Nolan N-Com X Series User manual

EN

EN
v.1 - 0123
USER INSTRUCTIONS AND SAFETY
Thank you for buying an N-Com product.
N-Com B602 was made using the most advanced technology and top-quality
materials. Long-running tests and thorough system development have made it
possible to achieve the highest audio quality.
Please read the user instructions before using the product.
For further information on the B602 and video tutorials and information on
installing the latest Firmware version, please visit www.n-com.it
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.; any
use of such marks by N-Com is under license. Other trademarks and trade names are those of their
respective owners.

Contents
1. WARNINGS AND SAFETY...............................................................................................................................4
1.1.Road safety...........................................................................................................................................................................................4
1.2.Switching on the system in safe environments .......................................................................................................................4
1.3.Interferences ........................................................................................................................................................................................4
1.4.Appropriate use..................................................................................................................................................................................4
1.5.Qualified personnel ...........................................................................................................................................................................5
1.6.Accessories and batteries................................................................................................................................................................5
1.7.Disposal..................................................................................................................................................................................................5
2. CONTENT OF THE PACKAGING....................................................................................................................6
3. INSTALLATION ON THE X-1005, X-903, X-552 HELMET..........................................................................7
3.1.Preliminary operations......................................................................................................................................................................7
3.2.Installing the system in the X-1005, X-903, X-552 helmets.................................................................................................7
3.3.Microphone positioning ..................................................................................................................................................................9
3.4.Repositioning the padding ...........................................................................................................................................................10
4. INSTALLATION ON THE X-LITE HELMETS.................................................................................................11
4.1.Preliminary operations....................................................................................................................................................................11
4.2.Installing the system in the helmet............................................................................................................................................11
4.3.Microphone positioning ................................................................................................................................................................13
4.4.Repositioning the padding ...........................................................................................................................................................14
5. REMOVING THE SYSTEM..............................................................................................................................14
6. BASIC FUNCTIONS.........................................................................................................................................15
6.1.Complete Mode and Simple Mode............................................................................................................................................15
6.2.Volume adjustment.........................................................................................................................................................................15
6.3.Auto Off function..............................................................................................................................................................................16
6.4.Multi-language voice messages..................................................................................................................................................16
6.5.N-Com EASYSET ...............................................................................................................................................................................17
6.6.Updating the firmware ...................................................................................................................................................................17
7. PAIRING MODE ..............................................................................................................................................18
7.1.Pairing Menu......................................................................................................................................................................................18
8. CONFIGURATION MENU..............................................................................................................................19
9. MOBILE PHONE / MP3 PLAYER PAIRING..................................................................................................20
10. SECOND MOBILE PHONE PAIRING............................................................................................................20
11. MOBILE PHONE..............................................................................................................................................21
11.1.Speed dial.........................................................................................................................................................................................21
11.2.Conference call function..............................................................................................................................................................22
11.3.Smart Navi System.........................................................................................................................................................................22
12. MUSIC VIA BLUETOOTH...............................................................................................................................23
12.1.Sharing music via Bluetooth (A2DP Sharing).......................................................................................................................23
13. GPS PAIRING...................................................................................................................................................23
14. INTERCOM RIDER-PASSENGER...................................................................................................................24
14.1.N-Com “600”/”800”/”900” Series Intercom pairing ...........................................................................................................24
14.2.Pairing with other N-Com Systems .........................................................................................................................................24
14.3.Intercom function ..........................................................................................................................................................................25
15. “UNIVERSAL INTERCOM” INTERCOM........................................................................................................25
15.1.Pairing with the UNIVERSAL INTERCOM ...............................................................................................................................25
15.2.Universal Intercom Function......................................................................................................................................................25
16. REMOTE CONTROL........................................................................................................................................26
17. BATTERY AND RECHARGE............................................................................................................................27
17.1.Low battery signal..........................................................................................................................................................................27
17.2.Checking the Battery Level .........................................................................................................................................................27
17.3.Charging the system.....................................................................................................................................................................27
18. SUMMARY TABLE OF CONTROLS ..............................................................................................................28
19. WARRANTY .....................................................................................................................................................30
19.1.Warranty coverage and validity................................................................................................................................................30
19.2.Exclusions and limitations of coverage..................................................................................................................................30
19.3.Procedure for submitting claims ..............................................................................................................................................30
19.4.Product identification...................................................................................................................................................................31

