CCM600
Vintage Series™Old Fashioned Commercial
Cotton Candy Maker
Série d'antanMD Machine à barbe à
papa commerciale à l'ancienne
Instructions and Recipes
Instrucciones y recetas
Instructions et recettes

ENGLISH
2
Make everyday a party!
Visit www.nostalgiaelectrics.com for more fun products.
CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SAFETY
Appliance Specications:
120 Volts, 60 Hz
700 Watts, ETL Approved
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that
can kill or hurt you and others.
All safety messages will follow the safety alert symbol.
All safety messages will tell you what the potential hazard is, tell you how to reduce the
chance of injury, and tell you what can happen if the instructions are not followed.

ENGLISH
3
IMPORTANT PRECAUTIONS
1. NEVER use a scouring pad on the unit.
2. NEVER leave unit unattended while in use.
3. NEVER place anything other than the intended sugar in the Extractor Head.
4. NEVER pour water or any other liquid into the Extractor Head.
5. NEVER put ngers on or near the Extractor Head or Heating
Element while machine is on, nor while it is still hot.
6. Unplug unit from outlet when not in use and when cleaning.
7. DO NOT operate this appliance with a damaged cord or plug
or in the event the appliance ever malfunctions.
8. DO NOT put parts in dishwasher for cleaning.
9. DO NOT use outdoors. For indoor use only.
10. This appliance is NOT A TOY.
11. This appliance is not intended for use by young children.
12. Young children should be supervised while product is in use
to ensure that they do not play with the appliance.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions
should always be followed, including:
1. Read all instructions before operating this appliance.
2. DO NOT TOUCH the hot surfaces.
3. To protect against electrical shock do not immerse cord, plug
or any part of this unit in water or other liquids.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before removing parts for cleaning.
6. DO NOT operate any appliance with a damaged cord or plug or if the
appliance has been damaged in any manner. Return the appliance
to the nearest repair shop for examination or repair.
7. The manufacturer does not recommend the use of accessory
attachments. Use of attachments may cause injuries.
8. DO NOT let the cord touch hot surfaces.
9. DO NOT pour water or any other liquid into the Extractor Head.
10. DO NOT place parts on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving this appliance.
12. This unit must be on a level surface to operate properly.
13. DO NOT use this machine for other than its intended use.
14. DO NOT leave unit unattended while in use or when plugged into an outlet.

ENGLISH
4
15. Check the Extractor Head for foreign objects before switching to ON position.
16. The Extractor Head will get hot. Avoid contact until fully cooled.
17. A short power supply cord is provided to reduce the risk resulting
from becoming entangled or tripping over a long cord.
18. Extension cord can be used if care is exercised in use.
19. The marked electrical rating of an extension cord should be at
least as great as the electrical rating of the appliance.
20. This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electrical shock, this plug is intended to t into a polarized outlet only one way.
If the plug does not t fully into the outlet, reverse the plug. If it still does not t,
contact a qualied electrician. Do not attempt to modify the plug in any way.
21. Keep hands away from the machine when it is in the ON position and is spinning.
SAVE THESE INSTRUCTIONS!
INTRODUCTION
The OLD FASHIONED COMMERCIAL COTTON CANDY MAKERis designed
to resemble vendor carts of the early 1900s, with the convenience of a
modern appliance. Simply plug in, turn on, pour pure, granulated sugar into
the center receptacle, and start spinning colorful and tasty treats.
This fanciful product is fun for the whole family and brings out the kid in everyone.
Instantly, gatherings are transformed into carnivals and dessert time into party time!
Your OLD FASHIONED COMMERCIAL COTTON CANDY MAKERwill spin
the sugar into a sweet candy oss that you collect on cones by spinning
the cone as it circles the bowl…just like at the carnival!

ENGLISH
5
PARTS & ASSEMBLY
HARDWARE
#1 Screw (10mm) #2 Bolt (10mm) #3 Axle Bolt (95mm)
Qty. 8 Qty. 8 Qty. 2
#4 Bolt (60mm) #5 Small Flat Washer #6 Large Flat Washer #7 Nut Cap
Qty. 2 Qty. 10 Qty. 4 Qty. 4
#8 Extra Fuses #9 Extra Kryptol #10 Screw (6mm)
(10 Amp) Qty. 2 Qty. 2 Qty. 3
PARTS
(A) Bowl & Dome (B) Sugar Shovel (C) Main Unit (D) Display Tray

