USER’S MANUAL
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
Model No. NTEX71415.2
Serial No.
Write the serial number in the space
above for reference.
www.nordictrack.com
To register your product and
activate your warranty today, go
to www.nordictrackservice.com/
registration.
For service at any time, go to
www.nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
ACTIVATE YOUR
WARRANTY
CUSTOMER CARE
Serial Number
Decal

2
This drawing shows the location(s) of the warning
decal(s). If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decal(s) may not be
shown at actual size.
376541
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS..................................................................3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO USE THE EXERCISE BIKE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
FCC INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
MAINTENANCE AND TROUBLESHOOTING.....................................................33
EXERCISE GUIDELINES ....................................................................34
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Google Maps is a trademark
of Google Inc. The BLUETOOTH®word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are
used under license. Wi-Fi is a registered trademark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi
Alliance.

3
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all
important precautions and instructions in this manual and all warnings on your exercise bike before
using your exercise bike. ICON assumes no responsibility for personal injury or property damage
sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS
1. It is the responsibility of the owner to ensure
that all users of the exercise bike are ade-
quately informed of all precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
3. The exercise bike is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they are given supervi-
sion or instruction about use of the exercise
bike by someone responsible for their safety.
4. Use the exercise bike only as described in
this manual.
5. The exercise bike is intended for home use
only. Do not use the exercise bike in a com-
mercial, rental, or institutional setting.
6. Keep the exercise bike indoors, away from
moisture and dust. Do not put the exercise
bike in a garage or covered patio, or near
water.
7. Place the exercise bike on a level surface
with at least 2 ft. (0.6 m) of clearance around
the exercise bike. To protect the floor or
carpet from damage, place a mat under the
exercise bike.
8. Inspect and properly tighten all parts each
time the exercise bike is used. Replace any
worn parts immediately.
9. Keep children under age 13 and pets away
from the exercise bike at all times.
10. When connecting the power cord, plug the
power cord into a grounded circuit.
11. Do not modify the power cord or use an
adapter to connect the power cord to an
improper receptacle. Keep the power cord
away from heated surfaces. Do not use an
extension cord.
12. Do not operate the exercise bike if the power
cord or plug is damaged, or if the exercise
bike is not working properly.
13. DANGER: Always unplug the power
cord and press the power switch to the off
position when the exercise bike is not in
use and before cleaning the exercise bike.
Servicing other than the procedures in this
manual should be performed by an autho-
rized service representative only.
14. Wear appropriate clothes while exercising;
do not wear loose clothes that could become
caught on the exercise bike. Always wear
athletic shoes for foot protection.
15. The exercise bike should not be used
by persons weighing more than 375 lbs.
(170 kg).
16. Be careful when mounting and dismounting
the exercise bike.
17. Always keep your back straight while using
the exercise bike; do not arch your back.
18. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.

4

5
all
STANDARD SERVICE PLANS

6
Congratulations for selecting the revolutionary
NORDICTRACK®GRAND TOUR PRO exercise
bike. The GRAND TOUR PRO exercise bike is unlike
any ordinary exercise bike. With full adjustability, an
advanced console, an incline system allows you to
simulate actual terrain, and an array of other innova-
tive features, the GRAND TOUR PRO exercise bike is
designed to let you enjoy the outdoor cycling experi-
ence indoors.
For your benefit, read this manual carefully before
you use the exercise bike. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Seat
Seat Knob
Hand Weight
Fan
Incline Control
Handlebar
Handlebar Knob
Wheel
Water Bottle
Holder*
*Water bottle is not included
Pedal/Strap
Resistance
Control
Speakers
Tablet Holder
Leveling Foot
Power Switch/Power Cord
Console
Length: 4 ft. 8 in. (144 cm)
Width: 1 ft. 11 in. (59 cm)
Post Knobs

7
M10 x 58mm Screw (74)–4
M6 x 16mm
Screw (107)–3
M8 x 16mm
Screw (56)–4
#8 x 12mm
Screw (82)–4
M4 x 10mm
Screw (92)–4
M4 x 16mm
Screw (34)–4
M4 x 12mm
Screw (93)–1
M6 x 20mm
Screw (103)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.

