Nortel NAC User manual

Network Administration Center
User Guide Supplement
Publication number: P0886656
Product release: 2.5
Document release: Standard 1.0
Date: November 1998
Copyright © 1998 Northern Telecom
All rights reserved
Printed in the United States of America
Information is subject to change without notice. Northern Telecom reserves the right to make
changes in design or components as progress in engineering and manufacturing may warrant.
MERIDIAN 1, NETWORK ADMINISTRATION CENTER (NAC), NORTHERN TELECOM,
NORTEL NETWORKS, and NORTEL NETWORKS HOW THE WORLD SHARES IDEAS are
trademarks of Northern Telecom Ltd. MS-DOS, Microsoft Windows, and Windows NT are
trademarks of Microsoft Corporation.

iii
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Publication histor
y
November 1998 Standard 1.0 of this guide is released to the public.

iv Publication history
Standard 1.0 Network Administration Center November 1998
User Guide Supplement

Contents
Preface About this guide ix
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Inside this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
1What’s new in NAC 2.5 1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
New features in NAC 2.5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Additional software codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Time and year modifications. . . . . . . . . . . . . . . . . . . . . . . . . . 10
Changes to link status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Restrictions for list names. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Required documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2Preparing the system 15
Describing the system requirements . . . . . . . . . . . . . . . . . . . . 16
Using the MVME332XTS or MVME332XT card . . . . . . . . . 21
3Configuring the modems 23
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Section A: US Robotics modems 27
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Remote diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote supervisor login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Network link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

vi Contents
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Section B: Racal VI2422PA modem 35
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Network link and Racal VI2422PA modem . . . . . . . . . . . . . .37
4Using the Meridian Terminal Emulator 39
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Connecting through a serial port or modem . . . . . . . . . . . . . .42
Connecting through a LAN connection. . . . . . . . . . . . . . . . . .48
Configuring MTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
5Saving to a file 53
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Assigning a port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Printing to a file. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Formatting headings in a data stream report . . . . . . . . . . . . . .59
Downloading the report. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
6Handling local printing 65
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Restrictions for using local printing . . . . . . . . . . . . . . . . . . . .67
Printing to a LAN printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Before you configurea local printer. . . . . . . . . . . . . . . . . . . .69
Directing reports to a local printer. . . . . . . . . . . . . . . . . . . . . .70
Overriding the system printer . . . . . . . . . . . . . . . . . . . . . . . . .71
Adding a local printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Changing a local printer type. . . . . . . . . . . . . . . . . . . . . . . . . .75
Changing a local printer name. . . . . . . . . . . . . . . . . . . . . . . . .76
Deleting a local printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Contents vii
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
7Using Multiple Queue Assignment 79
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Interpreting the Network Position Status Counts Display. . . .81
8Configuring 10+ nodes 85
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Configuring the nodes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
9Remote supervisor login 99
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Configuring the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Configuring the Meridian MAX port . . . . . . . . . . . . . . . . . .104
Configuring the NAC port. . . . . . . . . . . . . . . . . . . . . . . . . . .107
Entering the phone number . . . . . . . . . . . . . . . . . . . . . . . . . .109
Accessing the remote site . . . . . . . . . . . . . . . . . . . . . . . . . . .111
10 Handling error messages 115
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Index 119

viii Contents
Standard 1.0 Network Administration Center November 1998
User Guide Supplement

Preface
About this guide
In this preface
Overview x
Inside this guide xi

xAbout this guide
Overview
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Overview
Introduction The Network Administration Center User Guide Supplement
describes the features in Network Administration Center
(NAC) 2.5.
Who should read
this guide This guide is for administrators, technicians, supervisors, and
others who are responsible for NAC 2.5.
Assumptions This guide assumes that you are familar with NAC 2 and
Meridian MAX.
This guide also assumes that the NAC 2.5 is correctly installed
and operational.
How to use this
guide NAC 2.5 is an upissue of NAC 2. You need to use this
supplement guide to understand the differences between NAC 2
and NAC 2.5.
For detailed instructions on how to install and operate the NAC
system, you must refer to the existing NAC 2 documentation. A
list of the existing documentation is provided in “Required
documentation” on page 13.

