Nokia X1-01 User manual

Nokia X1–01 User Guide
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Issue 2.0EN

Keys and parts
12
3
4
5
6
7
8
Select
Exit
1Earpiece
2Screen
3End/Powerkey
4Keypad
5Microphone
6Scrollkey
7Callkey
8 Selection keys
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

9
10
11
12
14
13
9 Headset connector
10 Loudspeaker
11 Music keys
12 Memory card slot
13 Flashlight
14 Charger connector
The headset and memory card may be
available separately.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert the SIM card and battery
Put your finger in the gap, and lift the
back cover.
1
Open the SIM 1 card holder
2
Insert SIM1.
3
Close the SIM card holder.
4
Open the SIM 2 card holder
5
Insert SIM2.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Close the SIM card holder.
7
Line up the battery contacts and push
the battery in.
8
Press the back cover into place.
9
Insert a memory card
Open the cover of the memory card
slot. See vi) in General Information.
1
Make sure the contact area is facing up,
and push the card in.
2
Close the cover.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Charge the battery
Connect the charger to a wall outlet.
1
Connect the charger to the phone.
2
The phone indicates a full charge. You
can use the phone while charging.
3
Switch on
2 seconds
Press and hold the power key .
1
Select Back
SIM1
Dual SIM
SIM2
2
1
Set which SIM card to use. Press OK.
See v) in General Information.
2
OK Back
Time:
09:0009
To set the hour, press up or down. You
can also press the number keys.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

OK Back
Time:
15:00
To set the minutes, press right, and
then press up or down. Press OK.
4
Time is set
The time is changed.
5
OK Exit
Date:
08.04.2011
08
To set the date, press up or down.
Press OK.
6
15:00
Menu Go to
The phone is ready to use.
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Explore your phone
Menu Go to
To see the available functions, press
Menu.
1
Select Exit
To go to a function, press the scroll key
up, down, left, or right.
2
Select Exit
To select the function, press Select.
3
Select Back
To select an item, press Select.
4
Select Back
To return to the previous view, press
Back.
5
ExitSelect
To return to the home screen, press
.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Select a SIM card for calls and messages
SIM1
SIM2
SIM1
SIM2
You can use two SIM cards, and share
your phone with your family.
Menu Go to Select Exit
Press Menu. Select Settings.
1
Select Back
Tone settings
Dual SIM
settings
Display
settings
Select Dual SIM settings. See v) in
General Information.
2
Select Back
Default SIM for
calls
Default SIM for
msgs
Ask every time
Ask every time
Select Default SIM for calls.
3
Select Back
Ask every time
SIM1
SIM2
Select Ask every time.
4
Default SIM for
calls:
Yes
Ask every time
Press the call key to
call directly!
Your phone asks which SIM card to use
when you make a call.
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Select Back
Default SIM for
calls
Default SIM for
msgs
Ask every time
Ask every time
Select Default SIM for msgs.
6
Select Back
Ask every time
SIM1
SIM2
Select Ask every time.
7
Default SIM for
msgs.:
OK
Ask every time
Press the call key to
send the message
directly!
Your phone asks which SIM card to use
when you send a message.
8
Menu Go to
Tip: To open Dual SIM settings from
the home screen, press and hold *.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Use one SIM card only
Menu Go to Select Exit
To save battery power, use only SIM1.
Press Menu. Select Settings.
1
Select Back
Tone settings
Dual SIM
settings
Display
settings
Select Dual SIM settings.
2
Select Back
Default SIM for
msgs
Standby mode
Dual SIM
Ask every time
Select Standby mode.
3
Select Back
SIM1
Dual SIM
SIM2
2
1
Select SIM1. SIM2 is disconnected from
the network.
4
Select Back
SIM1
Dual SIM
SIM2
2
1
Tip: To activate both SIM cards, repeat
steps 1-3, and select Dual SIM.
Menu Go to
Tip: To open Dual SIM settings from
the home screen, press and hold *.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Lock or unlock keypad
Menu Go to
To avoid accidental pressing of keys,
use the keypad lock.
Menu Go to
Press Menu, and then quickly press *.
1
Keypad
locked
The keypad locks. To unlock the
keypad, repeat step 1.
2
Make or answer a call
Make a call to a number that you have.
Options Clear
012345
Enter the phone number.
1
Select Back
SIM2
SIM1
2
1
If asked, select the SIM card to use.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

