Nokia BH-310 User manual

Nokia Bluetooth
Mono Headset
BH-310
5555555/1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Introduction
About your headset
With the Nokia Bluetooth Mono Headset BH–
310, you can handle calls hands-free, even
when using two phones at the same time.
The surface of this product is nickel-free.
Read this user guide carefully before using the
product. Also, read the user guide for the device
that you connect to the product.
For more info, go to www.nokia.com/
support.
About Bluetooth connectivity
You can use Bluetooth to make a wireless
connection to other compatible devices, such
as mobile phones.
Devices do not need to be in direct line-of-
sight, but they must be within 10 metres (33
feet) of each other. The connection may be
affected by obstructions such as walls or
other electronic devices.
This device is compliant with Bluetooth
Specification 3.0 + EDR supporting the following
profiles: headset profile (1.1) , handsfree profile
(1.5). Check with the manufacturers of other
devices to determine their compatibility with
this device.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Get started
Keys and parts
1Charger connector
2Multifunction key
3NFC area
4Earloop
5Earpiece
6Carrying clip
7Microphone
8Car holder
9Charger connector
10 Indicator light
Charge the battery
Warning: Use only chargers approved by
Nokia for use with this particular model. The use
of any other types may invalidate any approval
or warranty, and may be dangerous. Use of
unapproved chargers may present a risk of fire,
explosion, or other hazard.
1. Plug the charger into a wall outlet.
2. Plug the charger to the charger connector
on the headset or on the car holder. The
red indicator light turns green when the
battery is fully charged.
3. Unplug the charger from the headset or car
holder, then from the wall outlet.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

When you unplug a charger, hold and pull the
plug, not the cord.
The fully charged battery has power for up to
5 hours of talk time and up to 114 hours of
standby time. If you keep the headset in the
clip, the standby time is up to 90 days.
When the battery charge is low, the red
indicator light flashes, and you hear a voice
prompt every 5 minutes. If you've switched
voice prompts off, the headset beeps every 5
minutes.
Check the battery charge — When the
headset is switched on and you're not in a
call, press . A green light means there is
enough power. If the light is yellow, you may
need to recharge the battery soon. If the light
is red, recharge the battery.
Switch the headset on or off
Switch on — Remove the headset from the
clip or from the car holder. The headset
beeps, and a green indicator light flashes
once.
If you've never paired the headset with a
phone, or you've cleared the pairings, pairing
mode is switched on. Pair and connect the
headset with your phone within 3 minutes.
If you've paired the headset before, it
connects to the last phone it was used with.
If the headset can't find that phone, it tries
the next phone on its list of paired devices. If
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

not connected to a phone within 30 minutes,
the headset switches off.
Switch off — Put the headset in the clip. The
headset beeps, and a red indicator light
flashes once. All calls are ended.
Tip: Don't have the clip with you? To
switch the headset off, press and hold
for 5 seconds. To switch the
headset on, press .
Wear the headset
Slide the earloop behind your ear, then gently
push the earpiece against your ear. Point the
headset towards your mouth.
Change the earpad
1. The headset comes with different-sized
earpads. Select the earpad that fits the
best, and is the most comfortable for your
ear.
2. To change the earpad, pull the current
earpad from the earpiece, and push the
new earpad into place.
The headset is set up to be used on your right
ear.
Use the headset on your left ear — Remove
and attach the earloop so that it is to the left
of .
When you're not using your headset, keep it
in the clip, or car holder.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Tip: Have your headset always at
hand – clip it to your pocket as you
would a pen.
Use the car holder
1. Make sure the surface of the car dashboard
is dry and clean.
2. Remove the protective film from the
bottom of the car holder.
3. Firmly press the car holder into place.
Tip: You can also charge your headset
through the car holder. Use a
compatible charger that uses the car
cigarette lighter socket, and connect
it to the holder.
Pair the device
Pair and connect the headset to your
phone
Before using the headset, you must pair and
connect it to a compatible phone.
You can pair your headset with 8 phones, but
you can only connect it to a maximum of 2
phones at the same time.
With some phones, you may need to make
the connection separately after pairing.
When the headset is connected to a phone,
the Bluetooth indicator light flashes slowly.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Pair and connect the headset using
NFC
If the compatible phone supports NFC, switch
its NFC feature on, then switch the headset
on, and touch the NFC area of the headset
with the NFC area of your phone. The headset
connects to the phone automatically.
You can also disconnect the headset using
NFC. For details on NFC, see the user guide of
the phone.
If the phone does not support NFC, pair the
headset manually.
Pair the headset manually
1. Make sure your headset is switched off and
your compatible phone is on.
2. If you've never paired the headset with a
device, or you've cleared the pairings,
switch the headset on.
If you've previously paired your headset
with another device, press and hold for
5 seconds.
Pairing mode is switched on, and a blue
indicator light starts to flash quickly.
3. Within 3 minutes, switch Bluetooth on in
your phone, then set it to search for
Bluetooth devices. For details, see the user
guide of the phone.
4. On your phone, select the headset from the
list of found devices.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

