1 700008606 Frontschutzbügel
2 abgesetzte Stahldistanzen ø30 x ø21 x 34 mm
2 Stahldistanzen ø14 x ø10 x 13mm
2 Spezialschrauben M16 x 40 x 1,5mm
mit Innengewinde M8
2 Linsenkopfschrauben M8x30
4 U-Scheiben ø8,4
2 Zylinderschrauben M8x45 (10.9)
Heckschutzbügel / Rear protection bar
Motorschutzbügel inkl. ProtectionPad / Engine guard incl. ProtectionPad
Soziusfußrasten-Tieferlegungssatz / Passenger footrest lowering set
Alurack
C-Bow Halter / C-Bow holder
1 700008606 front guard
2 special steel spacer ø30 x ø21 x 34 mm
2 steel spacer ø14 x ø10 x 13mm
2 special screw M16 x 40 x 1,5mm with thread M8
2 filister head screw M8x30
4 washer ø8,4
2 allen screw M8x45 (10.9)
Frontschutzbügel
Front protection bar for driving schools
YAMAHA MT - 07
Baujahr 2014-2017 / date of manufacture 2014-2017
Artikel Nr.: / Item-no.:
5034537 00 05 anthrazit/anthracite
Als weiteres Zubehör lieferbar / Also available:
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
YAMAHA MT - 07
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.:
5034560 00 05 anthrazit/anthracite
INHALT
CONTENTS
2
Vorbereitung:
Lenkergewichte links und rechts
demontieren, Originalschrauben
entfallen.
1
An Stelle der Lenkergewichte die
abgesetzten Stahldistanzen
ø30 x ø21 x 34 mm mit den
Spezialschrauben M16x40x1,5
eindrehen und festziehen.
Montage des Schutzbügels links+rechts:
An den zuvor montierten Spezial-
schrauben (Innengewinde M8) mit den
Linsenkopfschrauben M8x30 sowie U-
Scheibe ø8,4.
2x
2x
2x
2x
Preparing:
Dismantle handle bar weights left + right
Original screws are obsolete.
Mount special steel spacer ø30 x ø21
x 34 mm instead the handle bar weights
Use special screws M16 x 40 x 1,5 to
fix.
Fastening of the crash bar left+right:
at the inner thread of the special screw,
mounted before. Use filister head screws
M8x30 with washers ø8,4.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Frontschutzbügel
Front protection bar for driving schools
YAMAHA MT - 07
Baujahr 2014-2017 /
date of manufacture 2014-2017
Artikel Nr.: / Item-no.:
5034537 00 05
YAMAHA MT - 07
ab Baujahr 2018 /
from date of manufacture 2018
Artikel Nr.: / Item-no.:
5034560 00 05
WICHTIG
IMPORTANT
Ratsche/Ratchet
Verlängerung/extension
Set
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
3
Preparing:
Dismantle screws of the upper fork
bracket left + right.
Original screws are obsolete.
Fastening of the crash bar front:
at the upper fork bracket with allen screws
M8x45 (10.9) and washers ø8,4.
Add steel spacer ø14xø10x13mm
between crash bar and fork bracket.
2
2x
Vorbereitung:
Die Originalschrauben der oberen
Gabelbrücke demontieren.
Originalschrauben entfallen.
Montage des Schutzbügels vorne:
Den Frontschutzbügel an der Gabel-
brücke mit den InbusschraubenM8x45
(10.9) sowie U-Scheiben ø8,4
verschrauben.
Zwischen Haltelasche und Gabelbrücke
die Stahldistanz ø14xø10x13mm fügen.
2x 2x
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
Frontschutzbügel
Front protection bar for driving schools
YAMAHA MT - 07
Baujahr 2014-2017 /
date of manufacture 2014-2017
Artikel Nr.: / Item-no.:
5034537 00 05
YAMAHA MT - 07
ab Baujahr 2018 /
from date of manufacture 2018
Artikel Nr.: / Item-no.:
5034560 00 05
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
