Nolan N-Com B601S Series User manual

EN

EN
Fw 1.0-1 - 29/07/2019
USER INSTRUCTIONS AND SAFETY
Congratulations on your purchase of an N-Com product.
N-Com B601 was made using the most advanced technologies and the best materials.
Long-running tests and thorough system development have allowed the highest audio
quality to be achieved.
For additional information about B601 visit the website www.n-com.it
Firmware version: 1.0
REFERENCE STANDARDS
The products of the N-Com line are in compliance with standards as per the table below:
B601
The Bluetooth system complies with the main safety requirements and
other applicable provisions of Directive RED 2014/53/EU, Directive
2009/65/EC, Directive 2011/65/CE, Directive 2012/19/EU
Battery
charger
Dire
ct
ive
2014/35/EU LVD, 2014/30/EU EMC, 2009/125/CE ErP,
2011/65/EU RoHS, 2012/19/EU WEEE
Battery
Directive
2001/95/CE
–
GPSD, 2013/56/UE BAT, 2014/30/EU
The Declarations of Compliance can be downloaded from the website www.n-com.it (Download
section).
Model: B601 S
PMN: N-Com B601 S
FCC ID:
Y6MNCOM19
IC:
9455A-NCOM19
R-NZ
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc.
and any use of such marks by N-Com is under license. Other trademarks and trade names are those
of their respective owners.

Contents
1. WARNINGS AND SAFETY.................................................................................................................... 5
1.1.Road safety.........................................................................................................................................................................................5
1.2.Switching on the system in safe environments................................................................................................................5
1.3.Interferences......................................................................................................................................................................................5
1.4.Appropriate use ...............................................................................................................................................................................5
1.5.Qualified personnel........................................................................................................................................................................6
1.6.Accessories and batteries............................................................................................................................................................6
1.7.Disposal................................................................................................................................................................................................6
2. CONTENT OF THE PACKAGING......................................................................................................... 7
3. INSTALLATION ...................................................................................................................................... 8
3.1.Installing the microphone...........................................................................................................................................................9
3.2.Installing the system on the helmet.......................................................................................................................................9
3.3.Removing the system................................................................................................................................................................. 11
4. BASIC FUNCTIONS .............................................................................................................................12
4.1.Volume adjustment..................................................................................................................................................................... 12
4.2.Multi-language voice messages ...........................................................................................................................................12
4.3.N-Com EASYSET ........................................................................................................................................................................... 12
5. CONFIGURATION MENU...................................................................................................................13
6. PAIRING UP WITH MOBILE PHONES OR OTHER BLUETOOTH DEVICES ................................ 13
7. MOBILE PHONE...................................................................................................................................14
7.1.Speed dial ........................................................................................................................................................................................ 14
7.2.Conference call function ........................................................................................................................................................... 15
8. MANAGING TWO MOBILE PHONES (OR BLUETOOTH DEVICES)............................................. 15
9. SMART NAVI SYSTEM........................................................................................................................15
10. MUSIC VIA BLUETOOTH....................................................................................................................16
10.1.Sharing music via Bluetooth (A2DP Sharing)............................................................................................................... 16
11. SATELLITE NAVIGATOR FOR MOTORCYCLES............................................................................... 16
12. INTERCOM ...........................................................................................................................................17
12.1.N-Com “900”/”600” Series Intercom pairing up ........................................................................................................ 17
12.2.N-Com “900”/”600” Series Intercom function (one-to-one connection).......................................................17
13. “UNIVERSAL INTERCOM” INTERCOM ............................................................................................ 18
13.1.Pairing up the UNIVERSAL INTERCOM ........................................................................................................................... 18
13.2.Universal Intercom Function ................................................................................................................................................ 18
14. BATTERY AND RECHARGE ................................................................................................................ 19
14.1.Low battery signal ..................................................................................................................................................................... 19
14.2.Checking the Battery Level ................................................................................................................................................... 19
14.3.Charging the system ................................................................................................................................................................ 19
15. SUMMARY TABLE OF CONTROLS...................................................................................................20
16. LIMITED WARRANTY..........................................................................................................................21
16.1.Warranty coverage.................................................................................................................................................................... 21
16.2.Exclusions and limitations of the coverage ..................................................................................................................21
16.3.Validity of this limited warranty.......................................................................................................................................... 22
16.4.Procedure for the forwarding of claims ......................................................................................................................... 22
16.5.Product identification .............................................................................................................................................................. 22
17. WARRANTY REGISTRATION FORM.................................................................................................23