4
1. WARNINGS AND SAFETY
Product compliant with EU Directive 2014/53/EU (RED). Complete compliance statement downloadable at
www.n-com.it
Read this User Manual carefully, as well as the simple rules listed below. Failure to comply with these rules
may lead to dangerous situations.
Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing
tracks and the like.
Caution: Installation of the N-Com system results in a weight increase of approximately 100-120 g, which is
added to the weight of the helmet and of the other accessories.
Warning: The electronic components of the N-Com system mounted inside the helmet are not waterproof.
Consequently, make sure the inside of the helmet, including the comfort padding, does not get wet in
order to avoid damage to the system. If water seeps into the helmet, remove the comfort padding from
the helmet and allow to air dry.
1.1. Road safety
Always obey all Traffic Regulations in force. While riding your motorcycle, your hands should always be
engaged in actually riding the vehicle. Any operation to the N-Com system must be carried out with the
motorcycle stopped. Specifically:
•Set your cell phone on automatic answer (see the cell phone instructions to do this).
•If your cell phone is not equipped with this function, first stop your vehicle in a safe area, in compliance
with Traffic Regulations and then answer the call.
•Do not make any calls while riding. Stop your vehicle in a safe place in compliance with Traffic
Regulations and then make the call.
•Adjust the volume so that it does not cause a disturbance or distraction while riding and at the same time
allows you to hear background noises clearly.
•Do not operate your cell phone or other devices connected to the N-Com system while riding your
motorcycle.
•In all cases, obey the Traffic Regulations and remember that riding the motorcycle has absolute priority
over any other manoeuvre.
1.2. Switching on the system in safe environments
•When using the N-Com system, comply with all limitations and instructions related to the use of cell
phones.
•Do not turn on your cell phone or the N-Com system whenever their use is forbidden or when these
devices can cause interference or dangerous situations.
•Turn off while refuelling. Do not use the N-Com system at filling stations. Do not use the device near
combustible materials or chemical products.
•Turn off when near explosive materials.
1.3. Interferences
All phones and devices with wireless signal transmission are subject to interferences that may affect the
performance of the device connected to them. These interferences are not ascribable to a defect of the N-
Com system.
1.4. Appropriate use
Use the device only in the normal position, as described in the product documentation. Do not attempt to
disassemble, tamper with, or modify any part of the N-Com system.

5
Caution: Adjust the volume of the N-Com system and of the audio sources connected to it before you use
the system on the road.
Caution: Adjusting the volume to exceedingly high levels may cause damage to your hearing.
Caution: Incorrect installation of the system in the helmet may alter the aerodynamic and safety
characteristics of the helmet itself, thus creating dangerous conditions. Install the N-Com system
according to the instructions provided in the product documentation. In case of doubt, please contact
your local N-Com dealer.
Warning: Listening to other equipment should not interfere with riding your motorcycle, which must be the
top priority at all times. Carry out all operations on the electronic equipment and on the N-Com system
with the vehicle stopped, in compliance with Traffic Regulations.
1.5. Qualified personnel
•Only qualified personnel can carry out technical assistance on this product. In case of any malfunction,
always turn to your local dealer.
•The helmet is a safety device. Tampering with it and/or with the electronic system inside the helmet can
result in dangerous situations, in addition to invalidating the product warranty.
1.6. Accessories and batteries
•Only use the type of batteries, battery chargers and accessories approved by Nolangroup for the specific
model.
•Using a battery type different from the recommended one may lead to dangerous situations and
invalidate the warranty.
•Contact your local dealer to see about the availability of approved accessories.
•When disconnecting the power supply cable of any accessory or of the battery charger, always grab and
pull the plug, not the cable.
•Do not use batteries for purposes other than the prescribed ones.
•Never use batteries or battery chargers that turn out to be damaged.
•Do not short-circuit the battery.
•Keep the battery at a temperature between 0° / +45°C (charging): -10° / +55°C (in use).
•Danger of fire or explosion: do not throw the batteries into a fire or expose them to high temperatures!
•Do not throw out batteries together with household refuse. The batteries should be disposed of in
compliance with local regulations
•Do not wear the helmet while the battery is recharging.
•The helmet should never be left within the reach of unsupervised children in order to prevent damage to
their health caused by access to the batteries.
1.7. Disposal
Refer to this user manual and to manuals related to other parts of the N-Com system in order to
disassemble the system from the helmet. Once the system has been disassembled, dispose of it according to
the following instructions:
•The presence of a crossed-out wheelie bin indicates that in the European Union the product
is subject to separate collection at the end of its useful life.
•Do not dispose of these products together with undifferentiated urban waste.
•The proper disposal of obsolete equipment contributes to preventing possible negative consequences on
people’s health and on the environment.
•Within the European Union, the dealer, when supplying the new equipment, ensures that the used
equipment will be collected free of charge, provided it is equivalent to a ratio of one to one.
•For more detailed information on the disposal of obsolete equipment, contact your municipality, a waste
disposal service, or the store where the product was purchased.

