Nokia NSB-8 Installation instructions

PAMS Technical Documentation
NSB-8 Series Transceivers
Issue 1 01/02 ãNokia Corporation
Assembly & Disassembly
Instructions

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 2 ãNokia Corporation Issue 1 01/02
Table of Contents Page No
Disassembling the NSB-8 Transceiver.......................................................................... 3
Assembling the NSB-8 Transceiver............................................................................... 9

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 3
Disassembling the NSB-8 Transceiver
1
2
3
Remove Battery cover.
Remove Battery.
1
2

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 4 ãNokia Corporation Issue 1 01/02
Remove A-cover.
When a new
A-cover is set
remove the inner
protective layer.
Remove Keypad
(only if it is necessary to
replace keypad).
In assembly place A-cover
pins (4 pieces) in respective
holes in the keypad.

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 5
Remove the 6 screws.
Drive size is torx plus 6.
Note! Screws contain thread
locking compound. Used screws
must be scrapped and not used
again.
Remove UI module.
1. Use plastic tweezers or similar
tool to gently press the UI module
locking snap.
2. Carefully lift up the UI module.
1
2UI handling precautions!
Do not damage the following
items when handling the UI
module:
1. Speaker spring contacts.
2. LCD driver.
3. LCD contact pads.
4. UI PWB contact pads.
5. UI frame metal coating.
1.
3.
2.
4.
5.
6.

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 6 ãNokia Corporation Issue 1 01/02
Remove speaker
(only if it is necessary to
replace speaker).
Speaker can be lifted up
using a straight-bladed
screwdriver as shown in
the picture.
Note! Do not touch
speaker springs or
membrane.
UI handling precautions!
1. Speaker spring contacts.
2. LCD driver.
3. LCD contact pads.
4. UI PWB contact pads.
5. UI frame metal coating.
1.
3.
2.
4.
5.

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 7
Remove System connector
Note! Do not damage the
spring contacts in the
System connector.
Remove System Module
System Module handling
precautions!
Do not touch the following
spring contacts when
handling the module:
1. LCD connector.
2. Board to board connector.
1. 2.

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 8 ãNokia Corporation Issue 1 01/02
Remove SIM cover
(only if it is necessary to replace
SIM cover).
3. Turn the SIM cover to
upright position.
4. Squeeze the SIM cover
slightly from the side to
release the side fixings one
at the time.
1. Slightly lift the front edge
of the SIM cover to unlocked
position
2. and slide it backwards.
1
4
55. Pull SIM cover out of B cover.
3
2

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 9
Assembling the NSB-8 Transceiver
1. Insert SIM cover into B-cover.
2
2. Squeeze the SIM cover from the
side and insert into the appropriate
slots in the B-cover.
3
3. Tilt SIM cover down.
4. Slide forward.
4

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 10 ãNokia Corporation Issue 1 01/02
1. Insert System Connector.
2. Insert System Module.
A
B
C
D E 3. Obtain UI Module
Use caution handling the following:
A. Speaker spring contacts
B. LCD driver
C. LCD contact pads
D. PWB contact pads
E. Frame metal coating

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 11
1. Insert UI Module into phone.
Locking
Snap
Fasten screws in the order as shown in
the picture.
Drive size is torx plus 6.
Tightening torque is 17Ncm @
800 - 1200 rpm.
Note: Screws contain threadlocking
compound. Screws without this
compound or used screws should not be
fastened.

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 12 ãNokia Corporation Issue 1 01/02
Insert Keymat into A-cover.
Attach A-cover to phone.

PAMS Technical Documentation Assembly & Disassembly Instructions
NSB-8
Issue 1 01/02 ãNokia Corporation Page 13
Insert battery.
Attach battery cover.
Snap
Slide cover on till the snap locks it in
place.

NSB-8
Assembly & Disassembly Instructions PAMS Technical Documentation
Page 14 ãNokia Corporation Issue 1 01/02
