NOMA OLLIE 052-9255-6 User manual

Ollie 30” Ceiling Fan
model no. 052-9255-6
Total weight of fan plus light kit are 4.9 kgs
Instruction Manual
Toll-free: 1-866-827-4985
IMPORTANT: Please read and understand this manual before any assembly
Before beginning assembly of product, make sure all parts are present.
Compare parts with exploded view. If any part is missing, or if you have any
. .)eerf-llot(5894-728-668-1taecivresremotsuctcatnoc,snoitseuq

Table of Contents
Technical Data
Important Safety Instructions
Parts List
Parts Locations
Before Installation
Installation
Operation
Care and Maintenance
Troubleshooting
Warranty
2
2
3
4
5
6
8
12
14
14
16
Technical Data Table of Contents
Operating voltage: 120 V/60 Hz
Power consumption: Fan only: 45 W (Maximum)
Bulbs: One A19 11W(Max) LED bulb (included)

WARNING!
or circuit breaker box before installing, servicing or cleaning.
WARNING!
WARNING!
NOTE:
DO NOT use the ceiling fan if it shows any sign of damage or if it has been dropped.
DO NOT expose the ceiling fan to rain or moisture. Do not operate it outdoors or with wet hands.
DO NOT operate the fan without blades.
DO NOT insert foreign objects between the rotating blades.
Pay special attention to the fan and blades when cleaning, painting or working near the fan.
To prevent injury, make sure the blades are not bent and that there are no objects within the
rotation area.
Do not reverse the rotation until blades have come to a complete stop.
The ceiling fan must be grounded as a precaution against possible electric shock. Electrical
installation should be done or approved by a licensed electrician.
Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do
not know enough about electrical wiring, have the fan installed by a licensed electrician.
The outlet box and joist must be securely mounted and capable of reliably supporting at least
35 lb (15.9 kg).
Use only outlet boxes marked “Acceptable for Fan Support” and use the supplied outlet box
screws. Most outlet boxes commonly used to support light fixtures are not acceptable for fan
support and may need to be replaced. Consult a qualified electrician if in doubt.
The fan must not be installed in a ceiling thermally insulated to a value greater than R40.
To reduce the risk of electric shock, this fan must be installed with a wall-isolating control/switch.
All screws must be checked and re-tightened where necessary.
Only use the parts and accessories supplied with this product, or specifically
designated for use with this product by the manufacturer. Substitution with
parts and accessories not designated by the manufacturer could result in
personal injury or property damage.
This ceiling fan is designed for household use only and not for commercial applications.
No responsibility is accepted for damage resulting from improper use or
non-compliance with the instructions.
The important precautions, safeguards, and instructions appearing in this manual are
not meant to cover all possible situations. It must be understood that common sense
and caution are factors that cannot be built into the product.
Not suitable for use with SOLID-STATE speed controls.
SAVE THESE INSTRUCTIONS
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.
Important Safety Instructions
The fan must be mounted with the blades at least 6’ 11” (2.1 m) above the floor to prevent
accidental contact with the blades.
All installation should be conducted in accordance with the national and local wiring codes,
including fire-rated construction. Use the national codes if local codes do not exist.

Toll-free: 1-866-827-4985 · model no. 052-9225-6
Parts List
Mounting
Bracket
Canopy
A
Cap L
Downrod
Assembly B
Motor with
Light Kit F, G
Glass Shade
Blade
Blade Arm
H
I
J 4
Name No. Illustration Qty. Name No. Illustration Qty.
1
1
1
1
1
4
E1
Wood Screw
with Flat
Washer
Blade Screw
Extra Blade
with flat
washer & nut
Bracket Screw
Mouting
Screw with
Split Washer
2
13
1
2
N
N
N
N
1
N
N
N
N
N
1
1
1
3
“J” Hook
Zip Tie
Balancing Kit 1
Note:
Parts labelled 'N' above are packed in
hardware bag. (Hardware notshown to
actual size.)
O
P
Bulb
(A19 X 11 W
LED)
1
Downrod clip
Downrod pin
Wire
connector

A
B
C
E
F
G
I
JK
No. Description Qty
A Mounting Bracket
B Downrod
C Canopy
D Cap
E Motor Housing
F
G Glass shade
No. Qty
H Blade 4
4
I Blade Arm
J Parts pack 1
1
1
K
Balance Pack
Description
L
Bulb (A19 X11W LED)
H
L
D
Light Kit
1
1
1
1
1
1
1
Parts Locations

