NordicTrack NTEX04911.0 User manual

Serial Number
Decal
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Model No. NTEX04911.0
Serial No.
Write the serial number in the space
above for reference.
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri., 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
www.nordictrack.com
USER’S MANUAL

2
TABLE OF CONTENTS
WARNING DECAL PLACEMENT
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HOW TO USE THE HEART RATE MONITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
HOW TO USE THE EXERCISE BIKE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
NORDICTRACK is a registered trademark of ICON IP, Inc.
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.

3
WARNING: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your exercise bike before using your exercise bike.
ICON assumes no responsibility for personal injury or property damage sustained by or through the
use of this product.
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the exercise bike only as described in
this manual.
3. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
4. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
5. Keep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
6. Place the exercise bike on a level surface
with at least 2 ft. (0.6 m) of clearance around
the exercise bike. To protect the floor or
carpet from damage, place a mat under the
exercise bike.
7. Inspect and properly tighten all parts regu-
larly. Replace any worn parts immediately.
8. Keep children under age 12 and pets away
from the exercise bike at all times.
9. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
10. The exercise bike should not be used by
persons weighing more than 350 lbs.
(159 kg).
11. The heart rate monitor is not a medical
device. Various factors, including the user’s
movement, may affect the accuracy of heart
rate readings. The heart rate monitor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
12. Always keep your back straight while using
the exercise bike; do not arch your back.
13. Over exercising may result in serious injury
or death. If you feel faint or if you experience
pain while exercising, stop immediately and
cool down.
IMPORTANT PRECAUTIONS

4
Seat
Accessory Tray
Seat Handlebar
Handlebar
Heart Rate Monitor
Pedal/Strap
Wheel
Leveling Foot
Console
Backrest
Adjustment Handle
Handle
Thank you for selecting the revolutionary
NORDICTRACK®GX 5.0 PRO exercise bike. The GX
5.0 PRO exercise bike provides an impressive selec-
tion of features designed to make your workouts at
home more effective and enjoyable.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Length: 4 ft. 11 in. (150 cm)
Width: 2 ft. 3 in. (69 cm)

5
M8 Locknut
(86)–2
M6 Washer
(88)–8
M4 x 16mm
Screw (77)–7
M8 x 16mm
Screw (69)–8
M8 x 65mm Button
Bolt (70)–2
M6 x 38mm Screw
(25)–8
M6 x 18mm
Screw (75)–2
M10 x 105mm Bolt
(65)–4
M10 x 16mm
Screw (67)–4
M10 Split
Washer (100)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.

6
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish assembly.
• To identify small parts, see page 5.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
ASSEMBLY
1. Orient the Front Stabilizer (15) so that the indi-
cated hole is facing the pin on the Frame (1).
While a second person lifts the front of the
Frame (1), attach the Front Stabilizer (15) to the
Frame with two M10 x 105mm Screws (65). 15
1
1
65
Hole
Pin
2. While a second person lifts the rear of the Frame
(1), attach the Rear Stabilizer (16) to the Frame
with two M10 x 105mm Screws (65).
16
65
1
2

7
3
3. Orient the Seat Frame (52) as shown.
Attach the Seat Frame (52) to the Seat Carriage
(41) with four M8 x 16mm Screws (69).
52
69
41
4. Tip: Avoid damaging the wires inside the
Seat Handlebar (11) during this step.
Attach the Seat Handlebar (11) to the Seat
Frame (52) with two M8 x 65mm Button Bolts
(70) and two M8 Locknuts (86).
4
11
70
86
52

8
5
5. Plug the Seat Pulse Wire (10) into the receptacle
in the Right Rear Shield (97).
97
10
6. Attach the Seat (9) to the Seat Frame (52)
with four M6 x 38mm Screws (25) and four M6
Washers (88). Note: Only two Screws and two
Washers are shown.
6
52
9
25
88

9
8
7
103
75
7. Attach the Backrest (8) to the Seat Frame (52)
with four M6 x 38mm Screws (25) and four M6
Washers (88).
8. Attach the Backrest Cover (103) to the Backrest
(8) with two M6 x 18mm Screws (75).
52
25
25
88
88
8
8

