Nokia 7380 User manual

1
Nokia 7380 User Guide
924xxx
Issue 1

2
LEGAL INFORMATION
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Navi, and Nokia 7380 are trademarks or registered
trademarks of Nokia Corporation. Other product and company names mentioned herein may
be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2005. Tegic Communications, Inc. All rights reserved.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
The information contained in this user guide was written for the Nokia 7380 product. Nokia
operates a policy of ongoing development. Nokia reserves the right to make changes to any
of the products described in this document without prior notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY
APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR
WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
EXPORT CONTROLS
This device may contain commodities, technology, or software subject to export laws and
regulations from the U.S. and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the condition that this device does not cause harmful interference. Any changes or
modifications not expressly approved by Nokia could void the user’s authority to operate this
equipment.
924xxxx/Issue 1

Contents
3
Contents
For your safety 5
About your device ................................................................................................................ 7
Access codes .......................................................................................................................... 7
Network services................................................................................................................... 8
Configuration settings service.......................................................................................... 8
Download content and applications............................................................................... 9
Nokia support and contact information ........................................................................ 9
1. Your phone .................................................................................... 10
Keys and connectors......................................................................................................... 10
Spinner ................................................................................................................................. 11
Standby mode..................................................................................................................... 12
Keypad lock (keyguard).................................................................................................... 14
2. Get started..................................................................................... 15
Install the SIM card .......................................................................................................... 15
Charge the battery ............................................................................................................ 16
Switch the phone on and off ......................................................................................... 16
Normal operating position.............................................................................................. 17
Wrist strap........................................................................................................................... 17
3. Call functions................................................................................ 18
Make a call.......................................................................................................................... 18
Voice dialing ....................................................................................................................... 19
Answer or decline an incoming call............................................................................. 19
Options during a call ........................................................................................................ 20
4. Write text ...................................................................................... 21
Tips for writing text .......................................................................................................... 21
5. Using the menu............................................................................. 23
Accessing a menu function ............................................................................................ 23
6. Menu functions............................................................................. 24
Messaging............................................................................................................................ 24
Contacts ............................................................................................................................... 31
Call log.................................................................................................................................. 33
Settings ............................................................................................................................... 34
Gallery................................................................................................................................... 41
Media .................................................................................................................................... 42

Contents
4
Organizer.............................................................................................................................. 46
Web........................................................................................................................................ 49
SIM services......................................................................................................................... 55
Number entry...................................................................................................................... 56
7. PC Connectivity ............................................................................ 57
Nokia PC Suite.................................................................................................................... 57
Data communication applications................................................................................ 58
8. Battery information...................................................................... 59
Charging and discharging................................................................................................ 59
Care and maintenance ..................................................................... 62
Additional safety information......................................................... 64
Index.................................................................................................. 69

For your safety
5
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the phone at a refuelling point. Do not use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting is in
progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.

For your safety
6
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure that the phone is switched on and in service. Press the end
key as many times as needed to clear the display and return to the
start screen. Press and hold the middle selection key and enter the
emergency number, then press the call key. Give your location. Do
not end the call until given permission to do so.

General information
7
General information
■About your device
The wireless device described in this guide is approved for use on the EGSM 900
and GSM 1800/1900 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect the privacy and
legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
Shared memory
The following features in this device may share memory: contacts, messages,
voice commands and SMS distribution lists, calendar and to-do notes. Use of one
or more of these features may reduce the memory available for the remaining
features sharing memory. For example, saving many multimedia messages may
use all of the available memory. Your device may display a message that the
memory is full when you try to use a shared memory feature. In this case, delete
some of the information or entries stored in the shared memory features before
continuing. Some of the features, such as xxxx may have a certain amount of
memory allotted to them in addition to the memory shared with other features.
Gallery files share a different memory. For further information, see
"Gallery," p. 41.
■Access codes
•Security code (5 to 10 digits): The security code helps to protect your phone
against unauthorized use. The code is supplied with your phone. The preset
code is 12345. To change the code and to set the phone to request it, see
"Security," p. 41.
•PIN code (4 to 8 digits): The PIN (personal identification number) code helps
to protect the SIM card against unauthorized use. It may be supplied with the
SIM card. If you activate the PIN code request function in the Security
settings menu, the code is requested each time the phone is switched on.

