NOMA 052-1602-8 User manual

Deck & Pathway
Instruction Manual
model no. 052-1602-8
Toll-free: 1-866-827-4985
IMPORTANT: Please read this manual carefully
before using this product and save it for reference
SOLAR PATH LIGHT

2
model no. 052-1602-8 | contact us: 1-866-827-4985
Table of ContentsFeatures
1. Path Light Add a new ambience and a fresh look to your house, garden,
patio and yard.
2. Crystalline Solar
Panel
The solar panel converts sunlight into electricity and
recharges the battery. Crystalline solar panels hold a better
charge than the amorphous solar panels.
3. Body The body of the fixture is made of cast-aluminum for extra
durability.
4. Filament LED Traditional look with LED technology.
5. Spike Made of plastic, it holds the path light in the ground.
6. Photocell Photocell technology automatically turns on at dusk and
turns o at dawn.
7. Battery Includes 1 AA NiMh rechargeable battery.
Specifications 3
Know Your Product 3
Operation 4
First Time Use 4
Assembly and Operation 5
Troubleshooting 6
Battery Replacement 7
Caution 8
Warranty 8

3
Model 052-1602-8
Colour Black
Solar Panel Crystalline
Battery (Included) 1 X AA NiMh 800 mAh Rechargeable Battery
Weatherproof Yes
Dusk-to-Dawn Yes
Net Weight 1 lb 12 oz (0.80 kg)
Dimensions (L x W x H) 6 5/16 x 6 5/16 x 17 3/16” / 16 cm x 16 cm x 43.7 cm
SpecificationsKnow Your Product
KNOW YOUR PATH LIGHT
Before use of this product, familiarize yourself with all
operating features and safety rules.
1. Solar Panel
2. Top Cap
3. Body
4. Post
5. Spike
1
2
3
4
5

4
model no. 052-1602-8 | contact us: 1-866-827-4985
Operation
HOW YOUR SOLAR PATH LIGHT WORKS
During the day, the solar panel converts sunlight into electricity and recharges the
battery. At night, the light turns on automatically using the electricity stored during
that day.
The number of hours the light stays on depends on your geographical location, weather
conditions and seasonal sunlight availability.
Place the solar path light fixture in an area where it can receive direct sunlight for at least
8 hours each day. Shadowed locations will not allow the battery to charge fully and will
reduce the hours of nighttime lighting. The selected location should not be near night-
time light sources, such as porch lights, street lights or pool lights, as these may cause the
solar light to turn o prematurely.
REMINDER: Make sure the Path Light gets eight (8) hours of sunlight before use.
FIRST TIME USE
If the solar panel is covered by a protective film, remove it before using the product.
Remove the pull-tab from the solar light. Place the solar light in a location where it can
receive a full 8 hours of sunlight to allow the rechargeable battery to reach maximum
capacity.

5
Assembly and Operation
- Remove top cap by turning counter-clockwise.
- Remove pull-tab.
- Re-install top cap by turning clockwise.
- Attach body to the post by pressing them together.
- Attach spike to the post by pressing them together.
Pull-tab
Body
Pull-tab
Top cap
Post
Spike

6
model no. 052-1602-8 | contact us: 1-866-827-4985
Troubleshooting
If the light does not turn on at dusk after 8 hours of charging:
Ensure that the solar lantern is in a bright sunny location and not in a shady area during
the day.
Make sure that the light’s photocell is not aected by other light sources at night.
Make sure the pull-tab has been removed.
Verify that the battery is making contact with the terminal and that they have been
inserted in the correct polarity.

7
Battery Replacement
NOTES•
• This operation should be done in the morning on a sunny day. This will allow
the solar panel to receive a full 8 hours of sunlight so that the rechargeable
battery can reach maximum capacity.
Remove the top cap by turning it counter-clockwise.
Remove the battery compartment cover.
Remove the old battery and replace it with a new AA size rechargeable battery of same
or greater mAh.
(USE RECHARGEABLE BATTERY ONLY).
Note: Clean the battery contacts and those of
the device prior to battery installation.
• Be sure to insert the battery in the proper direction.
• Replace the battery cover.
• Replace top cap by turning it clockwise.
Top Cap
Battery
Battery
compartment
cover

8
model no. 052-1602-8 | contact us: 1-866-827-4985
Caution
• Safe for outdoor operation.
• Failure to insert battery in the correct polarity, as indicated in the battery compartment,
may shorten the life of the battery or cause battery to explode or leak.
• Do not dispose of battery in fire.
• Battery must be recycled or disposed of properly. Dispose of as per requirements of your
local municipality.
• Remove battery if it’s no longer working or if product is to be left unused for a long period.
• REPLACEMENT PARTS MAY BE ORDERED BY USING THE FIXTURE MODEL NUMBER AND THE
PART’S NAME.
Made in China
Imported by/Importé par
Noma Canada, Toronto, Canada M4S 2B8
ONE-YEAR LIMITED WARRANTY
This product carries a one (1) year warranty against defects in workmanship and
materials. Noma agrees to replace the defective product free of charge within the stated
warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.

9
Notes

Noma Canada
Toronto, Canada M4S 2B8