10
9
44
40
42
43
2
10
Wire Ties
Wire
Ties
1
9. Orient the Upright (2) and the Top Shield (44)
as shown. Slide the Top Shield upward onto the
Upright.
Have a second person hold the Upright (2) and
the Top Shield (44) near the Frame (1) until step
10.
Locate the wire ties in the Upright (2). Tie the
lower end of one wire tie to the Main Wire (43)
and to the Frame Pulse Wire (42). Tie the end of
the other wire tie to the end of the Receiver Wire
(40). Next, pull the upper ends of the wire ties
upward out of the top of the Upright.
Tip: To prevent the wires from falling into the
Upright (2), secure the wires with the wire
ties.
10. Tip: Avoid pinching the wires. Slide the
Upright (2) onto the Frame (1).
Attach the Upright (2) with four M10 x 16mm
Screws (67) and four M10 Split Washers (100).
Tip: Tighten the two Screws in the front of
the Upright, and then tighten the other two
Screws.
Slide the Top Shield (44) downward and press it
onto the Left and Right Front Shields (13, 14).
Avoid pinching
the wires
2
1
67
67
100
100
13, 14
44

11
11
12
13
11. Identify the Right Handlebar (20), which is
marked with a “Right” sticker, and orient it as
shown.
Attach the Right Handlebar (20) to the Upright
(2) with two M8 x 16mm Screws (69).
Attach the Left Handlebar (7) in the same
way.
12. Identify and orient the Rear Upright Cover (57)
as shown.
Attach the Rear Upright Cover (57) to the Upright
(2) with an M4 x 16mm Screw (77).
7
20
77
57
2
2
2
69
69
13. Untie and discard the wire ties on the Main
Wire (43), the Frame Pulse Wire (42), and the
Receiver Wire (40).
While a second person holds the Console (4)
near the Upright (2), connect the wires on the
Console to the Main Wire (43), to the Frame
Pulse Wire (42), and to the Receiver Wire (40).
Insert the excess wires into the Upright (2) or
into the Console (4).
Tip: Start all the screws before tightening
any of them. Also, avoid pinching the wires.
Attach the Console (4) to the Upright (2) with
four M4 x 16mm Screws (77).
4
77
43
42 40
Avoid pinching
the wires

12
14
15
16
14. Identify and orient the Front Upright Cover (58)
as shown.
Attach the Front Upright Cover (58) to the
Upright (2) with two M4 x 16mm Screws (77).
16. Plug the Power Adapter (51) into the receptacle
on the frame of the exercise bike.
To plug the Power Adapter (51) into an outlet,
see HOW TO PLUG IN THE POWER ADAPTER
on page 14.
17. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise bike to protect the floor.
2
58
77
15. Identify the Right Pedal (21), which is marked
with an “R.”
Using an adjustable wrench, firmly tighten the
Right Pedal (21) clockwise into the Right Crank
Arm (23).
Firmly tighten the Left Pedal (not shown)
counterclockwise into the Left Crank Arm (not
shown).
If necessary, press the right strap onto the
post on the Right Pedal (21). To loosen the
strap, press the indicated tab and pull the strap
upward. To tighten the strap, simply pull the end
of the strap downward. Adjust the strap on the
Left Pedal (not shown) in the same way.
21
51
Tab
Strap
Post
23