ENGLISH
6
PARTS & ASSEMBLY
HARDWARE
#1 Screw (10mm) #2 Bolt (10mm) #3 Axle Bolt (95mm)
Qty. 8 Qty. 8 Qty. 2
#4 Bolt (60mm) #5 Small Flat Washer #6 Large Flat Washer #7 Nut Cap
Qty. 2 Qty. 10 Qty. 4 Qty. 4
#8 Extra Fuses #9 Extra Kryptol #10 Screw (6mm)
(10 Amp) Qty. 2 Qty. 2 Qty. 3
PARTS
(A) Bowl & Dome (B) Sugar Shovel (C) Main Unit (D) Display Tray
(E) Push Handle (F) Wheels (G) Base Support (H) Leg Assembly
(I) Cross Bar (J) Screwdriver (K) Wrench #1 (L) Wrench #2
ASSEMBLY OF BASE SUPPORT
1. Insert Cross Bar (I) into the square inserts on the inside of Base Support (G)
and secure from below with two #2 Bolts and two #5 Flat Washers.
2. Insert the Leg Assembly (H) into the square inserts between the ends of
the Base Support (G) and fasten from inside with two #4 Bolts, two #6 Flat
Washers and two #7 Nut Caps and from the top with two #2 Bolts.

ENGLISH
7
ASSEMBLY OF THE WHEELS
1. Insert #3 Axle Bolt into Base Support (G).
2. Put on #6 Flat Washer. Slide one Wheel (F) into #3 Axle Bolt and
add a #5 Flat Washer and a #7 Nut Cap.
3. Use #2 Wrench (L) to tighten the #7 Nut Cap.
4. Insert the second #3 Axle Bolt to the other side of Base Support (G), add #6
Flat Washer, second Wheel (F), another #5 Flat Washer, and #7 Nut Cap to
the other side of the #3 Axle Bolt, following the directions above.
5. Use #2 Wrench (L) to tighten the #7 Nut Cap.
ASSEMBLY OF THE MAIN UNIT
1. Assemble Base Support (G) into the bottom of the Main
Unit (C) and secure with four #2 Bolts.
2. Push Handle (E) attaches onto the Main Unit (C) using four of the supplied #1 Screws
and four #5 Flat Washers. Attach Display Tray (D) to Main Unit (C) using four #1 Screws.
3. Attach Bowl (A) to Main Unit (C) by placing Bowl (A) over collar and
turning clockwise. Attach Dome to Bowl using three #10 Screws.
CHANGING THE FUSES
The Fuses are marked under each fuse compartment. Two
extra 10 Amp fuses are also included with this unit.
1. Using a at head screwdriver, push in, turning counter-clockwise.
2. Fuse is then accessible and can be changed. Once changed,
push in and turn clockwise to lock fuse into place.

ENGLISH
8
CHANGING EXTRACTOR HEAD
1. Before changing the Extractor Head, make sure that the machine is turned
OFF, unplugged, and that the Extractor Head has cooled completely.
2. Use #1 Wrench (K) to remove the center bolt.
3. Use pliers to loosen and remove the red and black wires
from the bottom of the Extractor Head.
4. Attach the red and black wires to the new Extractor Head and tighten.

ENGLISH
9
5. Place the new Extractor Head with wires attached onto the shaft and replace center bolt.
6. Tighten the center bolt using the #1 Wrench (K).
CHANGING THE KRYPTOL
The Kryptol is the connection point that powers the heating element on the extractor
head. The electricity from the machine transmits heat through the Kryptol which allows
the Extractor Head to get hot and melt the sugar. Eventually the Kryptol wears down
with continued use of the OLD FASHIONED COMMERCIAL COTTON CANDY MAKER,
and needs to be replaced. Follow the directions below when changing the Kryptol:
1. Before replacing the Kryptol, make sure that the machine is turned OFF,
unplugged, and the Extractor Head has cooled completely.
2. Use the Screwdriver to remove all screws from the collar and remove collar.