8
2
23
1
74
2. If there is a shipping support attached to the
rear of the Base (1), remove the screws from the
shipping support, and discard the screws and
the shipping support.
Attach the Rear Stabilizer (23) to the Base (1)
with two M10 x 58mm Screws (74).
ASSEMBLY
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• To identify small parts, see page 7.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
Assembly may be easier if you have your own set
of wrenches. To avoid damaging parts, do not use
power tools.
1. Go to ww.nordictrackservice.com/registration
on your computer and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have internet access, call
Customer Care (see the front cover of this
manual) and register your product.
1

9
4
8
92
3
3. If there is a shipping support attached to the
front of the Base (1), remove the screws from
the shipping support, and discard the screws
and the shipping support.
Attach the Front Stabilizer (22) to the Base (1)
with two M10 x 58mm Screws (74). 74
22
1
4. Attach the Water Bottle Holder (8) to the Seat
Carriage (4) with four M4 x 10mm Screws (92);
start all the Screws, and then tighten them.
4
5
5. Attach the Seat (5) to the Seat Carriage (4)
with four M8 x 16mm Screws (56); start all the
Screws, and then tighten them.
4
5
56

10
6
6. Locate the Post Knob (47) near the rear of the
Frame (2). Loosen and pull the Post Knob.
Next, insert the Seat Post (3) into the Frame
(2), and release the Post Knob (47) into one of
the adjustment holes (A) in the Seat Post. Make
sure that the Post Knob is in an adjustment
hole. Then, tighten the Post Knob.
7. Loosen and pull the Seat Knob (29).
Next, insert the Seat Carriage (4) into the Seat
Post (3), and release the Seat Knob (29) into
one of the adjustment holes in the Seat Carriage.
Make sure that the Seat Knob is in an adjust-
ment hole. Then, tighten the Seat Knob.
See the inset drawing. Tighten an M4 x 12mm
Screw (93) into the underside of the Seat
Carriage (4).
7
29
3
4
93
4
3
A
2
47

11
9
47
68
2
9. Tip: Avoid pinching the Main Wire (68) during
this step.
Locate the Post Knob (47) near the front of the
Frame (2). Loosen and pull the Post Knob.
Next, insert the Handlebar Post (6) into the
Frame (2), and release the Post Knob (47) into
the lowest adjustment hole (F) in the Handlebar
Post. Then, tighten the Post Knob. Note: After
the exercise bike is assembled, you can adjust
the Handlebar Post to the desired height.
8
8. Have a second person hold the Handlebar Post
(6) near the Frame (2).
Locate the long wire tie (B) in the Handlebar
Post (6). Tie the lower end of the long wire tie to
the Main Wire (68).
Next, locate the middle of the long wire tie (B) in
the access hole (C) in the Handlebar Carriage
(99). Pull the long wire tie upward in the indi-
cated location (D) until the end of the Main Wire
(68) is in the access hole.
See the inset drawing. Next, pull the free end
of the long wire tie (B) until the Main Wire (68) is
routed through the Handlebar Carriage (99) as
shown. Then, untie and discard the long wire tie;
do not remove the short wire tie (E).
99
68
B
Avoid pinching the
Main Wire (68)
B
C
D
6
99
2
68 B
6
F
E

