Daavlin UV Series User manual

MNL-00008 [5] Proprietary and Confidential Page 1of 55
ClearLink™Controlled Phototherapy Equipment
Clinical Operation Manual

MNL-00008 [5] Proprietary and Confidential Page 2of 55
Table of Contents
1.0 Introduction ....................................................................................5
2.0 Indications for Use .........................................................................6
3.0 Classifications .................................................................................6
4.0 Operating Specifications................................................................7
5.0 Transport and Storage Specifications ..........................................7
6.0 EMC Precautions ...........................................................................7
7.0 Labels and Symbols........................................................................8
7.1 Domestic and International Units..................................................................................... 8
7.2 UV Risk Group 2 Labels (CE Devices Only) ................................................................ 10
8.0 Delivery and Inspection ...............................................................10
9.0 Lamp Inspection ...........................................................................11
10.0 Site Selection .................................................................................12
11.0 Training Requirements................................................................12
12.0 Important Safeguards and Warnings ........................................12
13.0 Unlocking the Device....................................................................15
14.0 Changing or Disabling the Key Code.........................................15
15.0 Checking the Power Output of Device .......................................15
16.0 Operating the ClearLink Controlled Phototherapy Equipment
Control Systems .....................................................................................16
16.1 Dosimeter Instructions: 3 Series NeoLux, UV Series, 7 Series, M Series, and 4 Series
16
16.1.1 Setting up a Treatment ............................................................................................ 16
16.1.2 Special Functions of the Integrated Dosimeter....................................................... 16
16.1.3 Special Notes .......................................................................................................... 16
16.1.4 ClearLink Controller Range and Accuracy............................................................. 17
16.2 Dosimeter Instructions: 1 Series................................................................................. 17
16.2.1 Setting Up a Treatment ........................................................................................... 17
16.2.2 Special Functions of the Integrated Dosimeter....................................................... 17
16.2.3 Special Notes .......................................................................................................... 18
16.2.4 Dosimeter Range and Accuracy.............................................................................. 18
16.3 Time Only Instructions: 3 Series NeoLux, UV Series, 7 Series, M Series, and 4 Series
18
16.3.1 Determining a Treatment Time............................................................................... 18
16.3.2 Setting Up a Treatment Time.................................................................................. 19
16.3.3 Special Functions of the Integrated Dosimeter....................................................... 19
16.3.4 Special Notes .......................................................................................................... 19
16.3.5 Timer Range and Accuracy .................................................................................... 20
16.4 Time Only Instructions: 1 Series ............................................................................... 20
16.4.1 Determining a Treatment Time............................................................................... 20
16.4.2 Setting Up a Treatment Time.................................................................................. 21

MNL-00008 [5] Proprietary and Confidential Page 3of 55
16.4.3 Special Functions of the Integrated Dosimeter....................................................... 21
16.4.4 Special Notes .......................................................................................................... 21
16.4.5 Timer Range and Accuracy .................................................................................... 21
17.0 3 Series NeoLux Information ......................................................21
17.1 Available Models:....................................................................................................... 21
17.2 How to Position the Patient ........................................................................................ 22
17.3 Patient Control Buttons .............................................................................................. 22
17.4 3 Series NeoLux Lamp Removal and Replacement................................................... 22
18.0 UV Series CX and UV Series CT Information..........................23
18.1 Domestic and Non-CE Electrical Requirements ........................................................ 23
18.2 European CE Electrical Requirements ....................................................................... 24
18.3 Circuit Breaker ........................................................................................................... 24
18.4 Unpacking and Assembly........................................................................................... 24
18.5 How to Position the Patient ........................................................................................ 25
18.6 UV Series Lamp Removal and Replacement ............................................................. 25
19.0 7 Series CX and 7 Series CT Information .................................26
19.1 Electrical Requirements.............................................................................................. 26
19.2 Unpacking and Assembly........................................................................................... 27
19.3 How to Position the Patient ........................................................................................ 28
19.4 7 Series Lamp Removal and Replacement ................................................................. 29
20.0 M Series CX and M Series CT Information..............................29
20.1 Electrical Requirements.............................................................................................. 29
20.2 Unpacking and Assembly........................................................................................... 30
20.3 Special Notes .............................................................................................................. 31
20.4 How to Position the Patient ........................................................................................ 31
20.5 M Series Lamp Removal and Replacement ............................................................... 31
21.0 4 Series Information.....................................................................32
21.1 Electrical Requirements.............................................................................................. 32
21.2 Unpacking and Assembly........................................................................................... 32
21.3 How to Position the Patient ........................................................................................ 33
21.4 4 Series Lamp Removal and Replacement ................................................................. 34
22.0 1 Series CX and 1 Series CT Information .................................34
22.1 Electrical Requirements.............................................................................................. 34
22.2 Unpacking and Assembly........................................................................................... 35
22.3 How to Position the Patient ........................................................................................ 35
22.3.1 Hand and Foot Treatments:..................................................................................... 35
22.3.2 Larger Area Treatment:........................................................................................... 36
22.4 1 Series Lamp Removal and Replacement ................................................................. 36
22.5 Special Notes for 1 Series Units Equipped with Integrated Dosimetry ..................... 36
22.5.1 Treatment Distance ................................................................................................. 36
22.5.2 Calibration Output Certificate................................................................................. 37
22.6 Special Notes for 1 Series Units Equipped with the Digital Timer............................ 37
22.6.1 Treatment Distances and Your Calibration Output Certificate............................... 37
23.0 Treatment Protocols.....................................................................39