ENGLISH
10
3. Remove Kryptol Housing Cover using (K) Wrench #1.
4. Pull Kryptol out of Housing and replace with new Kryptol.
5. Replace Kryptol Housing cover and tighten with #1 Wrench (K).
6. Repeat steps 3, 4 and 5 with the other Kryptol Housing.
7. Replace Collar and tighten screws using Screwdriver.
Kryptol

ENGLISH
11
HOW TO OPERATE
1. First, position OLD FASHIONED COMMERCIAL COTTON CANDY MAKER close
to an electrical outlet before starting. Make sure the cord is away from any
water source. It is acceptable to use an extension cord if needed.
2. Plug in unit at the OFF position.
3. Turn both power switch and heater switch to ON position and allow unit to run for at
least 10 minutes before adding sugar. This will allow the Extractor Head to heat.
4. Once Extractor Head has heated, turn unit OFF.
5. Place no more than one scoop of sugar (avored or white, granulated)
or up to four pieces of hard candy into the Extractor Head.
6. Switch to ON position.
7. When you see the cotton candy web begin, collect the cotton candy on the cone by
holding the cone and rotating the cone with your ngers while you circle the bowl.
8. Repeat above steps by turning o machine and adding another scoop of sugar or four more
pieces of hard candy into the Extractor Head. Once you have added sugar or candy, start
machine again. The cotton candy should ow more quickly as the unit is suciently warm.
9. Never use ingredients other than sugar or hard candy. DO NOT overll the Extractor
Head by adding more than one scoop of sugar or more than four pieces of hard
candy at a time. This will cause clogging and unit will not work properly.
10. By following these simple instructions, using your OLD FASHIONED
COMMERCIAL COTTON CANDY MAKER will be a fun experience for kids of
all ages and will bring the excitement of a carnival to any occasion.
HELPFUL TIPS
How Cotton Candy is Made
Cotton candy is made by heating sugar. This turns sugar into a liquid form.
Then the sugar liquid is forced out of tiny mesh with holes in the extractor
head by centrifugal force as the extractor head spins. As the liquid sugar hits
the air, it returns to a solid uy material that adheres to a paper cone.
Cleaning the Extractor Head
It is very important that the unit be cleaned properly after every use. If it
is not, the holes will get clogged and sugar will not be able to sift through
the tiny holes properly. NEVER put water in the extractor head.
You can clean the Extractor Head by letting the machine run
with an empty Extractor Head for ve minutes.
Catching Floss
If oss does not adhere easily to the cone, you can spray the cone lightly with water.

ENGLISH
12
CLEANING & MAINTENANCE
1. When you have nished making cotton candy, run unit for about ve
minutes until all sugar has been released through the extractor head.
2. When all remaining sugar is gone, unplug unit and allow to cool down before cleaning.
3. Make sure the unit is unplugged and has had time to cool down before cleaning.
4. Use a clean, slightly damp, non-abrasive sponge or non-abrasive cloth to
wipe the outside of the metal extractor head, aluminum Bowl, and inside and
outside of plastic Dome, then wipe with a non-abrasive towel to dry.
5. Use a clean, slightly damp, non-abrasive sponge or non-abrasive cloth to wipe
down the outside of the Main Unit, then wipe with a non-abrasive towel to dry.
6. NEVER put water in the Extractor Head.

ENGLISH
13
RETURNS & WARRANTY
SHOULD YOUR UNIT NOT WORK OR IS DAMAGED WHEN YOU FIRST TAKE IT OUT
OF THE BOX PLEASE RETURN IT TO THE PLACE OF PURCHASE IMMEDIATELY.
Vintage Series™
Old Fashioned Commercial Cotton Candy Maker/ CCM600
Should you have any questions, please contact us via email or at the
customer service number listed below between the hours of 8:00 AM
and 5:00 PM, Monday through Friday, Central Standard Time.
Distributed by:
Nostalgia Products Group LLC
1471 Partnership Dr.
Green Bay, WI 54304-5685
Customer Service
Phone: [phone]
Web: www.nostalgiaelectrics.com
Customer Service Inquiry
To submit a Customer Service inquiry, go to www.nostalgiaelectrics.com and
ll out the Customer Service Inquiry form and click the Submit button.
A representative will contact you as soon as possible.
This appliance is designed and built to provide many years of satisfactory performance
under normal household use. The distributor pledges to the original owner that
should there be any defects in material or workmanship during the rst 90 days of
purchase, we will repair or replace the unit at our option. Our pledge does not apply
to damages caused by shipping, mishandling or unit being dropped. A product
deemed defective either from manufacturing or being mishandled is up to the
distributor’s discretion. In order to obtain service under this warranty, please contact
Nostalgia Products Group, LLC at the telephone number listed above or by lling
out the Customer Service Inquiry Form located at www.nostalgiaelectrics.com.
This warranty does not apply to re-manufactured merchandise.
Please read these instructions carefully. Failure to comply with these instructions,
damages caused by improper replacement parts, abuse or misuse will void this
pledge to you and is being made in place of all other expressed warranties.
For more information, visit us online at www.nostalgiaelectrics.com.
Like us on Facebook at www.facebook.com/NostalgiaElectrics.