1 cross-head
screwdriver
1 wrench
1 stepladder
1 wire stripper / pliers
1 drill
Up to 50' (15 m) 14
50-100' (15-30 m) 12
Toll-free : 1-866-827-4985 · model no. 052-9225-6
WARNING!
WARNING!
Do not install or use the ceiling fan if any part is damaged or missing.
WARNING!
or circuit breaker box before installing, servicing or cleaning.
Tools Needed for Assembly (not supplied):
Materials
Unpacking Instructions
Wire Length Wire Size (A.W.G.)
Read each step carefully before beginning any installation and make sure you
understand each step.
Keep children and pets away during installation.
Keep fingers away from the places where they can be pinched or injured.
Wiring, outlet box and box connectors must be of the type required by the local code.
The minimum wire should be a three-conductor (two-wire with ground) of the following sizes:
Place all parts from the box on a working space in a cleared area.
1 flat screwdriver
Unpack and inspect carefully to make sure all parts are included and not damaged (fig. 1).
shock (fig. 2).
Before Installation

Before Installation
Choosing a Location for the Ceiling Fan
CAUTION! If there is light fixture at your
chosen location, remove the light
fixture first. Before removal, ensure to
fuse or circuit breaker box.
Choosing Mounting Styles
WARNING!
The outlet box and joist must be securely mounted and capable of reliably
supporting at least 35 lb (15.9 kg).
To reduce the risk of electric shock, mount the fan only to an outlet box marked
“Acceptable for Fan Support”, and use the supplied outlet box screws. Most outlet
boxes commonly used to support light fixture are not acceptable for fan support
and may need to be replaced. Consult a qualified electrician if in doubt.
Flush-mount installation (for lower ceilings) Drop-mount installation (for normal ceilings)
Choose a location where there is a high
enough ceiling clearance, at least 6’ 11”
(2.1 m) between the floor and the blades
(fig. 3).
located in the centre of the room, or a
minimum of 32” (81.3 cm) from adjacent
walls or obstructions.
This method is recommended if the ceiling
is sloped or vaulted or if the ceiling is
extra high, requiring a downrod (fig. 5).
Follow steps 1-9, omitting step 2 in the
manual.
≥6’ 11”(2.1 m)
This method is recommended if maximum
headroom is required. The ceiling must be
completely horizontal and level (fig. 4).
Follow steps 1-9, omitting step 3 in the
manual.

Installation
Toll-free: 1-866-827-4985 · model no. 052-9255-6
1. Installing Mounting Bracket
WARNING! The mounting bracket must sit firmly against the outlet box. If the
outlet box is recessed, remove the wall board until the mounting bracket comes
into contact with the box. If bracket and/or outlet box are not securely attached,
the fan could wobble or fall.
Before drilling, ensure there are no electrical wires or water pipes behind the
drill spots.
While drilling, we recommend wearing protective goggles and hearing
protection.
CAUTION!
Secure the mounting plate to the ceiling outlet box as
shown in Figure 6 by using two screws and washers (not
provided). Make sure the mounting plate is level. You may
need to insert additional washers (not provided) between
the outlet box and the mounting plate to make it level.
hook on the mounting plate (Figure 7).
Attach the blade decoration and blade
bracket to the blade (fig. 9).
Apply the blade screws and secure properly
(fig. 9).
2. Blade Assembly
Note: This fan includes four dual-finished
blades. Depending on personal
preference, choose the side that best
suits the décor or furniture of your
room.
Blade screw
Blade
Screw and washer
Blade arm
Figure 6
Outlet Box
Figure 7
Canopy
Round Hole
Bayonet
Slot
Canopy
Screw
Hook
Mounting
Plate
Before making the electrical connections, engage one of
the screw holes at the top of the ceiling canopy with the