5. If asked, type in the passcode 0000.
In some devices, you may need to make the
connection separately after pairing.
Pair and connect the headset to two
devices
1. Make sure Bluetooth is switched on in both
phones.
2. To switch the headset off, press and hold
for 5 seconds.
3. Press and hold for 5 seconds to switch
pairing mode on, then pair the headset
with the second phone.
4. Switch the headset off and back on. The
headset connects to both phones.
Make calls
Make and receive calls
To make and receive calls using your headset,
you need to connect it to your phone.
Make a call — Make a call in the normal way.
Answer a call — Remove the headset from
the clip.
Tip: If the headset is not in the clip,
press .
End a call — Put the headset in the clip.
Tip: To end a call, you can also press
.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Decline a call — Press twice.
Switch a call between your headset and
phone — Press and hold for 2 seconds.
When you're not in a call, you can redial the
last called number or use voice dialling, if
your phone supports these features with the
headset.
Redial the last called number — Press
twice.
Use voice dialling — Press and hold for
2 seconds, then follow the instructions in the
user guide of your phone.
Handle calls from two phones
Continue an ongoing call, and decline a
call on another phone — Press twice.
End an ongoing call, and answer a call on
another phone — Press .
Put an ongoing call on hold, and answer a
call on another phone — Press and hold
for 2 seconds.
Switch between active and held calls —
Press and hold for 2 seconds.
End an ongoing call, and go back to a held
call — Press .
If you redial or use voice dialling, the call is
made on the phone you last used for a call
with the headset.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Product and safety
information
Driving safety
Obey all local laws. Always keep your hands free
to operate the vehicle while driving. Your first
consideration while driving should be road
safety. Only use the car holder if it is safe to do
so under all driving conditions.
When you install the car holder in a car, make
sure it does not interfere with or hinder the
steering or braking systems or other systems
used in the operation of the vehicle (for example,
airbags) or disturb your field of vision while
driving.
Check that the deployment of the airbag is not
blocked or impaired in any way. Make sure that
the car holder is not installed where you might
come in contact with it in the event of an accident
or collision.
Battery and charger information
This device has an internal, nonremovable,
rechargeable battery. Do not attempt to remove
the battery from the device as you may damage
the device.
This device is intended for use when supplied
with power from the following chargers: DC-6.
The exact charger model number may vary
depending on the type of plug. The plug variant
is identified by one of the following: E, X, AR, U,
A, C, K, or B.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