14
ESPAÑOL
14
¡Convierta todos los días en una etsa!
Visite www.nostalgiaelectrics.com para ver más productos divertidos.
CONTENIDO
PRECAUCIONES IMPORTANTES . . . . . . . . . . . . . . . . . . . . . . . . . . 15
MEDIDAS IMPORTANTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
INTRODUCCIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
PARTES Y ENSAMBLAJE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
CÓMO FUNCIONA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CONSEJOS ÚTILES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
LIMPIEZA Y MANTENIMIENTO . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
DEVOLUCIONES Y GARANTÍA . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SEGURIDAD
Especicaciones del electrodoméstico:
120 Volts, 60 Hz
700 Watts, aprobado por ETL
Su seguridad y la de otras personas es muy importante.
Hemos proporcionado numerosos mensajes de seguridad importantes en este manual
y en su electrodoméstico. Siempre lea y obedezca todos los mensajes de seguridad.
Este es el símbolo de alerta de seguridad.
Este símbolo le previene de peligros potenciales que pueden
causar la muerte o lesiones a usted y a otras personas.
Todos los mensajes de seguridad estarán antecedidos por el símbolo de alerta.
Todos los mensajes de seguridad le dirán de qué peligro potencial se trata, cómo reducir
la posibilidad de lesiones y qué puede ocurrir si no se obedecen las instrucciones.

15
ESPAÑOL
15
PRECAUCIONES IMPORTANTES
1. NUNCA utilice un estropajo en la unidad.
2. NUNCA deje la unidad sin atención mientras se encuentra en uso.
3. NUNCA ponga nada en la Boca de Entrada del Extractor salvo el azúcar previsto.
4. NUNCA vuelque agua ni ningún otro líquido en la Boca del Extractor.
5. NUNCA ponga los dedos sobre la Boca de Entrada del Extractor ni
cerca del mismo ni del Elemento para Calentar mientras la máquina se
encuentra encendida ni mientras aún permanezca caliente.
6. Desenchufe la unidad del tomacorriente cuando no esté en uso o mientras se limpia.
7. NO maneje este aparato si tiene un cable o enchufe dañado o
en el caso de un mal funcionamiento del mismo.
8. NO lo coloque en el lavavajillas.
9. NO utilice este aparato en el exterior. Sólo debe utilizarse en el interior.
10. Este equipo NO ES UN JUGUETE.
11. Este aparato no debe ser utilizado por niños.
12. Se debe supervisar a los niños pequeños para asegurarse de que
no jueguen con el aparato mientras se encuentre en uso.
MEDIDAS IMPORTANTES
Cuando utiliza aparatos eléctricos, siempre se deben seguir algunas
medidas básicas de seguridad que incluyen las siguientes:
1. Lea todas las instrucciones antes de manejar este equipo.
2. NO toque supercies calientes.
3. Para protegerlo de una descarga eléctrica, no sumerja el cable, el enchufe
ni ninguna parte de esta unidad en agua ni en ningún otro líquido.
4. Se requiere de una especial atención cuando el aparato
es utilizado por niños o cerca de ellos.
5. Desenchufe del toma corriente cuando no está en uso
y antes de retirar partes para su limpieza.
6. NO utilice ningún aparato que tenga el cable o el enchufe dañado o
si el aparato se dañó de alguna manera. Lleve el aparato al local de
reparación más cercano para que sea revisado o reparado.
7. El fabricante del aparato no recomienda el uso de accesorios. Estos podrían ocasionar daños.
8. NO deje que el cable toque supercies calientes.
9. NO vuelque agua ni ningún otro líquido en la Boca de Entrada del Extractor.
10. NO lo coloque sobre una hornalla a gas o sobre un quemador eléctrico
caliente, ni cerca de ellos y tampoco dentro de un horno caliente.
11. Se debe tener extremo cuidado cuando mueve el aparato.
12. Esta unidad debe estar en una supercie nivelada para que funcione correctamente.