Installation
Toll-free: 1-866-827-4985 · model no. 052-9255-6
Raise the canopy.
Loosen the two downrod set screws on the
coupling (fig. 14).
Insert the downrod into the coupling. Make sure to
align the holes of these two parts.
Install the peaked pin through the aligned holes and
secure it with the clip.
Tighten the two downrod set screws on the coupling
(fig. 14).
3. Securing Downrod Assembly
4. Wiring Instructions
ScrewClip
Peaked
pin
Figure 8
diagram indicates light kit wiring
Figure 9
diagram indicates optional wiring
Figure 10
diagram indicates optional wiring
BlackBlackBlack
Black
Black
Black
White
White
White
White
White
White
Blue
Blue
Blue
Green
Green
Green
Ground
Conductor
Ground
Conductor
Ground
Conductor
Outlet Box
Outlet Box
Outlet Box
Green
Ground Lead
Green
Ground Lead
Green
Ground Lead
White
White
or experience, have your fan installed by a licensed electrician.
Follow the steps below to connect the fan to your household
wiring. Use the plastic wire splice connectors (BB) supplied with
your fan. Securethe connectors with electrical tape. Make sure
there are no loose strands or connections.
Connect the fan supply (black) wire and light supply (blue)
wire to the black household wire as shown in Figure 8. Do
not connect the blue wire if the light kit is not used.
Connect the neutral fan (white) wire to the white neutral
household wire.
Connect the fan ground wires (green) on the mounting plate
and the downrod assembly to the household ground wire.
After connecting the wires, secure the wire connectors (BB)
with black electrical tape and spread them apart so that
the green and white wires are on oneside of the outlet box
and the black and blue wires are on the otherside. (i.e.,
grounded conductor on one side and hot wires on the other
side.)
Turn the wire connectors (BB) upward and push the wiring
into the outlet box.
If you wish to control the light from a wall switch and the fan from
the pull chain switch or if you wish to control both fan and light
from wall switches, refer to the wiring diagrams in Figures 9 and 10.
If you feel that you do not have enough electrical wiring knowledge
If you choose to install anotherlight kit, it must be a UL
Listed light kit accessory marked suitable for use with this
fan.Follow the instructions packed with the light kit.

Installation
Toll-free: 1-866-827-4985 · model no. 052-9225-6
Hold the bare metal leads together and twist until tight.
After all connections are done, turn the splices upward and push them carefully upward through
the mouting bracket into the outlet box.
Spread the wires apart so that the green and white wires are on one side of the outlet box and the
black and blue wires are on the other side of the outlet box.
Warning!
Be sure no bare wire or wire strands are visible after making connections.
While connecting wires, make sure to:
Note: The silver cord is only a safety cable (fig. 19).
You can wrap it over the mounting bracket and
loop it into the hook on the mounting bracket or
alternatively, secure it to the ceiling, using the
provided short wood screw and lock washer.
Hold the fan assembly by the canopy and
raise it to align the holes in the canopy
with the holes in the mounting bracket.
Diagonally apply two sets of side screws
with lock washers to the mounting bracket.
Do not tighten the side screws at this stage.
Hang the two “L” slots of the canopy on
the mounted side screws (fig. 20).
Diagonally apply another two sets of side
screws with lock washers. Tighten all the
side screws properly.
5. Fan Assembly to Mounting Bracket
Match up the wires first.
Insert the twisted ends into a wire connector and turn the wire connector until tight (fig. 18).
Canopy

Installation
Remove all the blade bracket screws with
split washers from the motor bottom, through
the oval slot on the light kit (fig.21).
Attach one blade assembly to the motor
bottom and secure with the blade bracket
screws and split washers (fig.22).
Repeat the above procedures for the other
three blade assembly.
Install one A19 11W(max) Led bulb
into the light
socket (fig.23)
6. Blade Assembly to Motor
7. Installing Bulb
Note:The dimmer function can not be
used if CFL bulb is used. There is
only ON/OFF function.
Light kit
Blade
screw
Caution! Your fan has an energy-saving wattage limiter. If you replace the bulb with over
below 70W.
23

Installation
Operation
Toll-free: 1-866-827-4985 · model no. 052-9225-6
8. Installing Glass shade
Attach the glassshade to the light kit and
turn clockwise till light (fig. 24).
Now your ceiling fan is assembled and ready
for use.
Forward and Reverse Function
Downward air flow Upward air flow
Ceiling fans work best by blowing air
downward (counter-clockwise blade
rotation) in warm weather to cool the
room with a direct breeze (fig. 26).
In winter, having the fan draw air upward
(clockwise blade rotation) will distribute
the warmer air trapped at the ceiling
around the the room without causing
a draft (fig.27)
Glass shade
This ceiling fan is equipped with a reverse switch for downward or upward air flow.