End call
Calling
0123456789
Press .
3
Silence
calling
9876543210
A friend's phone rings. To answer,
press .
4
You can enjoy chatting with your
friend. To end the call, press .
5
Change the volume
Is the volume too loud during a call or
when listening to the radio?
Volume
Press left for quieter, right for louder.
1
Better.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Use the loudspeaker
Others in the room can join in with a
call.
Loudsp.
0123456789
00:00:05
Options
During a call, press Loudsp..
1
Place the phone on a table.
2
Use the headset
You can make a hands-free call with a
headset.
calling
0123456789
Connect a headset.
1
End call
Calling
0123456789
Make a call.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Switch off
To save battery power, switch the
phone off.
2 seconds
Switch off
Press and hold the power key .
1
The phone switches off.
2
Save a name and number
Add a friend's number to your phone.
Menu Go to Select Exit
Press Menu. Select Contacts.
1
Select Back
Search
Add contact
Delete
Select Add contact.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Select Back
SIM1
SIM2
Phone
Select where to save the contact.
3
OK Clear
Contact name:
Mi
Write the name.
4
OK Clear
Contact name:
Mike
Press OK.
5
OK Clear
Phone number:
0123
OK Clear
Phone number:
0123456789
Enter the phone number. Press OK.
6
Use Back
Go to a picture, and press Use.
7
Mike
Silence
calling
9876543210
When you receive a call, the name,
number, and picture are shown.
8
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Change the ringtone
Menu Go to Select Exit
Press Menu. Select Settings.
1
Select Back
Tone settings
Dual SIM
settings
Display
settings
Select Tone settings.
2
Select BackSelect Back
Ringing tone
Ringing volume
Level 4
SIM1
1
SIM2
2
Beach
Nokia tune
Select Ringing tone and a SIM card.
3
OK Back
Airy
Beach
Bold
Brook
Coconut
Desk phone
To listen to the sound of a ringtone, go
to the ringtone.
4
OK Back
Airy
Beach
Bold
Brook
Coconut
Desk phone
Press OK.
5
Done
The ringtone is selected.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1
SIM1
2
SIM2
Tip: To select different ringtones for
SIM1 and SIM2, repeat steps 3-5.
Options Back
Song 1
01:10 01:18
Demo songs
My favourite
songs
Use as
ringtone
Select Back
Tip: You can select an MP3 song as a
ringtone.
Flashlight
Use the flashlight if you need more
light. See iii) in General Information.
x2
22:35
Menu Go to
To use the flashlight, press up twice.
1
x1
22:35
Menu Go to
To switch the flashlight off, press up
once.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Send and receive messages
Menu Go to Select Exit
Press Menu. Select Messages.
1
Select Back
Create
message
Inbox
Sent items
Select Create message.
2
Options Clear
Hello Anna,
To write your message, press the keys.
3
Options Clear
Hello Anna, how
are you today?
Press Options, and select Send. See i)
in General Information.
4
Select Back
SIM2
SIM1
2
1
If asked, select which SIM card to use.
See v) in General Information.
5
OK Clear
Phone number:
0123456789
Enter a phone number. Press OK.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

The message is sent.
7
10:58
Show Exit
1 message
received
To read a message, press Show.
8
Options Back
Hello Anna, how
are you today?
To view the rest of the message, press
down.
9
Write text
Press a key repeatedly until the letter
is shown.
Change the writing language: select
Menu > Settings > Phone
settings > Language, the language,
and OK. See iv) in General Information.
Insert a space: press 0.
Change a word: press *repeatedly
until the word is shown.
Insert a number: press and hold the
number key.
Insert a special character: press and
hold *.
Change the text input method: press #
repeatedly.
Use predictive text: select Options >
Dictionary and the language. Press a
key for each letter. When the word is
shown, press 0. Start writing the next
word.
Stop using predictive text: select
Options > Dictionary > Dictionary
off.