5
1. WARNINGS AND SAFETY
Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-
Com B601. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations.
Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and
the like.
Caution: Installation of the N-Com B601 system results in a weight increase of approximately 110g, which is added
to the weight of the helmet and of the other accessories.
Warning: The electronic components of the N-Com system mounted inside the helmet are not waterproof.
Consequently, make sure the inside of the helmet, including the comfort padding, does not get wet in order to
avoid damage to the system. If it does, remove the N-Com system and the helmet comfort padding and let it
air dry. Disconnect the battery connector and let it dry as well.
1.1. Road safety
Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should always be engaged in
actually riding the vehicle. Any operation to the N-Com system must be carried out with the vehicle stopped.
Specifically:
Set your cell phone on automatic answer (see the cell phone instructions to do this).
If your cell phone is not equipped with this function, first stop your vehicle in a safe area, in compliance with
Traffic Regulations and then answer the call.
Do not make any calls while riding. Stop your vehicle in a safe place in compliance with Traffic Regulations, and
then make the call.
Adjust the volume so that it does not cause a disturbance or distraction while riding and at the same time allows
you to distinctively hear background noises.
Do not operate your cell phone or other devices connected to N-Com while riding your motorcycle.
In all cases, obey the Traffic Regulations and remember that riding the motorcycle has absolute priority over any
other maneuver.
1.2. Switching on the system in safe environments
When using the N-Com system, comply with all limitations and instructions related to the use of cell phones.
Do not turn on your cell phone or the N-Com system whenever their use is forbidden or when the devices can
cause interference or dangerous situations.
Turn off while refueling. Do not use the N-Com system in filling stations. Do not use the device near combustible
materials or chemical products.
Turn off in proximity to explosive materials.
1.3. Interferences
All phones and devices with wireless signal transmission are subject to interferences that may affect the
performance of the device connected to them. These interferences are not ascribable to a defect of the N-Com
system.
1.4. Appropriate use
Use the device only in the normal position, as described in the product documentation. Do not attempt to
disassemble, tamper with or modify any part of the N-Com system.
Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it before
you use the system on the road.
Caution: Adjusting the volume to very high levels may cause damage to your hearing.
Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected to it so as to
avoid audio reproduction at high volumes. Constant exposure to high audio volumes may damage your
hearing.

EN
6
Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and safety characteristics of
the helmet itself, thus creating dangerous conditions. Install the N-Com system according to the instructions
provided in the product documentation. In case of doubt, please contact your local N-Com dealer.
Warning: Listening to other equipment should not interfere with driving the vehicle, which must be the top priority
at all times. Carry out all operations on the electronic equipment and on the N-Com system with the vehicle
stopped, in compliance with Traffic Regulations.
1.5. Qualified personnel
Only qualified personnel can carry out technical assistance on this product. In case of any malfunction, always
turn to your local dealer.
The helmet is a safety device. Tampering with it and/or with the electronic system inside the helmet, in addition
to invalidating the product warranty, can also lead to dangerous situations.
1.6. Accessories and batteries
Only use the type of batteries, battery chargers and accessories approved by Nolangroup for the specific model.
The use of a battery type different from the recommended one may lead to dangerous situations and invalidate
the warranty.
Contact your local dealer to see about the availability of approved accessories.
When disconnecting the power supply cable of any accessory or of the battery charger, always grab and pull the
plug not the cable.
Do not use batteries for purposes other than the prescribed ones.
Never use batteries or battery chargers that turn out to be damaged.
Do not short-circuit the battery.
Keep the battery at a temperature between 0° / +45°C (charging); -20° / +60 °C (in use).
Danger of fire or explosion: do not throw the batteries into a fire nor expose them to high temperatures!
Do not throw out batteries together with household refuse. The batteries should be disposed of in compliance
with local regulations
Do not wear the helmet while the battery is recharging.
The helmet should never be left within the reach of unsupervised children in order to prevent damage to their
health caused by access to the batteries.
Battery
PL053448
P
3,7V
–
1000 mAh
1.7. Disposal
Refer to this user manual and to manuals related to other parts of the N-Com system in order to disassemble the
system from the helmet. Once the system has been disassembled, dispose of it according to the following
instructions:

The presence of a crossed-out wheelie bin indicates that in the European Union the product is
subject to separate collection at the end of its useful life (European Directive 2002/96/EC).
Do not dispose of these products together with undifferentiated urban waste.
The proper disposal of obsolete equipment contributes to preventing possible negative consequences on
people’s health and on the environment.
For more detailed information on the disposal of obsolete equipment, contact your municipality, a waste disposal
service or the store where the product was purchased.

7
2. CONTENT OF THE PACKAGING
The N-Com B601 package contains:
e
-
box
B601
Electronic plate
PC connection cable
Microphone
Battery holder
Rechargeable battery
Key, screw, clamp Microphone
-
Stop
Adhesive Velcro pads

EN
8
3. INSTALLATION
Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 16.5).
You can download the installation video from www.n-com.it N-Com / Download section.
Remove the “N-Com” protection plate located on the helmet shell (Fig. 1) and open the helmet
chin guard (flip up helmets).
Remove the right and left cheek pads from the helmet (see specific instructions provided in the
user manual of the helmet).
Remove the back of the comfort padding by pulling on the neck roll until it separates from the
shell.
Temporarily put the padding on the outside of the helmet (Fig. 2).
Remove the N-Com cover from the helmet border gasket. Push from the inside of the helmet to
facilitate the removal (Fig. 3).
Fig. 1 Fig. 2 Fig. 3
Fig. 4
ONLY FOR FULL-FACE HELMETS:
Remove the chin guard by pulling on the special red tab (Fig. 4).
Fig. 5
Remove the right and left polystyrene cheek pads by gently
pulling them out of the helmet. The helmet shell can be opened
slightly to facilitate the removal of the cheek pad.
Caution: In case the polystyrene cheek pad is damaged during
this operation, turn to your local dealer for its replacement.

9
3.1. Installing the microphone
JET HELMETS OR FLIP-UP HELMETS
Prepare the microphone by inserting the microphone clamp, being careful to position it properly
(Fig. 6).
Position the microphone in its support as shown in figure 7, being careful that the fluorescent
clamp is facing toward the inside of the helmet.
Insert screw in the microphone clamp; use the key to screw in the microphone securing screw to
the shell frame (Fig. 8).
Fig. 6 Fig. 7
Fig. 8
FULL-FACE HELMETS
Take the polystyrene cheek pad (left-hand side) and position the microphone in its housing, as shown
in Fig. 9, making sure that the fluorescent band stays facing the inside of the helmet (Fig. 10).
Fig. 9 Fig. 10
3.2. Installing the system on the helmet
Position the system inside the helmet as shown in figure 11, next to the N-Com housing in the
shell.
Looking at the helmet from the outside, slide the rear positioning tab into groove A as shown in
the figure.
Press in the area marked PUSH from inside the helmet until the fastening clasp B clicks (Fig. 12).
Pull out the connector’s area from the helmet gasket: the gasket will have to be slightly deformed
to facilitate the insertion (Fig. 13).

