Nokia 105s User manual

Part No. N450000309 Rev 001
Published August 2006
Nokia 105s Gateway
Installation Guide

2 Nokia 105s Gateway Installation Guide
COPYRIGHT
©2006 Nokia. All rights reserved.
Rights reserved under the copyright laws of the United States.
RESTRICTED RIGHTS LEGEND
Use, duplication, or disclosure by the United States Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013.
Notwithstanding any other license agreement that may pertain to, or accompany the delivery of,
this computer software, the rights of the United States Government regarding its use,
reproduction, and disclosure are as set forth in the Commercial Computer Software-Restricted
Rights clause at FAR 52.227-19.
IMPORTANT NOTE TO USERS
This software and hardware is provided by Nokia Inc. as is and any express or implied
warranties, including, but not limited to, implied warranties of merchantability and fitness for a
particular purpose are disclaimed. In no event shall Nokia, or its affiliates, subsidiaries or
suppliers be liable for any direct, indirect, incidental, special, exemplary, or consequential
damages (including, but not limited to, procurement of substitute goods or services; loss of use,
data, or profits; or business interruption) however caused and on any theory of liability, whether in
contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use
of this software, even if advised of the possibility of such damage.
Nokia reserves the right to make changes without further notice to any products herein.
TRADEMARKS
Nokia is a registered trademark of Nokia Corporation. Other products mentioned in this document
are trademarks or registered trademarks of their respective holders.
060101

Nokia 105s Gateway Installation Guide 3
Nokia Contact Information
Corporate Headquarters
Regional Contact Information
Nokia Customer Support
Web Site http://www.nokia.com
Telephone [phone] or
1-650-625-2000
Fax [phone]
Mail
Address Nokia Inc. 313 Fairchild Drive
Mountain View, California
94043-2215 USA
Americas Nokia Inc.
313 Fairchild Drive
Mountain View, CA 94043-2215
USA
Tel: [phone]
Outside USA and Canada: [phone]
email: [email protected]
Europe,
Middle East,
and Africa
Nokia House, Summit Avenue
Southwood, Farnborough
Hampshire GU14 ONG UK
Tel: UK: [phone]
Tel: France: [phone]
email: [email protected]
Asia-Pacific 438B Alexandra Road
#07-00 Alexandra Technopark
Singapore 119968
Tel: [phone]
email: [email protected]
Web Site: https://support.nokia.com/
Email: [email protected]
Americas Europe
Voice: 1-888-361-5030 or
1-613-271-6721 Voice: [phone]
Fax: [phone] Fax: [phone]
Asia-Pacific
Voice: [phone]
Fax: [phone]
050602

4 Nokia 105s Gateway Installation Guide

Nokia 105s Gateway Installation Guide 5
Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
In this Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Conventions this Guide Uses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Command-Line Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
About the Nokia 105s Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Built-In Gigabit Ethernet Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
PMC Expansion Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Managing the 105s Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Site Requirements, Warnings, and Cautions . . . . . . . . . . . . . . . . . 24
Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Product Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2 Installing the Nokia 105s Gateway . . . . . . . . . . . . . . . . . . . . . . . 29
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Rack Mounting the Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connecting Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Connecting to the Console or Auxiliary Port. . . . . . . . . . . . . . . . . . 32
Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Auxiliary Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Connecting to Network Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . 37

6 Nokia 105s Gateway Installation Guide
3 Performing the Initial Configuration . . . . . . . . . . . . . . . . . . . . . 39
Using a Console Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using Nokia Network Voyager. . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Viewing Nokia IPSO Documentation by Using Nokia Network
Voyager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Using the Command-Line Interface . . . . . . . . . . . . . . . . . . . . . . . . 45
4 Installing and Replacing Network Interface Cards . . . . . . . . . 49
Deactivating Configured Interfaces . . . . . . . . . . . . . . . . . . . . . . . . 50
Removing, Installing, and Replacing NICs. . . . . . . . . . . . . . . . . . . 50
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Configuring and Activating Interfaces . . . . . . . . . . . . . . . . . . . . . . 57
Monitoring Network Interface Cards. . . . . . . . . . . . . . . . . . . . . . . . 57
5 Connecting PMC Network Interface Cards . . . . . . . . . . . . . . . . 59
Four-Port 10/100 Mbps Ethernet NICs. . . . . . . . . . . . . . . . . . . . . . 59
Ethernet NIC Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Ethernet NIC Connectors and Cables. . . . . . . . . . . . . . . . . . . . . 61
Two-Port Copper Gigabit Ethernet Network Interface Card. . . . . . 63
Copper Gigabit Ethernet NIC Features. . . . . . . . . . . . . . . . . . . . 63
Copper Gigabit Ethernet Connectors and Cables. . . . . . . . . . . . 64
Two-Port Fiber-Optic Gigabit Ethernet Network Interface Card. . . 66
Fiber-Optic Gigabit Ethernet NIC Features. . . . . . . . . . . . . . . . . 66
Fiber-Optic Gigabit Ethernet Connectors and Cables. . . . . . . . . 67
6 Installing and Replacing Other Components . . . . . . . . . . . . . . 69
Installing or Replacing a Hard-Disk Drive . . . . . . . . . . . . . . . . . . . 70
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Replacing or Upgrading Memory . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Replacing the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Nokia 105s Gateway Installation Guide 7
7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
General Troubleshooting Information. . . . . . . . . . . . . . . . . . . . . . . 87
Troubleshooting Routing Problems . . . . . . . . . . . . . . . . . . . . . . . . 97
A Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Space Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
NIC Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
B Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Compliance Statements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
FCC Notice (US) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

