CS1 P13
OPERATING INSTRUCTIONS
1Basic Safety Instructions 6
1.1 Symbols 6
1.2 Machine plate 7
1.3 Safety instructions for particular operating phases 7
2General description of the CS1 8
2.1 Short description 8
2.2 Layout 8
2.3 Technical data 9
3Assembly and commissioning 10
3.1 Tool assembly 10
3.2 Water cooling system 10
3.3 Starting the machine 11
4Transport and Storing 12
4.1 Securing for transport 12
4.2 Transport procedure 12
4.3 Long period of inactivity 12
5Operating the CS1 13
5.1 Site of work 13
5.2 Cutting method 13
6Maintenance and service 14
6.1 Maintenance of the machine 14
6.2 Maintenance of the engine 15
7Faults: causes and cures 18
7.1 Fault-finding procedures 18
7.2 Trouble-shooting guide 18
7.3 Customer service 18

6
1 Basic Safety Instructions
The CS1 is exclusively designed for the cutting of floors made of asphalt, green and cured
concrete (reinforced or not) as well as of industrial cement.
Uses other than the manufacturer's instructions shall be considered as contravening the
regulations. The manufacturer shall not be held responsible for any resulting damage. Any risk
shall be borne entirely by the user. Observing the operating instructions and compliance with
inspection and servicing requirements shall also be considered as included under use in
accordance with the regulations.
1.1 Symbols
Important warnings and pieces of advice are indicated on the machine using symbols. The
following symbols are used on the machine:
Read operator’s instructions Ear protection shall be worn
Rotation direction of the blade Never move the machine with the blade
running idle.
Emergency Stop Rotation direction of the blade
Danger: risk of cut

7
1.2 Machine plate
Important data can be found on the following plate located on the machine:
1.3 Safety instructions for particular operating phases
Before commencing work
•Before commencing work, make yourself familiar with the working environment at the place
of use. The working environment includes: obstacles in the area of work and manoeuvre,
the firmness of the floor, necessary protection at the site relating to public thoroughfares and
the availability of help in the event of accidents.
•Check for correct mounting of the blade regularly.
•Immediately remove damaged or badly worn blades, as they endanger the operator whilst
rotating.
•Always cut with the blade guard in position.
•Only fit NORTON diamond blades to the machine! The use of other tools can damage the
machine!
•Attention is drawn to the use of BS2092 safety goggles in conformity with specified
Processes No.8 of the Protection of Eyes Regulation 1974, Regulation 2(2) Part 1.
•For security reasons, never leave the machine unattended, untied or unlocked.
While the engine is running
•Do not move the machine whilst the blade is running idle.
•Do not run the machine without the security guards in place.
•Apply cooling water continuously whilst cutting and in good time!
Diesel powered machines:
•Always use the fuel advised.
•In confined areas, exhaust gases should be evacuated and the job site properly aerated.
•Diesel machines, which by their nature emit toxic exhaust gases, must not be used in places
prohibited by the Health at Work Act 1974 or which are prohibited by Factory Inspectors or
Safety Officers.
•Diesel is flammable. Before filling the tank, shut down the engine, extinguish all open flames
and do not smoke. Take care that no diesel is spilled on any motor part. Always wipe up
spilled fuel.
Machine type Serial number Power Safety standard Blade speed
Machine Model Machine Code Bore diameter
Max. blade diameter
Year of productionWeight