Operation
Changing Air-flow Direction
Balancing Kit
Side Description
complete stop.
Slide the reverse switch on the light kit.
Restart the fan.
Left Downward air-flow (Forward)
This balancing kit should be used only if there is an unacceptable amount of fan wobble after all
installations are correctly completed (fig. 29).
In case of excessive fan wobble, do as below:
Switch on the fan and choose the fan speed at which the fan wobbles the most.
Switch on the fan to check whether the wobble has increased or decreased. Switch the fan
noting the blade on which the greatest improvement is achieved.
Replace the balancing clip on the blade that shows the greatest improvement. Move the
balancing clip inward and outward, and operate the fan to find the position where the
balancing clip gives the greatest improvement.
Remove the balancing clip and secure the balancing weight (using a provided sticker) on the
top of the blade, along the centre line near the point where the balancing clip was positioned.
If the fan wobble persists, repeat the above procedures and add a second (or more) balancing
weight.
Right Upward air-flow (Reverse)
Reverse
switch
balancing clip, halfway between the blade bracket and the blade tip of the trailing edge
(fig. 30).
Blade
Blade
arm

Toll-free: 1-866-827-4985 · model no. 052-9255-6
Warning!
Cleaning
Problem Possible reason Solution
Care and MaintenanceTroubleshooting
or circuit breaker box before installing, servicing or cleaning.
Never clean the fan while in use!
Because of the fan’s natural movement, some connections may become loose. Check the
support connections, brackets and blade attachments regularly. Make sure they are secure.
There is no need to oil your fan. The motor has permanently-lubricated bearings.
If the ceiling fan works abnormally, follow the instructions below or consult a qualified
electrician.
WARNING!
main fuse or circuit breaker box before servicing.
Fan is noisy
during
operation
Blade screws are loose.
The mounting bracket or canopy is
loose.
Screws securing decorative housing
to mounting bracket are loose.
Glass shade is loose.
Screws securing downrod to
mounting bracket are loose.
Wire connectors are vibrating
against the inside of the canopy.
Light kit or light bulb is not firmly
attached.
Canopy is rattling against ceiling.
Motor housing screws are loose.
Tighten the blade screws.
Check and fasten the screws.
Check and fasten the screws.
Tighten by hand, as necessary.
Check and fasten the screws.
Disconnect power at fuse box, loosen
canopy and reposition connectors.
Remove and reattach.
Be sure canopy is not touching ceiling.
Check and fasten the screws.
Check main fuse and branch circuit fuses
or circuit breaker. Repair as necessary.
Check all the wire connections to fan and
housing wiring. Repair as necessary.
Make sure the reverse swith is set to one
side only.
Check and ensure the remote works.
Fuse or circuit breaker is blown.
Loose or incorrect power line,
connections to the fan or switch
wires.
Reverse switch is stuck in the middle.
Remote is not working.
Fan does
not start
When cleaning the fan, use a soft brush or lint-free cloth to prevent scratching. A vacuum
cleaner brush nozzle can remove heavier dust.
Remove surface smudges or accumulated dirt and dust using a mild detergent and a slightly
dampened cloth. Never use abrasive cleaning agents, as they will damage the finish.
Clean wood finish blades with a furniture polishing cloth. Occasionally apply a light coat of
furniture polish for added protection and beauty.
To prevent bending the blades during cleaning, support the blades so that no pressure is
applied to them.

Troubleshooting
Problem Possible reason Solution
Light does
not work
Wires are not properly connected.
Light bulb is faulty.
This fan is equipped with a 70 W
LIMITER that will automatically turn
exceeds the maximum wattage level.
Remote is not working.
Fan is in reverse mode (blades are
moving in a clockwise direction).
Fan is not properly located.
Screws securing blades to motor are
losse.
Screws securing blade assembly are
loose.
Canopy and mounting bracket are
not tightened securely.
Blades are unbalanced.
Non-match coding between remote and
receiver.
Ensure wire connector in the switch
housing is connected.
Remove light bulb and replace with a
new one of the same type.
with lower wattage bulbs so that the
total wattage will be below 70 W.
Check and ensure the remote works.
Counter-clockwise (forward) direction is
recommended in warm weather. Switch
to stop. Use the eraser end of a pencil to
set the forward/reverse switch to the left
side.
Adjust the fan so that the ends of the
blades have at least 12” (30 cm) clearance
from walls or other obstructions, in the
centre of the room.
Tighten the screws.
Tighten the screws.
Tighten the mounting bracket to the
outlet box.
Check by selecting a point on the ceiling
above the tip of one of the blades.
Measure this distance and ensure all
blades are same (fig. 31). If all blade
levels are not equal, adjust accordingly.
If fan woddle persists, apply the balancing
kit (see page 15).
Fan does
not seem to
provide the
expected
Fan
wobbles
or shakes
excessively
Remote
does not
work
Used electrical appliances are recyclable and should not be discarded in your regular
domestic waste. Please actively support us in conserving resources and protecting the
environment by returning this appliance to a collection centre (if available).
ENVIRONMENTAL PROTECTION
fuse or circuit breaker box. Wait for at
least 10 seconds and switch on the power
supply again.
Within 30 seconds after power supply is
switched on again, press and hold buttons
1 and 3 simultaneously for five seconds.
The red LED indicator flashers.
Now the remote and receiver are paired.
The fan runs at low speed and with the