8 Nokia 105s Gateway Installation Guide

Nokia 105s Gateway Installation Guide 9
Tables
Table 1 Command-Line Conventions . . . . . . . . . . . . . . . . . . . . . 15
Table 2 Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 3 Specifications for the 105s Gateway . . . . . . . . . . . . . . . 20
Table 4 PMC Network Interface Card Slots . . . . . . . . . . . . . . . . 22
Table 5 System Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Table 6 Pin Assignments Console Connector and Cable . . . . . . 36
Table 7 Pin Assignments for AUX Connector and Modem Cable 37

10 Nokia 105s Gateway Installation Guide

Nokia 105s Gateway Installation Guide 11
Figures
Figure 1 Component Locations Front View . . . . . . . . . . . . . . . . . 20
Figure 2 Component Locations Rear View . . . . . . . . . . . . . . . . . 21
Figure 3 Built-In Gigabit Ethernet Ports Details . . . . . . . . . . . . . . 21
Figure 4 Gateway Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 5 Mounting Screws Location . . . . . . . . . . . . . . . . . . . . . . 30
Figure 6 Adjustable Mounting Brackets . . . . . . . . . . . . . . . . . . . . 31
Figure 7 Back Panel Power Switch and Socket . . . . . . . . . . . . . 32
Figure 8 Nokia Network Voyager Reference Access Points . . . . 45
Figure 9 Four-Port Ethernet NIC Front Panel Details . . . . . . . . . 60
Figure 10 Output Connector for the Ethernet Cable . . . . . . . . . . 62
Figure 11 Ethernet Crossover-Cable Pin Connections . . . . . . . . 62
Figure 12 Gigabit Ethernet Crossover Cable Pin Connections . . 63
Figure 13 Two-Port Copper Gigabit Ethernet NIC . . . . . . . . . . . . 64
Figure 14 Copper Gigabit Ethernet Cable Connector Output Pin
Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Figure 15 Gigabit Ethernet Crossover Cable Pin Connections . . 65
Figure 16 Two-Port Fiber-Optic Gigabit Ethernet NIC . . . . . . . . . 67
Figure 17 Hard-Disk Drive Location . . . . . . . . . . . . . . . . . . . . . . 70
Figure 18 DIMM Socket Locations . . . . . . . . . . . . . . . . . . . . . . . 77

12 Nokia 105s Gateway Installation Guide

Nokia 105s Gateway Installation Guide 13
About this Guide
This guide describes how to install and use Nokia 105s gateways. Installation
and maintenance should be performed by experienced technicians or Nokia-
approved service providers only.
This preface provides the following information:
In this Guide
Conventions this Guide Uses
Related Documentation
In this Guide
This guide is organized into the following chapters and appendixes:
Chapter 1, “Overview” presents a general overview of the 105s gateway.
Chapter 2, “Installing the Nokia 105s Gateway” describes how to
rack-mount the gateway and how to physically connect it to a network
and power.
Chapter 3, “Performing the Initial Configuration” describes how to make
the gateway available on the network.
Chapter 4, “Installing and Replacing Network Interface Cards” describes
how to install, monitor, and replace network interface cards (NICs).
Chapter 5, “Connecting PMC Network Interface Cards” describes how to
connect to and use each of the supported NICs.

14 Nokia 105s Gateway Installation Guide
Chapter 6, “Installing and Replacing Other Components” describes how
to install or replace RAM memory and hard-disk drives.
Chapter 7, “Troubleshooting” describes problems you might encounter
and proposes solutions to these problems.
Appendix A, “Technical Specifications” provides technical specifications
such as interface characteristics.
Appendix B, “Compliance Information” provides compliance and
regulatory information.
Conventions this Guide Uses
The following sections describe the conventions this guide uses, including
notices, text conventions, and command-line conventions.
Notices
Warning
Warnings advise the user that bodily injury might occur because of a
physical hazard.
Caution
Cautions indicate potential equipment damage, equipment
malfunction, loss of performance, loss of data, or interruption of
service.
Note
Notes provide information of special interest or recommendations.