MNL-00008 [5] Proprietary and Confidential Page 4of 55
23.1 UVA Clearing Phase Protocols (Skin Types I - III)................................................... 39
23.2 UVA Clearing Phase Protocols (Skin Types IV - VI)................................................ 41
23.3 UVA Maintenance Phase Protocols: .......................................................................... 43
23.4 UVA Treatment Limits for Maintenance & As Required Protocols .......................... 44
23.5 LO Dose Broad Band UVB Clearing Phase Protocols:.............................................. 44
23.6 LO Dose Broad Band UVB Maintenance Phase Protocols:....................................... 44
23.7 LO Dose Broad Band UVB Treatment Limits for Maintenance & As Required
Protocols ................................................................................................................................... 45
23.8 HI Dose Broad Band UVB Clearing Phase Protocols: 11011, 3/week, 2/week....... 45
23.9 HI Dose Broad Band UVB Maintenance Phase Protocols: 1/week ........................ 45
23.10 LO Dose Narrow Band UVB Clearing Phase Protocols: 11011, 3/week, 2/week .... 46
23.11 LO Dose Narrow Band UVB Maintenance Phase Protocols: 1/WEEK.................... 46
23.12 LO Dose Narrow Band UVB Treatment Limits for Maintenance & As Required
Protocols ................................................................................................................................... 46
23.13 HI Dose Narrow Band UVB Clearing Phase Protocols: ............................................ 46
23.14 HI Dose Narrow Band UVB Maintenance Phase Protocols: ..................................... 47
23.15 HI Dose Narrow Band UVB Treatment Limits for Maintenance & As Required
Protocols ................................................................................................................................... 48
24.0 Care of Your Phototherapy Unit ................................................49
24.1 Recommended Maintenance Schedule....................................................................... 49
24.2 Cleaning/Disinfection................................................................................................. 49
24.2.1 General Cleaning .................................................................................................... 49
24.2.2 Low-Level Disinfection .......................................................................................... 49
24.2.3 High-Level Disinfection ......................................................................................... 50
24.3 Resetting Your Lamp Hours....................................................................................... 50
25.0 EMC Guidelines ...........................................................................50
26.0 Warranty and Contact Information...........................................53
26.1 Limited Warranty Policy ............................................................................................ 53
26.2 Warranty Coverage..................................................................................................... 54
26.3 Customer Responsibility............................................................................................. 54
26.4 Warranty Service ........................................................................................................ 54
26.5 Disposal ...................................................................................................................... 55
26.6 Other Services............................................................................................................. 55
26.7 Contact Information.................................................................................................... 55

MNL-00008 [5] Proprietary and Confidential Page 5of 55
1.0 Introduction
Thank you for purchasing a Daavlin Phototherapy Unit. The use of light for the treatment of
photoresponsive skin disorders has been our passion since 1981. From the beginning we have
been devoted to providing our customers with the highest quality products coupled with
industry-leading customer service.
At Daavlin, we are always keeping track of new developments and are doing our best to
implement the latest findings in our products. We appreciate receiving feedback from the
medical community and patients, so we can further improve our products. If you have any
comments or suggestions, please contact our Customer Service department and your input will
be channeled to the appropriate person.
The purpose of this manual is to instruct users on the proper methods of operation and general
maintenance. In addition to this, the manual also addresses important information regarding
device specifications, warnings, treatment protocols and warranty information. Please take a
moment to read the entire operation manual before operating your Daavlin phototherapy unit.
Here at Daavlin we are proud of our tradition of development and innovation in the field of
phototherapy, and we are honored that you have chosen us for your phototherapy needs. Let’s be
clear. Our commitment to you starts…Now!
Sincerely,
Daavlin Distributing Company
205 West Bement Street
P.O. Box 626
Bryan, OH 43506-0626
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: www.Daavlin.com