12
10
99
7
10. Have a second person hold the Handlebar (7)
near the Handlebar Carriage (99).
Locate the short wire tie (E) in the Handlebar
Carriage (99). Tie the indicated end of the
short wire tie to the two wires (G) on the
Handlebar (7).
Next, pull the other end of the wire tie until the
two wires are routed through the Handlebar
Carriage (99). Then, untie and discard the wire
tie.
11. Loosen the Handlebar Knob (95). Next, slide the
Handlebar Carriage (99) forward as far as pos-
sible. Then, tighten the Handlebar Knob.
Tip: Avoid pinching the wires. Attach the
Handlebar (7) to the Handlebar Carriage (99)
with four M6 x 20mm Screws (103); start all the
Screws, and then tighten them.
11
12. Hold the Console Bracket (33) near the
Handlebar Carriage (99). Insert the Main Wire
(68) and the two wires (G) from the Handlebar
(7) upward through the Console Bracket.
Tip: Avoid pinching the wires. Attach the
Console Bracket (33) to the Handlebar Carriage
(99) with three M6 x 16mm Screws (107); start
all the Screws, and then tighten them.
Then, press the Wire Cover (32) onto the
Console Bracket (33).
12
33
7
99
68
107
107
G
32
Avoid pinching
the wires
99
Avoid pinching
the wires
7
103
95
E
G

13
13
13. Have a second person hold the Console (9) near
the Console Bracket (33).
Connect the console wires to the Main Wire (68),
to the Ground Wire (111), and to the two wires
(G) from the Handlebar (7); make sure to con-
nect the console wire that has an “R” tag to
the wire that has an “R” tag. Insert the excess
wire into the Console Bracket (33).
Tip: Avoid pinching the wires. Attach the
Console (9) to the Console Bracket (33) with four
M4 x 16mm Screws (34); start all the Screws,
and then tighten them.
14
9
10
14. Attach the Tablet Holder (10) to the Console (9)
with four #8 x 12mm Screws (82); start all the
Screws, and then tighten them.
15
15
72
69
15. Set the two Hand Weights (15) on the Hand
Weight Rest (83) and on the Armrests (69, 72).
82
83
15
9Avoid pinching
the wires
33
111
68
G
34
7

14
17. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly and that it
functions properly. Make sure that all parts are properly tightened before you use the exercise bike.
Extra parts may be included. Place a mat beneath the exercise bike to protect the floor.
62
63
61
16. Identify the Right Pedal (62).
Using the included flat wrench tool, firmly
tighten the Right Pedal (62) clockwise into the
Right Crank Arm (64).
Firmly tighten the Left Pedal (61)
counterclockwise into the Left Crank Arm
(63). IMPORTANT: You must turn the Left
Pedal counterclockwise to attach it.
To adjust the straps on the Pedals (61, 62),
see HOW TO USE THE PEDAL STRAPS on
page 16.
16
64

15
HOW TO PLUG IN THE POWER CORD
This product must be grounded. If it should mal-
function or break down, grounding provides a path of
least resistance for electric current to reduce the risk
of electric shock. The power cord has a plug with a
grounding pin.
Plug the
power cord
into an
appropriate
outlet that
is properly
installed and
grounded in
accordance
with all local
codes and
ordinances. The outlet must be on a nominal 120-volt
circuit.
A temporary
adapter may
be used to
connect the
power cord
to a 2-pole
receptacle
as shown
at the right
if a properly
grounded
outlet is not
available.
The lug or wire extending from the adapter must
be connected with a metal screw to a permanent
ground such as a properly grounded outlet box cover.
Some 2-pole receptacle outlet box covers are not
grounded. Before using an adapter, contact a quali-
fied electrician to determine whether the outlet
box cover is grounded before using an adapter.
The temporary adapter should be used only until
a properly grounded outlet can be installed by a
qualified electrician.
HOW TO USE THE EXERCISE BIKE
DANGER: Improper connection of
the power cord increases the risk of electric
shock. Do not modify the plug; if it will not fit
an outlet, have a proper outlet installed by a
qualified electrician. If you are unsure whether
the product is properly grounded, contact a
qualified electrician.
Grounded Outlet
2-pole Receptacle
Grounding Pin
Adapter
Lug
Metal Screw

