Nostalgia Electrics HSB-590 Quick guide

All products are trademarks of Nostalgia Products Group, LLC.
Worldwide design & utility patented or patents pending.
© 2011 Nostalgia Products Group, LLC.
www.nostalgiaelectrics.com
(rev. 10/14/11)

HSB590 SERIES
Stainless Steel Margarator
Instructions and Recipes

ENGLISH
2
CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . 3
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . 5
HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . . . 6
HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . 8
RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . . 12
SAFETY
Appliance Specifications:
120 Volts, 60 Hz
150 Watts, ETL Approved
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards
that can kill or hurt you and others.
All safety messages will follow the safety alert symbol.
All safety messages will tell you what the potential hazard
is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.

ENGLISH
3
IMPORTANT PRECAUTIONS
NEVER immerse the Base or cord in water.1.
NEVER use near water.2.
NEVER leave unit unattended if used near children.3.
NEVER use a scouring pad on the appliance.4.
NEVER use an abrasive sponge or harsh cleaning5.
products on or inside of the appliance.
NEVER use for anything other than what this item was originally intended.6.
Avoid contact with moving parts.7.
DO NOT operate this appliance with a damaged cord or plug,8.
or in the event the appliance ever malfunctions.
DO NOT place parts in dishwasher.9.
Keep out of reach of children.10.
Unplug appliance from electrical outlet when not in use and before11.
cleaning. Remove plug by gripping the plug body and pulling out
of the outlet. Never yank or twist cord to unplug the unit.
This appliance is NOT A TOY.12.
This appliance is not intended for use by young children or13.
cognitively challenged individuals without supervision.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including:
Read all instructions before operating this appliance.1.
NEVER put fingers or utensils into feed or discharge areas.2.
Keep hands and utensils out of container while blending to reduce3.
the risk of severe personal injury or damage to the appliance.
To protect against electrical shock do not immerse cord,4.
plug or main unit in water or other liquids.
Close supervision is necessary when any appliance is used by or near children.5.
Unplug from outlet when not in use and before removing parts for cleaning.6.
DO NOT operate any appliance with a damaged cord or plug or7.
if the appliance has been damaged in any manner. Return the
appliance to the nearest repair shop for examination or repair.
The manufacturer does not recommend the use of accessory8.
attachments. Use of attachments may cause injuries.
Blades are sharp. DO NOT touch.9.
DO NOT remove Lid when in use.10.

ENGLISH
4
DO NOT let the cord touch hot surfaces.11.
DO NOT place on or near a hot gas or electric burner, or in a heated oven.12.
Extreme caution must be used when moving this appliance with liquids inside.13.
This unit must be on a level surface to operate properly.14.
DO NOT use this appliance for other than its intended use.15.
DO NOT leave unit unattended while in use or when plugged into an outlet.16.
Check inside of the Blending Chamber for foreign objects prior to use.17.
A short power supply cord is provided to reduce the risk resulting18.
from becoming entangled or tripping over a long cord.
Extension cord can be used if care is exercised in use.19.
The marked electrical rating of an extension cord should be at20.
least as great as the electrical rating of the appliance.
This appliance has a polarized plug (one blade is wider than the other). To reduce the21.
risk of electrical shock, this plug is intended to fit into a polarized outlet only one way.
This appliance comes equipped with an AC electrical power cord. It is22.
versatile and can be used indoors or outdoors. DO NOT use near water.
Always operate the appliance with cover in place.23.
Make sure the Blending Chamber is properly attached24.
to the Base before turning on unit.
SAVE THESE INSTRUCTIONS!
INTRODUCTION
Thank you for purchasing the STAINLESS STEEL MARGARATOR™from
Nostalgia Electrics™! The STAINLESS STEEL MARGARATOR™is a frozen
drink machine that will add thirst-quenching fun to any occasion!
The STAINLESS STEEL MARGARATOR™uses crushed ice or small ice cubes
from your freezer. It not only makes fantastic margaritas, but can also mix up
batches of your other favorite frozen drinks such as daiquiris and slushes for
the kids! This machine is designed for kitchen or home bar use but can also be
used in places such as family rooms, dorm rooms, offices and club houses.
Features include:
Patented dual swivel system that pulverizes and shaves ice,•
dispensing consistently smooth frozen drinks
Insulated container ups to 128 ounces of your favorite frozen beverage•
Clear Blending Chamber detaches from Base for easy clean up•
Convenient Cord Storage•

ENGLISH
5
Blending Chamber
Base
Lid
Spout
Stainless Steel
Grinding Cage
Clear
Window
PARTS & ASSEMBLY
Cord Location
The cord storage is located at the base of the unit:
Attaching and Removing the Grinding Cage
It is very important that the Stainless Steel Grinding Cage is
assembled properly in order for the unit to work.
The Stainless Steel Grinding Cage is1.
attached to the inside of the Blending
Chamber with a round Plastic Collar.
Place the Stainless Steel Grinding2.
Cage with the smooth end
(opposite of end with three tabs)
into the Plastic Collar and twist
until the notch of the Stainless
Steel Grinding Cage locks into the
protrusion on the Plastic Collar.
Turn the assembled Stainless Steel Grinding Cage with Plastic Collar over, so3.
Plastic Collar is on the top to insert into the base of Blending Chamber.
Looking down into the interior of the Blending Chamber, you will
4.
Screws
Stainless Steel
Grinder
Plastic Collar

