass storage mode or PC Suite
mode to make sure that your device receives enough
power from USB charging.
The indicator light blinks when the device is charging. The
indicator light stays lit when the battery is fully charged.
If the battery is completely discharged, allow some time for
charging before using your device.
If your device is on and you have many applications running,
the device can consume more power than it receives from
USB charging. Close some of the applications and disconnect
data connections, or use the charger that comes with the
sales package.
Keys and parts
Keys and parts (front)
1Power key
2Light sensor
3Secondary camera lens
4Proximity sensor
5Earpiece
6Indicator light
7Touch screen
8Physical keyboard
To ensure proper functionality of the touch screen, remove
the protective film from the device display.
Do not cover the area left of the touch screen with, for
example, protective film or tape.
Keys and parts 11

Keys and parts (back)
1Lens cover
2Camera flash
3Camera lens
4Kickstand
Keys and parts (top)
1Zoom/Volume key
2Power key
3Capture key
4Infrared port
None of the pre-installed applications of your device use
the infrared port, but it enables the development of third
party applications requiring an infrared port. The
infrared port is not IrDA compatible.
Keys and parts (sides)
1Stereo speaker
2Micro USB connector
3Wrist strap eyelet
4Stereo speaker
12 Keys and parts

5Lock switch
6Nokia AV Connector (3.5 mm)
7Microphone
8Stylus
First start-up
Switch the device on
1 Press the power key.
2 If the device asks for a PIN code or lock code, enter it, and
select Done. The preset lock code is 12345. If you forget
the code and your device is locked, your device requires
service for which additional charges may apply. For more
information, contact a Nokia Care point or your device
dealer.
Switch the device off
Press the power key, and select Switch off!.
Tip: You can also switch the device off by pressing and
holding the power key.
Start-up wizard
1 Switch the device on. A welcome note is briefly displayed,
and the start-up wizard opens.
2 The language, region, time and date settings are
displayed. Define the following:
Language — Slide your finger up or down to scroll
through the list, and select the language.
Region — Slide your finger up or down to scroll through
the list and, select the region.
Time — Define the time format by moving the slider to
24 hrs or 12 hrs, and move the hands of the clock to the
correct time with your finger. If you are using the 12-hour
clock, move the slider to AM or PM.
Date — Set the current date. To do this, slide your finger
up or down on the day, month, and year columns.
3 To accept and save the settings, select Save.
Kickstand
The kickstand is on the back of the device, and when placed
on a flat surface, can be used when you watch, for example,
video clips, or photos.
First start-up 13

Open the kickstand
Stylus
Some functions, such as sketching, may be easier to use with
a stylus than with your finger.
Important: Use only a stylus approved by Nokia for use with
this device. Using any other stylus may invalidate any
warranty applying to the device and may damage the touch
screen. Avoid scratching the touch screen. Never use an actual
pen or pencil or other sharp objects to write on the touch
screen.
Use accessories
Headset
You can connect a compatible headset or compatible
headphones to your device. Nokia headsets with music
controls can also be used, but the device does not support
the music controls.
Warning:
When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can
endanger your safety.
Do not connect products that create an output signal as this
may cause damage to the device. Do not connect any voltage
source to the Nokia AV Connector.
When connecting any external device or any headset, other
than those approved by Nokia for use with this device, to the
Nokia AV Connector, pay special attention to volume levels.
Wrist strap
1 Remove the back cover.
14 Stylus

2 Hook a strap behind the clamp and close the back cover.
Introduction
About Maemo software
This device uses Maemo 5 software on Linux. The software is
built for computer-like performance, enabling the running of
multiple applications at the same time, and delivering a wide
range of activities ranging from web browsing to video
recording. Your device supports Maemo Update, which allows
updating the operating system and applications over a WLAN
or packet data connection.
With Maemo software, it is possible to develop your own
applications for your device. To do this, you can use the
Maemo Software Development Kit (Maemo SDK). For more
information on what Maemo software is and how to develop
applications, see maemo.nokia.com.
About the desktop
The desktop is displayed when you switch on the device. It
offers quick access to different features of your device. You
can have up to four desktops. The desktops can be
personalised to have different widgets, bookmarks,
background images, and shortcuts to applications and
contacts.
The desktop contains the following:
1Application menu
2Status area
3Your network service provider (if a SIM card is inserted)
4Widgets
Switch between desktops
Swipe left or right.
Introduction 15

