Nova 6061-R User manual

Pulley Hanger
H O W T O
ASSEMBLE YOUR
1
2
3
4
Remove all parts from box:
1 pulley hanger, 1 door bracket, 2 pulley mechanisms, 1 traction rope, and
2 exercise handles
Overdoor Exercise Set
Item # 6061-R
Weight capacity not to exceed 10 lb
No tools required
All parts included
Door Bracket Traction Rope
Pulley
Mechanisms
5
NOTE: It is much easier and safer to assemble this device with help from a second
person.
On one of the bent ends of the “PULLEY HANGER”, it will have
a locking notch on the side. With the “PULLEY HANGER” turned
upwards, slide that end into the triangle opening of the door
bracket.
Once the locking notch slides completely through the “DOOR
BRACKET”, turn the “PULLEY HANGER” downwards and slide
on both “PULLEY MECHANISMS.
Squeeze the “PULLEY HANGER” and insert the bent end
into the hole at the bottom of the “DOOR BRACKET”.
Once assembled, install the “DOOR BRACKET” over the top of
an interior door. Ensure the “DOOR BRACKET” is centered on
the door and the top of the bracket is pushed all the way down.
Close the door after secured.
NOTE: Make sure that no one opens the door while you are
using the exercise device. Use the “DO NOT OPEN” door sign
found at the end of this User Guide.
Easy to follow
step by step
instructions
Exercise Handles

Locking Notches
Ensure that both “PULLEY MECHANISMS” are on
the outside of both locking notches as shown.
Using the “TRACTION ROPE”, tie a “Traction Knot” through the center hole of the
“EXERCISE HANDLE”. Allow approximately 2 feet (60 centimeters) at the end of
the rope. This extra length of rope will allow you to adjust the knot and handle
height if needed. Once the knot is tied, pull on both the “TRACTION ROPE” and
“EXERCISE HANDLE” to tighten the knot. Check the knot to make sure it is secure.
(Refer to steps A-C under “HOW TO TIE A TRACTION KNOT”).
NOTE: The knot becomes tigher as more weight is put on the rope.
7
6
Thread the free end of the “TRACTION ROPE” through both “PULLEY
MECHANISMS”.
On the opposite end of the “TRACTION ROPE”, tie another “Traction Knot” through
the center hole of the second “EXERCISE HANDLE”. Again, allow approximately 2
feet (60 centimeters) at the end of the rope. This extra length of rope will allow you
to adjust the knot and handle height if needed. Once the knot is tied, pull on both
the “TRACTION ROPE” and “EXERCISE HANDLE” to tighten the knot. Check the
knot to make sure it is secure. (Refer to steps A-C under “HOW TO TIE A
TRACTION KNOT”).
NOTE: Before each use, ensure that all knots are tight, all hardware is secure, and
rope is not frayed. Ensure that the rope is in the pulley wheel grooves and moves
freely so that the rope does not come off-track and bind between the pulley
wheels and casing.
8
9
HOW TO TIE A TRACTION KNOT
A
PULL
B C

How to care for your: Overdoor Exercise Set
The ”TRACTION ROPE” can be hand washed in cold water. DO NOT machine
wash or use harsh cleansers or bleach. Hang to air dry.
6061 Overdoor Exercise Set Use
Use the Over Door Exercise Set to help improve range of motion and
coordination following a cardio vascular accident; the stronger arm pulls the
affected arm up in a controlled stretching motion. Useful for slow, passive
stretching exercises. Ideal for home range of motion programs. Large handles
are easy to grasp. The rope can be adjusted easily for proper fit. Over Door
Exercise Set with Extended Metal Bracket positions the pulleys 15" (38cm)
away from the door to give the client more room to move.
Cut out this Do Not Enter sign and
hang on back of door for safety when
using the Overdoor Exercise Set. DO NOT
DISTURB
nova medical products.com
DO NOT
ENTER

NOVA stands rm on our commitment to providing the highest quality products, as well as exceptional service. This product was
built to precise standards and thoroughly inspected prior to shipment. This warranty represents our condence in the materials
and workmanship of our product. NOVA extends this warranty only to the original purchaser of this product. The warranty
does not extend to any subsequent purchaser or owner. The warranty is void upon any sale or transfer of ownership or use by
other person. NOVA warrants its products are free from defects in material and workmanship under NORMAL use for the period
commencing upon the date of purchase and continuing for the following specied period of time after that date:
Metal Frame - Limited Lifetime Warranty
Non-Metal/Metal parts - One Year Limited Warranty
(rubber tips, plastic or metal hardware)
WARRANTY INFORMATION
IMPORTANT WARNING
READ THESE DIRECTIONS CAREFULLY BEFORE USE.
FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY.
WARNING: The 6061-R Over Door Exercise Set only
supports a weight of up to 10 lb and can be dangerous if
not used correctly. This product is not a toy. KEEP AWAY
FROM CHILDREN. Failure to do so could result in injury.
Use only under the care and instruction of a physician
or contact a health-care professional before using. If
you do not understand any part of these instructions or
need assistance in assembling, contact NOVA customer
service at [phone] option 1. If this device is not
properly assembled and adjusted, personal injury and/
or damage to the Overdoor Exercise Set could result.
WARNING: If parts are damaged or missing, contact
the dealer this device was purchased from or contact
NOVA customer service at [phone] option 1. Use
only NOVA replacement parts. Non-NOVA replacement
parts could cause personal injury and/or damage to the
Over Door Exercise Set.
CARE •QUALITY •INNOVATION
THE NOVA PROMISE
Connect with NOVA!
novamedicalproducts.com
facebook: novamedicalprod
twitter: novamedicalprod
twitter: novawalkerstalk
youtube: NOVA Medical Products
CONTACT US!
[e-mail]
1 800 557 6682
We’re here to help
This warranty does not cover problems due to user negligence, misuse
of the product, failure to adhere to product instructions, or normal
wear and tear. Items that have been subject to negligent abuse,
modied without prior written authorization are not covered within
this warranty.