EN
10
Fig. 11
Fig. 12 Fig. 13
Insert the microphone connector in the micro USB electronic plate (Fig. 14).
Before you place the speaker in its housing, apply the Velcro pad to the polystyrene cheek pad
(Fig. 15).
Position the loudspeaker in the special housing obtained in the polystyrene cheek pad (Fig. 16).
Replace the polystyrene cheek pad (left side), positioning the cable in the groove that you see in
the cheek pad.
Note: Make sure the cheek pad is properly positioned in its housing, pushing in the lined corner
underneath the ribbing on the shell.
Fig. 14
Fig. 15
Fig. 16
Fig. 17
ONLY FOR JET HELMETS OR FLIP-UP HELMETS:
Secure the battery-holder support to the right side of the
helmet, lining up the holes with the pins on the shell (Fig. 17).
Fig. 18
ONLY FOR FULL FACE HELMETS
Position the battery in the right polystyrene cheek pad housing
(Fig. 18).

11
Before you place the speaker in its housing, apply the Velcro pad to the polystyrene cheek pad
(right side).
Position the loudspeaker in its housing obtained in the polystyrene cheek pad (right side).
Replace the polystyrene cheek pad (right side), positioning the cable in the groove you see in the
cheek pad.
ONLY FOR FULL-FACE HELMETS: Insert the chin guard (microphone side), gently placing the
microphone in its housing. Then press down on the red tab until the chin guard is locked in place on
the helmet.
Position the comfort padding in its housing (see specific instructions provided in the helmet user
manual), hooking the neck roll.
Position both the comfort cheek pads in their housing (see specific instructions provided in the
helmet user manual) making sure that all the press-studs click.
Note: Carefully check the proper final positioning of the cheek pad, pulling the chinstrap toward the
inside of the helmet and testing the press-studs.
Caution: Make sure that there are no cables sticking out of the helmet and that the loudspeakers are
in their housing.
Caution: Always verify the proper length of the chinstrap and adjust it as necessary, once again
referring to the specific helmet instructions.
Position the e-box in the relevant housing. First insert the front part, then press down on the e-
box until both hooks fully click.
Warning: Do not leave the helmet exposed to atmospheric agents without the e-box or the
protection plate provided with the helmet.
3.3. Removing the system
Remove the protection plate, then, looking at the helmet from the outside, release the connector
by acting on the fastening clasp as illustrated in the figure.
After releasing the connector from the shell, also remove the right part by releasing the battery
holder.
Now remove the entire system from the helmet.
Fig. 19
To remove the system from the helmet, remove the
earphone and the comfort cheek pads as shown in the
assembly operations. Then remove the polystyrene cheek
pads.
To remove the e-box, press the two sliding hooks at the
same time until the e-box comes out.

EN
12
4. BASIC FUNCTIONS
Note: Before using the N-Com device for the first time, recharge the battery completely for at least
10 hours. To obtain best performances from the battery, it is recommended to completely recharge
the battery the first few times. Afterwards, you can recharge the battery for shorter periods. Whenever
possible, it is best to recharge the battery completely.
System ON
Press “
ON
” and keep it pressed for about 2 seconds, until the LEDs turn
on and you hear the voice announcement.
System OFF
Press
“
ON
” and keep it pressed for about
3
seconds, until the LEDs turn
off and you hear the voice announcement.
4.1. Volume adjustment
You can easily adjust the volume by tapping the “” button or the “”button. You will hear a beep
when the volume reaches the maximum or minimum level.
The volume is independent for each sound source. Once it is set for a specific source (phone call,
radio, Mp3), it will be remain in memory even after the system is switched off.
However, if you adjust the volume during stand-by mode, it will affect volume levels of every audio
source.
4.2. Multi-language voice messages
The N-Com system features voice messages that provide information on the system and on the active
functions.
The language set by default is English. The language of the voice messages may be changed through
the specific firmware installable with the N-Com EASYSET program. Please refer to the online HELP for
instructions on how to change the language settings.
Available languages: Italian, English, French, German, Spanish, Dutch.
4.3. N-Com EASYSET
“N
-
Com
EASYSET” is the
application that can be used to
manage and configure the
B601
system. The programme can be downloaded from the Internet site www.n-com.it, in the
“Download” section. The functions that can also be managed from the N-Com EASYSET
are listed here below with the specific icon.