General information
8
•PIN2 code (4 to 8 digits): This code may be supplied with the SIM card and is
required to access some functions, such as call counters.
•PUK and PUK2 codes (8 digits): The PUK (personal unblocking key) code is
required to change a blocked PIN code. The PUK2 code is required to change a
blocked PIN2 code.
•restriction password (4 digits): This code is required when using the Call
restrictions function in the Security settings menu.
•Module PIN and signing PIN: The module PIN is required to access the
information in the security module. See "Security module," p. 53.
The signing PIN is required for the digital signature.
See "Security module," p. 53.
■Network services
To use the phone you must have a service from a wireless service provider. Many
of the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with your service provider before you can
utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network services. For instance,
some networks may not support all language-dependent characters and services.
■Configuration settings service
To use some of the network services, such as mobile Internet services, MMS, or
synchronization, your phone needs the correct configuration settings. You may
receive the settings directly as a configuration message, and you need to save the
settings on your phone. The service provider may provide a PIN that is needed to
save the settings. For more information on the availability of the settings,
contact your network operator, service provider, nearest authorized Nokia dealer
or visit the support area on the Nokia Web site, www.nokia.com/support.
When you have received a configuration message, Configuration settings
received is displayed. To view the received settings, select Show.
To save the received settings, select Save. If the device asks Enter settings' PIN:,
enter the PIN-code for settings, and select OK. Select whether you want these

General information
9
settings as the default. For availability of the PIN code, contact the service
provider that supplies the settings.
To discard the received settings, select Discard.
To view and edit the settings, see "Configuration," p. 40.
■Download content and applications
You may be able to download content, such as themes, tones, and video clips to
the phone (network service). Select the download function (for example, in the
Gallery menu). To access the download function, see the respective menu
descriptions. For the availability of different services, pricing, and tariffs, contact
your service provider.
Important: Only install and use applications and other software from
sources that offer adequate security and protection against harmful
software.
■Nokia support and contact information
Check www.nokia.com/support or your local Nokia Web site for the latest version
of this guide, additional information, downloads, and services related to your
Nokia product.
On the Web site, you can get information on the use of Nokia products and
services. If you need to contact customer service, check the list of local Nokia
Care contact centers at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia Care services location at
www.nokia.com/repair.

Your phone
10
1. Your phone
■Keys and connectors
• Earpiece (1)
• Display and mirror (2)
• Upper selection key, lower selection key, middle selection key (3)
The function of these keys depend on the guiding text shown on the display
beside these keys. See "Standby mode," p. 12.
•Navi
TM spinner (4)
Use the spinner to scroll through the character bar when entering text and
numbers, scrolling through different lists, and browsing messages. See
"Spinner," p. 11.
• End key (5) ends an active call and exits from any function. Press and hold the
end key to switch on and off.
• Call key (6) dials the phone number and answers a call. In the standby mode,
it shows the list of the most recently called numbers.
• Pulsating light indicator (7)
• Camera lens (8)
• Camera flash (9)

Your phone
11
• Microphone (10)
• Enhancement connector
(11) used to connect a
headset or other
enhancement
• Charger connector (12)
• Loudspeaker (13)
• SIM card slot (14)
■Spinner
You can use the spinner to enter characters, scroll through
different lists, and browse messages.
To use the spinner, rotate it clockwise or counterclockwise.
The middle selection key is located in the center of the
spinner.
In the standby mode you can use the spinner as follows:
Press and hold the middle selection key to enter a phone number.
Rotate the spinner to scroll to a digit of the phone number in the character bar
that is shown at the bottom of the display, and press Select. Repeat this for each
digit of the phone number.
To call the phone number, press the call key, or select Options > Call.
To save the phone number with a name, select Options > Save, and the letters of
the name one by one from the character bar, and Options > Accept.