EN
6
2. CONTENT OF THE PACKAGING
The N-Com B602 package contains:
e-box with wiring
Adesive Keypad
Microphone
Microphone for helmet X-903
Rechargeable battery
USB-C wire
Adhesive strips for loudspeakers
Flat head tool
Key
Microphone foam

7
3. INSTALLATION ON THE X-1005, X-903, X-552 HELMET
Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 19.4).
The installation video can be seen at www.n-com.it / Support section.
3.1. Preliminary operations
•Remove the internal comfort padding by following the specific instructions provided in the helmet
user manual, being careful to also remove the size adjustment tab.
•Remove from the polystyrene cheek pads the foam material at the housing of the N-Com
earphones. Keep this filling materials should you decide in the future to use the helmet without the
N-Com system installed.
3.2. Installing the system in the X-1005, X-903, X-552 helmets
•On the left side of the helmet, open the cheek pad lining door (Fig. 1). Remove the filling material.
Keep it in case you want to use your helmet without the N-Com system installed in the future.
•Remove the small N-Com cap positioned on the left side of the helmet. To make the operation
easier, we recommend pushing the cap from inside the helmet (Fig. 2).
•Thoroughly clean the outside surface of the shell to make sure that the adhesive keypad sticks
properly. Before you apply the keypad, make sure that the shell area is completely clean and grease
or dirt free.
•Remove the protective film from the back of the adhesive keypad using the special tab (Fig. 3).
•Pass the keypad cable through the hole in the outer shell (Fig. 4).
•Apply the keypad to the shell and press down on its entire surface to make sure that it sticks
properly (Fig. 5).
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
N.B.: Make sure you do not glue the cable underneath the keypad.

EN
8
N.B.: In the event that the keypad is not positioned correctly, peel it off right away with extreme care
and repeat the positioning.
N.B.: It takes up to 24 hours for the keypad to stick completely. During this time, do not expose the
helmet to atmospheric agents.
•Position the e-box in its seat (Fig. 6).
•Line up the keypad connector to the e-box (Fig. 7).
•Gently position the connector in its seat until it is all the way in (Fig. 8).
Fig. 6
Fig. 7
Fig. 8
Fig. 9
•Connect the battery to the cable in the
direction indicated by the arrows (Fig. 9).
•Check that the system is switched on correctly.
Press and hold the “n”key for about 2 seconds,
until the blue LED light on the keyboard turns
on and you hear the voice prompt. Proceed
with installation.
•Position the left loudspeaker in its seat, inserting the cable in the special groove. If necessary,
secure the earphone using the adhesive supplied as standard equipment (Fig. 10).
•Hook up the microphone to the connector coming out of the e-Box (Fig. 11).
Fig. 10
Fig. 11