8
2 General description of the CS1
Any modification, which could lead to a change in the original characteristics of the machine,
may be done only by Saint-Gobain Abrasives S.A. who shall confirm that the machine is still in
conformity with the safety regulations. Saint-Gobain Abrasives S.A. keeps the right of making
technical or design modification without prior notification.
2.1 Short description
The Floor Saw CS1 you have chosen,is used for small repair works in concrete and asphalt,
for cutting induction loops and installing cables as well as for cutting expansion joints. It can be
used for either wet or dry cutting operations. Being of small construction, it can be transported in
a car or van. The water container is enclosed in the frame. All component parts on the CS1 are
assembled to a high quality standard, ensuring long life, reliability and a minimum of
maintenance. Special types of blades are available for asphalt, green concrete, cured concrete
(reinforced or not) as well as for industrial cement flooring.
2.2 Layout
Made of jig welded open profile steel, the CS1 is stable but at the same time, easily
transportable.
The one-piece blade guard (1) fully protects the operator and his working environment. It is
firmly fixed to the main frame but can be opened by rotation to change blades.
A manually operated hand wheel mechanism (2) enables graduated depth setting. Turning the
hand wheel clockwise or anti-clockwise will lower or raise the cutting blade.

9
The pivoting frame (3), hinged on the rear axle, is supporting the engine, the blade shaft
assembly, and the protecting guards. Four heavy-duty belts drive the blade.
The precisely manufactured blade shaft is fitted into two heavy-duty self-aligning pillow block
bearings, including grease nipples. A four-belt taper lock pulley is fitted on one end. The shaft is
reduced to 25,4mm at the other end, allowing an inner flange complete with dowel pinholes to
be fixed.
The steel belt guard (4) is bolted to the mainframe of the machine. It is covering the four drive
belts and pulleys for protection of the environment while the machine is running. The pointer (5)
allows the operator to make precise cut easily.
The Honda GX390 engine (6) is connected to an emergency shut down switch (7) on the board
of the machine. This allows an immediate stop of the machine in case of danger. The water
cooling system (8) is composed of a 70 litres water tank, a water tank tap and two water nozzles
on the blade guard ensuring adequate flow of water to both sides of the blade.
2.3 Technical data
Engine Honda GX390, 4 strokes, 1 cylinder, 13HP (9,6kW)
Fuel
Automotive unleaded gasoline
Oil
Honda 4-Stroke, or equivalent high detergent, premium quality
motor oil certified to meet or exceed U.S. automobile
manufacturer’s requirement for service classification SG, SF. (SG,
SF designated on the oil container).
SAE 10W-30 recommended
Starter Manual pull chord
Air filter Dual type (machine type 99277, 99556, 99557, and 99558)
Cyclone type (machine type 99939)
Max. blade diameter 500 mm
Bore 25,4 mm
Max. cutting depth mm 190 mm
Flange diameter 115 mm
Blade shaft speed 2600 min
-1
Driving belts 4
Water tank 70 l
Machine dimensions
(length x width x height) 1088x580x925mm
Weight 140 kg
Max. operating weight 220 kg
Sound pressure level 89 dB (A) following ISO EN 11201
Sound energy level 105 dB (A) following ISO EN 3744

10
3 Assembly and commissioning
Before beginning the work with the CS1, you have to assemble some parts.
3.1 Tool assembly
Only use NORTON blades with the CS1.
A blade with a maximum diameter of 500 mm can be fitted. All tools used must be selected with
regard to their maximum permitted cutting speed for the machine’s maximum permitted rotation
speed.
Before mounting a new blade, switch the machine off.
To mount a new blade, follow these steps:
•Turn the wheel until the cutting head is in the raised position.
•Loosen the screw maintaining the blade guard with the 19mm wrench, and turn it open.
•Loosen the hexagonal nut, which holds the removable outer flange with the 36mm wrench.
•Remove the outer flange.
•Clean the flanges and blade shaft and inspect for wear.
•Mount the blade on the shaft ensuring that direction of rotation is correct. Wrong direction of
rotation blunts the blade quickly.
•Replace outer blade flange.
•Tighten hexagonal nut with spanner supplied for this purpose.
•Close the blade guard.
The blade bore must correspond exactly to the blade shaft. Cracked or damaged bore is
dangerous for the operator and for the machine.
3.2 Water cooling system
Fill the water tank with clean water.
Open water-tap (note that handle on water-tap should be in line with water-flow).
Ensure that water is flowing freely in the circuit and delivered adequately to both sides of the
blade, as insufficient water supply may result in premature failure of the diamond blade.
In case of frost, empty the water cooling system.

