Norton Clipper C13PE User manual

OWNERS
MANUAL
Small Concrete Saw
Models:
C13PE and C14PE
FORM: C13PE rev 3-2013

2
WARRANTY
Norton warrants all products manufactured by it against defects in
workmanship or materials for a period of one (1) year from the date of
shipment to the customer.
The responsibility of Norton under this warranty is limited to
replacement or repair of defective parts at Norton's Gainesville,
Georgia factory, or at a point designated by it, of such part as shall
appear to us upon inspection at such point, to have been defective in
material or workmanship, with expense for transportation borne by the
customer.
In no event shall Norton be liable for consequential or incidental
damages arising out of the failure of any product to operate properly.
Integral units such as gasoline engines, electric motors,batteries,
tires, transmissions, etc., are excluded from this warranty and are
subject to the prime manufacturer's warranty.
This warranty is in lieu of all other warranties, expressed or implied,
and all such other warranties are hereby disclaimed.
Important: Before placing equipment in operation, record the following
information.
MODEL:_________ SERIAL NO.___________
PURCHASE FROM: _____________________
ADDRESS: ____________________________
CITY_______ STATE ______ ZIP ________
TELEPHONE NO. ______________________
Before using this equipment, make sure that any person using it
reads and understands the instructions in this owner’s manual.

3
Table of Contents
CONTENTS PAGE
I. Preparation
A. Safety Precautions 4-6
B. Assembly 7
C. C13PE/C14PE Series Concrete Saw Specifications 8
D. Engine Precautions 9
E. Pointer Alignment 9
II. Operation
A. Blade Installation 9-10
B. Starting The Engine 10-13
C13PE 13HP Honda 10-12
C14PE 14HP Subaru 12-13
C. Water Supply 13
D. Operating The Saw 13-14
E. Cutting Technique 14-16
III. Maintenance
A. Engine 16-18
B. Wiring Diagram 19-20
C13PE 13HP Honda 19
C14PE 14HP Subaru 20
C. Bearings 21
D. V-Belts 22-25
E. Depth Control 26
F. Inspection and Cleaning 26
IV. Parts List Section
A. Ordering Information 27
B. Parts Drawing and Service Parts List 28-35
Depth Control And Depth Lock Group 28-29
Blade Guard and water Control Group 30
Engine Group 31
Blade Shaft Group 32
Raise Axle Group 33
Main Frame and Belt Guard Group 34
Front Pointer Group 35
Read Owners Manual Before Use
Safety Alert Symbol: Information Following This Symbol Is
Very Important.
Use Only Norton Diamond Blades

4
I. PREPARATION
A. Safety Precautions
Important! The following safety precautions must always be observed.
Hazard Symbols
Fuel (gasoline) is extremely flammable and its vapors can
explode if ignited. Store gasoline only in approved containers,
in well-ventilated, unoccupied approved areas, and away from
sparks or flames. Do not fill the fuel tank while the engine is hot
or running. Do not start the engine near spilled fuel. Never use
the fuel as a cleaning agent
Engine components can get extremely hot from operation. To
prevent burns, do not touch the engine or related parts while the
engine is running or immediately after it is turned off. Never
operate the engine with any heat shields or guards removed.
Keep all guards in place when operating any piece of equipment
Keep hands, feet, hair, and clothing away from all rotating parts
Lethal Exhaust Gas: use only in well ventilated areas. Engine
exhaust gases contain poisonous carbon monoxide, which is
odorless, colorless, and can cause death if inhaled. Avoid
inhaling exhaust fumes, and never run the engine in a closed
building or confined area.
Never tamper with the governor components of settings to
increase the maximum speed. Severe personal injury and
damage to the engine or equipment can result if operated at
speed above maximum. Always obey the maximum speed
rating of blade.
DO NOT LIFT THE SAW BY THE HANDLE
BARS

5
Dust and Silica Warning
Grinding/cutting/drilling of masonry, concrete, metal and other materials can
generate dust, mists and fumes containing chemicals known to cause serious or
fatal injury or illness, such as respiratory disease, cancer, birth defects or other
reproductive harm. If you are unfamiliar with the risks associated with the
particular process and/or material being cut or the composition of the tool being
used, review the material safety data sheet and/or consult your employer, the
material manufacturer/supplier, governmental agencies such as OSHA and
NIOSH and other sources on hazardous materials and make certain to comply
with all product warnings and instructions for the safe and effective use of the
material being cut. California and some other authorities, for instance, have
published lists of substances known to cause cancer, reproductive toxicity, or
other harmful effects.
Control dust, mist and fumes at the source where possible. In this regard use
good work practices and follow the recommendations of the manufacturer/supplier,
OSHA/NIOSH, and occupational and trade associations. Water should be used
for dust suppression when wet cutting is feasible. When the hazards from
inhalation of dust, mists and fumes cannot be eliminated through engineering
controls such as vacuum and/or water mist, the operator and any bystanders
should always wear a respirator approved by NIOSH/MSHA for the material being
cut.
Use Approved:
Eye Protection Hearing
Protection Respiratory Protection Head Protection