About this guide xi
Inside this guide
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Inside this guide
The Network Administration Center User Guide Supplement is
structured as follows:
Chapter 1, “What’s new in NAC 2.5,” describes the new
features in NAC 2.5. It also provides the modifications to the
software installation and upgrade code. Finally, this chapter lists
the documentation manuals you should use with NAC 2.5.
Chapter 2, “Preparing the system,” describes the hardware
and software requirements of NAC 2.5. It also describes the
MVME332XTS eight-channel asynchronous board, which is a
new feature in NAC 2.5.
Chapter 3,“Configuring the modems,” describes the modems
you can use with NAC 2.5.
Chapter 4, “Using the Meridian Terminal Emulator,”
describes how to use Meridian Terminal Emulator (MTE) 9 to
access NAC 2.5.
Chapter 5, “Saving to a file,” describes how to save reports
into files. Third-party software, such as database and
spreadsheet applications, can use these files.
Chapter 6, “Handling local printing,” describes how to print
a report to a printer attached to your PC.
Chapter 7, “Using Multiple Queue Assignment,” describes
how to interpret the Network Position Status Counts Display
screen if you usethe Multiple Queue Assignment (MQA)
feature.
Chapter 8, “Configuring 10+ nodes,” describes how to
configure NAC 2.5 to monitor up to 20 Meridian MAX nodes.

xii About this guide
Inside this guide
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Chapter 9, “Remote supervisor login,” describes how to
remotely log in to a Meridian MAX node from your NAC
workstation.
Chapter 10, “Handling error messages,” contains a list of the
error messages that can be generated in NAC 2.5.
The Index provides the index entries in this guide.

Chapter 1
What’s new in NAC 2.5
In this preface
Overview 2
New features in NAC 2.5 3
Additional software codes 6
Time and year modifications 10
Changes to link status 11
Restrictions for list names 12
Required documentation 13

2What’s new in NAC 2.5
Overview
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Overview
Introduction This chapter describes the new features introduced in NAC 2.5.
It also describes modifications made to the software, such as
new installation messages and a new format for entering the
year.

What’s new in NAC 2.5 3
New features in NAC 2.5
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
New features in NAC 2.5
Introduction This section describes the new features in NAC 2.5.
List of new
features The following table lists the new features in NAC 2.5 and where
to find more information on these features.
New feature For more information, refer to
Support for the Year 2000 “Support for the Year 2000” on page 4
Higher network link speed “Higher network link speeds” on page 4
MVME332XTS eight-channel
asynchronous board Chapter 2, “Preparing the system”, “Using the MVME332XTS or MVME332XT card” on page 21
US Robotics Sportster 28.8 modem Chapter 3, “Configuring the modems”
Meridian Terminal Emulator
interface Chapter 4, “Using the Meridian Terminal Emulator”
Savereports to a file Chapter 5, “Saving to a file”
Print reports to a printer attached to
your PC Chapter 6, “Handling local printing”
Multiple Queue Assignment Chapter 7 “Using Multiple Queue Assignment”
Support for 10+ Meridian MAX
nodes Chapter 8, “Configuring 10+ nodes”

4 What’s new in NAC 2.5
New features in NAC 2.5
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Support for the
Year 2000 NAC 2.5 and its operating system are designed to support the
Year 2000. With this enhancement, NAC 2.5 can operate
between the years 1970 and 2037.
The screens in NAC 2.5 are modified to allow you to enter a
two-digit year or a four-digit year when you create reports.
Note: To enter a range of years in a two-digit format, the range
must consist of the years only within the 20th century, or the
years only within the 21st century. If the range of years is
different from the current century, you must specify the years
in a four-digit format. For example, to produce a report with
data from 1998 to 1999, you enter the years as 98 and 99. To
produce a report with data from 2000 to 2001, you enter the
years as 00 and 01. However, you cannot request data in a two-
digit format for the years ranging from 1998 to 2001. To
receive this data, you must enter the years in a four-digit
format.
A report with the Year field only shows a two-digit year. For
example, the Year 2000 appears as 00 on reports, and the Year
1999 appears as 99.
The Year 2000 appears in a two-digit format (for example, 00)
in the Configuration Control transaction log. In the system error
log, the years appear in a two-digit format only within the 20th
century (for example, 99), but in a four-digit format for years in
the 21st century (for example, 2000).
Higher network
link speeds NAC 2.5 offers a higher link speed of 19,200 baud on the
network link connected with a Meridian MAX 9 (or higher)
node. In previous releases, NAC supervisors could only
configure the network link up to a speed of 9600 baud.