11
3.3 Starting the machine
Make sure the blade is raised clear up the ground before starting the machine.
Turn the fuel valve to the ON position. Move the choke lever to the CLOSED position.
NOTE: do not use the choke if the engine is
warm or the air temperature is high.
Move the throttle control lever slightly to the
left. Put the engine switch on ON, and make sure the emergency switch on the board of the
machine is in the correct position.
Pull the starter grip lightly until you feel
resistance, then pull briskly.
CAUTION: Do not allow the starter grip to snap
back against the engine. Return it gently to
prevent damage to the starter.
As the engine warms up, gradually move the
choke lever to the OPEN position.
Position the throttle control lever for the
maximum engine speed.
To stop the engine, move the throttle control lever fully to the right, then turn the engine switch
to the OFF position. Turn the fuel valve to the OFF position.

12
4 Transport and Storing
Take the following measures in order to transport and store the CS1 securely.
4.1 Securing for transport
Before transporting the machine:
•Remove the blade.
•Empty the water tank.
•Raise the guide-a-cut in its upright position.
•Raise the cutting frame to its highest position using the handwheel.
4.2 Transport procedure
The machine can be moved on a flat surface using its wheels. Use the metal hook located on
the board of the machine over the motor to move the machine with a crane.
4.3 Long period of inactivity
If the machine is not going to be used for a long period, please take the following measures:
•Completely clean the machine.
•Loosen the drive belts.
•Grease the threaded shaft.
•Possibly change the motor oil.
•Empty the water system.
The storage site must be clean, dry and at a constant temperature.

13
5 Operating the CS1
5.1 Site of work
Before you start working, please check the following points:
•Remove from the site anything, which might hinder the working procedure.
•Make sure the site is sufficiently well lit.
•Make sure you have a continual adequate view of the working area so you can intervene in
the working process at any time.
•Keep other staff out of the area, so you can work securely.
5.2 Cutting method
In this section, you can find instructions to make a straight cut at the desired depth.
5.2.1 Preparing your cut
Before starting the machine,
•Draw a line on the floor over the cutting length.
•Make sure you have filled the engine tank with fuel, and the water tank with water. No petrol
is supplied with the machine.
•The engine is shipped with oil. Check oil level before starting. Top up if required.
•Make sure you have mounted the correct blade as recommended by the manufacturer
depending on the material to be worked, the working procedure (dry or wet cut) to be carried
out, and the efficiency required.
•Make sure that the flanges securely hold the diamond blade.
•Make sure that the blade is not touching the floor before starting.
•Roll the machine until the blade is over the line.
•Lower the guide-a-cut so it touches the line.
5.2.2 Cutting the floor
You can now start the engine.
To make your cut,
•Turn the depth hand wheel until the blade slightly touches the floor.
•Open water valve to control the amount of water required for the type of blade, using 15 to
25l/min for wet and 1-2l/min for dry cutting, dust control. Check for minimum water level
regularly.
•turn the hand wheel to lower blade into the cut.
•Once the required depth of cut is reached, push the machine forward with steady and gentle
pressure and follow the line with the pointer. The feed speed must be adjusted depending
on the material being cut, and depth of cut.
•At the finish of the cut, raise the blade out of the cut by turning the hand wheel, switch off
the engine and shut-off the water.