MNL-00008 [5] Proprietary and Confidential Page 6of 55
2.0 Indications for Use
The ClearLink Controlled Phototherapy Equipment are medical ultraviolet devices, which are
intended for use, by or under the direction of a physician, for therapeutic treatment for
individuals who require ultraviolet radiation for diagnosed skin disorders. When equipped with
blue lamps the ClearLink Controlled Phototherapy Equipment is intended for use for the
treatment of acne vulgaris.
Note: Only Daavlin’s 1 Series or 4 Series devices, when equipped with blue lamps and
controlled with the ClearLink Controlled Phototherapy Equipment, have intended use for the
treatment of acne vulgaris.
WARNING: Do not use these devices for anything other than their intended purposes.
CAUTION: Federal law restricts this device to sale by or on the order of a physician or any
other practitioner licensed by the law of the state in which he/she practices.
The 7 Series Phototherapy Device is not a Class III or implantable device. The Summary of Safety
and Clinical Performance is not required.
3.0 Classifications
FDA:
Class II Device
93/42/EEC:
Class IIa Device
IEC 60601-1:
Class I Device
Pollution Degree:
Class II
Mode of Operation:
Non-continuous
IEC/EN 62471:2006
UV Risk Group:
Risk Group 2 (Moderate-Risk)
WARNING: This device is designed for intermittent operation only and not for continuous use.
The device should not be cycled continuously for more than 10 minutes. After such time, the unit
should either be turned off or left idling for at least 10 minutes.

MNL-00008 [5] Proprietary and Confidential Page 7of 55
4.0 Operating Specifications
Ambient Temperature:
15°C to 30°C (59°F to 86°F)
Relative Humidity:
10% to 95%, Non-condensing
Liquid Ingress Rating:
IPX0 (This device does not have protection
against ingress of water.)
Ocular Hazard Distance:
3 Meters (9.84 Feet)
Ambient Luminance:
250 –500 lux
Atmospheric Pressure
70 kPa to 106 kPa
WARNING: Equipment not suitable for use in the presence of a flammable anesthetic mixture
with air or with oxygen or nitrous oxide.
5.0 Transport and Storage Specifications
Ambient
Temperature:
-40°C to 70°C (-40°F to 158°F)
Relative Humidity:
10% to 95%, Non-condensing
Atmospheric
Pressure:
50 kPa to 106 kPa
6.0 EMC Precautions
The devices contained in this manual have been tested and found to comply with the EMC limits
of the international standard IEC 60601-1-2. These limits are designed to provide reasonable
protection against interference in a typical medical installation. The system can radiate radio
frequency energy if not installed in accordance with the instructions and may cause harmful
interference to other devices in the vicinity. There is no guarantee that interference will not
occur in a particular installation. If the system does cause interference with other devices, which
can be determined by turning the system off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Re-orient or relocate the receiving device
•Increase the separation between the equipment
•Connect the System into an outlet on a circuit different from that to which the other
device(s) is connected
•Consult the manufacturer or field service technician for help

MNL-00008 [5] Proprietary and Confidential Page 8of 55
7.0 Labels and Symbols
7.1 Domestic and International Units
Each device comes affixed with an orange “unlock code” label on top of the ClearLink Control
System. This label will provide you with important information about the factory default key
code needed to unlock the unit.
Figure 1 Unlock Code
A warning label is affixed to your device in a prominent and easily readable position. Please read
the label carefully as it contains important safety information for you.
Figure 2 Warning Labels
In addition to the warning labels mentioned above, an identification label, see Figure 3
Identification Label, indicates the serial number and date of manufacture that is specific to your
device.
Figure 3 Identification Label

MNL-00008 [5] Proprietary and Confidential Page 9of 55
Figure 4 Medical Device Label
The following is a chart detailing all symbols located on the cabinet and their definitions:
Table 1 Symbols
Symbol
Description
DANGEROUS VOLTAGE
!
ATTENTION, CONSULT ACCOMPANYING
DOCUMENTS
NON-IONIZING RADIATION
TYPE B EQUIPMENT (3 Series NeoLux & M Series) *
FAN (3 Series NeoLux Only)
LIGHTS (3 Series NeoLux Only)
PROTECTIVE EARTH (ground)
INSTRUCTION MANUAL
KEEP DRY
MEDICAL DEVICE
*The only applied part in the M Series is the acrylic lamp cover, a Type B part