16
ESPAÑOL
16
13. NO utilice el aparato de otro modo que no sea para su uso pretendido.
14. No deje la unidad sin atención mientras esté en uso o enchufada a un tomacorriente.
15. Controle la Boca de Entrada del Extractor para comprobar que no
haya objetos extraños antes de ENCENDER la unidad.
16. La Boca de Entrada del Extractor estará caliente. Evite el contacto
hasta que se haya enfriado completamente.
17. Se proporciona un cable de energía corto, para reducir el riesgo de
estrangulamiento o tropiezos que podrían resultar con un cable largo.
18. Se pueden utilizar cables prolongadores de suministro
de energía si se tiene cuidado en su uso.
19. La clasicación eléctrica indicada en un prolongador debe ser al menos
del mismo valor que la clasicación eléctrica del aparato.
20. Este electrodoméstico tiene un enchufe polarizado (una hoja es más ancha que la otra).
Para reducir el riesgo de una descarga eléctrica, este enchufe está diseñado para insertarse
en un tomacorriente polarizado solamente en una posición. Si el enchufe no encaja
totalmente en el toma corriente, invierta el enchufe. Si aún no encaja, contacte
a un electricista calicado. No intente modicar el enchufe de ninguna forma.
21. Mantenga las manos fuera de la máquina cuando se encuentra ENCENDIDA y esté girando.
¡GUARDE ESTAS INSTRUCCIONES!
INTRODUCCIÓN
La FÁBRICA DE ALGODÓN DE AZÚCAR COMERCIAL ESTILO ANTIGUO está diseñada para
que se asemeje a un carrito callejero de comienzos del siglo XX, pero con la practicidad
de un aparato moderno. Simplemente enchúfela, enciéndala, vierta azúcar granulada
pura en el centro del receptáculo y comience a girar coloridos y sabrosos dulces.
Este fantástico producto es divertido para toda la familia y despierta
al niño que todos llevamos adentro. ¡Las reuniones se convierten
inmediatamente en carnavales y la hora del postre en una esta!
Su FÁBRICA DE ALGODÓN DE AZÚCAR COMERCIAL ESTILO ANTIGUO hará girar azúcar
formando algodón de azúcar que se recoge haciendo girar los conos de plástico
alrededor del recipiente en forma de círculo… ¡al igual que los puestos callejeros!

17
ESPAÑOL
17
PIEZAS Y ENSAMBLAJE
HARDWARE
N°1 - 8 Tornillos N°2 - 8 Pernos N°3 - 2 Pernos
de 10mm de 10mm Eje de 95mm
N°4 - 2 Pernos N°5 - 10 Arandelas N°6 - 4 Arandelas N°7 - 4 Tuercas
de 60mm Planas Pequeñas Planas Grandes Ciegas
N°8 - 2 Fusibles N°9 - 2 Kryptoles N°10 – 3 Tornillos
Adicionales de 10 Amperes Adicionales de 6mm
PARTS
(A) Bol y Domo (B) Cuchara para (C) Unidad Principal (D) Bandeja de
el Azúcar Visualización

18
ESPAÑOL
18
PIEZAS Y ENSAMBLAJE
HARDWARE
N°1 - 8 Tornillos N°2 - 8 Pernos N°3 - 2 Pernos
de 10mm de 10mm Eje de 95mm
N°4 - 2 Pernos N°5 - 10 Arandelas N°6 - 4 Arandelas N°7 - 4 Tuercas
de 60mm Planas Pequeñas Planas Grandes Ciegas
N°8 - 2 Fusibles N°9 - 2 Kryptoles N°10 – 3 Tornillos
Adicionales de 10 Amperes Adicionales de 6mm
PARTS
(A) Bol y Domo (B) Cuchara para (C) Unidad Principal (D) Bandeja de
el Azúcar Visualización
(E) Manija para Empujar (F) Ruedas (G) Soporte Base (H) Ensamble de las Patas
(I) Barra transversal (J) Destornillador (K) Llave N° 1 (L) Llave N° 2
ARMADO DEL SOPORTE BASE
1. Introduzca la Barra Transversal (I) en las inserciones cuadradas que se
encuentran en la parte interior del Soporte Base (G) y sujete desde
abajo con dos Pernos N°2 y dos Arandelas Planas N°5.
2. Introduzca el Ensamble de la Pata (H) en las inserciones cuadradas que se encuentran
entre los extremos del Soporte Base (G) y sujete desde adentro con dos Pernos N°4, dos
Arandelas Planas N°6 y dos Arandelas Ciegas N°7 y desde arriba con dos Pernos N°2.
