North-Vision Tech Prince 180B User manual

I
North-vision Easy ECG
Prince 180B
User Manual
Version: 1.4
Issued by: Sara Lo Date: 5/11/2020
Reviewed by: Albert Huang Date: 5/11/2020
Document No: UM-ECG-201108-01
North-Vision Tech. Inc.
2460

II
Dear Users,
User Manual for Easy ECG Monitor
Instructions to User
Thank you very much for purchasing our product. Please read the manual very carefully
before using this device.
These instructions describe the operating procedures to be followed strictly. Failure to
follow these instructions may cause measuring abnormality, device damage, or personal
injury.
The Manual is published in English and we have the ultimate right to explain the
Manual. No part of this manual may be photocopied, reproduced or translated into
another language without the prior written consent. We reserve the right to improve and
amend it at any time without prior notice.

III
User Manual for Easy ECG Monitor
Announcement
Information furnished by the manufacturer is believed to be accurate and reliable.
However, no responsibility is assumed by manufacture for its use, or any infringements
of patents or other rights of third parties that may result from its use.
Declaration ofConformity:
The manufacturer hereby declares that this device complies with the following
standards:
IEC 60601-1
IEC 60601-1-2
and follows the provisions of the Council Directive MDD 93/42/EEC.

IV
User Manual for Easy ECG Monitor
WARNING
1. Check the device to make sure that there is no visible damage that may affect user’s
safety and measurement performance. Stop using the unit, when there is obvious
damage.
2. Do NOT make diagnosis oneself by the measurement and measurement results,
always consult the doctor if abnormal information is presented frequently.
3. It is NOT designed or intended for medical diagnosis.
4. Do NOT use the device in the bathroom or moist circumstance.
5. Do NOT use if you carry a cardiac pacemaker.
6. Do NOT operate in the environment where strong electro-magnetic interference
exists.
7. Necessary service must be performed by qualified service engineers ONLY.
8. Clinical ECG examination is suggested for normal examination of your heart
condition.

V
User Manual for Easy ECG Monitor
9. Connect/Disconnect data cable to the monitor gently and carefully, do NOT wring or
shake the data cable plug with force to insert into or unplug from data interface port,
or the data interface port may be damaged.
10. Dispose of the expired device and its accessories according to applicable local
regulations.

VI
User Manual for Easy ECG Monitor
Table of Contents
1 OVERVIEW ..............................................................................................................1
1.1 APPEARANCE.......................................................................................................1
1.2 NAME AND MODEL .............................................................................................3
1.3 STRUCTURE.........................................................................................................3
1.4 FEATURES............................................................................................................3
1.5 APPLICATION SCOPE...........................................................................................4
1.6 OPERATING ENVIRONMENT ...............................................................................4
2 INSTALLATION .......................................................................................................5
2.1 INSTALLATION OF BATTERIES ............................................................................5
2.2 INSERT/REMOVE SD CARD ................................................................................6
3 OPERATION .............................................................................................................7
3.1 START TO MEASURE ECG..................................................................................7

VII
User Manual for Easy ECG Monitor
3.2 ECG MEASUREMENT.....................................................................................10
3.2.1 ECGMEASURING METHOD .............................................................................10
3.3 WAVE REVIEW................................................................................................19
3.4 DATA MANAGEMENT......................................................................................28
3.5 SYSTEM SETTING ...........................................................................................34
3.6 HELP..............................................................................................................42
4 TECHNICALSPECIFICATIONS.........................................................................43
4.1 ECG MEASUREMENT.....................................................................................43
4.2 POWER ...........................................................................................................44
4.3 CLASSIFICATION.............................................................................................44
4.4 DISPLAY..........................................................................................................45
4.5 DATA MEMORY...............................................................................................45
4.6 OVERALL DIMENSION AND WEIGHT............................................................46
5 ACCESSORIES........................................................................................................46

VIII
User Manual for Easy ECG Monitor
6 MAINTENANCE AND SERVICE.........................................................................47
7 TROUBLESHOOTING ..........................................................................................49
8 ERROR PROMPTINGAND ELIMINATION.....................................................51
9 KEY OF SYMBOLS................................................................................................54
APPENDIX..................................................................................................................55
GENERAL KNOWLEDGE OF ECG ............................................................................55

1
1Overview
1.1 Appearance
User Manual for Easy ECG Monitor
1. Power: Long time press (about 2 seconds) makes the device power on or off;
short time press turns on/off the backlight.

2
2. Metal Electrode I, II
User Manual for Easy ECG Monitor
3. Measurement: shortcut button for measuring, press this button to start
measuring.
4. ▇OK: confirm selection or modification.
5. Navigationkey:
/Up/left/increase: move the cursor upwards/to the left, or adjust parameter
values.
/Down/right/decrease: move the cursor downwards/to the right, or adjust
parametervalues.
6. Return: back to upper level of menu.
7. Display screen: display ECG waveforms and data.
8. Metal Electrode III
9. SD CARD: SD Card Port.

3
User Manual for Easy ECG Monitor
10. Data interface port: for connecting to data
cable.
1.2 Name and Model
Prince 180B Easy ECG Monitor
1.3 Structure
Prince 180B Easy ECG Monitor consists of main board, panels and electrodes.
1.4 Features
1. Small in size and light in weight to carry.
2. One-key measurement, easy to operate.
3. ECG waveform and interpretation of results are displayed clearly on dot-matrix
LCD screen.
4. Seventeen types measurement result can be presented.
5. Up to 300 records can be stored in built-in memory.
6. Support SD Card to extend memory capacity.