14
6 Maintenance and service
ATTENTION : to perform maintenance on the machine, always switch it off. Always wear a face
mask and safety goggles while performing the maintenance of machine.
6.1 Maintenance of the machine
To ensure a long-term quality from the cutting with the CS1, please follow the maintenance plan
below:
Regular service period
Perform at every indicated period



After one hour of work
Begin of the day During the changing of the tool End of the day Every week After a fault After a damage
Visual control (general aspect,
watertightness) Whole machine Clean
Flange and blade fixing devices Clean
Belts tension Control
Water hoses and nozzles Clean
Depth screw Grease
Engine housing Clean
Reachable nuts and screws Tighten up
Adjustment and replacement of the belts
After one hour of work, the belts heat and stretch. Therefore, you have to re-tension them.
To adjust the belts, firstly remove the belt guard by unscrewing the 2 nuts. Loose the 2 bolts at
the back of the engine-plate and shift the engine by using the screw on the back of the plate to
retighten the belts.
To replace the belts, move the engine completely down by unscrewing the screw at the back of
the engine-plate. Adjust the belts and retighten them using the screw at the back of the engine
plate.
Always use a matched set of belts. Do not replace single belts. After controlling or retightening
the belts, reassemble the belt guard on the frame of the machine.
Lubrication
The CS1 uses life-lubricated bearings. Therefore, you don’t need to lubricate them at all.
Grease the depth screw every day.
Cleaning of the machine
Your machine will last longer if you clean it thoroughly after each day of work.

15
6.2 Maintenance of the engine
Regular service period
Perform at every indicated month or
operating hour interval, whichever comes
first



Each use First month or 20 hours Every 3 months or 50 hours Every 6 months or 100 hours
Check level
Engine oil Change
Check
Air cleaner filter Clean
Fuel strainer cup Clean
Spark plug Check-Clean
Fuel line Check (Replace if necessary) Every 2 years
Engine oil
To change the oil,
•Remove the oil filler cap/dipstick and
drain bolt.
•Allow the oil to drain completely.
•Dispose of used motor oil in a manner
that is compatible with the
environment. We suggest you to take
used oil in a sealed container to your
local recycling centre or service station
for reclamation. Do not throw it in the
trash, pour it on the ground or down in
a drain.
•Reinstall the drain bolt, and tighten it
to 18 N.m.
•Fill the crankcase with the engine oil to
the outer edge of the oil filler neck.
•Reinstall the filler cap/dipstick.

16
Air cleaner
The CS1 has a dual type filter.
To service the air cleaner filter, follow
these instructions:
•Remove the nut, air cleaner cover and
wing nut.
•Remove the pre air cleaner elements
and separate them.
•Carefully check both elements for
holes or tears and replace if damaged.
•Paper element: tap element lightly
several times on a hard surface to
remove excess dirt or blow
compressed air lightly through the filter
from the inside out. Never brush the
dirt off; brushing will force dirt into the
fibres.
•Foam element: clean in warm soapy
water, rinse and allow to dry
thoroughly. Dip the element in clean
engine oil and squeeze out all the
excess. The engine will smoke during
initial start-up if too much oil is left in
the foam.
•Shine a light through the elements,
and inspect them carefully. Reinstall
the elements if they are free of holes
and tears.
Fuel strainer cup
To service fuel strainer cup, follow these
instructions:
•Turn off the fuel valve and remove the
strainer cup.
•Clean the strainer cup with solvent.
•Install the O-ring and strainer cup.
•Tighten the strainer cup to 4N.m.

17
Spark plug
To service the spark plug, follow these
instructions:
•Visually inspect the spark plug.
Discard the plug if the insulator is
cracked or chipped.
•Remove carbon or other deposits with
a stiff wire brush.
•Measure the plug gap with a wire-type
feeler gauge. If necessary, adjust the
gap by bending the side electrode.
•Make sure the sealing washer is in
good condition; replace the plug if
necessary.
•Install the plug fingertight to seat the washer, then tighten with a plug wrench (an additional
½ turn if a new plug) to compress the sealing washer. If you are reusing a plug, tighten 1/8-
1/4 turn after the plug seats.
Fuel line
To service the fuel line, follow these
instructions:
•Drain the fuel into a suitable container,
and remove the fuel tank.
•Disconnect the fuel line, and unscrew
the fuel filter from the tank.
•Clean the filter with solvent, and
check, that the filter screen is
undamaged.
•Place the O-ring on the filter and
reinstall. Tighten the filter to 2N.m.
After reassembly, check for fuel leaks.
Further maintenance
For further maintenance, please contact the nearest engine maintenance centre.