MNL-00008 [5] Proprietary and Confidential Page 10 of 55
7.2 UV Risk Group 2 Labels (CE Devices Only)
According to IEC/EN 62471:2006, sources of optical radiation are classified into risk groups
subject to their potential photobiological hazard. This device falls under Risk Group 2
(Moderate-Risk) and does not pose a severe hazard due to the natural aversion response to bright
light or thermal discomfort. A Risk Group 2 warning label, which also includes the primary
emission range and potential output range, is affixed to your device in a prominent and easily
readable position.
Figure 5 Risk Group 2 Warning Labels
8.0 Delivery and Inspection
When you first receive the device, please inspect the shipping crate or box.
Any signs of shipping damage must be noted on the delivery receipt that you will be asked to
sign by the delivery driver. Be sure to open the crate and verify that there is no damage to your
unit before the driver leaves. If it is not possible for you to inspect your unit before the driver
leaves, we recommend you write “Concealed damage possible. Further inspection required”
on the delivery receipt. If damage is discovered after unpacking the unit, save all packing
materials and call Daavlin at 1 800 322 8546 for inspection and repair.
Note: The delivering carrier must be notified of any shipping damage within twenty-four (24)
hours to protect your right to an insurance claim.
Note: As part of the claims process the delivering carrier may require that a damage inspection
be conducted. The delivering carrier may request to conduct the inspection at the delivery site,
provided that a mutually agreed upon date and time can be established, or they may elect to
collect the package for inspection at their facilities.

MNL-00008 [5] Proprietary and Confidential Page 11 of 55
9.0 Lamp Inspection
Your device can be equipped with a variety of different lamps, each having a different effect on
the skin. While you are unpacking and setting up your device it is important to check that the
proper lamps are installed in the device. Consult Table 2 Lamp Specification Guide on page 11
and if there is any question as to whether or not your device it is equipped with the lamps that
you have ordered, contact Daavlin immediately. The code numbers shown are generally located
at the base of the lamp.
Table 2 Lamp Specification Guide
Applicable
Units
UVA
UVA-1
Narrowband
UVB
Broadband
UVB
Blue
Visible
3 Series
NeoLux:
-F72T12-
BL-HO-
RDC
-TL100W
/10R
-TL-
01/100W-
FS72 –
FS72T12/NB
UVB/HO/RD
C/100W
-FS72T12-
UVB-HO-
TL100W/12
N/A
Undefined
UV Series:
-F72T12-
BL-HO-
RDC
-TL100W
/10R
-TL-
01/100W-
FS72 –
FS72T12/NB
UVB/HO/RD
C/100W
-FS72T12-
UVB-HO-
TL100W/12
N/A
Undefined
7 Series:
-F72T12-
BL-HO-
RDC
-TL100W
/10R
-TL-
01/100W-
FS72 –
FS72T12/NB
UVB/HO/RD
C/100W
-FS72T12-
UVB-HO-
TL100W/12
N/A
Undefined
M Series:
-PLL-
36W/P-
F24T12/
BL/HO/R
DC
-PLL-
36W/10/4
P
-PLL-
36W/01/4P
-TL20W/01-
RS
-060PLL-
36W-06-
FS24T12-
UVB-HO
N/A
Undefined
4 Series:
-PLL-
36W/P
-PLL-
36W/10/4
P
-PLL-
36W/01/4P
-060PLL-
36W-06
PLL-
36W/03
Undefined
1 Series:
-PLL-
36W/P
-PLL-
36W/10/4
P
-PLL-
36W/01/4P
-060PLL-
36W-06
PLL-
36W/03
Undefined