4
User Manual for Easy ECG Monitor
7. Data records can be reviewed, copied, deleted, and uploaded to PC as well.
8. Power saving technique with automatic shutting-off function.
9. TwoAAAbatteries can be used for more than 1000 times measurement.
1.5 Application Scope
Prince 180B Easy ECG is designed for major use indoor/outdoor of home-care. It is
intended for self-monitoring ECG waveform as well as heart rate of its major function.
The device is designed for spot-check by 30 seconds measurement and the
measuring data can be saved in its memories which is very helpful for a reference by
the doctor. It is not designed to substitute the normal ECG examination or real time
monitoring. This device is used for pediatric/child and adult, excepting infant/neonate.
1.6 Operating Environment
Operating temperature 5℃~ 40℃
Operating humidity 15% ~ 93%
Atmospheric pressure 700 hPa ~1060hPa

5
2Installation
User Manual for Easy ECG Monitor
2.1 Installation of Batteries
1. Open the battery cover (see the Figure
2-1).
2. Insert two AAA size batteries directly.
3. Close the battery cover.
Do NOT insert batteries with their
polarities reversed. Dispose of the used
batteries according to applicable local
regulations.
Figure 2-1
Note: Protecting films are attached to the electrodes of device, so please remove the
protecting films before measurement.

6
User Manual for Easy ECG Monitor
2.2 Insert/Remove SD Card
Please use the SD card with the memory not more than 8GB, or it may not compatible
with the device. The following brand and capacity of the SD card are tested to work
normally with this device: SanDisk (≤8GB), Kingston (≤8GB).
Insert SD card:
1. Open the rubber cover of SD card.
2. Insert the SD card into the SD card slot, make
sure that the golden contactors face downward
(see the Figure 2-2).
3. Push the SD card to make it locked, and then
close the rubber cover.
Remove SD card:
1. Open the rubber cover of SD card. Figure 2-2 Insert SD Card
2. Push the SD card to make it pop-up.
3. Remove the SD card , and then close
the rubber cover.
Please switch off the
monitor
when inserting or removing SD card.

7
3Operation
User Manual for Easy ECG Monitor
3.1 Start to measure ECG
Press the Power button (lasting for 2 seconds) to turn on the unit. The unit starts to
initialize, and displays the following pictures Figure 3-1A and Figure 3-1B.
Figure 3-1A Figure 3-1B
After boot-strap, the unit enters into menu screen, as shown in Figure 3-2.

8
User Manual for Easy ECG Monitor
Note: During initialization, press “Return” button to enter into main menu screen, as
shown in Figure 3-2. If press “Measurement”, it will enter into measuring screen, as
shown in Figure 3-4.
Figure 3-2
There are 5 tool buttons, press navigation key to shift cursor and press “ ◼ OK”to
confirm. Each functional button will be defined as follows:

9
User Manual for Easy ECG Monitor
Measure: detect ECG waveform and HR value, and analyze whether the ECG
waveform is normal.
Review: review the ECG records saved in this device or in SD card (including ECG
waveform and measurement result).
Memory: delete the ECG records saved in this unit or in SD card; copy ECG
records to SD card or upload the ECG records to PC.
Setting: set system date, time, language, mode, brightness and contrast etc.
parameters.
Help: provide with measuring methods etc. information.
Note: “ ” is SD card symbol, there is no SD card symbol if SD card is not inserted
into the device.

10
User Manual for Easy ECG Monitor
3.2 ECG Measurement
3.2.1 ECG Measuring Method
1 ChestMeasurement
In order to obtain ideal ECG waveform, chest
measurement is suggested firstly. Hold the device with
the right hand. Make sure that the palm and fingers
touch the metal electrode I and II reliably. Place the
electrode III on bare skin about 5cm away below the
left nipple. The ECG signal detected by Chest
Measurement is similar to Lead V ECG signal.
Improper operating method: Figure 3-3A Chest Measurement
A. The contact place of electrode III deviates from left chest.
B. The holding gesture is incorrect.
C. The electrode can not contact bare skin completely. (For example place the electrode
on clothing.)

11
electrode III on the skin 10cm away above the left
foot ankle. The ECG signal detected by Leg
Measurement is equivalent to Lead II ECG signal.
Improperoperating method:
Figure 3-3B
Leg Measurement
A. Wrong holding gesture.
2 LegMeasurement
User Manual for Easy ECG Monitor
If it is not convenient to use chest measurement,
the leg measurement will be recommended. When
measuring, hold the device with the right hand.
Make sure that the palm and fingers touch the
metal electrode I and II reliably. Place the
B. The electrode III can not contact bare skin completely. (For example, place the
electrode III on the sleeve of trousers or socks.)

12
3 PalmMeasurement
User Manual for Easy ECG Monitor
Hold the device with right hand. Make sure that the palm and fingers touch the metal
electrode I and II reliably. Press the electrode III close against the center of the left palm.
The ECG signal detected by Palm Measurement is equivalent to Lead I ECG signal.
Improperoperating method: 3-3C Palm Measurement
A. Waving your both hands at will.
B. Both hands loose contact with electrodes during measurement.
C. Not palm contacts the electrode.