Your phone
12
■Standby mode
When the phone is ready for use, and you have not keyed in any characters, the
phone is in the standby mode.
• Signal strength of the cellular network (1)
• Name of the network or the operator logo (2)
• Battery charge level (3)
• The upper selection key (4) in the standby
mode is Go To
• The middle selection key (5) in the standby mode is Menu
• The lower selection key (6) in the standby mode may be Names
See "Essential indicators," p. 13.
Wallpaper and screen saver
You can set your phone to display a background picture, wallpaper and a screen
saver when the phone is in the standby mode. See "Display settings," p. 34.

Your phone
13
Power saving
For power saving, the light of the display and the keys is switched off after a
certain period of time. The pulsating light indicator shows that the phone is
switched on. The first keypress switches the display light on.
Deactivating the pulsating light indicator (Light effects) also saves power. See
"Profiles," p. 34.
Essential indicators
You have received one or several text or multimedia messages. See
"Read and reply to an SMS message or an SMS e-mail," p. 25 or "Read
and reply to a multimedia message," p. 28.
The phone keypad is locked. See "Keypad lock (keyguard)," p. 14.
The phone does not ring for an incoming call or text message when
Incoming call alert is set to Off and Message alert tone is set to Off. See
"Tones," p. 34.
The alarm clock is set to On. See "Alarm clock," p. 46.
When the (E)GPRS connection mode Always online is selected and the
(E)GPRS service is available, the indicator is shown on the top left of the
display. See "Packet data connection," p. 38.
When the (E)GPRS connection is established, the indicator is shown on
the top left of the display. See "Packet data connection," p. 38 and
"Browse pages," p. 50.
The (E)GPRS connection is suspended (on hold) (for example if there is
an incoming or outgoing call during the (E)GPRS connection).
Bluetooth wireless technology indicator. See "Bluetooth wireless
technology," p. 36.
The loudspeaker has been activated. See "Options during a call," p. 20.
Calls are limited to a closed user group. See "Security," p. 41.
, ,
A headset, handsfree, or loopset, or similar enhancement is connected
to the phone.

Your phone
14
■Keypad lock (keyguard)
You can lock the keypad to prevent the keys from being accidentally pressed.
Select Menu or Unlock, then the call key within 1.5 seconds to lock or unlock the
keypad. If the Security keyguard is set to On, select Unlock, and enter the security
code.
An incoming call can be operated normally. When you end or decline the call, the
keypad automatically locks.
For Automatic keyguard and Security keyguard, see "Phone settings," p. 39.
Note: When the Keyguard is on, calls still may be possible to the official
emergency number programmed into your device. For more details, see
"Emergency calls," p. 66.

Get started
15
2. Get started
■Install the SIM card
Keep all SIM cards out of the reach of small children. For availability and
information on using SIM card services, contact your SIM card vendor. This may
be the service provider, network operator, or other vendor.
To open the SIM slot, slide the SIM door to
the left (1) and open it (2).
Insert the SIM card with the gold-colored
contacts on the card facing downwards and
the edge with the cut-off corner facing
inwards.
Close the SIM door and press until you hear a
distinct click.
1
2

Get started
16
To close the SIM door slide it to the right.
To release the SIM card, slide the SIM door to
the left. Press the SIM door inwards until you
hear a distinct click and the SIM card is
released.
■Charge the battery
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
This device has an internal, non-removable, rechargeable battery. Do not attempt
to remove the battery from the device as you may damage the device. Nokia
recommends taking it to the nearest authorized service facility for replacement
of the battery.
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from the AC-1, ACP-7, ACP-12, or
LCH-12 chargers.
1. Connect the charger to an AC wall socket.
The text Charging is displayed briefly if the
phone is switched on. If the battery is
completely discharged, it may take a few
minutes before the charging indicator
appears on the display or before any calls
can be made.
2. Connect the lead from the charger to the socket on the bottom of your phone.
The charging time depends on the charger used. Charging a battery with the AC-
1 charger takes up to 1 hour and 30 minutes while the phone is in the standby
mode.
The BL-8N internal fixed battery provides up to 3 hours of talk time and up to
10 days of standby time. Operation times are estimates and may vary depending
on network conditions, charging, and device use.
■Switch the phone on and off
Warning: Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.