16
HOW TO ADJUST THE EXERCISE BIKE
The exercise bike can be adjusted to promote correct
form and to ensure proper training of the muscles.
Note: Make adjustments in small increments,
and then pedal the exercise bike to test the
adjustments.
How to Adjust the Seat Post
For effective train-
ing, the seat should
be at the proper
height. As you
pedal, there should
be a slight bend in
your knees when
the pedals are in
the lowest position.
To adjust the height
of the seat post,
loosen and pull the
post knob, move the seat post upward or downward,
release the post knob into an adjustment hole in the
seat post, and then tighten the post knob. Move the
seat post upward or downward slightly to make
sure that the post knob is engaged in an adjust-
ment hole.
How to Adjust the Seat Carriage
To adjust the posi-
tion of the seat
carriage, loosen
and pull the seat
knob, move the seat
carriage forward or
backward, release
the seat knob into
an adjustment hole
in the seat carriage,
and then retighten
the seat knob.
How to Adjust the Handlebar Post
To adjust the height
of the handlebar
post, loosen and
pull the post knob,
move the handle-
bar post upward or
downward, release
the post knob into
an adjustment hole
in the handlebar
post, and then
tighten the post
knob. Move the seat post upward or downward
slightly to make sure that the post knob is engaged
in an adjustment hole.
How to Adjust the Handlebar Carriage
To adjust the
position of the
handlebar car-
riage, loosen the
seat knob, move
the handlebar car-
riage forward or
backward, and then
retighten the seat
knob.
HOW TO USE THE PEDAL STRAPS
To tighten the
straps, pull the ends
of the straps down-
ward. To loosen the
straps, press the
tabs on the pedals
and pull the straps
upward.
Post
Knob
Seat
Knob
Post
Knob
Handlebar
Knob
Strap
Tab

17
HOW TO LEVEL THE EXERCISE BIKE
If the exercise bike
rocks slightly on
your floor during
use, turn one or
both of the level-
ing feet on the rear
stabilizer until the
rocking motion is
eliminated.
HOW TO USE THE HAND WEIGHTS
To add upper body
exercise to your
workouts, use the
hand weights while
you pedal. When
you are not using
the hand weights,
store them on the
hand weight rest.
HOW TO USE THE TABLET HOLDER
IMPORTANT: The tablet holder is designed for use
with most full-size tablets. Do not place any other
electronic device or object in the tablet holder.
To insert a tab-
let into the tablet
holder, set the bot-
tom edge of the
tablet in the tray.
Then, pull the clip
over the top edge
of the tablet. Make
sure that the tablet
is firmly secured
in the tablet
holder. Rotate the tablet holder to the desired angle.
Reverse these actions to remove the tablet from the
tablet holder.
Leveling
Feet
Hand
Weights
Tablet
Holder

18
Benz
EBNT71415
NTEX71415
CONSOLE DIAGRAM
MAKE YOUR FITNESS GOALS A REALITY WITH
IFIT.COM
With your new iFit-compatible fitness equipment, you
can use an array of features on iFit.com to make your
fitness goals a reality:
Train anywhere in the world with
customizable Google Maps.
Download training workouts designed to
help you reach your personal goals.
Measure your progress by competing
against other users in the iFit community.
Upload your workout results to the iFit cloud
and track your accomplishments.
Set calorie, time, distance, or watts goals
for your workouts.
Choose and download sets of weight-loss
workouts.
Go to iFit.com to learn more.
Watch high-definition videos with simulated
workouts.