Toll-free: 1-866-827-4985 · model no. 052-9225-6
Warranty
This Noma product carries a limited one (1) year warranty against defects in workmanship and materials.
Noma Canada agrees to replace the defective product free of charge within the stated warranty period,
when returned by the original purchaser with proof of purchase. This product is not guaranteed against
wear or breakage due to misuse and/or abuse.
Made in China
Imported by
Noma Canada, Toronto, Canada M4S 2B8
Subject to the conditions and limitations described below, this product, if returned to us with proof of
purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear the
cost of any repair or replacement and any costs of labor relating thereto.
These warranties are subject to the following conditions and limitations:
a) A bill of sale verifying the purchase and purchase date must beprovided;
b) This warranty will not apply to any product or part thereof which is worn or broken or which has
become inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation,
operation or maintenance (as outlined in the applicable owner’s manual or operating instructions)
or which is being used for industrial, professional, commercial or rental purposes;
c) This warranty will not apply to normal wear and tear or to expendable parts or accessories that
may be supplied with the product that are expected to become inoperative or unusable after a
reasonable period of use;
d) This warranty will not apply to routine maintenance and consumable items such as, but not limited
to blades, belts, tune-ups or adjustments;
e) This warranty will not apply where damage is caused by repairsmade or attempted by others
(i.e. persons not authorized by the manufacturer);
f) This warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless otherwise specified in writing);
g) This warranty will not apply to any product or part thereof if any part from another manufacturer
is installed therein or any repairs or alterations have been made or attempted by unauthorized
persons;
h) This warranty will not apply to normal deterioration of the exterior finish, such as, but not limited
to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical
cleaners; and
i) This warranty will not apply to component parts sold by and identified as the product of another
company, which shall be covered under the product manufacturer’s warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor
the manufacturer shall be liable for any other expense, loss or damage, including, without limitation,
any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or
inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify, take
away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or
federal legislation.

Ventilateur de plafond de 30po Ollie
N° de modèle: 052-9255-6
Guide d'utilisation
Sans frais: 1866827-4985
IMPORTANT: Veuillez lire ce guide et bien le comprendre avant de
commencer l’assemblage. Assurez-vous que toutes les pièces sont
présentes avant de commencer l’assemblage. Comparez les pièces
avec la vue éclatée. S’il manque une pièce ou si vous avez des
questions, communiquez avec le service à la clientèle au numéro
sans frais: 1866827-4985.
Poids total du ventilateur et de l'ensemble éclairage est de 4,9 kg

Table des matières
Caractéristiques techniques
Consignes de sécurité importantes
Liste des pièces
Emplacement de pièces
Avant l’installation
Installation
Utilisation
Entretien
Dépannage
Garantie
2
2
3
4
5
6
8
12
14
14
16
Caractéristiques techniques Table des matières
Tension opérationnelle: 120V/60Hz
Consommation d’énergie: Ventilateur seulement: 45W (maximum)
Ampoules: Une ampoule à DEL A19 11W (maximum) (comprise)