Conventions this Guide Uses
Nokia 105s Gateway Installation Guide 15
Command-Line Conventions
You might encounter one or more of the following elements on a command-
line path.
Table 1 Command-Line Conventions
Convention Description
command This required element is usually the product name or other
short word that invokes the product or calls the compiler or
preprocessor script for a compiled Nokia product. It might
appear alone or precede one or more options. You must
spell a command exactly as shown and use lowercase
letters.
Italics Indicates a variable in a command that you must supply. For
example:
delete interface if_name
Supply an interface name in place of the variable. For
example:
delete interface nic1
angle brackets < > Indicates arguments for which you must supply a value:
retry-limit <1–100>
Supply a value. For example:
retry-limit 60
Square brackets [ ] Indicates optional arguments.
delete [slot slot_num]
For example:
delete slot 3

16 Nokia 105s Gateway Installation Guide
Text Conventions
Table 2 describes the text conventions this guide uses.
-flag A flag is usually an abbreviation for a function, menu, or
option name, or for a compiler or preprocessor argument.
You must enter a flag exactly as shown, including the
preceding hyphen.
.ext A filename extension, such as .ext, might follow a variable
that represents a filename. Type this extension exactly as
shown, immediately after the name of the file. The extension
might be optional in certain products.
( . , ; + * - / ) Punctuation and mathematical notations are literal symbols
that you must enter exactly as shown.
' ' Single quotation marks are literal symbols that you must
enter as shown.
Table 1 Command-Line Conventions
Convention Description
Table 2 Text Conventions
Convention Description
monospace font Indicates command syntax, or represents computer or
screen output, for example:
Log error 12453
bold monospace font Indicates text you enter or type, for example:
# configure nat
Key names Keys that you press simultaneously are linked by a
plus sign (+):
Press Ctrl + Alt + Del.

Related Documentation
Nokia 105s Gateway Installation Guide 17
Related Documentation
You can find this guide in PDF on the Nokia support Web site (https://
support.nokia.com/) and on the Nokia IPSO operating system CD-ROM
issued with your Nokia 105s gateway.
In addition to this guide and other documents shipped with your gateway,
documentation for this product includes the following:
Nokia Network Voyager Reference Guide for the version of Nokia IPSO
you are using
CLI Reference Guide for the version of Nokia IPSO you are using
Getting Started Guide and Release Notes for the version of Nokia IPSO
you are using
Nokia IPSO Boot Manager Reference Guide
Nokia Network Voyager inline help
Nokia Secure Access System Release Notes for the version of NSAS you
are using
Menu commands Menu commands are separated by a greater than
sign (>):
Choose File > Open.
The words enter and type Enter indicates you type something and then press
the Return or Enter key.
Do not press the Return or Enter key when an
instruction says type.
Italics •Emphasizes a point or denotes new terms at the
place where they are defined in the text.
•Indicates an external book title reference.
•Indicates a variable in a command:
delete interface if_name
Table 2 Text Conventions
Convention Description

18 Nokia 105s Gateway Installation Guide
Nokia Secure Access System New Feature Guide for the version of NSAS
you are using
Nokia Secure Access System Getting Started Guide for the version of
NSAS you are using
Nokia Secure Access System End Users Guide for the version of NSAS
you are using
Nokia Secure Access System Technology Overview for the version of
NSAS you are using
Nokia Secure Access System Configuration Guide for the version of
NSAS you are using
Nokia 105s Information Sheet
You can find the most up-to date version of the Nokia 105s Gateway
Installation Guide and other documents in the preceding list in PDF on the
Nokia support site (https://support.nokia.com). You can access inline help, the
Nokia Network Voyager Reference Guide, and the CLI Reference Guide from
Nokia Network Voyager.
060306

Nokia 105s Gateway Installation Guide 19
1Overview
The Nokia 105s gateway combines the power of Nokia IPSO software and
Nokia Secure Access System (NSAS). NSAS enables enterprises to securely
extend enterprise network resources to users outside the intranet. Users can
access enterprise resources from any Web-capable platform and location. The
small size of the 105s gateway makes it ideal for installations that need to
conserve space.
As network devices, 105s gateways support a comprehensive suite of
IP-routing functions and protocols, including RIPv1/RIPv2, IGRP, OSPF and
BGP4 for unicast traffic, and DVMRP for multicast traffic.
This chapter provides an overview of the 105s gateway and the requirements
for using it. The following topics are covered:
About the Nokia 105s Gateway
Managing the 105s Gateway
Site Requirements, Warnings, and Cautions
Software Requirements
Product Disposal
About the Nokia 105s Gateway
The 105s is a one rack-unit gateway that incorporates a serviceable slide-out
tray into the chassis design and support for various network interface cards
(NICs).

1Overview
20 Nokia 105s Gateway Installation Guide
The Nokia IPSO system is stored on the hard-disk drive.
Table 3 shows the specifications for the 105s gateway
The following figures show component locations for the Nokia 105s gateway.
Figure 1 Component Locations Front View
Table 3 Specifications for the 105s Gateway
Feature Nokia 105s
Maximum memory size 2 GB
Network interface cards
(NICs) support •Two or fewer four-port 10/100 Ethernet NICs
•Two or fewer two-port copper Gigabit Ethernet NICs
•Two or fewer two-port fiber-optic Gigabit Ethernet
NICs
00525gen
System status LEDs
AUX port
Console port
Four-port Gigabit Ethernet
PC-card slots
PMC NIC slots (slots 1 and 2)
unpopulated in base bundle
Reset button
