Nouhaus Cobra NHG-0005 User manual
NOUHAUS
ERGONOMIC
OFFICE CHAIR
USER MANUAL
Cobra
@nouhaus_official
@nouhaus
Nouhaus
@nouhaus_official
Nouhaus
nouhaus.com
Subscribe
Customer
Service Center
H.Q
10985 Oleander Avenue Fontana, CA 92337
+1 (888) 387-5949
NOUHAUS Inc.
10985 Oleander Ave. Fontana, CA 92337
Scan QR code to Watch our Assembly Video
NOUHAUS
ERGONOMIC
OFFICE CHAIR
USER MANUAL
Thank you for purchasing the NOUHAUS Ergonomic Oce Chair.
Please read this manual carefully before using.
Retain this manual for your reference.
This user manual contains the product warranty information.
The design and/or specication of this product is subject to change without notice.
Instructions on Safe Use
Assembly Parts
How to Assemble
How to Use
Product Specications and Information
Customer Service Information
Product Warranty
CONTENTS
Cobra
NHG-0005
Pg 05
Pg 06
Pg 07
Pg 09
Pg 11
Pg 12
Pg 13
01
02
03
04
05
06
07
05 06
Cobra
01 Instructions on Safe Use 02 Assembly Parts
PLEASE READ
1. Do not discard any of the packaging until you are certain that you have all
the necessary parts for the assembly.
2. Please ensure that the packaging is disposed of in a safe and
environmentally responsible way.
3. During assembly, tighten screws by hand only. Once all screws are in place,
you may tighten all screws completely.
CAUTION
1. NEVER use this chair as a step ladder.
2. Check that screws have not become loosened every 6 months.
Retighten if necessary.
3. Do not allow children to play with or operate the mechanism.
4. Keep hands and feet clear of the mechanism.
5. Only the occupant should operate mechanism.
Allen WrenchM6 x 1.18”M8 x 0.79”
(A) Chair Back x1
(G) x3
(H) x6
(I) x1
(B) Chair Seat x1
(E) Chair Base x1
(D) Gas Lift x1
(C) Arms Left x1 Right x1
(F) Casters x5
*Extra screws included*Extra screws included
07 08
*you can use the Blade wheels(I)
Step 1 Step 2
Step 3
Step 4
Complete!
Tools Needed: Allen Wrench - Provided
Please read all instructions before assembly.
Step 1
Insert Casters (F) into Chair Base (E). Insert Gas Lift (D) into the hole in the
center of the Chair Base (E).
Step 2
Attach Arms (C) to both sides of the Chair Seat (B) using M6 x 1.18” S crews (H).
Tighten with Allen Wrehch (I).
Step 3
Attach Chair Back (A) to Chair Seat using M8 x 0.79” Screw (G).
Tighten with Allen Wrench (I).
Step 4
Carefully place the assembled Chair Frame onto the Gas Lift (D). Aligning the hole into
the Seat Mechanism on the Chair Seat (B) with the Gas Lift (D). Press down on the Chair
Seat (B) to secure in place.
Cobra
03 How to Assemble
1
2
(E)
(F)
(D)
(G)x3
(A)
(D)
(B)
(H)x6
(C)
(B)
09 10
04 How to Use
A
B
C
D
E
4-DIRECTIONAL ARMRESTS - DIRECTION
Push the armrests to adjust 1) from side to side, 2) forward and backward, and
3) pivot outwards and inwards.
HEIGHT
Lift the lever on the front right corner (when seated) to adjust the height of
the chair.
TILT MECHANISM
Lower the lever/
Lift the lever on the front left corner (when seated) to
lock/
unlock the tilt mechanism.
*Two locking positions: upright and fully reclined
TILT TENSION
Turn the knob clockwise to loosen the tilt tension of the chair, anti-clockwise
to tighten. Adjust according to your own preference.
4-DIRECTIONAL ARMRESTS - HEIGHT
Press and hold the outer side button to adjust the height of the armrests.
Cobra
C
A
B
D
E
11 12
05 06 Customer Service Information
Product Specications and Information
61.72 lbs
Product Name
Model Number
Chair Dimensions
Seat Depth
Max Hip Width
Net Weight
Gross Weight
Weight Capacity
Customer Service
Height Capacity
Fabric
Wheels
Base
Nouhaus Cobra
NHG-0005
W25.98 x D25.39 x H48.03/55.51 in
21.26”
26.18”
47.84 lbs
85 lbs - 275 lbs
10985 Oleander Ave. Fontana, CA 92337
+1(888)387-5949
5’4” – 6’2”
PVC Leather
XL Pro Wheels
5-Point ADC#12 Aluminum Wheelbase
NOUHAUS oce chairs are warranted for a period of THREE years against
1.
Missing materials from the Product at the time of delivery;
2. Defects in the manufacturing of materials used for the Products
at the time of delivery;
3. Failure of the Products to correspond with the description in the
applicable contract of sale at the time of delivery; and
4. Major defects in the functional department, such as :
a. Skeletal frame failure
b. Casters mechanism failure
c. Tilt mechanism failure
d. Gas lift failure
e. Armrest mechanism failure
Subject to the following:
Any replacement parts shall be sent to the address of the original purchaser,
replaced parts may be required to be shipped back to NOUHAUS at its discretion;
to benet under this warranty, NOUHAUS must be notied of any defect within
14 days of the occurrence of such defect via an image or video of the relevant defect
by NOUHAUS; to the extent permitted under the applicable Federal and State
law of the United States of America, all parts replaced or repaired under this
warranty shall be warranted for the remainder of the designated Warranty Period.
What Our Warranty Does Not Cover
All warranties listed on this page exclude the following where permitted
under the applicable Federal and State law of the United States of America:
1.
Excludes normal wear and tear of surfaces that are not attributable to manufact-
uring, including but not limited to (a) degradation of upholstery (PU leather /
fabric / genuine leather / mesh), top portion of armrests, pillows, casters exterior
or mesh stitching, (b) damage to plastic coverings, (c) variance of tightness
of mechanisms, and (d) excludes damage from accidents, natural disasters,
physical damage from pets, re and ood, and non-manufacturing incidents
covered under insurance policies (regardless of whether you are in possession
of the relevant insurance), (e) excludes any variations in dimensions and color;
2. Any claims for indirect, consequential or incidental losses.
3. Damage to a product that has been modied or altered without
the written permission of NOUHAUS;
4. Damage caused to all NOUHAUS products during self-assembly due to
failure to adhere to the relevant self-assembly manual instructions provided;
5. Minor misalignments, variations arising out of hand-made workmanship. To
ensure your product enjoyment and safety, and protection under the“Warranty
Period”, please ensure you have NOUHAUS assembly and care guidelines for this
product, and follow them for the correct assembly and care for your item. Contact
our Customer Service Team to obtain these guidelines if you do not have them.
Cobra
07 Product Warranty
13
NOUHAUS, Inc.
10985 Oleander Ave.
Fontana, CA 92337
For warranty information, please visit the Warranty page at www.nouhaus.com
Product Information
. . .
. . .
Product Name
Manufacture Date
. . .
Purchase Store
Date of Purchase
Date of Installation
Model Number
Manufacture Number
Purchase Store Contact
Order Number
. . .
Warranty Date
Customer Information
Name
Contact
Address