13
HOW TO PUT ON THE HEART RATE MONITOR
The heart rate monitor has two components: a chest
strap and a sensor unit (see the drawing below). Insert
the tab on one end of the chest strap into one end of
the sensor unit, as shown in the inset drawing. Press
the end of the sensor unit under the buckle on the
chest strap. The tab should be flush with the front of
the sensor unit.
Next, wrap the heart
rate monitor around
your chest and attach
the other end of the
chest strap to the sen-
sor unit. Adjust the
length of the chest
strap, if necessary.
The heart rate monitor should be under your clothes,
tight against your skin, and as high under the pectoral
muscles or breasts as is comfortable. Make sure that
the logo on the sensor unit is facing forward and is
right-side-up.
Pull the sensor unit away from your body a few inches
and locate the two electrode areas on the inner side
(the electrode areas are covered by shallow ridges).
Using saline solution such as saliva or contact lens
solution, wet both electrode areas. Return the sensor
unit to a position against your chest.
CARE AND MAINTENANCE
• Dry the heart rate monitor after each use. The heart
rate monitor is activated when you wet the electrode
areas and put on the heart rate monitor; the heart
rate monitor shuts off when it is removed and the
electrode areas are dried. If the heart rate monitor is
not dried after each use, the battery may be drained
prematurely.
• Store the heart rate monitor in a warm, dry place. Do
not store the heart rate monitor in a plastic bag or
other container that may trap moisture.
• Do not expose the heart rate monitor to direct sun-
light for extended periods of time or to temperatures
above 122° F (50° C) or below 14° F (-10° C).
• Do not excessively bend or stretch the sensor unit
when using or storing the heart rate monitor.
• Clean the sensor unit using a damp cloth—never use
alcohol, abrasives, or chemicals. Hand wash and air
dry the heart rate monitor.
TROUBLESHOOTING
If the heart rate monitor does not function properly, try
the suggestions below.
• Make sure that you are wearing the heart rate
monitor as described at the left. Note: If the heart
rate monitor does not function when positioned as
described, move it slightly lower or higher on your
chest.
• Use saline solution such as saliva or contact lens
solution to wet the two electrode areas on the sensor
unit. If heart rate readings do not appear until you
begin perspiring, re-wet the electrode areas.
• Position yourself near the console. For the console
to display heart rate readings, the user must be
within arm’s length of the console.
• The heart rate monitor is designed to work with
people who have normal heart rhythms. Heart rate
reading problems may be caused by medical condi-
tions such as premature ventricular contractions
(pvcs), tachycardia bursts, and arrhythmia.
• The operation of the heart rate monitor can be
affected by magnetic interference caused by high
power lines or other sources. If it is suspected that
this is a problem, try relocating the elliptical.
HOW TO USE THE HEART RATE MONITOR
Chest Strap
Sensor Unit
Tab
Buckle
Sensor
Unit
Logo

14
HOW TO PLUG IN THE POWER ADAPTER
IMPORTANT: If the exercise bike has been exposed
to cold temperatures, allow it to warm to room
temperature before plugging in the power adapter.
If you do not do this, you may damage the console
displays or other electronic components.
Plug the power
adapter into the
receptacle on the
frame of the exer-
cise bike. Plug the
power adapter into
an appropriate outlet
that is properly
installed in accor-
dance with all local codes and ordinances.
HOW TO ADJUST THE PEDAL STRAPS
To loosen the strap
on a pedal, press
the indicated tab
and pull the strap
upward. To tighten
the strap, simply pull
the end of the strap
downward.
HOW TO ADJUST THE SEAT
The seat can be
adjusted forward
or backward to the
position that is the
most comfortable
for you. To adjust
the seat, push
downward on the
seat adjustment
handle, slide the
seat to the desired
position, and then
pull upward on the
handle to lock the
seat in place.
HOW TO LEVEL THE EXERCISE BIKE
If the exercise bike
rocks slightly on
your floor during
use, turn one or
both of the leveling
feet under the rear
stabilizer until the
rocking motion is
eliminated.
HOW TO MOVE THE EXERCISE BIKE
To move the exer-
cise bike, hold the
handle on the rear
stabilizer and care-
fully lift it until the
exercise bike can be
moved on the front
wheels. Carefully
move the exercise
bike to the desired location and then lower it.
Pedal
Strap
Tab
Seat
Handle
HOW TO USE THE EXERCISE BIKE
Leveling
Feet
Handle
Power Adapter

15
CONSOLE DIAGRAM FEATURES OF THE CONSOLE
The advanced console offers an array of features
designed to make your workouts more effective and
enjoyable.
When you use the manual mode of the console, you
can change the resistance of the pedals with the touch
of a button. While you exercise, the console will display
continuous exercise feedback. You can also measure
your heart rate using the handgrip heart rate monitor or
the included chest heart rate monitor.
The console offers thirty onboard workouts—fifteen cal-
orie workouts and fifteen performance workouts. Each
workout automatically changes the resistance of the
pedals as it guides you through an effective workout.
The console also features an iFit Live mode that
enables the console to communicate with your wireless
network through an optional iFit Live module. With the
iFit Live mode, you can download personalized work-
outs, create your own workouts, track your workout
results, race against other runners, and access many
other features. To purchase an iFit Live module at
any time, go to www.iFit.com or call the telephone
number on the front cover of this manual.
You can even connect your MP3 player or CD player
to the console sound system and listen to your favorite
music or audio books while you exercise.
To use the manual mode, see page 16. To use the
sound system, see page 17. To use an onboard
workout, see page 18. To use an iFit Live work-
out, see page 19. To change console settings,
see page 20.
Note: If there is a sheet of plastic on the display,
remove the plastic.