13
5. CONFIGURATION MENU
All Bluetooth pair ups and other adjustments are carried out in this mode.
To put the system in “Configuration mode” (starting from a switched off system) press the “ON” key
and keep it pressed for 4 seconds, until you hear the voice announcement “ Configuration ”.
Once in the “Configuration” menu, press the keys“” and “” to scroll through the various menu
items.
In the items marked with an “*”, it is possible to enable / disable the function or carry out the
commands by pressing the “ON” key to confirm.
The following items make up the “Configuration” menu:
A. Mobile phone pairing (chapter 6)
B. Intercom pairing (chapter 12)
C. Universal Intercom pairing (chapter 13)
D. Second mobile phone pairing (chapter 8)
E. Speed dial* (chapter 7.1)
F. Smart Navi System (cap. 9)
G. Delete all pairings*
In order to delete all Bluetooth pair ups stored in the device, press the key “” or “” until you
hear the voice announcement “ Delete all pairings ”.
Press the “ON” confirmation key to delete all Bluetooth devices stored in memory.
H. Reset*
In order to restore the factory settings of the device, press the key “” or “” until you hear the
voice message “ Reset ”.
Press the “ON” confirmation key to restore all the factory settings of the device.
I. Exiting the configuration*
To exit the “Configuration” menu, press the key “” or “” until you hear the voice
announcement “ Exit the configuration ”.
Press the “ON” confirmation key to exit the “Configuration” menu.
If no key is pressed within 10 seconds, the device automatically exits the “Configuration” menu.
6. PAIRING UP WITH MOBILE PHONES OR OTHER BLUETOOTH DEVICES
Make sure the B601 is turned off.
Put the system in the “Configuration” mode, then press the “ON” key and keep it pressed for 4
seconds, until you hear the voice announcement “ Configuration ”.
Press the key “” to access the “Mobile phone pair up mode”.
Turn on the search for Bluetooth devices (smartphone, GPS, MP3 reader) on the device.
Select the N-Com device. If a password is requested, enter 0000 (four zeros).
Connection between the two devices is established after a few seconds.
Note: The affiliation is stored in the helmet and in the cell phone and it is not lost when the two
devices are turned off. As a result it needs to be carried out only once.
Automatic Connection
Once the Bluetooth device has been paired up, connection is automatic
when the system is turned on.
Manual Connection
In case
connection is not automatically initiated after a few seconds, you
can connect from the Bluetooth device or by pressing “ON” and keep it
pressed for about 2 seconds.