6
1. Before mounting any blade on the saw, the blade should be inspected for
any damage which might have occurred during shipment, handling or
previous use.
2. The blade collars and arbors should be cleaned and examined for damage
before mounting the blade.
3. The blade must be properly fitted over the arbor with the drive pin on the
outside collar projecting through the drive pin hole on the blade and
inside collar.
4. The blade shaft nut, which is a left-hand thread nut, must be tightened
securely against the outside blade shaft collar.
5. The blade must be operated within the specified maximum operating
speed listed on the blade.
6. Turn water control valve to full to provide adequate coolant (4 to 6 gallons
per minute) for diamond blades and wet cutting abrasive blades.
Insufficient coolant could result in severe blade breakage or diamond
segment separation.
7. The blade guard must be in place with the nose guard down and locked
when the saw is running.
8. The operator should wear safety glasses and any other appropriate safety
equipment.
9. When starting the saw, the operator should stand away and to the side of
the blade.
10.If for any reason the saw should stall in the cut, raise the blade out of the
cut. Check the outside blade shaft collar and nut for tightness. Inspect
the blade for damage before restarting the saw. Use caution when
resuming a cut. Be certain that the blade is in alignment with the previous
cut.
11.During cutting operations do not exert excess side pressure on the
handles as a method of steering. Do not force the blade into the cut by
lowering the blade too fast or by pushing the saw too fast.
You Are Responsible For Your Safety!!!

7
I. PREPARATION
B. Assembly
The C13PE compact concrete saw is shipped completely assembled and ready
for use except for diamond blade, gasoline, and oil. Inspect the saw for
shipping damage. If any damage is found, contact the shipper immediately
and file a freight claim. Norton Clipper is not responsible for any freight-related
damages.
Remove the saw from the pallet. Inspect the machine for concealed shipping
damaged. Read and understand ALL instruction included in this manual.
Failure to understand and follow the instruction covered in this manual can
result in injury or damage to the machine. Level the cutting frame and check
the engine oil level and add if required (See Engine Manual) and add fuel (See
Engine Manual).
Front Pointer
Assembly
Handle Bar
Lifting Bale
Depth Adjustment
Hand Wheel
Front Pointer Rod
Garden Hose Swivel
and Water Flow
Control Valve
Belt Guard
Blade Guard
Emergency
Stop Switch
Engine ON/OFF
Switch
Engine Choke,
Fuel Shut Off, and
Throttle Controls
Engine Air Cleaner