Get started
17
Press and hold the end key until the phone
switches on or off.
If the phone asks for a PIN code or the
security code, scroll to the desired digit in
the character bar, and select it. Repeat this
for each digit of the code. If you enter an
incorrect character, select Clear to delete it. Select Options > Accept.
See also PIN code request in "Security," p. 41 and "Access codes," p. 7.
■Normal operating position
Your phone has an internal antenna. Use the phone only in its
normal operating position.
Note: As with any other radio transmitting
device, do not touch the antenna unnecessarily
when the device is switched on. Contact with
the antenna affects call quality and may cause
the device to operate at a higher power level
than otherwise needed. Avoiding contact with
the antenna area when operating the device
optimizes the antenna performance and the
battery life.
■Wrist strap
Thread the strap as shown in the picture, and tighten it.

Call functions
18
3. Call functions
■Make a call
1. Press and hold the middle selection key in the standby mode, and enter the
phone number, including the area code. To enter the phone number, scroll to
the desired digit in the character bar, and select it. Repeat this for each digit
of the phone number. If you enter an incorrect character, select Clear to
delete it.
For international calls, enter the + character for the international access
code, the country code, the area code without the leading 0, if necessary, and
the phone number.
2. Press the call key to call the number.
3. Press the end key to end the call or to cancel the call attempt.
Make a call using contacts
To search for a name or phone number that you saved in Contacts, see "Search
for a contact," p. 31. Press the call key to call the number.
Call a recently dialed number
In the standby mode, press the call key once to access the list of up to 20
numbers that you last called or attempted to call. Scroll to the number or name
that you want, and press the call key to call the number.
Call your voice mailbox
In the standby mode, press and hold the middle selection key, select 1, and press
the call key. See also "Nokia Xpress audio messaging," p. 28. If supported by the
network, the indicator shows new voice messages. Select Listen to call your voice
mailbox number.
Make another call during a call (network service)
During a call, select Options > New call. Enter the phone number, or select
Options > Find to search for the phone number in the contacts. Select Call or the
call key. The first call is put on hold. To switch between the two calls, press the
call key.

Call functions
19
■Voice dialing
You can make a phone call by saying the name that is stored in the contact list of
the phone. A voice command is added automatically to all entries in the contact
list of the phone.
Make a voice dialing call
If an application is sending or receiving data using a packet data connection, end
the application before you use voice dialing.
Voice commands are language-dependent. For the language setting, see
Playback language in "Phone settings," p. 39.
Note: Using voice commands may be difficult in a noisy environment or
during an emergency, so you should not rely solely upon voice dialing in
all circumstances.
1. In the standby mode, press and hold the right selection key. A short tone is
played, and Speak now is displayed.
If you are using a compatible headset with the headset key, press and hold
the headset key to start the voice dialing.
2. Say the voice command clearly. If the voice recognition was successful, a list
with matches is shown. The phone plays the voice command of the match on
the top of the list. After a time-out of 1.5 seconds, the phone dials the
number; or, if the result is not the right one, scroll to another entry, and select
it to dial the number. See "Voice commands," p. 35.
■Answer or decline an incoming call
Press the call key to answer the call. If you want to mute the ringing tone, select
Silence.
To decline the call, press the end key. The declined call is forwarded if you have
activated the Forward if busy function. See "Call," p. 38.
Call waiting
You can answer a call while you have another call in progress if you have
activated the Call waiting function in the Call settings menu (network service). To
answer the waiting call, select Answer or press the call key. The first call is put on
hold.

Call functions
20
■Options during a call
Many of the options that you can use during a call are network services. For
availability, contact your network operator.
Call options are Volume, Mute or Unmute, Number entry, Contacts, Menu,
Record, Lock keypad, Loudspeaker or Handset.
Network services options are Answer and Decline, Hold or Unhold, New call,
Conference, End call, End all calls and the following:
Touch tones—to send tone strings
Swap—to switch between the active call and the call on hold
Transfer calls—to connect a call on hold to an active call and disconnect yourself
Private call—to discuss privately in a conference call
For more information, see the user guide for your phone model in the support
area on the Nokia Web site, www.nokia.com/support.
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