EN
14
7. MOBILE PHONE
To pair up a mobile phone to the B601 system, follow the procedure illustrated in Chapter 6.
Answering a phone call Briefly press any key when you hear the incoming call signal.
Vocal answer (VOX phone)
When you hear the ringtone, say any word out loud.
You can enable / disable the “VOX phone” function by using
the N-Com EASYSET program.
Voice call Press “ON” and keep it pressed for about 2 seconds.
Hanging up/rejecting a phone call Press “ON” and keep it pressed for about 2 seconds.
Manual phone connection Press “ON” and keep it pressed for about 2 seconds.
7.1. Speed dial
Using the N-Com EASYSET program, you can store up to 3 of your favourite numbers,
which you will be able to dial from the “ Speed Dial ” menu.
Saving the Speed Dial numbers
To assign one or more speed dialling numbers:
Put the system in the “Configuration” mode: starting from a switched off system, press the “ON”
key and keep it pressed for 4 seconds, until you hear the voice announcement “ Configuration ”.
Press the key “” or “” until you hear the voice command “ Speed dial ”.
Press the “ON” confirmation key. You will hear the voice announcements “ Speed dial 1 ” and
“ Phone connected ”.
Press the keys “” or “” to select the speed dialling number to be assigned. The saved position
is confirmed by the voice announcement “ Speed dial 1 “/ “ Speed dial 2 ” / “ Speed dial 3 ”.
On your own mobile phone (paired up and connected to the N-Com system), call the phone
number you wish to assign to the selected speed dialling position. The call is interrupted before it
goes through, and the selected number will be saved; at this point you will hear the special voice
announcement confirming the selection (“ Save Speed Dial 1 ” / “ Save Speed Dial 2 ” / “ Save Speed
Dial 3 ”).
Using the stored numbers
To access the “Speed Dial” menu, press at the same time the “ON” and “” keys (“ Speed Dial”) , then
use the keys “” and “” to scroll through the menu items.
Then press the “ON” key to confirm the selection of one of the following items:
 Last number redial
 Speed Dial 1
 Speed Dial 2
 Speed Dial 3
 Cancelled
If you wish to exit the “Speed Dial” menu, press the keys “” and “” until you hear the command
“ Cancelled ”, then press “ON” to confirm.
N.B.: If no key is pressed within 15 seconds, the system exits the “Speed Dial” menu.

15
7.2. Conference call function
When a call comes in on a mobile phone connected via Bluetooth to B601, the intercom is
temporarily turned off. However, if you wish to share the phone call with the other helmet, simply
turn on the intercom manually during the phone call.
Turning on the phone
conference call function
During the phone call, briefly press
“
ON
”
(channel 1).
During the phone call, press the “ON” key twice (channel 2).
During the phone call, press the “ON” key three times (channel 3).
Turning off the phone
conference call function During the phone call, briefly press “ON”.
N.B.: “Telephone Conference” function can only be used with the N-Com series “900” / “600”.
8. MANAGING TWO MOBILE PHONES (OR BLUETOOTH DEVICES)
The B601 system can be hooked up to two phones (or Bluetooth) devices at the same time.
The second phone (secondary device) can receive calls but not make them.
To pair up the second Bluetooth phone (secondary device):
Make sure the B601 is turned off.
Put the system in the “Configuration” menu: press the “ON” key and keep it pressed for 4
seconds, until you hear the voice announcement “ Configuration ”.
Press the pushbutton “” until you reach the option “ Second mobile phone pairing ”.
Turn on the search for Bluetooth devices (smartphone, GPS, MP3 reader) on the device.
Select the N-Com system from the list. If a password is requested, enter the code 0000 (four
zeroes).
After a few seconds, the connection between the two devices is activated.
Once the Bluetooth device has been paired up, connection is automatic when the system is turned
on.
If you wish to connect a mobile and a satellite navigator for motorbikes, it is recommended to pair up
the mobile as the MAIN DEVICE (chapter 6) and the navigator as the SECONDARY DEVICE, following
the procedure described above.
9. SMART NAVI SYSTEM
The “SMART NAVI SYSTEM” function allows you to listen to navigator directions coming from the
smartphone even during an intercom call.
The audio stops to allow transmission of the navigator directions from the smartphone and is
automatically re-established at the end of said instructions.
The “SMART NAVI SYSTEM” function is disabled by default on the device.
You can enable / disable the function from the Configuration Menu (Chapter 5).
N.B.: With the Smart Navi System enabled, all audio information coming from the smartphone (for
example, notification sounds) temporarily stops the audio under way.
You can enable / disable the “SMART NAVI SYSTEM” function by using the N-Com
EASYSET program.