9
3.3. Microphone positioning
ONLY FOR X-1005 HELMETS
•With the help of the flat head tool supplied as standard equipment, open the microphone-holder
clip located on the right side of the helmet (Fig. 12-13).
•Position the microphone at the desired length, sliding the excess portion inside the cheek pad
lining (Fig. 14).
N.B.: To ensure good voice transmission quality, it is recommended to adjust the length of the
microphone so that the foam part is in front of your mouth.
•Close the clip. Make sure that the microphone side with the letter “n” is facing the inside of the
helmet (Fig. 15).
Fig. 12
Fig. 13
Fig. 14
Fig. 15
ONLY FOR X-903, X-552 HELMETS
•Hook up the specific microphone for full-face helmets in its seat in the chin guard (Fig. 16).
•Position the microphone wire in the vertical groove and afterwards behind the cheek pad lining
(Fig. 17 –17B). If necessary, lift up the groove tabs and the cheek pad lining using a flat head tool
(supplied as standard equipment).
Fig. 16
Fig. 17
Fig. 17B

EN
10
Fig. 18
Fig. 19
•Pass the charging cable
through the elastic band
found on the comfort padding
(Fig. 18).
•Position the wiring in the rear
part of the helmet (Fig. 19).
Fig. 20 –X-1005 HELMET
Fig. 21 –X-903 HELMET
•On the right side of the
helmet, bend the cheek pad
lining and insert the battery in
its housing (Fig. 20 - 21 - 22).
ONLY FOR X-1005 HELMETS:
Remove the filling material.
Keep it in case you want to
use the helmet without the N-
Com system installed in the
future.
Fig. 22
Fig. 23
•Position the right loudspeaker
in its housing, inserting the
cable in the special groove
(Fig. 23). If necessary, secure
the earphone using the
adhesive supplied as standard
equipment.
3.4. Repositioning the padding
Reposition the internal comfort padding by following the specific instructions provided in the helmet
user manual.
Warning: Always verify the proper length of your chinstrap and adjust it if necessary, referring to the
specific helmet instructions.

11
4. INSTALLATION ON THE X-LITE HELMETS
This procedure must be followed for the installation of N-Com systems on X-lite helmets other than
model X-1005, X-903, X-552.
Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 19.4).
The installation video can be seen at www.n-com.it / Support section.
4.1. Preliminary operations
•Remove the internal comfort padding by following the specific instructions provided in the helmet
user manual.
•If present, remove from the polystyrene cheek pads the foam filling material that cover the
housings of the N-Com earphones. Keep this filling materials should you decide in the future to
use the helmet without the N-Com system installed.
4.2. Installing the system in the helmet
•Remove the small N-Com cap positioned on the left side of the helmet. To make the operation
easier, we recommend pushing the cap from inside the helmet (Fig. 24).
•Thoroughly clean the outside surface of the shell to make sure that the adhesive keypad sticks
properly. Before you apply the keypad, make sure that the shell area is completely clean and grease
or dirt free.
•Remove the protective film from the back of the adhesive keypad using the special tab (Fig. 25).
•Pass the keypad cable through the hole in the outer shell (Fig. 26).
Fig. 24
Fig. 25
Fig. 26
Fig. 27
•Apply the keypad to the shell and press down on its entire
surface to make sure that it sticks properly (Fig. 27).
N.B.: Make sure you do not glue the cable underneath the keypad.

EN
12
N.B.: In the event that the keypad is not positioned correctly, peel it off right away with extreme care
and repeat the positioning.
N.B.: It takes up to 24 hours for the keypad to stick completely. During this time, do not expose the
helmet to atmospheric agents.
•Position the e-box inside its housing in the left cheek pad (Fig. 28).
•Line up the keypad connector to the e-box (Fig. 29).
•Gently position the connector in its seat until it is all the way in (Fig. 30).
Fig. 28
Fig. 29
Fig. 30
Fig. 31
•Connect the battery to the cable in the direction indicated by the
arrows (Fig. 31).
•Check that the system is switched on correctly. Press and hold
the “n”key for about 2 seconds, until the blue LED light on the
keyboard turns on and you hear the voice prompt. Proceed with
installation.
•Temporarily reposition the polystyrene cheek pad inside the helmet.
•Position the battery in the right polystyrene cheek pad housing and secure it using the Velcro
ribbon (Fig. 32).
•Position the right-hand side speaker in the specific cheek pad housing and secure it using the
specific adhesive (Fig. 33).
Fig. 32
Fig. 33
ONLY FOR FULL-FACE HELMETS: Insert the chin strap into the polystyrene cheek pad loop.