The battery can be charged and discharged
hundreds of times, but it will eventually wear
out.
Talk and standby times are estimates only. Actual
times are affected by, for example, device
settings, features being used, battery condition,
and temperature.
If the battery has not been used for a long time,
to begin charging, you may need to connect the
charger, then disconnect and reconnect it.
If the battery is completely discharged, it may
take several minutes before the charging
indicator is displayed.
When your charger is not in use, unplug it from
the electrical plug and the device. Do not leave a
fully charged battery connected to a charger, as
overcharging may shorten the battery’s lifetime.
If left unused, a fully charged battery will lose its
charge over time.
Always keep the battery between 15°C and 25°C
(59°F and 77°F). Extreme temperatures reduce
the capacity and lifetime of the battery. A device
with a hot or cold battery may not work
temporarily.
Do not dispose of batteries in a fire as they may
explode. Dispose of batteries according to local
regulations. Recycle when possible. Do not
dispose as household waste.
Use the charger for its intended purpose only.
Improper use or use of unapproved chargers may
present a risk of fire, explosion, or other hazard,
and may invalidate any approval or warranty. If
you believe the charger is damaged, take it to a
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

service centre for inspection before continuing
to use it. Never use a damaged charger. Only use
the charger indoors.
Take care of your device
Handle your device, charger and accessories with
care. The following suggestions help you protect
your warranty coverage.
•Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that corrode
electronic circuits. If your device gets wet,
allow the device to dry.
•Do not use or store the device in dusty or
dirty areas. Moving parts and electronic
components can be damaged.
•Do not store the device in high
temperatures. High temperatures can
shorten the life of the device, damage the
battery, and warp or melt plastics.
•Do not store the device in cold
temperatures. When the device warms to
its normal temperature, moisture can form
inside the device and damage electronic
circuits.
•Do not attempt to open the device.
•Unauthorised modifications may damage
the device and violate regulations
governing radio devices.
•Do not drop, knock, or shake the device.
Rough handling can break internal circuit
boards and mechanics.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

•Only use a soft, clean, dry cloth to clean the
surface of the device.
•Do not paint the device. Paint can clog
moving parts and prevent proper
operation.
Recycle
Always return your used electronic products,
batteries, and packaging materials to dedicated
collection points. This way you help prevent
uncontrolled waste disposal and promote the
recycling of materials. Check how to recycle your
Nokia products at www.nokia.com/recycling.
Copyright and other
notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this
BH-310 product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of the
Declaration of Conformity can be found at
www.nokia.com/phones/
declaration_of_conformity/.
© 2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People and Nokia
Original Accessories logo are trademarks or
registered trademarks of Nokia Corporation.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Reproduction, transfer, distribution, or storage
of part or all of the contents in this document in
any form without the prior written permission of
Nokia is prohibited. Nokia operates a policy of
continuous development. Nokia reserves the
right to make changes and improvements to any
of the products described in this document
without prior notice.
The Bluetooth word mark and logos are owned
by the Bluetooth SIG, Inc. and any use of such
marks by Nokia is under license.
The contents of this document are provided "as
is". Except as required by applicable law, no
warranties of any kind, either express or implied,
including, but not limited to, the implied
warranties of merchantability and fitness for a
particular purpose, are made in relation to the
accuracy, reliability or contents of this document.
Nokia reserves the right to revise this document
or withdraw it at any time without prior notice.
To the maximum extent permitted by applicable
law, under no circumstances shall Nokia or any
of its licensors be responsible for any loss of data
or income or any special, incidental,
consequential or indirect damages howsoever
caused.
The availability of particular products may vary
by region. Please check with your Nokia dealer
for details. This device may contain
commodities, technology or software subject to
export laws and regulations from the US and
other countries. Diversion contrary to law is
prohibited.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of the FCC Rules
and Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following
two conditions: 1. This device may not cause
harmful interference; and 2. This device must
accept any interference received, including
interference that may cause undesired
operation. This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures: Reorient or relocate the receiving
antenna. Increase the separation between the
equipment and receiver. Connect the equipment
into an outlet on a circuit different from that to
which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for
help. NOTE: FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

located or operating in conjunction with any
other antenna or transmitter. NOTE: Changes or
modifications not expressly approved by Nokia
could void the user's authority to operate the
equipment.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