EN
16
10. MUSIC VIA BLUETOOTH
To pair up an Mp3 device to the B601 system, follow the procedure illustrated in Chapter 6.
Play music (Play) Press “” and keep it pressed for about 2 seconds.
Pause function (Pause) When the player is playing music, press “” for 2 about seconds.
Next track (Skip) When the player is playing music, press “” for 4 about seconds.
Previous track (Rew) When the player is playing music, press “” for 4 about seconds.
10.1. Sharing music via Bluetooth (A2DP Sharing)
During the intercom connection, you can start playing music by briefly pressing the “” key for about
2 seconds. The music will be played in both systems.
Music sharing temporarily cuts off the intercom conversation; however, this can be automatically
restored by stopping the music (this is done by pressing the “” key for about 2 seconds).
N.B.: Music shared through the intercom can be managed by both systems, for example, both
systems can change the track by pressing the relative command.
N.B.: the “Music Sharing” function can be used with the N-Com series “900” / “600”.
11. SATELLITE NAVIGATOR FOR MOTORCYCLES
B601 system is compatible with the most common satellite navigators for motorcycles. For a list of
compatible models and additional details, visit the website www.n-com.it
To pair up a satellite navigator to the B601 system, follow the procedure illustrated in Chapter 6.
N.B.: Intercom connection is automatically cut off every time the navigator gives directions and
restored at the end of the message from the navigator.

17
12. INTERCOM
The N-Com B601 system allows communication with other N-Com systems, up to a maximum
distance of about 150m (in open field, with no obstacles). The range of the communication varies
depending on the N-Com systems used.
Important: The procedure described below refers exclusively to the pairing up and operation between
the B601 and the “900” / “600” series N-Com systems.
To pair up to N-Com systems of a range other than the “900” / “600” series, please refer to the
procedure described in chapter 13 “Universal Intercom”.
N.B.: The range and quality of the communication may vary significantly depending on the presence
of obstacles, weather conditions, magnetic fields.
12.1. N-Com “900”/”600” Series Intercom pairing up
Make sure the systems are turned off.
Put the systems in “Configuration” mode: press the “ON” key and keep it pressed for 4 seconds,
until you hear the voice announcement “ Configuration ”.
On both systems, press the key “” until you reach the option “ Intercom pairing ”.
On system A, press the key pertaining to the “pre-setting position” where you wish to save
system B.
Pairing up CHANNEL 1 Briefly press “ON”.
Pairing up CHANNEL 2 Press the “ON” key twice.
Pairing up CHANNEL 3 Press the “ON” key three times.
The Intercom connection with the selected channel is automatically activated at the end of the pair up
procedure.
12.2. N-Com “900”/”600” Series Intercom function (one-to-one connection)
To establish an Intercom connection with one of the systems stored in memory, simply press the
command related to the channel where the system was saved.
Connection CHANNEL 1 Briefly press “ON”.
Call CHANNEL 2 Press the “ON” key twice.
Call CHANNEL 3 Press the “ON” key three times.
Disconnection of active intercom Briefly press “ON”.
N.B.: In case the pre-setting position is empty, or the system being called cannot be reached within
the maximum range or it is already engaged in a phone call, you will hear an error voice message.
N.B.: In case the Intercom connection system falls outside the range (Intercom connection
interrupted), the B601 system will automatically try to reconnect every 8 seconds. Double beeps will
be emitted until the Intercom connection is not restored.
If you do not want automatic reconnection, press the “ON” key to stop the automatic reconnection
attempts.