16
HOW TO USE THE MANUAL MODE
1. Begin pedaling or press any button on the
console to turn on the console.
When you turn on the console, the display will light.
The console will then be ready for use.
2. Select the manual mode.
Press the Manual Control button on the console to
select the manual mode.
If a wireless iFit Live module is not inserted into
the console and connected to iFit Live, the manual
mode will be selected automatically.
3. Change the resistance of the pedals as desired.
As you pedal, change the resistance of the pedals
by pressing the Resistance increase and decrease
buttons.
Note: After you press a button, it will take a
moment for the pedals to reach the selected resis-
tance level.
4. Follow your progress with the display.
The display can show the following workout
information:
Calories (Cals.)—This display mode will show the
approximate number of calories you have burned.
Calories per Hour (Cals./Hr)—This display mode
will show the approximate number of calories you
are burning per hour.
Distance (Dist.)—This display mode will show
the distance that you have pedaled in miles or
kilometers.
Pulse—This display mode will show your heart rate
when you use the handgrip heart rate monitor or
the included chest heart rate monitor (see step 5
on page 17).
Resistance (Resist.)—This display mode will
show the resistance level of the pedals for a few
seconds each time the resistance level changes.
Speed—This display mode will show your pedaling
speed in miles per hour or kilometers per hour.
Time—When the manual mode is selected, this
display mode will show the elapsed time. When an
onboard workout is selected, this display mode will
show the time remaining in the workout.
The matrix offers several display tabs. Press the
Display button until the desired tab is shown. You
can also press the increase and decrease buttons
next to the Enter button.
Speed—This tab will show a profile of the speed
settings of the workout. A new segment will appear
at the end of each minute.
My Trail—This tab will show a track that represents
1/4 mile (400 m). As you exercise, the flashing
rectangle will show your progress. The My Trail tab
will also show the number of laps you complete.
Calorie—This tab will show the approximate
amount of calories you have burned. The height of
each segment represents the amount of calories
burned during that segment.
As you exercise, the workout intensity level bar
will indicate the approximate intensity level of your
exercise.

17
Press the Home button to return to the default
menu (see HOW TO CHANGE CONSOLE
SETTINGS on page 20 to set the default menu).
If necessary, press the Home button again.
When a wireless iFit Live
module is connected, the wire-
less symbol at the top of the
display will show the strength
of your wireless signal.
Four arcs indicate full signal
strength.
To exit the manual mode or a workout, press the
Home button. If necessary, press the Home button
again.
Change the volume level
of the console by pressing
the Volume increase and
decrease buttons.
5. Measure your heart rate if desired.
To use the included chest heart rate monitor, see
page 13. To use the handgrip heart rate monitor,
follow the instructions below. IMPORTANT: If you
use both heart rate monitors at the same time,
the console will not display your heart rate
accurately.
If there are
sheets of plastic
on the metal
contacts on the
handgrip heart
rate monitor,
remove the
plastic. To mea-
sure your heart
rate, hold the
handgrip heart
rate monitor with your palms resting against the
contacts. Avoid moving your hands or gripping
the contacts tightly.
When your pulse is detected, a heart symbol in the
calorie display will flash each time your heart beats,
one or two dashes will appear, and then your heart
rate will be shown. For the most accurate heart rate
reading, hold the contacts for at least 15 seconds.
If the display does not show your heart rate, make
sure that your hands are positioned as described.
Be careful not to move your hands excessively or
to squeeze the contacts tightly. For optimal perfor-
mance, clean the contacts using a soft cloth; never
use alcohol, abrasives, or chemicals to clean the
contacts.
6. Turn on the fan if desired.
The fan has low and high
speed settings. Press the Fan
increase and decrease but-
tons repeatedly to select a fan
speed or to turn off the fan.
Note: If the pedals do not move for about thirty
seconds, the fan will turn off automatically.
7. When you are finished exercising, the console
will turn off automatically.
If the pedals do not move for several seconds, a
tone will sound, the console will pause, and the
time will flash in the display. To resume your work-
out, simply resume pedaling.
If the pedals do not move for several minutes and
the buttons are not pressed, the console will turn
off and the display will be reset.
HOW TO USE THE SOUND SYSTEM
To play music or audio books through the console
sound system while you exercise, plug the included
audio cable into the jack on the console and into a jack
on your MP3 player or CD player; make sure that the
audio cable is fully plugged in.
Next, press the play button on your MP3 player or
CD player. Adjust the volume level using the Volume
increase and decrease buttons on the console or the
volume control on your MP3 player or CD player.
Contacts