MNL-00008 [5] Proprietary and Confidential Page 12 of 55
10.0 Site Selection
A site should be chosen within reach of the specified electrical connection (refer to the Electrical
Requirements section of your specific device) and where the unit can be left in place without
obstructing traffic flow. The device should be positioned in such a way the power inlet or circuit
breakers on the device are easily accessible. It is important that the unit be properly grounded.
Extension cords are not recommended. The site should not be in any area where water or
moisture might collect and should be protected from access by children and other unintended
users.
WARNING: To avoid the risk of electric shock this equipment must only be connected to a
supply main with a protective earth.
11.0 Training Requirements
Phototherapy services require staff having appropriate training, knowledge, and clinical skills in
order to ensure effective outcomes and quality care for patients. Staff must be assessed as being
competent and safe in order to provide phototherapy treatments that maximize benefit and
minimize adverse effects. Recommended training requirements include:
•Staff should be either a physician, nurse, or any other practitioner licensed by the law of
the state or country in which he/she practices
•Training and experience in dermatology is important to provide holistic patient care. This
knowledge includes:
oAnatomy and the Physiology of the skin
oRecognition and understanding of skin diseases
oSkin assessment
oUnderstanding of photoresponsive diseases
•Theoretical knowledge of phototherapy and its use
•A period of supervised practice for approximately 3 months with a competent practitioner
•Managers should ensure that staff members have, or are provided with, the appropriate
level of training and education needed prior to administering phototherapy services.
12.0 Important Safeguards and Warnings
•To protect the eyes during operation, the operator and anyone in view of the device must
wear the provided UV blocking glasses or goggles designed to block 100% of all UVA
and UVB light from the eye area when worn. Always use Daavlin approved eyewear.
•Do not remove protective eyewear, or any other protective equipment, during treatment.
•If psoralens (photosensitizing drugs) are being used as part of treatment (“PUVA”), the
eyes should be protected from exposure to ultraviolet (sunlight) for 24 hours after taking
the drug. Ultraviolet blocking glasses are provided with all Daavlin devices.
•Do not use over skin eruptions without express consent from the attending physician.

MNL-00008 [5] Proprietary and Confidential Page 13 of 55
•If a patient experiences burning, never treat the patient until the noticeable effects of
burning subside, and always reduce the subsequent treatment time.
•To protect unaffected skin during operation, the operator, patient, and anyone in view of
the device must generously apply UV blocking skin protection to all exposed skin that the
physician does not intend to treat.
•During extremely long treatments, some surfaces may become hot. Remove any body
parts from those surfaces if it becomes uncomfortable. The unit should have a 50% duty
cycle of 10 minutes on, 10 minutes off.
•Erythema can result in as little as 15 seconds of exposure, or approximately 200
millijoules of dose to UVB light. If using the unit at home, contact your prescribing
physician for specific treatment instructions and dosing information.
•Center patients between the lamps during treatment to avoid over exposure to isolated
areas of the body.
•All people and pets should leave the treatment area to avoid exposure to ultraviolet light.
•If operating at home, ask your doctor about protecting areas of your body that have not
been exposed to sunlight.
•Do not use this device for anything other than its intended purpose.
•This device is only to be used by authorized users.
•Do not operate this device with a damaged cord or plug.
•If appliance coupler or mains plug is used as the mains disconnect, do not position the
ME equipment so that it is difficult to operate the disconnection device
•To avoid the risk of electric shock this equipment must only be connected to a supply
main with a protective earth.
•To prevent electric shock, remove power to the device prior to cleaning and servicing.
•To eliminate the risk of fire when replacing the fuse, replace ONLY with a fuse of the
same type and rating.
•NO MODIFICATION OF THIS EQUIPMENT IS PERMITTED. Unauthorized
modification will void the warranty and may result in hazardous or improper device
operation.
•DANGER - ULTRAVIOLET RADIATION. As with natural sunlight, overexposure
can cause eye and skin injury, and allergic reactions. Repeated exposure may cause
premature aging of the skin and/or skin cancer. ALWAYS WEAR PROTECTIVE
EYEWEAR: FAILURE TO DO SO MAY RESULT IN SEVERE ERYTHEMA OR
LONG-TERM INJURY TO THE EYES. Medications or cosmetics may increase skin
sensitivity to ultraviolet radiation. Inform physician before using this device if you are
using medications or have a history of skin problems or sensitivity to light.
•If the device malfunctions, cease operation immediately. If the device is placed close to
other equipment, it is possible that the cause is interference by external noise sources and

