Northern IP4W User manual

Installation & Quick Setup Guide
1
1
About this Manual
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
Please use this user manual under the guidance of professionals.
Legal Disclaimer
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY
SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE
EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS

Installation & Quick Setup Guide
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at their
own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.

Installation & Quick Setup Guide
3
3
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.

Installation & Quick Setup Guide
4
4
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 12 VDC according
to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Installation & Quick Setup Guide
5
5
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -30°C ~+60°C), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.

Installation & Quick Setup Guide
6
6
●Do not expose internal components to liquid or moisture.
●While in transit, the camera shall be packed in its original
packing, or packing of the same protection.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact tech
support at 855-388-7422. Never attempt to disassemble the
camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)

Installation & Quick Setup Guide
7
7
Table of Contents
1 Appearance Description ................................................................. 8
2 Installation.................................................................................... 10
2.1 Ceiling Mounting........................................................... 11
2.2 Installation of Network Cable Water-proof Jacket ......... 14
2.3 Ceiling Mounting with a Gang Box ................................ 17
2.4 Pendent Mounting ........................................................ 19
2.5 Wall Mounting .............................................................. 21
2.6 Install the Micro SD Card ............................................... 24
3 Setting the Network Camera over the LAN .................................. 25
3.1 Wiring ........................................................................... 25
3.2 Activating the Camera ................................................... 26
3.2.1 Activation via Web Browser................................ 26
3.2.2 Activation via SADP Software ............................. 27
3.3 Modifying the IP Address .............................................. 29
4 Accessing via Web Browser .......................................................... 32
5 Operating via Guarding Vision App .............................................. 35
5.1 Enable Guarding Vision Service on Camera................... 35
5.1.1 Enable Guarding Vision via SADP Software ........ 35
5.1.2 Enable Guarding Vision via Web Browser........... 36
5.2 Guarding Vision Setup................................................... 38
5.3 Adding Camera to Guarding Vision ............................... 38

Installation & Quick Setup Guide
8
8
1Appearance Description
8
4
2
1
3
7
6
Figure 1-1 Overview (1)
Figure 1-2 Overview (2)

Installation & Quick Setup Guide
9
9
Table 1-1 Physical Description
No.
Description
1
Front Cover
2
Dome Drive
3
Micro SD Card Slot
4
Network Cable
5
Lens
6
IR LED
7
Power Cable
8
Audio/Alarm Cables
9
Not applicable for this model
10
Serial Interface
11
Hex Screw
12
Built in Microphone
13
RESET Button
Press RESET button for 10s when the camera is powering on or
rebooting to restore the default settings, including the user
name, password, IP address, port No., etc.

Installation & Quick Setup Guide
10
10
No.8 is the audio/alarm cable interface, of which the “I”mark
connects to the alarm input, the “o”mark connects to the
alarm output, the “GND”mark connects the grounding, and the
“A”mark connects the audio output (for two way audio only).
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12V DC, please make sure your
power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.

Installation & Quick Setup Guide
11
11
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.
2.1 Ceiling Mounting
Steps:
1. Drill the screw holes and the cable hole in the ceiling according
to the supplied drill template.
Drill Template
A
1 1
Hole A :for cables routed through the wall
Screw hole1 :for Mounting Base
FRONT
Code:194101278
Figure 2-1 Drill Template
2. Loosen the set screw on the front cover to disassemble the
camera with the supplied Allen key.

Installation & Quick Setup Guide
12
12
Figure 2-2 Disassemble the Camera
3. Hammer the plugs of the expansion screws to the ceiling.
4. Connect the power cable, network cable, and the audio/alarm
cables.
5. Fix the camera body to the ceiling with the supplied expansion
screws.
Figure 2-3 Fix the Adapter Plate

Installation & Quick Setup Guide
13
13
6. View the image via the web browser.
7. Slightly loosen the hex screw beside the WPS/RESET button to
adjust the surveillance angle.
8. Use the supplied adjusting tool to adjust the pan [±30°], tilt
[0~80°], and rotation direction [0~360°].
Adjusting Tool
Rotation
Tilt
Pan
Figure 2-4 3-Axis Adjustment
9. Tighten the hex screw to fix the well-adjusted surveillance angle.
10. Align the front cover to the dome drive and tighten the set
screws on the front cover.

Installation & Quick Setup Guide
14
14
Figure 2-5 Install the Front Cover
11. Tear off the protection film softly to complete the installation.
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your hands.
2.2 Installation of Network Cable Water-proof
Jacket
Purpose:
If the camera is installed outdoor, you can adapt the water-proof
accessory for the network cable after the camera is secured on the
installation surface.

Installation & Quick Setup Guide
15
15
①②③④⑤⑥ ⑦
Figure 2-6 Water-proof Accessory Components
Table 2-1 Components
No.
Components
1
Camera’s Network Interface Socket
2
O-Type Gasket
3
Network Plug
4
Waterproof Endcap
5
Waterproof Rubber Gasket
6
Lock Nut
7
Network Cable from Router/Switch

Installation & Quick Setup Guide
16
16
Camera
Switch/Router
Align the snap and notch.
i. Insert ⑤into ④.
ii. Secure ⑥with ④.
Figure 2-7 Water-proof Accessory Installation
Steps:
1. Feed the plugless network cable ⑦through the lock nut ⑥,
waterproof rubber gasket ⑤(rubber gasket inset ridge must
face waterproof endcap), and the water-proof endcap ④in
order.
2. Crimp an RJ-45 network plug ③onto the end of the cable,
taking care to insert the twisted pairs of wires in correct order.

Installation & Quick Setup Guide
17
17
3. Place the O-type gasket ②onto the end of the camera’s
network interface socket ①. Place the O-type gasket ②onto
the end of the camera’s network interface socket ①.
4. Insert the network plug ③into the camera’s network interface
socket①.
5. Insert the water-proof rubber gasket ⑤into the waterproof
endcap ④, and secure lock nut ⑥with the water-proof
endcap ④.
6. Align the snap on the water-proof endcap ④with the notch on
the camera’s network interface socket ①,and then secure the
water-proof endcap ④to the camera’s network interface
socket ①to finish installation.
2.3 Ceiling Mounting with a Gang Box
Steps:
1. Fix the adapter plate to the gang box with the supplied PM4X8
screws.

Installation & Quick Setup Guide
18
18
Figure 2-8 Fix the Adapter Plate
2. Fix the dome drive to the adapter plate with the supplied PM4X8
screws.
Figure 2-9 Fix the Dome Drive
3. Connect the power cable, network cable, and the alarm/audio
cables.
4. Align the front cover to the dome drive and tighten the set
screws on the front cover.

Installation & Quick Setup Guide
19
19
Figure 2-10 Install the Front Cover
5. Tear off the protection film softly to complete the installation.
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your hands.
2.4 Pendent Mounting
Steps:
1. Install the bracket to the ceiling with the supplied screws in the
bracket package.
You need to purchases a pendant bracket separately if pendent
mounting is adopted.