Search for contacts
Start entering a name, using the physical keyboard.
Open the virtual keypad to make a call
Start entering a phone number on the desktop, using the
physical keyboard. To enter numbers, press and hold , and
press the desired numbers.
Application menu
The application menu displays the available applications.
Select .
Open an application
Select the application you want to open.
Close an application
Select . All unsaved changes and selections are cancelled.
Status area and status menu
Status area
The status area informs of the current status of items that are
relevant across the device. The current time, and battery and
signal strength are displayed. In addition, the status area may
indicate your internet connection status, available updates,
or your active profile.
Status area indicators
General indicators
A clock alarm is active.
The state of device battery, and possible
charging status.
The current signal strength.
Software updates or additional
applications are available.
The Silent profile is active.
Connectivity indicators
, , ,
or
The current network.
Synchronisation is in progress.
16 Introduction

A USB connection is active.
A packet data connection is active (network
service).
A wireless LAN connection is active.
An ad-hoc wireless LAN connection is
active.
Bluetooth connectivity is active.
A Bluetooth connection with one or more
Bluetooth devices is active.
SIM card not available (card not inserted or
PIN code not entered).
The Offline mode is active.
GPS indicators
The GPS function is active.
The GPS function is inactive.
Content sharing indicators
Sharing is ongoing.
Sharing is pending and needs your
attention.
Sharing is blocked.
Call indicator
A phone call is active.
Availability status indicators
Online
Busy
If the availability status is offline, no indicator is shown in the
status area.
Sound indicators
Your device is connected to wired or
Bluetooth headphones.
Your device is connected to a wired or
Bluetooth headset device.
The FM transmitter is activated.
If a third-party application adds an icon to the status area, it
is placed after the default icons.
Open the status menu
Tap the status area.
The status menu displays, for example, the remaining battery
life, device volume, and Bluetooth connection status. To
change the displayed status, select the respective status
menu item.
Introduction 17

Dashboard
The applications that are currently running can be seen on
the dashboard. The dashboard also displays the notifications
that you have received but have not opened yet, for example,
text and mail messages, as well as missed calls.
Open the dashboard
When you open an application, the icon changes to the
dashboard icon . Select to open the dashboard. The
application remains open, and you can return to the
application by selecting it.
Switch between applications
When several applications are open, select and the
application you want to switch to.
Respond to a notification
1 When you receive, for example, a new mail, instant
message, or text message, a notification is briefly
displayed. You can view the message by selecting the
notification. If you do not select the notification while it
is displayed, the notification remains on the dashboard.
To indicate this, the icon blinks and then stays lit.
2 To view the notification on the dashboard, select the
notification.
About the touch screen
Touch screen actions
Tap
To select or open an application or other element on the
touch screen, tap it once with your finger.
Select
In this user documentation, opening applications or items by
tapping them once is called "selecting". If you need to select
several items in a sequence, the display texts to select are
separated by arrows.
Drag
Dragging can be used, for example, to scroll up or down a list.
To drag, place your finger on the screen, and slide it across
the screen.
18 Introduction

Swipe
Swiping can be used, for example, to switch between images
in the Photos application. To swipe, slide your finger quickly
left or right on the screen.
Touch screen backlight
Turn touch screen backlight on
The touch screen backlight is turned off after a period of
inactivity. To turn the backlight on, tap the screen. If the
screen and keys are locked, use the lock switch to unlock
them.
Touch screen actions in applications
Open the application menu
Tap the title bar of the currently open application.
Close a dialog
Tap on a blank space on the desktop. All changes and
selections will be cancelled.
Basic use
About your device
Antenna locations
Your device may have internal and external antennas. Avoid
touching the antenna area unnecessarily while the antenna
is transmitting or receiving. Contact with antennas affects the
communication quality and may cause a higher power level
during operation and may reduce the battery life.
Basic use 19

Cellular antenna
Bluetooth and WLAN antenna
GPS antenna
Control volume
Adjust the volume
Use the volume keys.
Tip: You can view the current volume setting, and also adjust
the volume, from the status menu. Tap the status area to
open the menu. Use the volume slider to adjust
the volume.
Mute sounds
Drag the volume slider in the status menu all the way to the
left.
Adjust call and message tone volumes
Select > Settings and Profiles.
Notification light
The notification light can indicate the status of your device.
For example, it can inform you about the battery charging
status, and tell you if you have missed a phone call or
received, for example, a mail or text message. You can enable
or disable the notification light for each notification type by
changing the notification light settings.
The colours of the notification light indicate the following:
Application triggered notification light (received text
message, instant message, or mail)
Battery charging
Battery full
Related topics
•See "Notification light settings ", p. 98.
20 Basic use