13
Fig. 34
•Arrange the battery connector behind the polystyrene cheek
pad.
•Position the wiring in the rear part of the helmet (Fig. 34).
4.3. Microphone positioning
FLIP UP OR JET HELMETS
NB: The parts required for positioning the microphone (microphone clamp and screw) can be found
inside the helmet on the left side of the internal shell.
Should the helmet not contain these parts, the microphone clamp and screw are available to buy
separately from your Nolangroup dealer.
•Insert the microphone clamp on the arm of the microphone (Fig. 35).
•Position the microphone on the left side of the helmet, screwing in the screw in the small shell
frame (Fig. 36). Make sure that the side of the microphone with the caption “n” is facing the inside
of the helmet (Fig. 37).
Fig. 35
Fig. 36
Fig. 37
N.B.: On certain helmets, the housing for the microphone rod must be created by cutting out the
helmet border gasket along the pre-cut area.
FULL-FACE HELMETS
•Take the polystyrene check pad (left side) and position the microphone in the special housing.
Make sure that the side of the microphone with the caption “n” is facing the inside of the helmet.
•Connect the microphone to the connector coming out of the e-box (Fig. 38).
•Position the left-hand side speaker in the cheek pad housing and secure it using the specific
adhesive (Fig. 39).
•Reposition the left polystyrene cheek pad in its housing.
ONLY FOR FULL-FACE HELMETS: Insert the chin strap into the polystyrene cheek pad loop.

EN
14
Fig. 38
Fig. 39
4.4. Repositioning the padding
•Pass the USB-C wire through the elastic band found on the comfort padding.
•Replace the internal comfort padding by following the specific instructions found in the helmet user
manual.
Warning: Always verify the proper length of your chinstrap and adjust it if necessary, referring to the
specific helmet instructions.
Warning: After the B602 is installed on the helmet, make sure the microphone is properly positioned
in front of your mouth, if necessary adjusting the moveable element.
Warning: The wind protector, supplied as standard equipment with helmets that can be opened, may
make it more difficult to open and close the chin guard when the microphone is installed.
5. REMOVING THE SYSTEM
To remove the system from the helmet, proceed as for the installation, by removing the various parts.
Important: to remove the keypad, proceed as follows.
•Remove the keypad from the helmet shell (Fig. 40).
•Unplug the keypad connector (Fig. 41).
•Now completely remove the keypad from the helmet.
Fig. 40
Fig. 41
The keypad can be removed in case you decide to no longer use the system. However, it cannot be
reused again as it will have lost its adhesive properties. Contact your local dealer to purchase a new
keypad double sided-adhesive tape that will stick properly to the helmet shell.

15
6. BASIC FUNCTIONS
Note: Before using the N-Com device for the first time, recharge the battery completely for at least 10
hours. To obtain best performances from the battery, it is recommended to completely recharge the
battery the first few times. Afterwards, you can recharge the battery for shorter periods. Whenever
possible, it is best to recharge the battery completely.
System ON
Press and hold the “n” key for about 2 seconds, until the LEDs turn on
and you hear the voice prompt.
System OFF
Press and hold the “n” key for about 4 seconds, until the LEDs turn off
and you hear the voice prompt.
6.1. Complete Mode and Simple Mode
The B602 system offers two user modes, Complete and Simple. You choose which mode you prefer
according to your requirements, thus making the most of your experience on the road.
Available functions depend on which user mode is selected. At the beginning of each section below,
you will find confirmation as to whether the function is available only in Complete Mode. If this is not
specified, the function on this system can be used in both user modes.
The system is preset with Complete Mode.
It is possible to change to Simple Mode as follows:
Via the N-Com system
- Whilst the system is switched off, press and hold the “n”and “” keys simultaneously for 5 seconds.
- You will hear the voice message “ Simple user interface enable ”.
- The system will shut down. When you next turn it on, Simple Mode will have been activated.
To reactivate Complete Mode, follow the above steps. You will hear the voice message “ Simple user
interface disable ”.
Via the N-Com EASYSET app
- Access the “Basic Settings” menu and enable the “Simple Mode” option.
Via your computer using the N-Com EASYSET program
- Access the “Settings” menu and select “Simple Mode”.
6.2. Volume adjustment
You can easily adjust the volume by tapping the “” or the “” key. You will hear a beep when the
volume reaches the maximum or minimum level.
Some volume parameters can be adjusted through the N-Com EASYSET APP for smartphone or the
N-Com EASYSET computer program (chapter 4.5).
N.B.: The volume level set during the trip is not stored when the system is turned off. Each time the
N-Com system is switched on, the audio goes back to the set default volume level.