18
7 Faults: causes and cures
7.1 Fault-finding procedures
Should any fault occur during the use of the machine, turn it off. Let only qualified staff make
any intervention other than the one described in the previous section.
7.2 Trouble-shooting guide
Trouble Possible source Resolution
Not enough fuel Fill fuel tank
Fuel filter clogged Clean fuel filter
Spark plug faulty Inspect spark plug
Hard starting
Stronger fault Contact nearest engine
maintenance centre
Air filter restricted Clean or replace air filterEngine lacks power Stronger fault Contact nearest engine
maintenance centre
7.3 Customer service
When ordering spare parts, please mention:
•The serial number (7 digits).
•The code of the part.
•The exact denomination.
•The number of parts required.
•The delivery address.
•Please indicate clearly the means of transportation required such as "express" or "by
air". Without specific instructions, we will forward the parts through the means which
seem appropriate to us and but which is not always the quickest way.
Clear instructions will avoid problems and faulty deliveries.
If not sure, please send us the defective part.
In the case of a warranty is claim, the part must always be returned for evaluation.
Spare parts for the engine can be ordered with the manufacturer of the engine or with their
dealer, which is often quicker and cheaper.
This machine has been manufactured by Saint-Gobain Abrasives S.A.
190, Bd. J.F.Kennedy
L- 4930 BASCHARAGE
Grand-Duché de Luxembourg.
Tel. : [phone]
Fax : [phone]
http://www.construction.norton.eu

19
Guarantee can be claimed and technical support obtained from your local distributor where
machines, spare parts and consumables can be ordered as well:
Benelux and France:
From Saint-Gobain Abrasives
in the Grand-Duché de Luxembourg
Free telephone numbers:
Belgium : 0 800 18951
France: 0 800 90 69 03
Holland: 0 8000 22 02 70
e-mail: [e-mail]
Germany
Saint-Gobain Diamond Products GmbH
Birkenweg 45-49,
D-50389 WESSELING
Tel : [phone]
Fax : [phone]
e-mail: [e-mail]
Spain
Saint-Gobain Abrasivos S.A.
C/. Verneda del Congost s/n
Pol.Ind. El Pedregar
E-08160 MONTMELÓ (Barcelona)
Tel: [phone]
Fax: [phone]
e-mail: [email protected]m
Hungary
Saint-Gobain Abrasives KFT.
Banyaleg Utca 60B
H-1225 BUDAPEST
Tel: ++36 1 371 2250
Fax: ++36 1 371 2255
e-mail: [e-mail]
Czech Republic
Norton Diamantove Nastroje Sro
Vinohrdadska 184
CS-13000 PRAHA 3
Tel: [phone]
Fax: [phone]
e-mail: [e-mail]
United Kingdom
Saint-Gobain Abrasives Ltd.
Doxey Road
Stafford
ST16 1EA
Tel : [phone]
Free fax : [phone]
e-mail : [email protected]m
Italy
Saint-Gobain Abrasivi S.p.A.
Via per Cesano Boscone, 4
I-20094 CORSICO-MILANO
Tel: [phone]
Fax: [phone]
e-mail: Norton.ediliz[email protected]om
Austria
Saint-Gobain Abrasives GmbH
Telsenberggasse 37,
A-5020 SALZBURG
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Poland
Saint-Gobain Diamond Products Sp.zO.O.
AL. Krakowska 110/114
PL-00-971 WARSZAWA
Tel: [phone]
Tel/Fax: [phone]
e-mail: [e-mail]

20
SAINT-GOBAIN ABRASIVES
190, Bd. J. F. Kennedy
L-4930 BASCHARAGE
LUXEMBOURG
Tel.: ++352 50401-1
Fax: ++352 501633
e-mail: [e-mail]
www.construction.norton.eu
10.12.2008