AVERTISSEMENT! Afin d’éviter les décharges électriques, éteignez le courant au fusible
principal ou au coret de fusibles avant l’installation, la réparation ou le nettoyage.
NE PAS utiliser le ventilateur de plafond s’il montre des signes de dommages ou s’il a été échappé.
AVERTISSEMENT!
AVERTISSEMENT!
REMARQUE:
Utilisez seulement les pièces et les accessoires fournis avec cet article, ou précisément
désignés pour l’utilisation avec cet article par le fabricant. La substitution avec des
pièces et accessoires non désignés par le fabricant peut entraîner des blessures ou
des dommages matériels.
Ce ventilateur de plafond est conçu pour un usage domestique et non commercial.
Aucune responsabilité n’est acceptée pour les dommages causés par l’utilisation
inadéquate ou le non-respect des instructions.
Les précautions, mesures de protection et instructions importantes figurant dans
ce manuel ne sont pas conçues pour couvrir toutes les situations possibles. Il doit
être entendu que le gros bon sens et la précaution sont des facteurs qui ne peuvent
pas être intégrés au produit.
Ne convient pas pour l’utilisation avec des commandes de vitesse À
SEMI-CONDUCTEURS.
CONSERVEZ CES INSTRUCTIONS
IMPORTANT: CONSERVEZ CE GUIDE À TITRE DE RÉFÉRENCE ET LISEZ-LE
ATTENTIVEMENT.
Important Safety Instructions
NE PAS exposer le ventilateur de plafond à la pluie ou l’humidité. Ne faites pas fonctionner le
ventilateur de plafond à l’extérieur ou avec les mains mouillées.
NE PAS faire fonctionner le ventilateur sans pales.
NE PAS insérer d’objets étrangers entre les pales en rotation.
Afin de prévenir les blessures, assurez-vous que les pales du ventilateur ne sont pas pliées et qu’il
n’y a pas d’objets dans l’aire de rotation.
N’inversez pas le sens de rotation des pales avant qu’elles s’arrêtent complètement.
Le ventilateur de plafond doit être mis à la terre par mesure de précaution contre la possibilité de
décharges électriques. L’installation électrique doit être faite ou approuvée par un électricien qualifié.
Suivez les instructions recommandées pour la bonne méthode de câblage pour votre ventilateur de
plafond. Si vous n’avez pas susamment de connaissances au sujet du câblage électrique, faites
installer le ventilateur par un électricien qualifié.
La boîte à prises et la solive doivent être solidement fixées et capables de soutenir au moins
15,9kg (35lb).
Utilisez seulement une boîte à prises portant la mention «acceptable pour soutenir un ventilateur»
et utilisez les vis de boîte à prises fournies. La plupart des boîtes à prises généralement utilisées pour
fixer des luminaires ne sont pas appropriées pour soutenir un ventilateur; vous pourriez donc devoir
la remplacer. Consultez un électricien qualifié au besoin.
Le ventilateur ne doit pas être installé dans un plafond isolé à une valeur supérieure à R40.
Afin de réduire les risques de décharges électriques, ce ventilateur doit être installé avec un
interrupteur ou une commande isolant.
Toutes les vis doivent être vérifiées et resserrées lorsque nécessaire.
Attardez-vous au ventilateur et aux pales lorsque vous nettoyez, peinturez ou faites des travaux
à proximité.
Le ventilateur doit être fixé avec les pales à au moins 2,1m (6pi 11po) au-dessus du plancher afin
de prévenir le contact accidentel avec les pales.
Toutes les installations doivent être eectuées en conformité avec les codes de câblage national et
local, y compris les normes de résistance au feu. Utilisez le code national si un code local n’existe pas.

Sans frais: 1866827-4985 modèle no052-9225-6
Liste des pièces
Support
de fixation
Toit
A
Protecteur L
Assemblage
de la tige B
Moteur avec
l’ensemble
d’éclairage
F, G
Abat-jour
en verre
Pale
Bras de
pale
H
I
J 4
Nom No QtéIllustration Nom No QtéIllustration
1
1
1
1
1
4
E1
Vis à bois
avec rondelle
plate
Vis de pale
Vis
additionnelle
pour support
de pale
Vis de
fixation avec
rondelle à
ressort
2
13
1
2
N
N
N
N
1
N
N
N
N
N
1
1
1
3
Crochet
en J
Attache
autobloquante
Trousse
d’équilibrage 1
Remarque:
Les pièces étiquetées «N» ci-dessus sont
emballées dans le paquet de quincaillerie.
(La quincaillerie n'est pas illustrée en
taille réelle).
O
P
Ampoule
(DEL
A19 X 11W)
1
Goupille
de tige
Broche
de tige
Connecteur
de fils