ENGLISH
6
see two stainless steel screws. This is where the clips attached
to the Plastic Collar lock the grinding mechanism down.
When putting the Plastic Collar into position, align5.
the Tabs with the indents in the base of the Blending
Chamber. With firm but gentle pressure, press the
Plastic Collar down until the Clips “click” into place.
Once everything is in place, make sure the Clips6.
are pushed inward toward the screws to lock the
unit into position and lift slightly to ensure the
Stainless Steel Grinding Cage is in fact locked
into position properly and will not release. Lock
and unlock Clips carefully to avoid breaking.
NOTE: IF THE PLASTIC COLLAR IS NOT LOCKED PROPERLY
THE UNIT WILL GRIND BUT WILL NOT DISPENSE.
Now you are ready to enjoy cold, refreshing margaritas and
drinks from your STAINLESS STEEL MARGARATOR™!
HOW TO OPERATE
Before first use, remove all packaging materials and detach Blending Chamber from1.
Base by sliding the three UNLOCK/LOCK switches to the UNLOCK position.
Pour warm, soapy water into the Blending Chamber and2.
dispense all of the soapy water through the Spout.
After dispensing all warm, soapy water, rinse by pouring clean water3.
into the Blending Chamber and dispense clean water through the Spout
until no soapy residue remains and water comes out clean.
Wipe down the STAINLESS STEEL MARGARATOR™ exterior with a clean,4.
non-abrasive cloth or sponge. Dry interior and exterior thoroughly with
dry, non-abrasive cloth or sponge. DO NOT put the Base in water.
After drying, firmly attach Blending Chamber to Base by placing the5.
Blending Chamber on top of Base so that Spout faces forward and
slide the three LOCK/UNLOCK switches to the LOCK position.
If Blending Chamber is attached properly, it will be aligned6.
with Base so that the Spout is over the Drip Tray.
Find a stable surface near an electrical outlet before starting. Make sure the cord is1.
away from any water source. It is acceptable to use an extension cord if needed.
DO NOT place the STAINLESS STEEL MARGARATOR™2.
near the edge of a table or countertop.
Fill the Blending Chamber with ice and ingredients to3.
the Max Fill line. DO NOT exceed the Max Fill line.
To make a batch of margaritas, fill Blending Chamber4.
with ice up to the Max Fill line and then pour three
parts concentrated mix (approximately 45 oz.) to 1 part
Tequila (approximately 15 oz.). For a slushier mix, less
liquid or more ice is recommended. It is NOT recommended that you use fruit.
Plastic Collar
Clips
Tabs

ENGLISH
7
Place Lid on unit and line up arrows on5.
Lid and Blending Chamber. This is a
safety feature and the unit will not turn on
without the Lid in the correct position.
You can add additional liquid at6.
any time by opening the Clear
Window in the Lid. Add more
liquid after mixing to reach desired consistency.
Plug in unit and turn ON by flipping the switch upward to ON position.7.
Blend for approximately 10 minutes or until mixture8.
has reached the desired consistency.
While the unit is still on, place glass underneath the Spout and dispense9.
the beverage by lifting the Spout handle up. It is recommended to place
a towel or other cloth on the table or countertop underneath the Spout
to protect against any drips. NOTE: the Spout has a locking upright
position for filling multiple drink glasses or a pitcher of drinks.
If the Spout drips after dispensing, place a glass or container underneath10.
Spout and open and close the valve by pushing down on the Spout
Handle once or twice quickly. Small ice chips can sometimes get
caught in the gasket, preventing it from closing completely.
Turn off the unit when desired consistency is achieved and it will11.
keep your beverage cold until ready to dispense again.
Always dispense beverage with the appliance turned ON. Allow the unit to12.
run for 8 seconds to mix before dispensing if unit has been sitting. When
you have finished, turn side knob to OFF position and unplug unit.
ON OFF

ENGLISH
8
HELPFUL TIPS
UNIT IS NOT TURNING ON
If the unit is not turning on, make sure that it is fully•
and properly plugged into the outlet.
Blending Chamber must be firmly attached to Base or unit will not turn on.•
BEVERAGE IS NOT DISPENSING
Add more liquid to Blending Chamber if vacuum•
occurs around shaving cage during use.
If the beverage is not dispensing, make sure that the•
Stainless Steel Grinding Cage did not get loose.
Make sure that there is enough liquid left inside.•
Make sure that switch is flipped up to the ON position.•
Make sure that there aren't any ice chips stuck inside the Spout. Open and•
close the valve by pushing down on the Spout Handle once or twice quickly.
CLEANING & MAINTENANCE
After using your STAINLESS STEEL MARGARATOR™, disconnect from1.
electrical outlet. Remove plug by gripping the plug body and pulling
out of the outlet. Never yank or twist cord to unplug the unit.
Dispense all remaining liquid from the Blending Chamber.2.
Remove Blending Chamber from Base and fill Blending Chamber with clean3.
water. Dispense all of the water through the Spout until liquid runs clear.
Wipe inside and outside of Blending Chamber with a wet, non-abrasive4.
cloth or sponge and dry thoroughly with a soft, non-abrasive towel.
Wipe Base with a dry, non-abrasive cloth.5.
DO NOT submerge Blending Chamber or Base in water. When6.
needed, use a damp, non-abrasive cloth to wipe exterior.
DO NOT put any parts in the dishwasher.7.
Once washing and drying is complete, reassemble your STAINLESS8.
STEEL MARGARATOR™. Wind the cord and return to the
convenient storage location in the bottom of the Base. Now your
STAINLESS STEEL MARGARATOR™ is ready to use again.
To prolong the life of your STAINLESS STEEL MARGARATOR™, be sure9.
to follow the cleaning instructions after every use and make sure that the
Spout is flushed thoroughly while washing the unit to prevent build up.
NEVER use abrasive cleaners or towels on the Base to maintain
10.
the original stainless steel finish and prevent scratches.
You may need to occasionally remove and clean the Stainless Steel Grinding Cage.11.
Refer to the directions in the Parts & Assembly section to perform this function.