EN
16
6.3. Auto Off function
The Auto Off function automatically shuts down the N-Com system after five minutes without an
active Bluetooth connection (telephone, GPS, motorbike audio system etc) or communication via
intercom.
The “Auto Off”function is enabled by default on the device.
You can enable / disable the function from the Configuration Menu (Chapter 6).
6.4. Multi-language voice messages
“Voice prompts” are available only in Complete Mode.
The N-Com system offers voice prompts providing system information and confirmation of which
functions are activated or disactivated. The default language is English.
It is possible to change the language as follows:
Via the N-Com system
- Select Configuration Menu: with the N-Com already switched on, press and hold the “”and “”
keys simultaneously, until the red LED light appears.
- Press the “” key until you find “ Language ”mode .
- Press the “n” key to access the list of available languages.
- Press the “”and “”keys to navigate between the various languages. When you find the
language you require, press the “n” key to confirm your choice. A voice prompt in your chosen
language will confirm its selection.
Via the smartphone N-Com EASYSET app
- Access the Basic Settings menu and under “Language” select your chosen language from the drop-
down menu.
Via your computer using the N-Com EASYSET program
- Connect the N-Com system to the N-Com EASYSET program.
- Select the Settings menu and under the heading “Language”, select your chosen language from the
drop-down menu.
Available languages: English, Italian, French, German, Spanish, Dutch, Polish, Slovenian.
The default function is enabled on the device.
You can enable / disable the “VOICE PROMPTS” function by using the N-Com
EASYSET program or the N-Com EASYSET APP.

17
6.5. N-Com EASYSET
“N-Com EASYSET” is the application that can be used to manage and configure the B602
system. The program can be downloaded from the Internet site www.n-com.it, in the
“Support/Download” section. The functions that can also be managed from the N-Com
EASYSET are listed here below with the specific icon.
The N-Com system can be managed from the dedicated App “N-Com EASYSET”, which
makes it possible to configure the N-Com system directly from your Smartphone.
The N-Com APP can be downloaded free of charge from Google Play or Apple Store.
For additional details, please visit the website www.n-com.it
The functions that can also be managed from the N-Com EASYSET App are listed here
below with the specific icon.
6.6. Updating the firmware
Firmware updates for the N-Com system can be installed using the N-Com EASYSET program on your
computer, or the N-Com EASYSET app on your smartphone.
Via your computer with the N-Com EASYSET program
•Download the N-Com EASYSET program from the N-Com website –in the
“Support”/”Download”/”Software” section.
•Hook up the N-Com system to the computer and open the N-Com EASYSET program.
•Follow the directions until the program recognises the N-Com system.
•From the screen "FIRMWARE UPDATE", select the desired language from the drop-down menu.
•Click on "DOWNLOAD" and save the file in the computer.
•Click on "UPDATE" and wait for the firmware update to end.
Via the N-Com EASYSET app for smartphones
•Download and install the N-Com EASYSET app from Google Play or Apple Store.
•Pair and connect the telephone to the N-Com system (section 7).
•On opening, the app recognizes the firmware version installed on the N-Com system. If an update
is available, follow the directions provided by the app.
The release notes of the last Firmware version can be found on the website www.n-com.it –in the
“Support”/”Download”/”Software” section.