8
C. C13PE Series Concrete Saw Specifications
C13PE C14PE
Dimensions/Weight
Length (Working) 63" (1,600mm) 63" (1,600mm)
Length (Transport) 42-3/4" (1,086mm) 42-3/4" (1,086mm)
Width 21-27/64" (544mm) 21-27/64" (544mm)
Height 38-13/16" (986mm) 38-13/16" (986mm)
Weight 220 lbs (100 kg) 220 lbs (100 kg)
Engine
Engine Mfg. Honda Subaru
Model GX390 EX40
Spec No. GX390UT2QXC9 EX400D50140
Engine Type Single Cylinder 4 Cycle Single Cylinder 4 Cycle
Horse Power - Gross 13 hp* (9.5kW) @ 3,600 rpm 14 hp* (9.5kW) @ 3,600 rpm
Max Torque – Gross 19.5 ft-lbs (26.5 Nm, 2.7 kg-m)
@ 2,500 rpm 19.91 ft-lbs (27 Nm, 2.75 kg-m) @ 2,400 rpm
Cooling System Air Air
Oil Capacity 1.16 US qt (1.1 liter) 1 US qt (1.2 liter)
Fuel Capacity 1.79 US gal (6.5 liter) 1.85 US gal (7.0 liter)
Fuel Type Unleaded Gasoline (86 pump
octane) Unleaded Gasoline (86 pump octane)
Low Oil Sensor Yes Yes
Air Filtration Three Stage Cyclone Three Stage Cyclone
Characteristics
Max Blade 18” (450 mm) 18” (450 mm)
Depth of Cut 18” (406 mm) 6.75” (172 mm) 6.75” (172 mm)
16” (406 mm) 5.75” (146 mm) 5.75” (146 mm)
14” (356 mm) 4.75” (121 mm) 4.75” (121 mm)
12” (305 mm) 3.75” (95 mm) 3.75” (95 mm)
Arbor Bore 1” (25.4 mm) 1” (25.4 mm)
Blade Shaft Locking Device Machined Into Flats Of Tight Collar Machined Into Flats Of Tight Collar
Blade Shaft Speed 2,700 rpm 2,700 rpm
Depth Control Hand Wheel With Screw Feed Hand Wheel With Screw Feed
Depth Lock Standard Standard
Depth Gauge Customer Installed Accessory Customer Installed Accessory
Number Of Belts Three (3) 3VX300 Belts Three (3) 3VX300 Belts
Blade Guard Type Hinged, All Steel Construction Hinged, All Steel Construction
Side of Cut Right Right
Lifting Bale Yes Yes
Water Hose Connector Standard Garden Hose With Flow
Control Valve Standard Garden Hose With Flow Control Valve
Recessed Rear Wheels Standard Standard
* = Horse power and Torque ratings are Gross Horse power and are supplied by the engine manufacturer. Actual output of the engine will vary due to many
factors including operational speed of engine, environmental conditions, maintenance, fuel, and other variables. Saint-Gobain Abrasives, Inc. makes NO
claim to actual or gross horse power and torque ratings.

9
D. Engine Precautions
Prior to attempting to operate the engine, read the information
contained in the engine owner's manual. An engine owner’s manual is
supplied with every gasoline powered concrete saw.
1. Check Oil: Add oil if low. Refer to the engine owner's manual for the
recommended SAE viscosity grades. Capacity of oil is 1.16 US quarts (1.1
liters)
2. Check Fuel: Fill if low. Use only unleaded gasoline with a pump sticker
octane rating of 86 or higher is recommended. Never use an oil and
gasoline mixture!
3. Air Cleaner: Never run the engine without the air cleaner! Rapid engine
wear will result from contaminants being drawn through the carburetor and
into the engine.
4. Engine Starting: Refer to the engine owner's manual additional proper
engine starting procedure.
E. Pointer Alignment
1. Use a straight edge, and carefully mark a line 12 feet long on a smooth level
surface.
2. Place the saw blade on the marked line, move the saw to the center of the
marked line and then lower the blade until it is about 1/16” above the
marked line
3. Measure from each end of the saw frame to insure that the frame is parallel
to the marked line. Adjust the saw as needed.
4. With the blade centered on the marked line and the saw frame parallel to
the marked line, lower the front pointer.
5. Adjust the pointer by bending it until is aligned with the marked line.
II. OPERATION
A. Blade Installation
1. Disconnect the spark plug.
2. Remove the blade shaft nut, (Turn clockwise),and remove the outside
collar.

10
3. Clean off any foreign particles on the clamping surfaces of both collars
and on the mounting surface of the blade.
4. Place the blade on the blade shaft, lining up the drive pin hole in the
blade with the drive pinhole in the inside collar.
For Best Performance Use Only Norton Diamond Blades
Specified For the Material Being Cut.
5. Slide the outside blade shaft collar onto the blade shaft. The drive pin
on the outside collar must project through the drive pin hole in the blade
and into the inside collar.
6. Tighten the blade shaft nut (counter-clockwise) securely against the
outside collar.
7. Reconnect the spark plug.
B. Starting the Engine
C13PE 13HP Honda
1. Refer to the engine owner's manual for detail starting procedures.
2. Always cut with engine rpm in the full throttle setting.
Before starting, insure that the blade is properly installed,
all guards are in place and in safe operating condition, and
that the Blade is not in contact with any surface or object.
Also verify that the area where the work is to be preformed
is clean, safe, and has proper ventilation and lighting.
Always located and properly mark all water, gas, and
electrical services before beginning any work.
Turn the Fuel Control To the ON Position
Move the choke lever to the CLOSED position.
NOTE: The Choke may not be needed if the engine
is warm or the air temperature is high.