What’s new in NAC 2.5 5
New features in NAC 2.5
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Note: If NAC 2.5 is monitoring a Meridian MAX 8 (or lower)
node, the network link should configure up to 9600 baud.
NAC supervisors can configure a modem or direct network link
connection with this new speed on any of the serial ports. The
new speed improves the response time for network operations
sent over the network link.
The network link is assigned on the NAC Communication Port
Assignment screen. For more information on this screen, refer
to the Network Administration Centre (NAC) Installation Guide
(NTP 553-4011-110), “Maintenance and administration system
shutdown” chapter, “Configure NAC System” section.

6What’s new in NAC 2.5
Additional software codes
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Additional software codes
Introduction System messages appear on your screen when you install the
software. The messages indicate the status of the installation or
upgrade procedure.
Several new lines of installation/upgrade code appear in NAC
2.5 that did not appear in earlier releases of NAC. This section
describes those lines of code.
Previous
installation
code
During a new software installation, the system configures the
port devices. This code is shown in the Network Administration
Center (NAC) Installation Guide (NTP 553-4011-110),
“New software installations” chapter, page 6-17.
During this configuration process, the earlier versions of NAC
displayed the following messages:
***> Configuring port devices...(TIME)
***> Finished configuring port devices.(TIME)
If you are completing reentry point 2, 3, or 4, the following
message appears:
port_hold started.
Stream Error logging started.
netspec “tcpip” not set up.
Line printer scheduler started.
Module ID = NAC00

What’s new in NAC 2.5 7
Additional software codes
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
New software
installation code In NAC 2.5, the new software installation code appears as
follows:
***> Configuring port devices...(TIME)
***> Finished configuring port devices.(TIME)
If you are completing reentry point 2, 3, or 4, the following
message appears:
port_hold started.
Transport Provider daemon started.
Internet services provided.
portmap started.
Stream Error logging started.
netspec “tcpip” not set up.
Network Commands: rwalld
routed started.
NFS Startup...
ONC daemons:
NFS daemons:
Lock manager:
NFS Startup complete.
Line printer scheduler started.
Module ID = NAC00

8What’s new in NAC 2.5
Additional software codes
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
Previous
reinstallation and
upgrade code
During a software reinstallation or upgrade, the system
configures the port devices. This code is shown in the
Network Administration Center (NAC) Installation Guide
(NTP 553-4011-110), “Software reinstallations and upgrades”
chapter, page 8-20.
During this configuration process, the earlier versions of NAC
displayed the following messages:
***> Configuring port devices...(TIME)
***> Finished configuring port devices.(TIME)
The following message appears only if you use reentry point 2,
3, or 4:
port_hold started.
Stream Error logging started.
netspec “tcpip” not set up.
Line printer scheduler started.
Module ID = NAC00

What’s new in NAC 2.5 9
Additional software codes
Standard 1.0 Network Administration Center November 1998
User Guide Supplement
New software
reinstallation or
upgrade code
In NAC 2.5, the new software installation code appears as
follows:
***> Configuring port devices...(TIME)
***> Finished configuring port devices.(TIME)
The following message appears only if you use reentry point 2,
3, or 4.
port_hold started.
Transport Provider daemon started.
Internet services provided.
portmap started.
Stream Error logging started.
netspec “tcpip” not set up.
Network Commands: rwalld
routed started.
NFS Startup...
ONC daemons:
NFS daemons:
Lock manager:
NFS Startup complete.
Line printer scheduler started.
Module ID = NAC00