MNL-00008 [5] Proprietary and Confidential Page 14 of 55
fields, in which case you should follow the remedies found under EMC Precautions. If
the device continues to malfunction cease operation and contact the Daavlin Service
Department.
•If necessary, operation of equipment may be terminated by disconnecting unit from AC
mains. This can be accomplished by unplugging device or, if hard wired, turning off
quick disconnect.
•Prior to each use, always verify that the device is in correct working order and operating
condition and plugs, sockets, lamps, and electrical cables and connections are not worn or
damaged.
•Only original components and accessories should be used with the device to avoid
damage.
•This device should be a minimum of 12 inches (30 cm) away from RF generating
equipment
•Before opening the device casing to perform maintenance or service, disconnect the
device from the power source.
•The device must never be directly exposed to flowing or splashing liquids of any kind. If
the device is inadvertently exposed to liquid, it must be tested for safe function before
being placed in operation again.
•The device contains glass lamps. Avoid excessive force to the device to prevent lamp
damage.
•The device control system display is susceptible to damage from excessive force. Avoid
excessive force to the control system to prevent damage.
•All treatments must be administered under the direction of a licensed physician only.
•The room that the device is placed in should be vented to allow free air displacement to
ensure the device and surroundings remain cool.
•The device should be placed a minimum of 1 inch (2.5 cm) away from surrounding walls,
devices, and furniture to ensure proper cooling airflow.
•A qualified, licensed electrician must wire the service for all devices in accordance with
all national and local codes and the electrical instructions provided in the accompanying
Service & Installation Instructions manual. Unauthorized personnel should not open the
panels. The Daavlin Service Department should be consulted before any service is
performed.

MNL-00008 [5] Proprietary and Confidential Page 15 of 55
13.0 Unlocking the Device
To prevent unauthorized
use, the device will “self-
lock” when left idle for
twenty (20) minutes. To
unlock your unit, follow
the instructions below.
1. Tap screen to
awaken your unit.
The Logo Screen will appear.
2. Tap Logo Screen. This will open the Lock Screen.
3. The factory preset Key Code is “0007”. On the touch keypad, enter the number “7”.
4. Press the Enter key to unlock your unit.
14.0 Changing or Disabling the Key Code
If you would like to disable or personalize your factory default key code, please contact the
Daavlin service department at 1-800-322-8546 for step-by-step instructions.
The Daavlin service department is available to assist you Monday through Thursday 7:30am-
8:00pm EST and Friday 8:30am-5:00pm EST.
15.0 Checking the Power Output of Device
The power output value of your device, as measured at the factory, is shown on the Power
Output Certificate included with your device literature.
Note: It is not necessary to take a power output reading before each treatment. We suggest once
every couple of weeks, or earlier if the backup time ends your treatment before the full dose has
been delivered.
1. After unlocking device, tap the “Lamp Warmup” button.
2. Select Lamp Type to warmup (Only applicable for Combo devices).
3. Ensure that no persons are in treatment area.
4. Tap the Enter Arrow to begin lamp warmup.
5. Once Lamp Warmup Completes, lamps will turn off and output will remain displayed on
screen.
6. If lamps are cold, it may take more than one Lamp Warmup to determine max output.
Figure 6 Logo Screen
Figure 7 Lock Screen

MNL-00008 [5] Proprietary and Confidential Page 16 of 55
16.0 Operating the ClearLink Controlled Phototherapy Equipment
Control Systems
Daavlin ClearLink Controlled Phototherapy Equipment is available with two distinct control
systems, Time Only and Dosimetry. Please verify the type of control system incorporated in
your unit and proceed to the applicable operating instructions.
16.1 Dosimeter Instructions: 3 Series NeoLux, UV Series, 7 Series, M Series,
and 4 Series
Your Daavlin phototherapy unit features a built-in power meter that measures energy output.
Once a dose has been entered the unit will use the information gathered by the sensor to
determine the exact amount of time that each treatment will last. The dose is entered in
millijoules for UVB and Joules for UVA.
The output of fluorescent lamps varies with age, use and other factors such as room temperature.
Integrated Dosimetry measures for such variations and then integrates them into the dose
treatment time resulting in a very effective way to ensure the precision and consistency of each
treatment.
16.1.1 Setting up a Treatment
1. After unlocking device, tap the Treat Patient button.
2. Touch the ▲/▼ arrows to set desired dose in millijoules (UVB) or Joules (UVA).
3. Tap the Enter Arrow to enter Treatment Confirmation screen.
4. Ensure patient has put on goggles and positioned themselves per the instructions.
5. Confirm Dose and Estimated Treatment Time.
•If Dose and Estimated Treatment Time are correct, tap Enter Arrow to begin
treatment.
•If changes need to be made to Dose, tap Return Arrow to return to step #2.
6. Following delayed start, if enabled, treatment will begin, and screen will display
progress.
To repeat the same dose for another exposure, touch the Repeat button
Note: The system beeps to signal the end of the treatment and displays the delivered
dose with the elapsed time.
16.1.2 Special Functions of the Integrated Dosimeter
•To pause an active treatment, tap the Pause button
•To resume a paused treatment, tap the Play button
•To end or cancel an active treatment, first pause the treatment and then tap the Cancel
button
16.1.3 Special Notes
•It is not possible to enter a time of 60 seconds. You must enter 1 minute instead.