EN
18
7. PAIRING MODE
All the Bluetooth pairing operations are carried out in this mode.
In order to access the Pairing function, starting with the N-Com system switched off, press and hold
the “n” key for 4 seconds, until the red LED light appears.
7.1. Pairing Menu
The “Pairing Menu” is available only in Complete Mode.
Once in the “Pairing” menu, press the “”and “”keys to scroll through the various menu items.
The following items make up the “Pairing” menu:
A. Mobile phone pairing (chapter 7)
B. Intercom pairing (chapter 12)
C. Pairing with Other N-Com Systems (chapter 12.2)
D. Universal Intercom pairing (chapter 13)
E. Second mobile phone pairing (chapter 8)
F. GPS pairing (chapter 11)
G. Remote control pairing (chapter 14)
H. Delete all pairings
In order to delete all Bluetooth pairings stored in the device, press the “” or “” key until you
hear the voice prompt “ Delete all pairings ”.
Press the “n” confirmation key to delete all Bluetooth devices stored in memory.
I. Exiting the configuration
To exit the “Pairing” menu, press the “” or “” key until you hear the voice prompt “ Exit
configuration ”. Press the “n” confirmation key to exit the “Pairing” menu.
If no key is pressed within 15 seconds, the device automatically exits the “Pairing” menu.

19
8. CONFIGURATION MENU
The “Configuration Menu” is available only in Complete Mode.
All the settings of the N-Com system are managed in this mode.
To access the Configuration Menu starting with the N-Com switched on, press and hold the “”and
“”keys simultaneously for 4 seconds, until the red LED light appears.
Once in the “Configuration” menu, press the “”and “”keys to scroll through the various menu
items.
In the items marked with an “*”, it is possible to enable / disable the function by pressing the “n” key to
confirm.
The following items make up the “Configuration” menu:
A. Speed dial* (chapter 9.1)
B. Smart Navi System* (chapter 9.3)
C. Auto Off*(chapter 4.3)
D. Audio boost*
By enabling the “Audio boost”, all the audio sources inside the device will be reproduced at a
higher and potentially less clear volume.
Press the “n” confirmation key to enable / disable the function, which is not enabled by default on
the device.
E. Language
To change the language in which the system provides voice prompts, please see section 4 of the
Manual.
F. Reset
In order to restore the factory settings of the device, press the “” or “” key until you hear the
voice message “ Factory Reset ”. Press the “n” confirmation key to restore all the factory settings of
the device. The system will shut down automatically.
G. Exiting the configuration
To exit the “Configuration” menu, press the “” or “” key until you hear the voice prompt “ Exit
configuration ”.
Press the “n” confirmation key to exit the “Configuration” menu.
If no key is pressed within 15 seconds, the device automatically exits the “Configuration” menu.

EN
20
9. MOBILE PHONE / MP3 PLAYER PAIRING
•Make sure the B602 is turned off.
•Put the system in “Pairing” mode: press and hold the “n” key for 4 seconds, until the red LED light
appears.
• In Complete Mode : press the “” key until “ Phone pairing ” appears.
In Simple Mode : do not press any key.
•Activate the search of Bluetooth devices on the mobile phone.
•Select the N-Com device. If a password is requested, enter 0000 (four zeros).
•Connection between the two devices is established after a few seconds.
N.B.: The affiliation is stored in the helmet and in the cell phone and it is not lost when the two
devices are turned off. As a result it needs to be carried out only once.
NB: if a Bluetooth device has already been stored in the B602 system’s memory, any new pairing will
overwrite the previous pairing.
Automatic Connection
Once the Bluetooth device has been paired, connection is automatic
when the system is turned on.
Manual Connection
In case connection is not automatically initiated after a few seconds, you
can connect from the Bluetooth device or by pressing and holding the “n”
key for about 2 seconds.
10. SECOND MOBILE PHONE PAIRING
The “Second mobile phone” function is available only in Complete Mode.
The B602 system can be hooked up to two phones at the same time. The second phone (secondary
device) can receive calls but not make them.
To pair the second Bluetooth phone (secondary device):
•Make sure the B602 is turned off.
•Put the system in “Pairing”mode: press and hold the “n” key for 4 seconds, until the red LED light
appears.
•Press the “”key until you hear the voice prompt “ Second mobile phone pairing ”.
•Activate the search of Bluetooth devices on the mobile phone.
•Select the N-Com system from the list. If a password is requested, enter the code 0000 (four
zeros).
•After a few seconds, the connection between the two devices is activated.
Once the Bluetooth device has been paired, connection is automatic when the system is turned on.
N.B.: The affiliation is stored in the helmet and in the cell phone and it is not lost when the two
devices are turned off. As a result it needs to be carried out only once.
NB: if a second device has already been stored in the B602 system’s memory, any new pairing will
overwrite the previously stored pairing.