EN
18
13. “UNIVERSAL INTERCOM” INTERCOM
The N-Com B601 system can be connected via Bluetooth to intercom systems of other brands or to
N-Com systems other than the “900” / “600” series, thanks to the UNIVERSAL INTERCOM function.
Important: N-Com systems other than the “900” / “600” series must be paired up to the N-Com B601
by following the procedure “Pairing up the Universal Intercom”.
13.1. Pairing up the UNIVERSAL INTERCOM
The N-Com system can be paired up to the other intercom (from now on referred to as Intercom B)
as if it was a mobile phone.
Make sure the B601 is turned off.
Put the system in the “Configuration” mode: press the “ON” key and keep it pressed for 4
seconds, until you hear the voice announcement “ Configuration ”.
Press the pushbutton “” until you reach the option “ Universal intercom pairing ” mode.
Put intercom B in the mobile phone pairing up mode (refer to the Intercom B manual).
After a few seconds, Intercom B will emit the confirmation beep.
N.B.: The system paired up using the UNIVERSAL INTERCOM is saved in the first available channel.
13.2. Universal Intercom Function
To turn on and off the audio between two helmets, proceed as follows:
From the N-Com B601 system:
Connect or disconnect Intercom B as you would for a regular N-Com intercom (chapter 12).
Intercom B may receive a dialing one that must be answered with a phone reply command.
From intercom B
Press the “ Voice call / Dial last number called ” command.
To disconnect the intercom, press “ Hanging up/rejecting a phone call ” command.
N.B.:
The N-Com B601 systems keeps an active connection with a mobile phone or a GPS even during
Bluetooth communication with other intercom systems.
The intercom system connected to N-Com B601 may not allow simultaneous connection to a
mobile phone.
Only one system paired up in Universal Intercom mode can be stored.

19
14. BATTERY AND RECHARGE
14.1. Low battery signal
During its operation, the system alerts the user with a voice message when the battery is low. From
the first message, the system has a 1-hour autonomy. Warning is given every 10 minute.
14.2. Checking the Battery Level
LED Indicator
When the system is powering on, their blue LED flashes rapidly indicating the battery level.
4 flashes = High, 70 ~ 100%
3 flashes = Medium, 30 ~ 70%
2 flashes = Low, 0 ~ 30%
Vocal Indicator
Starting from the system turned off, press at the same time the “ON” and “” buttons for about 3
seconds until you hear three, high toned beeps. Then you will hear a voice prompt indicating the
battery level. However, if you release the buttons as soon as the system turns on, you will not hear a
voice prompt for the battery level indication.
14.3. Charging the system
Fig. 20
To charge the system, hook it up to the battery charger or to a USB outlet
powered with the USB-
mini USB cable supplied as standard equipment. The
charge will take place as follows:
B601
system
turned off
When the
B601
system is connected to the battery charger, the blue LED starts to flash
quickly. When the battery is charged, the blue LED becomes steady.
B601
system
turned on
When the
B601
system is connected to the batte
ry charger, the blue LED starts to flash
quickly. When the battery is charged, the blue LED goes back to its standard flashing.
In case you don’t plan to use the N-Com system for a long time, you need to fully recharge the device
before storing it away.
In case the device is not used for a long time, carry out a complete recharging cycle of the device at
least once every 6 months to avoid possible damage to the battery.
In case the N-Com system is left for more than 6 months without ever being recharged, the device
may not switch on; in this case, recharge the N-Com system for at least 24 hours (even if the blue
signalling LED is not flashing), then try to switch on the device again.

EN
20
15. SUMMARY TABLE OF CONTROLS
Button ON 

+

Basic Functions
Turning on 2 sec
Turning off 3 sec
Increase Volume X
Decrease Volume X
Bluetooth Devices
Answer phone call* X X X
Voice call 2 sec
Speed Dialling Menu ** XX
Hang up/reject a phone call 2 sec
Manual Device Connection 2 sec
Phone Conference Activation
CHANNEL 1 X
Phone Conference Activation
CHANNEL 2 x2
Phone Conference Activation
CHANNEL 3 x3
Turning off the Conference function X
Bluetooth Music
Play music (Play) 2 sec
Pause Function (Pause) 2 sec
Next track (Forward) 4 sec
Previous track (REW) 4 sec
Share A2DP music 2 sec
N-Com
Intercom
(900/600 series)
Connection CHANNEL 1 X
Disconnection of active intercom X
Calling CHANNEL 2 x2
Calling CHANNEL 3 x3
*Press any key on the N-Com keypad.
**Press the keys at the same time.