MNL-00008 [5] Proprietary and Confidential Page 17 of 55
•If power goes off during a treatment, the system will remember how much of the
treatment has elapsed. When power is restored, your device provides option to resume
interrupted treatment.
16.1.4 ClearLink Controller Range and Accuracy
Backup Time Range:
1 Second - 59 Minutes 59 Seconds (00:01 - 59:59)
Dose Range:
UVA: 0.1 Joules - 999.9 Joules
UVB: 1 Millijoule - 9999 Millijoules
Accuracy:
+ / - 5%
Calibration:
1 year or every 100 hours of use
16.2 Dosimeter Instructions: 1 Series
Your Daavlin 1 Series features a built-in power meter that measures energy output. Once a dose
has been entered the unit will use the information gathered by the sensor to determine the exact
amount of time that each treatment will last. The dose is entered in millijoules for UVB and
Joules for UVA
The output of fluorescent lamps varies with age, use and other factors such as room temperature.
Integrated Dosimetry measures for such variations and then integrates them into the dose
treatment time. This is a very effective way to ensure the precision of each treatment.
16.2.1 Setting Up a Treatment
1. After unlocking device, tap the “Treat Patient” button.
2. Tap “0 inches” button or “9 inches” button depending on desired treatment distance.
3. Touch the ▲/▼ arrows to set desired dose in millijoules (UVB) or Joules (UVA)
4. Tap the Enter Arrow to enter Treatment Confirmation screen.
5. Ensure patient has put on goggles and positioned themselves per the instructions.
6. Confirm Dose and Estimated Treatment Time.
•If Dose and Estimated Treatment Time are correct, tap Enter Arrow to begin
treatment.
•If changes need to be made to Dose, tap Return Arrow to return to step #3.
7. Following delayed start, if enabled, treatment will begin, and screen will display
progress.
To repeat the same dose for another exposure, touch the Repeat button
Note: The system beeps to signal the end of the treatment and displays the delivered
dose with the elapsed time.
16.2.2 Special Functions of the Integrated Dosimeter
•To pause an active treatment, tap the Pause button
•To resume a paused treatment, tap the Play button

MNL-00008 [5] Proprietary and Confidential Page 18 of 55
•To end or cancel an active treatment, first pause the treatment and then tap the Cancel
button
16.2.3 Special Notes
•It is not possible to enter a time of 60 seconds. You must enter 1 minute instead.
•If power goes off during a treatment, the system will remember how much of the
treatment has elapsed. When power is restored, your device provides option to resume
interrupted treatment.
16.2.4 Dosimeter Range and Accuracy
Backup Time Range:
1 Second - 59 Minutes 59 Seconds (00:01 - 59:59)
Dose Range:
UVA: 0.1 Joules - 999.9 Joules
UVB: 1 Millijoule - 9999 Millijoules
Accuracy:
+ / - 5%
Calibration:
1 year or every 100 hours of use
16.3 Time Only Instructions: 3 Series NeoLux, UV Series, 7 Series, M Series,
and 4 Series
16.3.1 Determining a Treatment Time
When using time as a dose, there are two treatment methods that can be used. The simplest is to
start at a prescribed time and then increase treatment times by a specific time increment or by a
percentage. Another method is to use the factory power output levels (shown on the Power
Output Certificate) to determine estimated “time equivalents” needed to deliver doses in
millijoules (UVB) or Joules (UVA or visible light).
To determine a “time equivalent”, consult the laminated Time Chart that is provided and find the
power output on the top row (horizontal axis). The numbers in the left most column (vertical
axis) represent a range of potential treatment doses. Find the dose then trace that row to the right
until it intersects with the column corresponding to the factory power output of the device. The
time equivalent is shown where the two lines intersect. For example, if the factory power output
is 4.0 mW/cm2 and the dose to be delivered is 280 mJ, then the appropriate treatment time will
be 01:10. A partial time chart illustrating this is shown in Table 3 Partial UVB Time Chart on
page 19.
Note: For your convenience, and as an alternative to the UVB time chart, the latest version of
our free iPhone and Android application “Phototherapy Math” is available for download at the
iTunes app store and Android market. It quickly calculates treatment time and makes the
calculation of dose and time increases simple. If using a PC, visit www.phototherapymath.com
for a web-based calculator and additional information.