19
FEATURES OF THE CONSOLE
The advanced console offers an array of features
designed to make your workouts more effective and
enjoyable.
When you use the manual mode of the console, you
can change the resistance of the pedals and the incline
of the frame with the touch of a button.
While you exercise, the console will display continu-
ous exercise feedback, including watts and pedaling
cadence feedback.
During your workout, you can do intervals at any time
to measure your performance over short periods of
time. The console will record and display your results
for each interval.
You can also measure your heart rate using an optional
heart rate monitor. See page 31 for information
about purchasing an optional chest heart rate
monitor.
In addition, the console features a selection of onboard
workouts and several iFit demo workouts. Each work-
out automatically controls the resistance of the pedals
and the incline of the frame and prompts you to vary
your pedaling speed as it guides you through an effec-
tive exercise session. You can also set a customized
workout goal with the set-a-goal workout.
The console also features new iFit technology that
enables the console to communicate with your wireless
network. With iFit technology, you can download per-
sonalized workouts, create your own workouts, track
your workout results, and access many other features.
See www.iFit.com for complete information.
You can also browse the internet or listen to your
favorite workout music or audio books with the console
sound system while you exercise.
To turn on the power, see this page. To learn how to
use the touch screen, see page 20. To set up the
console, see page 20.
HOW TO TURN ON THE POWER
IMPORTANT: If the exercise bike has been exposed
to cold temperatures, allow it to warm to room tem-
perature before you turn on the power. If you do
not do this, you may damage the console displays
or other electrical components.
Plug in the power cord (see
HOW TO PLUG IN THE
POWER CORD on page
15). Next, locate the
power switch on the frame
near the power cord. Press
the power switch to the
reset position.
The display will then turn on and the console will be
ready for use.
Note: When you turn on the power for the first time,
the incline system may calibrate automatically. The
exercise bike will move upward and downward as it
calibrates. When the exercise bike stops moving, the
incline system is calibrated.
IMPORTANT: If the incline system does not cali-
brate automatically, see step 4 on page 29 and
manually calibrate the incline system.
IMPORTANT: The console features a display demo
mode, designed to be used if the exercise bike is
displayed in a store. If the demo mode is turned on,
the console will not turn off and the display will not
be reset when you nish exercising. To turn off the
demo mode, see step 7 on page 27.
Reset
Position

20
HOW TO USE THE TOUCH SCREEN
The console features a tablet with a full-color touch
screen. The following information will help you become
familiar with the tablet’s advanced technology:
• The console functions similarly to other tablets. You
can slide or flick your finger against the screen to
move certain images on the screen, such as the
displays in a workout. However, you cannot zoom in
and out by sliding your fingers on the screen.
• To type information into a text box, first touch the text
box to view the keyboard. To use numbers or other
characters on the keyboard, touch the ?123 but-
ton. To view more characters, touch the Alt button.
Touch the Alt button again to return to the number
keyboard. To return to the letter keyboard, touch the
ABC button. To use a capital character, touch the
button with an upward-facing arrow. To use multiple
capital characters, touch the arrow button again. To
return to the lowercase keyboard, touch the arrow
button a third time. To clear the last character, touch
the button with a backward-facing arrow and an X.
• Use these buttons on the console to navigate the
tablet. Press the home button to return to the main
menu. Press the settings button to access the
settings menu (see page 27). Press the back
button to return to the previous screen.
HOW TO SET UP THE CONSOLE
Before using the exercise bike for the first time, follow
the steps below to set up the console.
1. Connect to a wireless network.
Note: To access the internet, download iFit work-
outs, and use some other features of the console,
the console must be connected to a wireless
network. See HOW TO USE THE WIRELESS
NETWORK MODE on page 30 to connect the
console to your wireless network.
2. Check for firmware updates.
First, see step 1 on page 27 and step 2 on page
29 and select the maintenance mode. Then,
see step 3 on page 29 and check for firmware
updates.
3. Calibrate the incline system.
First, see step 1 on page 27 and step 2 on page
29 and select the maintenance mode. Then,
see step 4 on page 29 and calibrate the incline
system of the exercise bike.
4. Create an iFit account.
On your computer, smartphone, tablet, or other
internet-capable device, open an internet browser
and go to www.iFit.com. Follow the prompts on the
website to sign up for your iFit membership. If you
have an activation code, select the code activation
option.
The console is now ready for you to begin training. The
following pages explain the various workouts and other
features that the console offers.
To use the manual mode, see page 21. To use
an onboard workout, see page 23. To use a
set-a-goal workout, see page 24. To use an iFit
workout, see page 25.
To use the equipment settings mode, see
page 27. To use the maintenance mode, see
page 29. To use the wireless network mode,
see page 30. To use the sound system, see page
31. To use the internet browser, see page 31.
Note: If there is a sheet of plastic on the display,
remove the plastic.
The console can display speed and distance in either
miles or kilometers. To nd which unit of measurement
is selected, see step 14 on page 28. For simplicity,
all instructions in this section refer to miles.
Home Settings Back