18
HOW TO USE AN ONBOARD WORKOUT
1. Begin pedaling or press any button on the
console to turn on the console.
When you turn on the console, the display will light.
The console will then be ready for use.
2. Select an onboard workout.
To select an onboard workout, press the 15 Calorie
Workouts button or the 15 Performance Workouts
button repeatedly until the desired workout appears
in the display.
When you select an onboard workout, the display
will show the duration of the workout and the name
of the workout. A profile of the speed settings of the
workout will appear in the matrix.
The maximum resistance level and the maximum
speed for the workout will also appear in the
display.
3. Begin pedaling to start the workout.
Each workout is divided into one-minute seg-
ments. One resistance level and one target speed
is programmed for each segment. Note: The same
resistance level and/or target speed may be pro-
grammed for consecutive segments.
During the
workout,
the profile
on the
speed
tab will
show your
progress.
The flashing segment of the profile represents the
current segment of the workout. The height of the
flashing segment indicates the target speed for the
current segment.
At the end of each segment of the workout, a
series of tones will sound and the next segment of
the profile will begin to flash. If a different resis-
tance level and/or target speed is programmed for
the next segment, the resistance level and/or target
speed will appear in the display for a few seconds
to alert you. The resistance of the pedals will then
change.
As you exercise, you will be prompted to keep
your pedaling speed near the target speed for the
current segment. When an upward-pointing arrow
appears in the display, increase your pace. When a
downward-pointing arrow appears, decrease your
pace. When no arrow appears, maintain your cur-
rent pace.
IMPORTANT: The target speed is intended only
to provide motivation. Your actual pedaling
speed may be slower than the target speed.
Make sure to pedal at a speed that is comfort-
able for you.
If the resistance level for the current segment is
too high or too low, you can manually override
the setting by pressing the Resistance buttons.
IMPORTANT: When the current segment of the
workout ends, the pedals will automatically
adjust to the resistance level programmed for
the next segment.
The workout will continue in this way until the last
segment ends. To stop the workout at any time,
stop pedaling. The time will flash in the display. To
resume the workout, simply resume pedaling.
4. Follow your progress with the display.
See step 4 on page 16.
5. Measure your heart rate if desired.
See step 5 on page 17.
6. Turn on the fan if desired.
See step 6 on page 17.
7. When you are finished exercising, the console
will turn off automatically.
See step 7 on page 17.
Profile