11
Move the Engine Throttle Slightly to the Left
Place the engine ON/OFF switch to the ON position
and NOTE: The Engine ON/OFF Switch is located
on the front of the Engine.
Pull The Emergency Stop Switch to the UP Position.
NOTE: The Emergency Stop Switch is located on
the machine’s Console.
Pull the starter grip lightly until you feel resistance,
then pull briskly. CAUTION: Do not allow the starter
grip to snap back against the engine. Return it gently
to prevent damage to the starter.
As the engine warms up, gradually move the choke
lever to the OPEN position (fully to the right)
Position the throttle control lever for the maximum
engine speed (fully to the Left).
To stop the engine, move the Throttle Control Lever fully to the Forward
Position (fully to the right), press the Emergency Stop Switch (Down Position),
and then turn the engine switch to the OFF position. Turn the fuel valve to the
OFF position.
ON/OFF
Switch

12
Never transport the machine with the Fuel Valve in the ON
position. Never Store the machine with the Fuel Valve in the
ON position. Never Transport a machine with the blade
installed.
C14PE 14HP Subaru
1. Refer to the engine owner's manual for detail starting procedures.
2. Always cut with engine rpm in the full throttle setting.
Before starting, insure that the blade is properly installed,
all guards are in place and in safe operating condition, and
that the Blade is not in contact with any surface or object.
Also verify that the area where the work is to be performed
is clean, safe, and has proper ventilation and lighting.
Always located and properly mark all water, gas, and
electrical services before beginning any work.
Turn the Fuel Control To the ON Position
Move the choke lever to the CLOSED position.
NOTE: The Choke may not be needed if the engine
is warm or the air temperature is high.
Move the Engine Throttle to 1/3 the way to the high
position.
Place the engine ON/OFF switch to the ON position
and NOTE: The Engine ON/OFF Switch is located
on the front of the Engine.
ON/OFF
Switch

13
Pull The Emergency Stop Switch to the UP Position.
NOTE: The Emergency Stop Switch is located on
the machine’s Console.
Pull the starter grip lightly until you feel resistance,
then pull briskly. CAUTION: Do not allow the starter
grip to snap back against the engine. Return it gently
to prevent damage to the starter.
As the engine warms up, gradually move the choke
lever to the OPEN position (fully to the right)
Position the throttle control lever for the maximum
engine speed (fully to the Left).
To stop the engine, move the Throttle Control Lever fully to the Forward
Position (fully to the right), press the Emergency Stop Switch (Down Position),
and then turn the engine switch to the OFF position. Turn the fuel valve to the
OFF position.
Never transport the machine with the Fuel Valve in the ON
position. Never Store the machine with the Fuel Valve in the
ON position. Never Transport a machine with the blade
installed.
C. Water Supply
Pressurized source: Turn the water control to full "ON" when using wet
cutting blades. The required flow rate is 4-6 gallons per minute.
D. Operating the Saw
1. For blade installation instructions see section II. Operation sub heading
A. Installing the Blade. For the engine starting instructions, see the

14
Engine manual and follow the instructions located in section II. Operation
sub heading B. Starting the Engine.
2. Check the Engine Oil level. See Engine Manual for details.
3. Raise the saw to the full upright position. Do not let the blade come in
contact with the ground.
4. Maneuver the saw to the desired starting point.
5. If wet cutting, connect the water supply to the saw.
6. Follow the instructions for starting the engine found in the Engine manual.
7. If wet cutting, turn on the water supply at the source and then open the
water valves on the saw. Make sure that there is a minimum of 4-6 gallons
per minute of water flow!!
8. Be sure the engine is running at full throttle!!!
9. Slowly lower the blade by rotating the hand wheel clockwise until the
desired depth of cut is reached. Use a reasonable rate of feed. Do not
force the blade into the cut!!
10. When the end of the cut is reached, slowly raise the blade out of the cut by
rotating the Hand Wheel counter-clockwise until the blade is at least one
(1) inch above the ground.
11. Only move the saw in reverse with the blade in the raised position.
13. When moving the saw to a new location, be sure the blade is not touching
the ground. Always pay close attention to where you are moving and
where the blade is at all times.
E. Cutting Technique
Lower the blade into the concrete to the required depth by turning the hand
wheel clockwise.
Reduce the forward pressure if the saw begins to stall.
Note: For deeper cuts (4 inches or more), several cuts should be made in
incremental steps of 1-1/2 to 2 inches until the desired depth of cut is reached.
Push the saw steadily forward using the front pointer as a guide. Exert enough
forward pressure so that the engine begins to labor, but does not slow down. If
the saw begins to stall, reduce the forward movement until full rpm is restored
to the blade. If the saw stalls, raise the blade out of the cut before restarting.
Avoid excessive side pressure or twisting of the blade in the cut.
Additional Guide Lines For Sawing:

15
Understand and follow all of the instructions in this owner’s manual.
If wet cutting, turn on the water supply so that there is a minimum of 4-6
gallons per minute of water flow!!
In critically hard aggregate, more than a single pass may be needed to cut
the desired depth.
If the saw stalls in the cut, immediately stop the forward speed and raise the
blade out of the cut. If this is not done the belts can fail or the blade may be
damaged.
Go slowly with a new blade until it opens up, that is, until the diamonds can
be seen and felt.
III. MAINTENANCE
A. Engine
Follow the below schedule for engine maintenance. NOTE: Check the Honda
Engine manual that came with the engine for any changes to the maintenance
schedule. If the charts have any differences, follow the chart in the Honda
Engine Manual. Norton does not warranty the engine. If any warranty or
service of the engine is required contact your nearest Honda service center, or
from the Internet: http://engines.honda.com/dealer-locator
Honda engine (refer to owner's manual for complete maintenance.)
Honda Engine Maintenance Schedule

16
Subaru Engine Maintenance Schedule
Check the engine oil level before each use when the engine is cool and the
engine is level. Add oil if the level is low. The oil level should be within the
operating range (see the engine owner’s manual for details).
Only use a high-detergent, premium quality motor oil certified to meet or
exceed U.S. automobile manufacturer’s requirements for Service Classification
SG, SF/CC, or CD. Motor oils will show the classification on the container. A
SAE viscosity of 10W-30 is recommend by Honda for general, all temperature
use. Please consult the below chart or contact your local Honda service center
for the proper viscosity for your temperature range.

17
Always refer to the engine manual for more detailed information on checking
the oil, changing oil, and oil capacity, air filter changes, and fuel type to use.
Use only Honda air filters. Do not clean the air filter with gasoline or other
flammable solvents. A fire or explosion could result. To clean, follow the
instructions found in the Honda engine manual.
Dry Cutting Engine Maintenance
When operating the engine in dry cutting or dusty environments the
following is required:
Engine oil changed more often.
Every 50 hours (or more often if conditions require) clean all of the engine
cooling fins.
Every 25 hours (or more often if conditions require) clean the engine pre-
cleaner.
Every 100 hours (or more often if conditions require) replace the air filter. If
the engine is equipped with a reusable air cleaner, clean and re-oil it.
Check and clean the air filter after each use. Replace as needed.

18
B. Wiring Diagram
C13PE 13HP Honda

19
C14PE 14HP Subaru

20
C. Bearings
Re lubrication type bearings must be re-lubricated weekly to assure long
life. The grease used should conform to the NLGI grade two and be free of
any chemical impurities such as free acid or free alkali, dust, rust, metal
particles or abrasives.
For best results, bearings should be re-lubricated while in operation. Note:
Due caution for personal safety must be observed when servicing
rotating equipment. The grease should be pumped in slowly until a slight
bead forms around the seals. This bead, in addition to acting as an
indicator of adequate re-lubrication, provides additional protection against
the entry of foreign matter. If necessary to re-lubricate while the bearing is
idle refer to re-lubrication table for maximum grease capacity for the various
size bearings.
Shaft Size Maximum Grease Capacity of
Bearing Chamber in Ounces
1/2"' to 3/4" 1/8
7/8" to 1-3/16" 3/8
1-1/4" to 1-1/2" 5/8
Improper Maintenance Of Bearings Is Not Covered By Any
Warranty. Over Lubrication Will Damage A Bearing. Grease
Protruding From The Sides Of The Bearing Is A Sign Of
Over Lubrication. Not Lubricating Bearings Will Damage
The Bearing Unit. Damage Caused By Over or Under
Lubricating Bearings Is Not Covered By Any Warranty.
D. V-Belts
Warning: Never make adjustments to belts or pulleys while
engine is running!
The best tension for a belt drive is the lowest tension at which the belts will not
slip under full load.
To adjust the C13PE Belt Tension:
The C13PE uses a simple single point tensioning system for the belt tensioning.
The Belt Tensioning Assembly can be found behind the engine and is located
near the Operator’s Left Side Rear Engine Mounting Bolt. The Belt Tensioning
Device is designed to pull or push the engine from the center which helps to
reduce the Engine from twisting during the Belt Tensioning process. This new
system is designed to be simple to install and to maintain with the tools
equipped with the machine.