MNL-00008 [5] Proprietary and Confidential Page 19 of 55
mW/cm2
mJoules
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
7.0
240
01:36
01:20
01:09
01:00
00:53
00:48
00:44
00:40
00:34
280
01.52
01:33
01:20
01:10*
01:02
00:56
00:51
00:47
00:40
320
02.08
01:47
01:31
01:20
01:11
01:04
00:58
00:53
00:46
Table 3 Partial UVB Time Chart
The UVA Time Chart (not shown here) is configured the same as the UVB Time Chart. The
doses are listed in Joules and the energy output levels and times are different than the UVB
output levels. Each chart is clearly marked.
16.3.2 Setting Up a Treatment Time
1. After unlocking device, tap the “Treat Patient” button.
2. Touch the ▲/▼ arrows to set desired Treatment Time
3. Tap the Enter Arrow to enter Treatment Confirmation screen.
4. Ensure patient has put on goggles and positioned themselves per the instructions.
5. Confirm Treatment Time.
•If Treatment Time is correct, tap Enter Arrow to begin treatment.
•If changes need to be made to Treatment Time, tap Return Arrow to return to
step #2.
6. Following delayed start, if enabled, treatment will begin, and screen will display
progress.
To repeat the same dose for another exposure, touch the Repeat button
Note: The system beeps to signal the end of the treatment and displays the delivered
dose with the elapsed time.
16.3.3 Special Functions of the Integrated Dosimeter
•To pause an active treatment, tap the Pause button
•To resume a paused treatment, tap the Play button
•To end or cancel an active treatment, first pause the treatment and then tap the Cancel
button
16.3.4 Special Notes
•It is not possible to enter a time of 60 seconds. You must enter 1 minute instead.
•If power goes off during a treatment, the system will remember how much of the
treatment has elapsed. When power is restored, your device provides option to resume
interrupted treatment.

→

MNL-00008 [5] Proprietary and Confidential Page 20 of 55
16.3.5 Timer Range and Accuracy
Time Range:
1 Second - 59 Minutes 59 Seconds (00:01 - 59:59)
Accuracy:
+ / - 5%
16.4 Time Only Instructions: 1 Series
16.4.1 Determining a Treatment Time
When using time as a dose, there are two treatment methods that can be used. The simplest is to
start at a prescribed time and then increase treatment times by a specific time increment or by a
percentage, per your physician’s protocol. Another method is to use the factory power output
levels (shown on the Power Output Certificate) to determine estimated “time equivalents”
needed to deliver doses in millijoules (UVB) or Joules (UVA or visible light).
To determine a “time equivalent”, consult the laminated Time Chart that is provided and find the
power output on the top row (horizontal axis). The numbers in the column on the left (vertical
axis) represent a range of potential treatment doses. Find the dose then trace that row to the right
until it intersects with the column corresponding to the factory power output of the device. The
time equivalent is shown where the two lines intersect. For example, if the factory power output
is 4.0 mW/cm2 and the dose to be delivered is 280 mJ, then the appropriate treatment time will
be 01:10. A partial time chart illustrating this is shown in “
mW/cm2
mJoules
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
7.0
240
01:36
01:20
01:09
01:00
00:53
00:48
00:44
00:40
00:34
280
01.52
01:33
01:20
01:10*
01:02
00:56
00:51
00:47
00:40
320
02.08
01:47
01:31
01:20
01:11
01:04
00:58
00:53
00:46
Table 4 Partial UVB Time Chart” below.
Note: For your convenience, and as an alternative to the UVB time chart, the latest version of
our free iPhone and Android application “Phototherapy Math” is available for download at the
iTunes app store and Android market. It quickly calculates treatment times, backup safety times,
and makes the calculation of dose and time increases simple. If using a PC, visit
www.phototherapymath.com for a web-based calculator and additional information.
mW/cm2
mJoules
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
7.0
240
01:36
01:20
01:09
01:00
00:53
00:48
00:44
00:40
00:34
280
01.52
01:33
01:20
01:10*
01:02
00:56
00:51
00:47
00:40
320
02.08
01:47
01:31
01:20
01:11
01:04
00:58
00:53
00:46
Table 4 Partial UVB Time Chart
The UVA Time Chart (not shown here) is configured the same as the UVB Time Chart however
the doses are listed in Joules and the energy output levels and times are different than the UVB
output levels. Each chart is clearly marked.

→