19
HOW TO USE AN IFIT LIVE WORKOUT
1. Begin pedaling or press any button on the
console to turn on the console.
When you turn on the console, the display will light.
The console will then be ready for use.
2. Insert the iFit Live module into the console.
To use an iFit Live workout, insert the iFit Live
module into the console. To purchase an iFit Live
module at any time, go to www.iFit.com or call
the telephone number on the front cover of this
manual. You must have an iFit Live module to use
an iFit Live workout.
Note: To use an iFit Live module, you must have
access to a computer with an internet connection
and a USB port. You will also need an iFit.com
membership. To use a wireless iFit Live module,
you must also have your own wireless network
including an 802.11b router with SSID broadcast
enabled (hidden networks are not supported).
3. Select a user.
If more than one user is registered, you can switch
users in the iFit Live main screen. Press the
increase and decrease buttons next to the Enter
button to select a user.
4. Select an iFit Live workout.
To select an iFit Live workout, press one of the iFit
Live buttons. Before some workouts will download,
you must add them to your schedule on www.iFit.
com.
Press the iFit Live button to download the next
workout in your schedule. Press the My Trainer
button, the My Maps button, the World Tour but-
ton, or the Event Training button to download the
next workout of that type in your schedule. Press
the Compete button to compete in a race that you
have previously scheduled. For more information
on the iFit Live workouts, please see www.iFit.
com.
When you select an iFit Live workout, the display
will show the duration of the workout and the
approximate number of calories you will burn. The
display may also show the name of the workout. If
you select a competition workout, the display may
count down to the beginning of the race.
5. Start the workout.
See step 3 on page 18.
During some workouts, the voice of a personal
trainer will guide you through your workout. You
can select an audio setting for your personal trainer
(see HOW TO CHANGE CONSOLE SETTINGS on
page 20).
To stop the workout at any time, stop pedaling. The
time will flash in the display. To resume the work-
out, simply resume pedaling.
6. Follow your progress with the displays.
See step 4 on page 16.
The My Trail tab will show a map of the trail you are
walking or running or it will show a track and the
number of laps you complete.
During a competition workout, the Competition tab
will show your progress in the race. As you race,
the top line in the matrix will show how much of the
race you have completed. The other lines will show
other competitors. The end of the matrix represents
the end of the race.
7. Measure your heart rate if desired.
See step 5 on page 17.
8. Turn on the fan if desired.
See step 6 on page 17.
9. When you are finished exercising, the console
will turn off automatically.
See step 7 on page 17.
For more information on the iFit Live mode, go to
www.iFit.com.
IMPORTANT: To satisfy exposure compliance
requirements, the antenna and transmitter in the
iFit Live module must be at least 8 in. (20 cm) from
all persons and must not be near or connected to
any other antenna or transmitter.

20
HOW TO CHANGE CONSOLE SETTINGS
The console features a user mode that allows you to
view usage information, select a unit of measurement,
and adjust the contrast level of the display.
When an iFit Live module is connected to the console,
you can also use the information mode to choose an
audio setting for the voice of the personal trainer, set a
default menu, check the status of the iFit Live module,
and check for downloads.
1. Select the information mode.
To select the information mode, press and hold
down the Display button for a few seconds until the
information mode appears in the display.
2. View usage information.
The display will show the total number of hours that
the exercise bike has been used. The display will
also show the total distance (in miles or kilometers)
that has been pedaled on the exercise bike.
3. Select a unit of measurement if desired.
The word ENGLISH for English miles or the word
METRIC for metric kilometers will appear in the
display to indicate the currently selected unit of
measurement.
To change the unit of measurement, press the
Enter button repeatedly to select the desired unit of
measurement.
4. Adjust the contrast level of the display if
desired.
Press the decrease button to view the contrast
level. The currently selected contrast level will
appear in the display. Press the Resistance
increase and decrease buttons to adjust the con-
trast level.
5. Determine if an iFit Live module is connected to
the console.
If an iFit Live module is connected to the console,
the display will show the words WIFI MODULE or
USB MODULE.
If no module is connected, the display will show
the words NO IFIT MODULE. If no module is con-
nected, go to step 10.
6. Select an audio setting for the voice of the
personal trainer if desired.
Press the decrease button to view the audio setting
for the voice of the personal trainer. The currently
selected audio setting for the voice of the personal
trainer will appear in the display.
To change the audio setting, press the Enter button
repeatedly to turn the voice of the personal trainer
ON or OFF.
7. Set the default menu if desired.
Press the decrease button to view the default menu
setting. The default menu is the menu that will
appear when you turn on the console. Press the
Enter button repeatedly to select the manual mode
menu or the iFit Live menu as the default menu.
8 Check the status of the iFit Live module if
desired.
Press the decrease button to view the iFit Live
status display. The words CHECK WIFI STATUS or
CHECK USB STATUS will appear in the display.
Then, press the Enter button. After a few seconds,
the status of the iFit Live module will appear in the
display. To exit this display, press and hold down
the Display button for a few seconds.
9. Check for downloads if desired.
Press the decrease button to view the downloads
display. The words SEND/RECEIVE DATA will
appear in the display.
Then, press the Enter button. The console will
then check for iFit Live workouts and firmware
downloads.
10. Exit the information mode.
Press the Display button to exit the information
mode.
